Faro Barcelona PUNT User manual

Installation
Guide
PUNT
WHERE ARE WE CALL US DOWNLOAD FOLLOW US
Calle Dinámica Nº1, Pol. Ind. Santa Rita
08755 Castellbisbal, Barcelona SPAIN
Ph [phone]
Fax [phone]
[e-mail]
www.faro.es

CONGRATULATIONS
> ESPAÑOL elicidades por la compra
de su nuevo ventilador Faro Barce-
lona que le proporcionará, diseño,
calidad y confort durante muchos
años. Estamos orgullosos de nuestro
trabajo y apreciamos la oportunidad
de suministrarle uno de los mejores
ventiladores de techo disponibles.
¡Toca empezar a disfrutar de su venti-
lador de techo Faro Barcelona!
> CATALÀ Felicitats per la compra
del seu nou ventilador Faro Barce-
lona que li proporcionarà, disseny,
qualitat i confort durant molts anys.
Estem orgullosos del nostre treball i
apreciem l’oportunitat de subminis-
trar-li un dels millors ventiladors de
sostre disponibles. Comenci a gaudir
del seu ventilador de sostre Faro
Barcelona!
> ENGLISH Congratulations on the
purchase of your new Faro Barcelona
fan that will provide you, design, qua-
lity and comfort for many years.
We are proud of our work and appre-
ciate the opportunity to provide one of
the best ceiling fans available.
It’s time to start enjoying your Faro
Barcelona ceiling fan!
> FRANÇAIS Félicitations pour
l’achat de votre nouveau ventilateur
Faro Barcelona qui vous apportera
design, qualité et confort pendant de
nombreuses années. Nous sommes
l’opportunité de fournir l’un des
meilleurs ventilateurs de plafond
disponibles. Il est temps de commen-
plafond Faro Barcelona!
> ITALIANO Congratulazioni per aver
acquistato un ventilatore Faro Barce-
lona che le garantirà design, qualità e
comfort per molto tempo.
Siamo orgogliosi del nostro lavoro e
apprezziamo molto che ci abbia dato
l’opportunità di fornirle uno dei mi-
nel mercato. Cominci ad utilizzare il
Barcelona!
> PORTUGÊS Parabéns pela compra
do seu novo ventilador de Faro Bar-
celona que lhe proporcionará design,
qualidade e conforto por muitos anos.
Estamos orgulhosos do nosso trabal-
ho e apreciamos a oportunidade de
fornecer um dos melhores ventila-
dores de teto disponíveis. É hora de
começar a desfrutar do seu ventilador
de teto Faro Barcelona!
> DEUSTCH Herzlichen Glüc-
kwunsch zum Kauf Ihres neuen Faro
Barcelona Ventilators, der Ihnen
Design, Qualität und Komfort für
viele Jahre bieten wird. Wir sind stolz
auf unsere Arbeit und schätzen die
Möglichkeit, Ihnen einen der besten
Deckenventilatoren zu liefern. Es
ist an der Zeit, Ihren Faro Barcelona
Deckenventilator zu genießen!
> NEDERLANDS Gefeliciteerd met
de aankoop van uw nieuwe Faro Bar-
celona ventilator. Deze zal u kwaliteit
en confort bieden voor vele jaren. Wij
zijn trots op ons werk, en waarderen
de mogelijkheid om u een van de
beste beschikbare plafondventilato-
ren te leveren. Geniet van uw nieuwe
Faro Barcelona plafondventilator!
Faro Barcelona!
Gratulujeme vám k zakou-
pení vašeho nového ventilátoru Faro
Barcelona, který vám poskytne de-
sign, kvalitu a komfort po mnoho let.
stropní ventilátor Faro Barcelona!
Gratulujemy zakupu nowe-
go wentylatora Faro Barcelona, który
zaoferowania jednego z najlepszych
-
tylatorem Faro Barcelona!
nákupu vášho nového ventilátora
Faro Barcelona, ktorý vám poskytne
dizajn, kvalitu a komfort po mnoho
rokov. Sme hrdí na našu prácu a
jeden z najlepších stropných venti-
stropný ventilátor Faro Barcelona!
<<

