Safety Message to Installers of Warning Light Equipment
People’s lives depend on your proper installation and servicing of Federal Signal products. It is important
to read and follow all instructions shipped with this product and the original product. Listed below are
some other important safety instructions and precautions you should follow.
• To properly install the lighting system, you must have a good understanding of automotive systems,
along with proficiency in the installation and use of safety warning equipment.
• Do not install equipment or route wiring in the deployment path of an airbag.
• If a vehicle seat is temporarily removed, verify with the vehicle manufacturer if the seat needs to be
recalibrated for proper airbag deployment.
• Frequently inspect the light system to ensure that it is operating properly is securely attached to the
vehicle.
• When drilling into a vehicle structure, ensure that both sides of the surface are clear of anything that
could be damaged.
• Refer to the instructions packed with related products for additional precautions and information.
• File these instructions in a safe place and refer to them when maintaining and/or reinstalling the
product.
• Do not stare directly into the lights at a close range, or permanent damage to your eyesight may
occur.
Failure to follow all safety precautions and instructions may result in property damage, serious injury, or
death.
Product Overview
This publication has instructions for permanently mounting the Split Vision SLR to a vehicle. One kit is
supplied with VSLR3, and two kits with VSLR6 and VSLR8 models. For electrical installation instructions,
refer to the installation and maintenance instructions packed with the light bar.
Unpacking the Kit
After unpacking the kit, inspect it for damage that may have occurred in transit. If it has been damaged,
do not attempt to install or operate it. File a claim immediately with the carrier, stating the extent of the
damage. Carefully check all envelopes, shipping labels, and tags before removing or destroying them.
Ensure that the parts in the Kit Contents List are included in the package. If you are missing any parts,
contact Customer Support at 1-800-264-3578, 7 a.m. to 5 p.m., Monday through Friday (CT).
Permanent Mounting Kit for the
Split Vision SLR
2562677 A3 0620

Permanent Mounting Kit for the Split Vision SLR
2VSLR3, VSLR6, and VSLR8 Mounting Kits
Federal Signal www.fedsig.com
Table 1 Mounting kit contents
One kit is supplied with VSLR3, and two kits with VSLR6 and VSLR8 models.
Qty. Description Part Number
4 Screw, 1/4 x 3/4 inch, Type AB, HWH, SS BLK OX 7011183-12
8 Pad, Mounting, Rubber 8422A033
4 Nut, Hex, 3/8-16, HCR 7059124
4 Washer, 3/8, S.S 7072A035
4 Lockwasher, Split, 3/8 inch, S.S. 7074A046
1 Bracket, Mounting, LH 8652206-L
1 Bracket, Mounting, RH 8652206-R
Optional Brackets
Qty. Description Part Number
1 Bracket, Short, Mounting, LH 865200957-L
1 Bracket, Short, Mounting, RH 865200957-R
Installing the Mounting Brackets on the Light Bar
To install the mounting brackets on the light bar:
1. Carefully turn the light assembly upside down and place it on a surface that will not scratch the
domes.
2. Assemble one LH and RH mounting bracket on the factory installed carriage bolts using 3/8-16 hex
nuts, 3/8-inch flat washers, and 3/8-inch split lockwashers as shown in Figures 1 and 2. Secure the
brackets in position; torque the nuts to 20 ft-lb.
Figure 1 RH bracket attached to passenger side of light bar
RH Mounting Bracket
Carriage Bolt (4)
(Supplied with Light Bar)
3/8-16 Hex Nut
3/8-inch Split Lockwasher
3/8-inch Washer
290A6847
3. For the Model VSLR6 and VSLR8, repeat steps 1 and 2 on the other half of the light bar.

Permanent Mounting Kit for the Split Vision SLR
3
VSLR3, VSLR6, and VSLR8 Mounting Kits
Federal Signal www.fedsig.com
Installing the Light Bar on the Vehicle
ROOF SUPPORT STRUCTURE: There is a roof support member that spans the distance between
the driver and passenger side. DO NOT DRILL THROUGH THIS MEMBER! Adjust any hole
locations until the holes can be drilled without going through this member. Failure to follow this
warning will weaken the roof of the vehicle and may lead to an increased chance of bodily injury
or death in a rollover accident.
HEAVY OBJECT: Use lifting aids and proper lifting techniques when removing or replacing the
light bar. Failure to follow this warning may cause personal injury.
To install the light bar on the vehicle.
1. Position the light bar on the vehicle roof at the desired location. The light bar should be positioned
with the pods aligned facing forward. Ensure that the light bar does not interfere with the operation
of other apparatus. See Figure 2.
Figure 2 Light bar with brackets installed
RH Mounting Bracket
LH Mounting Bracket
Side View, Passenger Side
290A6848
Front
Large Offset,
Front
Bottom View, Passenger Side
DRILLING PRECAUTIONS: Before drilling holes, check the area into which you plan to drill to
ensure that you do not damage vehicle components. All drilled holes should be deburred and all
sharp edges should be smoothed. All wires going through drilled holes should be protected by
a grommet or convolute/split-loom tubing.
2. Using the mounting brackets as templates, scribe four drill position marks on the mounting surface.
3. For VSLR6 and VSLR8 models, repeat steps 1 and 2 on the other half of the light bar.
4. Before drilling, move the light bar(s) out of the way. Drill 0.199-inch (#8 drill) diameter holes at the
scribed drill position marks.
5. Place the light bar in position on the roof. For proper drainage, tilt the nose of the light bar downward,
using three mounting pads in back and one mounting pad in front on each bracket.

Permanent Mounting Kit for the Split Vision SLR
4VSLR3, VSLR6, and VSLR8 Mounting Kits
Federal Signal www.fedsig.com
6. Secure the light bar to the roof using the 1/4 by 3/4-inch black stainless steel thread-forming screws
and tighten them securely. The Split Vision SLR should now be solidly anchored to the roof. See
Figure 3.
Figure 3 Bracket secured to vehicle roof
Mounting Bracket
Thread-Forming Screw
V
ehicle Roof
Mounting Pads
(3 in Back, 1 in Front)
7. Ensure that all fasteners are tightened properly.
IMPORTANT: Frequently inspect the light bar to ensure that all fasteners and brackets are tight.
