INSTALLATION
final
public (B)
2007-09-25
M50805-4e-ID-B.doc
OBI
D
i-scan
®
ID ISC.MR101-USB
ID ISC.PR101-USB

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 2 of 20 M50805-4e-ID-B.doc
Note
©Copyright 2007 by
FEIG ELECTRONIC GmbH
Lange Strasse 4
D-35781 Weilburg-Waldhausen
Tel.: [phone]
http://www.feig.de
With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.
Copying of this document, and giving it to others and the use or communication of the contents thereof are
forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved
in the event of the grant of a patent or the registration of a utility model or design.
Composition of the information in this document has been done to the best of our knowledge. FEIG
ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this
manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,
despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC
GmbH does not give any guarantee promise for perfect function in cross environments.
FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this
document and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH
does not convey any license under its patent rights nor the rights of others.
OBID®and OBID i-scan®are registered trademarks of FEIG ELECTRONIC GmbH.

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 3 of 20 M50805-4e-ID-B.doc
Contents
1. Safety Instructions / Warning - Read before start-up ! 5
2. Performance Features of the readers 6
2.1. Performance features .........................................................................................................6
2.2. Available Reader-Types......................................................................................................6
3. Assembly and Wiring 7
3.1. Dimensions..........................................................................................................................7
3.2. Connector sockets..............................................................................................................8
3.3. USB-Interface connection X3.............................................................................................8
3.4. Power supply (only ID ISC.MR101)....................................................................................9
3.5. Antenna terminal X4 (only ID ISC.MR101).......................................................................10
3.6. Starting...............................................................................................................................11
3.6.1. ID ISC.MR101..............................................................................................................11
3.6.2. ID ISC.PR101..............................................................................................................11
4. Control and display elements 12
4.1. LED.....................................................................................................................................12
5. Technical Data 13
6. Approvals 15
6.1. Europe (CE)........................................................................................................................15
6.2. Canada (IC) ........................................................................................................................16
6.3. USA.....................................................................................................................................17
6.3.1. FCC .............................................................................................................................17
6.3.2. UL................................................................................................................................17
7. Appendix 18

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 4 of 20 M50805-4e-ID-B.doc
7.1. Accessories.......................................................................................................................18
7.1.1. Wall mounting kit ID ISC.MS.MR/PR-A.......................................................................19
7.1.2. Antennas......................................................................................................................20

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 5 of 20 M50805-4e-ID-B.doc
1. Safety Instructions / Warning - Read before start-up !
•The device may only be used for the intended purpose designed by for the manufacturer.
•The operation manual should be conveniently kept available at all times for each user.
•Unauthorized changes and the use of spare parts and additional devices which have not been
sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such
unauthorized measures shall exclude any liability by the manufacturer.
•The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid
for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,
or omissions in the manual or automatically set parameters for a device or for an incorrect
application of a device.
•Repairs may only be executed by the manufacturer.
•Installation, operation, and maintenance procedures should only be carried out by qualified
personnel.
•Use of the device and its installation must be in accordance with national legal requirements
and local electrical codes .
•When working on devices the valid safety regulations must be observed.
•Special advice for carriers of cardiac pacemakers:
Although this device doesn't exceed the valid limits for electromagnetic fields you should keep
a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in
an immediate proximity of the device respective the antenna for some time.

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 6 of 20 M50805-4e-ID-B.doc
2. Performance Features of the readers
2.1. Performance features
The Reader is designed for reading passive data carriers, so-called „Smart Labels“ at an operating
frequency of 13.56 MHz.
The reader ID ISC.MR101 is suitable for all applications in which moderate reading distances are
required. Also required is an external antenna connected to the Reader.
The ID ISC.PR101 is suitable for all applications which don’t require wide reader ranges. The
reader contains of an internal antenna, so that is no external antenna necessary.
An anti-collision function enables simultaneous reading of up to 30 transponders per second.
The Reader electronics is contained in a plastic housing having an IP30 enclosure rating.
Both readers comes with an USB-Interface.
The reader ID ISC.PR101-USB will be powered via the USB-Interface. An additional power supply
is not necessary.
2.2. Available Reader-Types
Reader-Types Description
ID ISC.MR101-A asynchronous RS232 interface and external antenna
ID ISC.MR101-A-M asynchronous RS232 interface and external antenna - Module
ID ISC.MR101-USB USB-Interface and external antenna
ID ISC.PR101-A asynchronous RS232 interface and internal antenna
ID ISC.PR101-A-M asynchronous RS232 interface and internal antenna - Module
ID ISC.PR101-USB USB-Interface and internal antenna
Table 1: Reader-Types

