Fanmaster PERH2400 User manual

FA NM A ST E R
cooling heating ventilation extraction
INSTRUCTION MANUAL
MODEL: PERH2400
ELECTRIC PEDESTAL/WALL RADIANT HEATER
TO PREVENT SERIOUS INJURY, READ & UNDERSTAND ALL WARNINGS &
INSTRUCTIONS BEFORE USE. PLEASE KEEP THIS DOCUMENT FOR YOUR RECORDS
FOR INDUSTRIAL USE ONLY

FOR YOUR INFORMATION
Thank you for purchasing a Fanmaster electric radiant heater. Please read this
instruction manual carefully before using this heater.
Disclaimer:
Fanmaster reserves the right to make alterations to specications, quantities,
dimensions, for production or other reasons, subsequent to publication.
While we believe the information is accurate and complete, we make no warranty
or representation for any particular purposes. The information is offered in good faith
and with the understanding that any use of the units or accessories in breach of the
directions and warnings in this document is at the sole discretion and risk of the user
Disposal Guidelines:
Do not dispose of this product with general household waste. This product must be
disposed according to the laws governing Waste Electrical and Electronic Equipment.
If required, contact your local authorities for information regarding the available
disposal facilities.

1. GENERAL SAFETY RULES & WARNINGS
• PLEASE READ INSTRUCTIONS CAREFULLY.
• PLACE INSTRUCTION MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. DO NOT ALLOW
ANYONE WHO HAS NOT READ THESE INSTRUCTIONS TO ASSEMBLE, ADJUST OR OPERATE THIS
HEATER.
• IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION
MAY RESULT IN CAUSING PROPERTY DAMAGE, SERIOUS INJURY OR LOSS OF LIFE.
• FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS
HEATER, CAN RESULT IN DEATH, SERIOUS INJURY AND PROPERTY LOSS OR DAMAGE FROM
HAZARDS OF FIRE, EXPLOSION, BURN, AND/OR ELECTRICAL SHOCK.
• ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS HEATER. IF YOU NEED ASSISTANCE OR REQUIRE HEATER INFORMATION SUCH AS
AN INSTRUCTION MANUAL, LABELS, ETC. CONTACT FANMASTER.
• DO NOT STORE OR USE GASOLINE, PETROL OR ANY OTHER FLAMMABLE OR COMBUSTIABLE
VAPORS AND LIQUIDS IN THE VICINITY OF THIS HEATER.
• FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS
BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER
AS RECOMMENDED BY THE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR
MAY CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNER, DUST PARTICLES OR UNKNOWN CHEMICALS
• NOT FOR DOMESTIC OR RECREATIONAL VEHICLE USE
• THE ELECTRICAL SYSTEM TO WHICH THE APPLIANCE IS CONNECTED MUST COMPLY WITH
LOCAL REGULATIONS. A RESIDUAL-CURRENT DEVICE (RCD) MUST BE INSTALLED.
• UNPLUG THE APPLIANCE BEFORE PERFORMING ANY MAINTENANCE OPERATIONS.
• ALWAYS CHECK THE POWER CABLE BEFORE USING THE APPLIANCE. IT MUST NOT BE BENT,
TAUT, STRETCHED, CRUSHED OR ANY WAY DAMAGED.
• IF THE POWER CORD AND/OR PLUG IS DAMAGED, IT MUST BE REPLACED BY FANMASTER, A
SERVICE AGENT OR A QUALIFIED PERSONS.
• DO NOT COVER THE FAN HEATER
• THE FRONT OUTLET IS VERY HOT DURING OPERATION. DO NOT TOUCH! BURN DANGER.
• DO NOT LEAVE THE HEATER UNATTENDED WHEN IN USE.
• NEVER USE THE HEATER WITH WET HANDS OR WHEN EITHER THE HEATER OR THE POWER CABLE
IS WET.
• CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE HEATER.
• THE HEATER IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LOCK OF EXPERIENCE & KNOWLEDGE.
FOR YOUR INFORMATION

2. PRODUCT DESCRIPTION & SPECIFICATIONS
PRODUCT DESCRIPTION
Industrial electric pedestal or wall radiant heater.
SPECIFICATIONS
MODEL PERH2400
Heat Output 2400 W
6,824 BTU
Element Type Quartz Lamp
Control settings 1 x Heat settiings
Adjustable thermostat
Settings (W) 2400
Voltage (V/Hz) 240V/50
Current Rating (A) 10
Net Weight (kg) 3.6 / 3.3
Dimensions (mm) HEAD: 910(L)*245(W)*325(H)
PED: 1090(L)*125(W)*220(H)
Replacement element: SP-PERH-ELEMENT
SAFETY DEVICES
This heater has the following protection devices:
• Tilt Switch - this will automatically turn the heater off if it is not in the appropriate
operating position, fallen over on its front or side.
• Self-Resetting Thermostat - this will automatically disconnect the power to the
heater at a pre-set overheat temperature.

