Fasttel FLEXITALK User manual





Flexitalk






Fasttelhastherighttochangethecontentwithoutprecedingannouncements.

FasttelBelgium,Spieveldstraat24,9160Lokeren.Tel+32(0)92446520,[email protected]
FasttelNetherlands,Heiligenboom3,5066CBMoergestel.Tel0135136514,[email protected]



MANUAL

Edition 3.5 pg 2 Flexitalk manual




TABLEOFCONTENTS



1.ADVANTAGESANDTECHNICALFEATURES3

2.TARGETANDGENERALDESCRIPTION 4

3.USEOFTHESYSTEM5

3.1.Incomingdoorcall5

3.2.Connectionwiththedoorphone5

3.3.Externalcallduringaconversationwiththedoorphone5

4.PUTTINGINSERVICETHESYSTEM6

5.CONNECTIONS8

5.1.Doorphone8

5.2.Doorphonewithvideo9




Edition 3.5 pg 3 Flexitalk manual
Dearuser,

Fasttelthanksyouforthepurchaseofthisproduct.Weareconvincedthattheapparatus,ifcorrectly
installed,willgiveyouentirelysatisfaction.Ifyouhaveneverthelessfurtherquestionsor
observations,donothesitate.Yourobservationshelpustoimproveourproduct.Youfindour
addressanddataonthefront‐page...


1.1.Advantages:

Veryeasytoinstall;
Possibilitytouseexistingcables;
Commutationbetweentelephonelineandtelephonedevice;
Putsonholdtheincomingline;
Opensthedoorwithtelephonekeyboard;
Controlofanextra(Domotics)contact;
Doorstation:Aluminiumdesign;
Vandalresistantdoorstationconstruction;
Highqualitysound;
Integrationofvideocameraispossible;

1.2.Technicaldata:

Power:230Volt
Camera(option):1.5luxblack/white,5colours
Videoin:Twistedpair(forexample,UTP,maximum300m)
Musiconhold:internal
Connections:Analoguelinein
:Telout
:DP,doorpost
:2contactsrelay,1A/30VDC
:powerexitfordoorpost
Type:built‐inorexternal
Dimensionsinterface:dinrail157x86x58

Edition 3.5 pg 4 Flexitalk manual
2.1.Target:

Theuseofyourtelephoneapparatusasadoorintercomreceiver,withthepossibilitytoopenthe
door,tocontrolanadditionalcontact(Homeautomationordomotics)andtoputcommunicationson
hold,withthepossibilityofinternalmusiconhold.

2.2.Generaldescriptionofthe‘Flexitalk’

Thesystemallowsyoutotransformyourtelephoneapparatusintoanintercomresponderanddoor
opener.
WerealizethisbyconnectingtheFLEXITALKbetweenyourenteringlineconnectionandyour
telephone.

Theconnectionpossibilitiesare:

FLEXITALK
PSTN line

FLEXITALK
PSTN line
PSTN line
PABX

FLEXITALK
PSTN line PABX
PSTN line



Edition 3.5 pg 5 Flexitalk manual
3.Useofthe‘Flexitalk’

3.1.Incomingdoorcall

Ifonepressesuponthebuttonoftheexternalstation,thecallcanbeestablishedin2
ways.

1.Youarenotinconversation
°Yourtelephonestartsringingwithanothercadence,differentfromanormalcall,
namely0.350secondson,0.30secondsoff,0.350secondson,0.30secondsoff,0.350
secondson2.35secondsinterval.
°Youanswerthecallasanordinaryphonecall.Thenyoucantalktothepersonatthe
doorphone.
°Youcanopenthedoorviacode#1#
°Youcanalsouseasecondcontactviacode#2#.
°Youbreakofftheconnectionbyputtingdownthereceiver.

2.Youareinconversation
°Viaanannouncementtone(duration1second),youareinformedofadoorcall.
°Youhave3possibilities:
1)Youcanfinishtheconversationwithyourcorrespondentbyputtingdownthe
receiver.Yourtelephonewillthereuponringwiththecadencementionedabove.
Whenyouputdownthereceiver,youareinconnectionwiththedoorstation.
2)Youcanputyourcorrespondentonholdbypressing*uponyourapparatus(your
correspondenthearsinternalonholdmusicandyouareautomaticallyconnected
withthedoorpost).
Nowyoucancommandthedoororthesecondcontact.
Youcantakebackyourcorrespondentbypressingupon*.
3)Youcandirectlyopenthedoorwithouttalkingtothepersonattheintercomby
pressingupon#1#or#2#.