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 7 of 20 M50805-4e-ID-B.doc
3. Assembly and Wiring
The Reader is designed for an office environment. It can be wall-mounted, in this case the wall-
mount kit should be ordered separately.
(see Appendix: 7.1. Accessories and 7.1.1. Wall mounting kit ID ISC.MS.MR/PR-A
Notes:
•The distance between two readers of the same type should not fall below 4m.
•Before any installation the intended position of the reader should be tested for it´s suit-
ability.
•Only ID ISC.PR101:
The reader must not be installed directly upon conductive materials as e.g. metal sur-
faces, metal grids (reinforcements) or metallized surfaces, as these surfaces reduce the
detection range of the reader. The distance between the reader and such surfaces
should be min. 10 cm.
3.1. Dimensions
85
RFID by FEIG ELECTRONIC
145 27
Fig. 1: Enclosure (all dimensions in mm)

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 8 of 20 M50805-4e-ID-B.doc
3.2. Connector sockets
X3 - USB
X1 - VCC
12 - 24 VDC X4 - Antenna
(50 Ω)
LED
Fig. 2: Connection sockets
3.3. USB-Interface connection X3
There is a USB-socket on board for the connection of the USB-Interface. The pinout is standard-
ized. The datarate is reduced to 12 Mbit (USB full speed). A standard USB-cable can be used.
A 2.5m USB-cable is available for the reader.. (see 7.1. Accessories).
Feig Article No. Part No.
1686.000.00 ID CAB.USB-A
Table 2: USB-cable 2,5m
Note:
The length of the USB-cable can be a max. of 3 meter. It isn’t allowed to use longer cables!
The reader ID ISC.PR101-USB does not need an external power supply. The power supply takes
place via the USB-Interface (Bus-powered). The USB-Interface must support a current of about
500mA (High Powered Interface).

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 9 of 20 M50805-4e-ID-B.doc
3.4. Power supply (only ID ISC.MR101)
Connect the 12-24 V DC/ supply voltage to socket X1 on the circuit board.
Terminal Name Description
X1 / inside Vcc Vcc – supply voltage (+)
X1 / outside GND Ground – supply voltage (-)
Table 3: Connecting the supply voltage
GND
(outside)
Vcc
(inside)
Fig. 3: DC/ socket X1 configuration.
Note:
Reversing the polarity of the supply voltage may destroy the device.
Power supply recommendations :
To take full advantage of the Reader module performance, you must use a sufficiently regulated
and low-noise power supply. When using a switching power supply, be sure that its internal
switching frequency is less than 300 kHz. (see: 7.1. Accessories).
Feig Article No Part No. Description.
1688.000.00 ID NET.12VDC-A Input voltage 230V AC
1688.001.00 ID NET.12VDC-B Input voltage 95 - 265V AC
Table 4: Recommended power supply
Note:
The power supply is supplied with a DC/ plug 2.5mm x 5.5mm. This is compatible with
the readers socket X1.