3. GETTING TO KNOW YOUR HEATER
1 SWITCH
2 HEATING ELEMENT
3BRACKET
4CABLE
5SAFETY BAR
6 COVER/GRILLE
1BASE
2LOWER TUBE
3ADJUSTMENT
HEIGHT KNOB
4TOP TUBE
5
FIXED SLEEVES/
ADJUSTMENT
ANGLE KNOBS
6 SPACER
7LOCATED BUTTON
8FIXED AXLE PIN
2. PRODUCT DESCRIPTION & SPECIFICATIONS

4. ASSEMBLING & OPERATING INSTRUCTIONS
Remove the heater from the carton. If the heater is damaged, please contact
Fanmaster or where you purchased the heater from.
How to assemble Pedestal stand
1. Using 4 x 20F head screws, x the balance weights to the bottom of the base.
2. Fix the 4 legs into the slots
3. Slide the cable clip & stand base cover on to the lower tube, then connect the
lower tube on to the base (feet).

4. ASSEMBLING & OPERATING INSTRUCTIONS4. ASSEMBLING & OPERATING INSTRUCTIONS
4. Adjust the height as required by tightening the plastic
collar (110cm to 180cm)
5. (1) Loosen the screws on the back of the heater head.
(2) Fix brackets to the back of the heater head.
(3) Loosen the knobs (5)
(4) Attached brackets to knob
(5) Tighten adjustment knob and screws.

Wall Mount installation:
1. There are 4 brackets & fasteners used with the heater. Furthermore, in the
channel on the backside of the heater, there are 4 square fastener washers
25x25mm. Relieve the square washers (Fig 7.1) and fasten 2 brackets to the
channel on the backsoide of the heater with the screws (Fig 7.2)
2. Fasten the brackets at the appropriate distance of each other (45-55cm).
3. The remaining two other brackets are xed to the wall with the sutiable xings
(xings not supplied) at the appropriate distance. (At least 1.8m from the oor &
at least 0.5m from the celining)
4. Join the brackets on the heater to the heaters xed to the wall with the screw
nuts. Install the heater at the required angle
4. ASSEMBLING & OPERATING INSTRUCTIONS

4. ASSEMBLING & OPERATING INSTRUCTIONS 4. ASSEMBLING & OPERATING INSTRUCTIONS
• Position the heater so it stands upright & is on a rm surface (when used as a
pedestal) and at a safe distance from wet environments and ammable objects.
• Connect the plug to the relevant power source.
• Set the thermostat knob to the MAX & let the heater operate on full power for 2
minutes then adjust accordignly.
• DO NOT TURN THE HEATER OFF FROM THE POWER SOURCE
5. CLEANING, MAINTENANCE & STORAGE
• Before starting any maintenance task, shut down, unplug and let the heater cool
down for at least 15 minutes.
• Do not attempt any electrical repair yourself. If the heater needs service or repair,
contact a qualied persons.
• When cleaning, make sure that water does not enter the unit.
• Do not open the enclosure to clean the inner parts. Do not spray water into the
heater.
• Never use solvents, gasoline, toluene and similar aggressive chemicals to clean
the heater.
Cleaning the Reector:
1. Remove the cover/grille
2. Wipe the reector with a soft cloth, treated by detergent, do not leave any prints
of sports on the surfahce

8. WARRANTY7. TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The heater does
not operate, even
when it is plugged
in & the switch,
thermostat is ON
The plug is loose, bad
connection
Disconnect the plug, check
the connection of the plug &
socket. Try another socket
Element is not
glowing Power or Voltage Surge Replace Element

8. WARRANTY
Any claim under this warranty must be made within 12 months of the date of
purchase of the product. To make a claim under the warranty, take the product
(with proof of purchase) to the store where you purchased the product or go to
https://www.fanmaster.com.au/warranty-claims-returns.
This warranty is given by Fanmaster Pty Ltd
ABN: 45 353 934 457
Unit 1/6-8 Yalgar Rd, KIRRAWEE NSW 2232
P: 1300 900 345
E: [email protected]
This warranty is provided in addition to other rights and remedies you have under law:
Our goods come with guarantees which cannot be excluded under the Australian
Consumer Law. You are entitled to replacement or refund for a major failure and
to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Exclusions: This warranty does not cover:
• Any defects caused by an accident, misuse, abuse, improper installation or
operation, lack of reasonable care, unauthorized modication, loss of parts,
tampering or attempted repair by a person not authorized by the distributor.
• Any product that has not been installed, operated or maintained to a
satisfactory level.
• Any damage caused by improper power input or improper cable connection.
7. TROUBLESHOOTING