Together we take care of the planet.
This is why we reduce paper consump-
tion. Please refer to the safety, mainte-
nance and warranty instructions at
www.faro.es. If you cannot access it,
call us at [phone] or write to
[e-mail].
Juntos cuidamos el planeta. Por eso
reducimos el consumo de papel.
Puedes consultar las instrucciones de
seguridad, mantenimiento y garantía
en www.faro.es. Si no puedes acceder,
llámanos al [phone] o escríbe-
nos a [e-mail].
Junts cuidem el planeta. Per això
reduïm el consum de paper. Pots
consultar les instruccions de segure-
tat, manteniment i garantia en www.fa-
ro.es. Si no hi pots accedir, telefona’ns
al [phone] o escriu-nos a
[e-mail].
Ensemble, nous prenons soin de la
planète. C’est pourquoi nous
réduisons la consommation de papier.
Veuillez-vous référer aux instructions
de sécurité, d’entretien et de garantie
sur www.faro.es. Si vous ne pouvez
pas y accéder, appelez-nous au +34
937 723 965 ou écrivez à export@fa-
ro.es.
Insieme proteggiamo il pianeta.
Questo è il motivo per il quale
abbiamo ridotto il consumo di carta.
Per favore, leggi le istruzioni sulla
sicurezza, la manutenzione e la
garanzia sul sito www.faro.es
Se non puoi accedere, chiamaci al +34
937 723 965 o scrivici a export@fa-
ro.es.
Juntos cuidamos do planeta. É por
este motivo que reduzimos o
consumo de papel. Consulte as
instruções de segurança, manutenção
e garantia em www.faro.es. Se não
conseguir aceder, ligue para +34 937
723 965 ou escreva para export@fa-
ro.es.
Gemeinsam sorgen wir uns um
unseren Planeten. Deshalb reduzie-
ren wir den Papierverbrauch. Bitte
beachten Sie die Sicherheits-,
Wartungs- und Garantiehinweise
unter www.faro.es. Wenn Sie nicht
darauf zugreifen können, rufen Sie uns
unter [phone] an oder
schreiben Sie an [e-mail].
We dragen samen zorg voor onze
planeet. Daarom verminderen wij het
papiergebruik. Raadpleeg de
veiligheids-,onderhouds-engarantie-
handleiding op www.faro.es. Kan u ze
niet raadplegen? Bel ons op +34 937
723 965 of schrijf ons op export@fa-
ro.es.
[e-mail].
Proto omezujeme spotřebu papíru.
Přečtěte si, prosím, pokyny týkající se
bezpečnosti, údržby a záruky na
www.faro.es. Pokud na stránky nemáte
přístup, zavolejte nám na tel. +34 937
723 965 nebo napište na export@fa-
ro.es.
Dlatego
zmniejszamy zużycie papieru. Proszę
zapoznaćsięz instrukcjami bezpiec-
zeństwa, konserwacji i gwarancji na
www.faro.es. Jeśli nie możesz uzyskać
do niego dostępu, zadzwońdo nas
pod numer [phone] lub napisz
na adres [e-mail].
Ето защо намаляваме
консумацията на хартия. Моля,
направете справка синструкциите за
безопасност, поддръжка игаранция
на www.faro.es. Ако нямате достъп до
сайта, обадете ни се на [phone]
или пишете на [e-mail].
To je dôvod, prečo sme znížiť
spotrebu papiera. Pozri pokyny k
bezpečanykurázaybžrdú,itson
www.faro.es. Ak nemôžete pristupo-
vať, zavolajte na telefónne č
íslo +34
937 723 965 alebo píšte n export@fa-
ro.es.
3

> ESPAÑOL: El manual de contiene
las instrucciones completas para
instalar y operar con su ventilador
de forma segura.
-
dos los tornillos y hacer todas las
conexiones correctamente.
> CATALÀ: Els manuals conten les
instruccions completes per ins-
tal·lar i operar amb el seu ventilador
de forma segura.
Recordi estrènyer fermament tots
els cargols i fer totes les conne-
xions correctament.
> ENGLISH: The manuals contain
the complete instructions for ins-
talling and operating with your fan
safely. Remember to tighten all
-
tions correctly
> FRANÇAIS: Le manuel d’utilisa-
tion contient les instructions com-
plètes pour installer et utiliser vo-
tre ventilateur en toute sécurité.
N’oubliez pas de serrer toutes les
vis fermement et de faire toutes les
connexions correctement
> ITALIANO: Il manuale operativo
contiene le istruzioni complete per
installare ed utilizzare il suo venti-
latore in totale sicurezza.
Ricordi di avvitare bene tutti I bullo-
ni e realizzare tutte le connessioni
nella maniera corretta.
> PORTUGÊS: O manual de ope-
ração contém as instruções com-
pletas para instalação e operação
com o seu ventilador com segu-
-
mente todos os parafusos e fazer
todas as conexões corretamente.
> DEUSTCH: Die Betriebsanleitung
enthält vollständige Anweisungen
für die sichere Installation und den
sicheren Betrieb Ihres Ventilators.
Denken Sie daran, alle Schrauben
fest anzuziehen und alle Verbin-
dungen korrekt herzustellen.
> NEDERLANDS: De gebruikshand-
leiding bevat de volledige instruc-
ties voor de installatie en de veilige
bediening van uw ventilator.
Vergeet niet om alle schroeven ste-
vig vast te draaien, en alle verbin-
ding correct aan te sluiten.
-
sahuje kompletní pokyny pro ins-
ventilátoru.
-
pojit!
zawiera kompletne wskazówki do-
-
!
Návod na obs-
ventilátorom.
správne.
<<