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 10 of 20 M50805-4e-ID-B.doc
3.5. Antenna terminal X4 (only ID ISC.MR101)
An SMA socket is provided on the circuit board for connecting the external antenna.
The maximum tightening torque for the SMA socket is 0.45 Nm.
Caution:
Higher tightening torque will damage the connector.
Terminal Description
X4 Connecting the external antenna
(input impedance 50Ω)
Table 5: Connecting the external antenna
Note:
•The input impedance for the antenna must be calibrated to a value of
50
Ω ± (15 Ω ∠ 15°).
•If the antenna ID ISC.ANT240340 is used a minimum distance of 20cm to any metal parts
are necessary. Otherwise there is a danger that the reader will be destroyed.
•The optimum operating Q factor of the antenna should be in a range of QB = 10...20. To
determine the operating Q the antenna must be supplied with a 50 Ohm source such as
a network analyzer or frequency generator.
•When connecting an antenna, ensure that it does not exceed the permissible limits pre-
scribed by the national regulations for radio frequency devices.

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 11 of 20 M50805-4e-ID-B.doc
3.6. Starting
The reader must be registered to the operating system by the first use. To do this you should read
the manual “Installation OBID USB-driver“.
3.6.1. ID ISC.MR101
For registering the reader to the operating system, the reader must be connected to the power
supply and the USB-cable. In which order the cables are connected will remain left to the user. The
reader should not be used without connected antenna. Due to the reader uses an external power
supply a “Low Powered Interface” is sufficient. The maximum current through the USB-Interface
amounts to 100mA.
3.6.2. ID ISC.PR101
If the reader is connected with the USB-Interface of the computer by using an USB-cable, it regis-
ters in the operating system automatically. The power requirement of the reader amounts to more
than 100mA. The USB-Interface must be a High Powered Interface. A High Powered Interface
supports the reader up to 500mA.
Note:
The function of the reader is only guaranteed if it is connected to a High Powered Interface.

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 12 of 20 M50805-4e-ID-B.doc
4. Control and display elements
4.1. LED
The Reader’s LED can be configured through software.
Abbreviation Description
LED green "RUN "
-Turns on when the Reader is ready
LED red „LABEL“
-Turns on when a transponder is detected.
LED orange „INITIALIZING“
- Flashes during Reader initialization after power-up.
Table 6: Standard configuration of the LEDs

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 13 of 20 M50805-4e-ID-B.doc
5. Technical Data
Mechanical Data
•Housing ABS plastic
Enclosed
•Dimensions (W x H x D) 85 x 145 x 31 mm / 3,35 x 4,72 x 1,77 in.
•Weight 200 g / 0,44 lbs
•Degree of Protection IP 30
•Color similar RAL 9018 (papyrus white)
Electrical Data
•Supply voltage
ID ISC.MR101-USB
ID ISC.PR101-USB
typical. 12 V DC/
max. 12 – 24 V ±15 %
5V DC/ (via USB)
•Current draw max. 0.5A
•Power consumption ID ISC.MR101: max. 8 VA
ID ISC.PR101: max. 2,5 VA
•Operating frequency 13,56 MHz
•Transmitting power ID ISC.MR101: 1,0 W ± 2dB
ID ISC.PR101: 0,5 W ± 2dB
•Antenna connection
(only ID ISC.MR101) SMA female (50Ω)
•Interfaces USB (12 Mbit)

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 14 of 20 M50805-4e-ID-B.doc
Functional Properties
•Protocol Modes - FEIG ISO HOST
- Scan Mode
•Supported transponders •ISO15693, ISO18000-3-Mode1
(EM HF ISO Chips, Fujitsu HF ISO Chips,
KSW Sensor Chips, Infineon my-d, NXP I-
Code, STM LRI ISO Chips, TI Tag-it)
•NXP I Code 1, I Code UID, I Code EPC
•Address setting for interface Device ID of the reader
•Visual indicators 1 LED ( multicolor – red / green)
Ambient Conditions
•Temperature range
- Operation
- Storage -25°C to +60°C / -13°F to +140°F
-25°C to +85°C / -13°F to +185°F
•Humidity 5 – 95% non condensing
Applicable Norms
•Radio approval
- Europe
- USA
- Canada
EN 300 330
FCC 47 CFR Part 15
RSS-Gen Issue 1, RSS-210 Issue 6
•EMC EN 300 489
•Safety
- Low-Voltage
- Human Exposure UL 60950-1
EN 50364