3.2.Gettingconnectedwiththedoorphone

Whenyouintroduce#*#youareconnectedtotheintercom.Youcanalsousethe
commandstoopenthedoor#1#ortousecontact2#2#.


Observation

Eachcommandisconfirmed,afterexecution,by3shortsuccessivebeeptones.
Onlythen,youcanintroduceanewcommand.
Alongbeeptonemeansabadintroduction.











Edition 3.5 pg 6 Flexitalk manual

4.Bringingintoservicethe‘Flexitalk’

Allconnections,exceptthemainsvoltage,happenviaa12‐poleclipline.

Itisbettertoconnectwithouttension.
Underthisclipline,youfindanindicationoftheconnections.
Itmeans:
15‐16LINE:connectionofthepublictelephonenetworkorextensionofthePABX
17‐18TEL:connectionofyourtelephoneorincominglineofyourtelephoneexchange
19‐20DP:connectiontodoorphoneunit
21‐22REL1:NO,normalopencontactrelay1
  C,commoncontactrelay1
23‐24REL2:NO,normalopencontactrelay2
  C,commoncontactrelay2
25‐26EXT:externalsupplyvoltageforthedoorphone
27‐28:mainsvoltage230Vac

Observation:ifaconnectionwithananaloguetelephonelineoraPABXextensionisimpossible,youmustbridgethepins
LINEenDPwith2wires.Inthiscase,youmakeanaudioconnectionwhenyoupickupthephone.Toactivatethevideo,you
mustpressupon#*#.

Relay1andrelay2actasimpulsecontactsifyouusethecode#1#and#2#.
Ifyouwanttousethecontactsasatoggle(on/oft),usethecodes,#11#toputoncontact1and#10#
toputoffcontact1.
Forthesecondcontact,userespectively#21#and#20#.
Thissecondcontactcanalsobeactivedfor3seconds,ifonepressesuponthebuttonoftheexternal
station(code#511,seepage7)orcontinuduringthewholeconversation(code#521,seepage7)


Whenonepressesuponthebuttonoftheexternalstation,thephoneswillring10times.
Youcanmodifythesetimesviathecode#90XXwherexx=01..99.
Youcanonlyintroducethiscodeaftertheconnectionwiththedoorphone.
Ifnecessary,youcanalsomodify,onthePCB(PrintedCircuitBoard)oftheexternalstation,the
volumeoftheloudspeakerandthemicrophonebysettingthepotentiometers.Seediagram
underneath.
 

Edition 3.5 pg 7 Flexitalk manual

Overviewcodes:

‐inrest

#*#:makeconnectionwithdoorunit


‐inconnection

Usercodes

#1#:controlrelay1for2seconds
#2#:controlrelay2for2seconds
#11#:controlrelay1(on)
#10#:controlrelay1(off)
#21#:controlrelay2(on)
#20#:controlrelay2(off)
*:breakofftheconnectionwiththedoorunit

Programcodes

#90XX:setupthetimestoringXX=01..99,default=99

#501:activatepermanentlythecamera
#500:donotactivatepermanentlythecamera
#511:controlrelay2for3secondswhenthereisadoorphonecall
#510:donotcontrolrelay2for3secondswhenthereisadoorphonecall=default
#521:controlrelay2continuduringthewholeconversationwhenthereisadoorphonecall
#520:donotcontrolrelay2afteradoorphonecall
#530:resettodelautvalues


‐incommunicationwithexternallineanddoorcall

*:puttheexternallineonholdandconnect
Whenyouintroduceagain*theexternallineistakenbackandtheconnectionwiththedoor
unitisbrokenoff.
#1#:controlrelay1for2seconds
#2#:controlrelay2for2seconds
#11#:controlrelay1(on)
#10#:controlrelay1(off)
#21#:controlrelay2(on)
#20#:controlrelay2(off)


5.Connections

5.1Doorphone
SD
123
456
789
*
0#
ABC DEF
GHI JKL MN
PRS TUV WXY
OQZ
i
Mute
LS-/
Redial
Individr ep.
Mail
Store/Red.
LS/Apply
LS+/-
Transfer
ISDNserv.y

Attention:ifyouhaveanADSLconnection,youmustconnectthetelephonelignebehindtheADSLfilter

Edition 3.5 pg 9 Flexitalk manual


5.2.Doorphonewithvideo
SD
123
456
789
*
0#
ABC DEF
GHI JKL MN
PRS TUV WXY
OQZ
i
Mute
LS-/
Redial
Individrep.
Mail
Store/Red.
LS/Apply
LS+/-
Transfer
ISDNserv.y


Attention:ifyouhaveanADSLconnection,youmustconnectthetelephonelignebehindtheADSLfilter