5

Technical Specifications PUNT
Speeds A W RPM CFM M3MIN
I 9 100
II 12 118
III 16 132
IV 21 152
V30 168
VI 33
0.07
0.09
0.12
0.16
0.21
0.24 176
3461
4085
4569
5262
5816
6093
98
116
129
149
165
173
Power Weight
V220-240 Hz 50 3.7 KG 8.2 LB
Smart Fan V100-240 Hz 50/60
Sizes mm / inch Finishes
Refs MOTOR (Steel) BLADES (ABS) With light
kit
33814,
33814WP White Blanco White Blanco 33814-20, 33814WP-20
33815,
33815WP Black Negro Black Negro 33815-21,
33815WP-21
33816,
33816WP White Blanco Maple Arce 33816-20,
33816WP-20
33817,
33817WP Black Negro Oak Roble 33817-21,
33817W-21
Onfly for PUNT with light kit SMD LED 20W 3000-4000-6500K max 1300Lm LED
Este producto contiene una fuente luminosa de la clase eficiencia energética F
This product contains a light source of energy efficiency class F
RF
DC
Ø 1300/51.2”
Ø 150/5.91”
Ø 132/5.2”
290/11.42”
322/12.68”
578/22.76”
D

7
Tools
Needed
7.Blades
Installation kit
Instructions manual
Package Contents
1.Bracket
4.Yoke cover
2.Down rod
3.Canopy
5.Body/motor
Blade balancing kit
Remote control unit
9.Light cover
6.Bottom cover
8.Light kit
34
5
6
1
2
1H 3H
6H
Z
Z
Z
AAA 1.5V
Need to be purchased separately
L N
.1.
7.Blades
Installation kit
Instructions manual
1.Bracket
4.Yoke cover
2.Down rod
3.Canopy
5.Body/motor
Blade balancing kit
Remote control unit
9.Light cover
6.Bottom cover
8.Light kit
34
5
6
1
2
1H 3H
6H
Z
Z
Z
AAA 1.5V
Need to be purchased separately
L N
Tools
Needed
7.Blades
Installation kit Instructions manual
Package Contents
1.Bracket
4.Yoke cover
2.Down rod
3.Canopy
5.Body/motor
Blade balancing kit
Remote control unit
9.Light cover
6.Bottom cover
8.Light kit
34
5
6
1
2
1H 3H
6H
Z
Z
Z
AAA 1.5V
Need to be purchased separately
L N
①
③
Step 1(Basic assembly of the fan)
Decompose Drown rod
Install the Yoke cover and Canopy. Then
insert the fixing pin, push the Hanging ball
up, and fix it with screws.
①
③
Decompose Drown rod
Install the Yoke cover and Canopy. Then
insert the fixing pin, push the Hanging ball
up, and fix it with screws.
no incl