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 15 of 20 M50805-4e-ID-B.doc
6. Approvals
6.1. Europe (CE)

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 16 of 20 M50805-4e-ID-B.doc
When properly used this radio equipment conforms to the essential requirements of Article 3 and
the other relevant provisions of the R&TTE Directive 1999/5/EC of March 99.
Equipment Classification according to ETSI EN 300 330 and ETSI EN 301 489: Class 2
6.2. Canada (IC)
IC Certification Number: 6633A-MR101
This Class B digital apparatus complies with Canadian ICES-003.
Installation with IC Approval:
IC-NOTICE: To comply with IC Radio Standards in Canada, the system must be professio-
nally installed to ensure compliance with the IC certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in
Canada. The use of the system in any other combination (such as colocated antennas
transmitting the same information) is expressly forbidden. This device has been designed
to operate with the antennas listed below. Antennas not included in this list are strictly pro-
hibited for use with this device. The required antenna impedance is 50 ohms. An SMA so-
cket is provided on the circuit board for connecting the external antenna.
Article No. Part No.
1663.000.00 ID ISC.ANT340/240-A
2396.000.00 ID ISC.ANT340/240-B
Table 7: Antennas with IC Approval

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 17 of 20 M50805-4e-ID-B.doc
6.3. USA
6.3.1. FCC
FCC ID PJMMR101-PR101
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con-
ditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Warning: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
Installation with FCC Approval:
FCC -NOTICE: To comply with FCC Part 15 Rules in the United States, the system must be
professionally installed to ensure compliance with the Part 15 certification. It is the respon-
sibility of the operator and professional installer to ensure that only certified systems are
deployed in the United States. The use of the system in any other combination (such as
colocated antennas transmitting the same information) is expressly forbidden. This device
has been designed to operate with the antennas listed below. Antennas not included in this
list are strictly prohibited for use with this device. The required antenna impedance is 50
ohms. An SMA socket is provided on the circuit board for connecting the external antenna.
Article No. Part No.
1663.000.00 ID ISC.ANT340/240-A
2396.000.00 ID ISC.ANT340/240-B
Table 8: Antennas with FCC Approval
6.3.2. UL

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 18 of 20 M50805-4e-ID-B.doc
7. Appendix
7.1. Accessories
The following accessories are available for the Reader.
Article No. Part No. Description
1688.000.00 ID NET.12V-A 12 V DC/ power supply with suitable
connector. Input voltage 230V AC
1688.001.00 ID NET.12V-B 12 V DC/ power supply with suitable
connector. Input voltage 95 - 265V AC
1691.000.01 ID ISC.MS.MR/PR-A Wall mounting kit for
ID ISC.MR101 and ID ISC.PR101.
1686.000.00 ID CAB.USB-A USB-cable 2,5m
1663.000.00 ID ISC.ANT340/240-A External antenna
Dimensions: 340mm x 240mm x 9mm
Degree of Protection: IP30
2396.000.00 ID ISC.ANT340/240-B Externe Antenne ohne Gehäuse
1451.000.00 ID ISC.ANT300/300 External antenna
Dimensions: 300mm x 300mm x 30mm
Degree of Protection: IP65
Table 9: Accessories

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 19 of 20 M50805-4e-ID-B.doc
7.1.1. Wall mounting kit ID ISC.MS.MR/PR-A
The wall mounting kit can be used to attach the reader to a flat surface.
•Remove the screws from the back side of the reader.
•Attach the individual wall hangers using the screws supplied with the mounting kit.
Fig. 4 + 5: Mounting wall hangers
93
125 153
65
Fig. 6 + 7: Mounting drill dimensioning (all dimensions in mm)

OBIDi-scan® Installation ID ISC.MR101-USB / ID ISC.PR101-USB
FEIG ELECTRONIC GmbH Page 20 of 20 M50805-4e-ID-B.doc
7.1.2. Antennas
Fig. 8: ID ISC.ANT340/240 Fig. 9: ID ISC.ANT300/300