Assembly Instructions
① ②
③ ④
Step 1(Basic assembly of the fan)
Decompose Drown rod Pass the cable through the down rod and
lock the down rod.
screw
Install the Yoke cover and Canopy. Then
insert the fixing pin, push the Hanging ball
up, and fix it with screws.
OK
②
④
Pass the cable through the down rod and
lock the down rod.
screw
Install the Yoke cover and Canopy. Then
insert the fixing pin, push the Hanging ball OK
Assembly Instructions
③Snap the basically assembled fan into the
installed Bracket.
Step 2 (Ceiling bracket installation and fan into the installed Bracket.)
Click!
buckle
OFF
①
Turn off the fan power supply at the circuit
breaker box and the wall switch. If it is a
cement roof, please drill the installation
hole at the installation location.
Can be installed on <15º sloped roof.
Choose the following installation methods
according to the actual situation of the roof.
②
or
Cement roof
Solid wood roof
.2.
③ ④
Install the Yoke cover and Canopy. Then
insert the fixing pin, push the Hanging ball
up, and fix it with screws.
OK
②
④
Decompose Drown rod Pass the cable through the down rod and
lock the down rod.
screw
Install the Yoke cover and Canopy. Then
insert the fixing pin, push the Hanging ball
up, and fix it with screws.
OK
2 3
5
46
1
Assembly Instructions
③Snap the basically assembled fan into the
installed Bracket.
Step 2 (Ceiling bracket installation and fan into the installed Bracket.)
OFF
①
Turn off the fan power supply at the circuit
breaker box and the wall switch. If it is a
cement roof, please drill the installation
hole at the installation location.
Can be installed on <15º sloped roof.
Choose the following installation methods
according to the actual situation of the roof.
②
or
Cement roof
Solid wood roof
Step 3 (Receiver installation and wiring)
FAN
Click!
buckle
①
Connect the wires according to the polarity (the color of the
House power cord may be different if the color is the same).
AC IN N(Blue)
AC IN L(Brown)
Ground(Yellow/green)
L For light(Blue) To Motor
House power
FAN
L N
Step 3 (Receiver installation and wiring)
FAN
①
Connect the wires according to the polarity (the color of the
House power cord may be different if the color is the same).
AC IN N(Blue)
AC IN L(Brown)
Ground(Yellow/green)
L For light(Blue)
N Neutral(White)
To Motor
U(Pink)
V(Gray)
W(Red)

7
8 9 10
9
.3.
③Snap the basically assembled fan into the
installed Bracket.
Step 3 (Receiver installation and wiring)
FAN
Click!
buckle
①
Put the receiver into the
Bracket and arrange the wires
②
Adjust the position of Canopy,
then lock it
③
Connect the wires according to the polarity (the color of the
House power cord may be different if the color is the same).
AC IN N(Blue)
AC IN L(Brown)
Ground(Yellow/green)
L For light(Blue)
N Neutral(White)
To Motor
U(Pink)
V(Gray)
W(Red)
House power
FAN
L N
Put the receiver into the
Bracket and arrange the wires
②
Adjust the position of Canopy,
then lock it
③
Connect the wires according to the polarity (the color of the
House power cord may be different if the color is the same).
.3.
Step 3 (Receiver installation and wiring)
Put the receiver into the
Bracket and arrange the wires
②
Adjust the position of Canopy,
then lock it
③
Connect the wires according to the polarity (the color of the
House power cord may be different if the color is the same).
House power
FAN
L N
Assembly Instructions
Step 4 (Blades and Light kit installation)
①Align the blades with the mounting holes,
and then fix them with screws.
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
.3.
Step 3 (Receiver installation and wiring)
①
Put the receiver into the
Bracket and arrange the wires
②
Adjust the position of Canopy,
then lock it
③
Connect the wires according to the polarity (the color of the
House power cord may be different if the color is the same).
AC IN N(Blue)
AC IN L(Brown)
Ground(Yellow/green)
L For light(Red )
N Neutral(Blue)
To Motor
U(Pink)
V(Gray)
W(Red)
House power
FAN
L N
faqs - www.faro.es
L marrón, marró, brown, marron,
marrone, castanho, braun, bruin,
-
Nazul, blau, blue, bleu, blu, azul,
amarillo-verde, groc-verd, ye-
llow-green, jaune-vert, giallo-ver-
de, verde-amarelo, gelb-grün,
-
①
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord
Step 5(Switch on and ceiling fan works)
②
Step 5(Switch on and ceiling fan works)
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord

Assembly Instructions
Light kit installation)
Align the blades with the mounting holes, ②Model NO LIGHT:Install bottom cover
directly
Model LED:Loosen the screw of the light
source cord buckle from the bottom of the ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
1312
11
②directly
Model LED:Loosen the screw of the light
source cord buckle from the bottom of the ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
Finally install the light cover.
Insert
Step 5(Switch on and ceiling fan works)
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
Finally install the light cover.
Insert
Step 5(Switch on and ceiling fan works)
Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
Finally install the light cover.
Insert
.4.
Step 5(Switch on and ceiling fan works)
ON
34
5
6
1
2
1H 3H
6H
Z
Z
Z
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
Finally install the light cover.
Insert
.4.
Step 5(Switch on and ceiling fan works)
ON
34
5
6
1
2
1H 3H
6H
Z
Z
Z
With light kit Con kit de luz With light kit Con kit de luzWith light kit Con kit de luz
Without light kit Sin kit de luz
.4.
Step 4 (Blades and
①Align the blades with the mounting holes,
and then fix them with screws.
Step 5(Switch on and ceiling fan works)
ON
34
5
6
1
2
1H 3H
6H
Z
Z
Z
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
Finally install the light cover.
Insert
.4.
Step 5(Switch on and ceiling fan works)
ON
34
5
6
1
2
1H 3H
6H
Z
Z
Z
②source cord buckle from the bottom of the
fan to release the light source cord
.4.
Assembly Instructions
Step 4 (Blades and Light kit installation)
①Align the blades with the mounting holes,
and then fix them with screws. ②
Step 5(Switch on and ceiling fan works)
ON
34
5
6
1
2
1H 3H
6H
Z
Z
Z
Model NO LIGHT:Install bottom cover
directly
②Model LED:Loosen the screw of the light
source cord buckle from the bottom of the
fan to release the light source cord ③
Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
then lock the light kit.
Finally install the light cover.
Insert

Model LED:Remove the pre-installed
screws.Connect the light kit cable, and
ESPAÑOL
1- Velocidades (1, 2, 3, 4, 5, 6)
2- Función inversa
3- Encendido y apagado del ventilador
4- Encendido y apagado del kit de luz
5- Programable: Funcionará durante 1h, 3h, 6h
6- El ventilador funciona automáticamente con las
velocidades 1 a 6
CATALÀ
1- Velocitats (1, 2, 3, 4, 5, 6)
2- Funció inversa
3- Encen i apaga el ventilador
4- Encen i apaga el kit de llum
5- Programable: Funcionarà durant 1h, 3h, 6h
6- El ventilador funcionrà automàticament en les ve-
locitats de 1 a 6
ENGLISH
1- Fan speeds (1, 2, 3, 4, 5, 6)
2- Reverse function
5- With Programmer: It will works for 1h, 3h, 6h
6- Natural wind: the fan speeds automatic cycle
between 1 to 6 speeds
FRANÇAIS
1- Vitesses (1, 2, 3, 4, 5, 6)
2- Interrupteur a sens inverse pour changer la di-
rection du tour du ventilateur
4- Fonction marche / arrêt de la lumière
5- Avec Programmateur: Fonctionne pendant 1h, 3h,
6h
6- Le ventilateur accélère le cycle automatique entre
1 et 6 vitesses
ITALIANO
1- Velocità (1, 2, 3, 4, 5, 6)
2- Senso di rotazione del ventilatore, in avanti o
indietro.
4- Funzione di accensione / spegnimento la luce
5- Programmabile. Finziona per 1t, 3t, 6t
6- La ventola accelera il ciclo automatico tra 1 e 6
velocità
PORTUGÊS
1- Velocidades da ventoinha (1, 2, 3, 4, 5, 6)
2- Controla a direcção de rotação, para a frente ou
para trás
3- Começando marcha e desemprego do venton-
hia
4- Acenda e apague a luz
5- Programável: Funciona por 1h, 3h, 6h
6- O ventilador acelera o ciclo automático entre 1 a
6 velocidades
NEDERLANDS
1- Snelheden van de ventilator (1, 2, 3, 4, 5, 6)
2- Inverse functie
4- Schakelaar licht kit
5- Programmeerbare: Werkt voor 1t, 3t, 6t
6- De ventilator snelheden automatische cyclus tus-
sen 1 tot 6 snelheden
DEUSTCH
1- ventilator snelheden (1, 2, 3, 4, 5, 6)
2- Umkehrfunktion
4- Lichtschalter
5- Programmierbar: Arbeitet für 1s, 3s, 6s
6- Der automatische Zyklus der Ventilatorgeschwindi-
gkeiten zwischen 1 und 6 Geschwindigkeiten
2- Inverzní funkce
5- Programmable: Pracuje na 1, 3, 6 hodin
6 rychlostmi
2- Punkcja odwrotna
2- Inverznej funkcie
3- zapnite a vypnite svetlo
4- zapnite a vypnite stropný ventilátor
<<
6 3 1
6 1
1
5
6
42
7
3
11
Remote control
2 x AAA 1.5V no incl

01-2022
