Feig Electronic OBID i-scan Installation and operating instructions

APPLICATION-NOTE
preliminary
public (B)
2008-06-17
N61100-2e-ID-B.doc
OBI
D
i-scan
®
Smartshelf Demo

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 2 of 17 N61100-2e-ID-B.doc
Note
©Copyright 2007/2008 by
FEIG ELECTRONIC GmbH
Lange Straße 4
D-35781 Weilburg
Tel.: [phone]
http://www.feig.de
With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.
Copying of this document, and giving it to others and the use or communication of the contents thereof are
forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved
in the event of the grant of a patent or the registration of a utility model or design.
Composition of the information in this document has been done to the best of our knowledge. FEIG
ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this
manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,
despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC
GmbH does not give any guarantee promise for perfect function in cross environments and does not give
any guaranty for the functionality of the complete system which incorporates the subject of this document.
FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed
with components and testing methods for a level of reliability suitable for use in or in connection with surgical
implants or as critical components in any life support systems whose failure to perform can reasonably be
expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application
designer must take reasonably prudent steps to protect against system failures.
FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this docu-
ment and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does
not convey any license under its patent rights nor the rights of others.
OBID®and OBID i-scan®are registered trademarks of FEIG ELECTRONIC GmbH.
I-CODE®is a registered trademark of Philips Electronics N.V.
Tag-itTM is a registered trademark of Texas Instruments Incorporated.
Microsoft®and Windows®are registered trademarks of Microsoft Corporation
Linux is a registered trademark of Linus Torvalds.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 3 of 17 N61100-2e-ID-B.doc
General information's regarding this document
•The sign ")" indicates extensions or changes of this manual compared with the former issue.
•If bits within one byte are filled with "-", these bit spaces are reserved for future extensions or
for internal testing- and manufacturing-functions. These bit spaces must not be changed, as this
may cause faulty operation of the reader.
•The following figure formats are used:
0...9: for decimal figures
0x00...0xFF: for hexadecimal figures,
b0...1 for binary figures.
•The hexadecimal value in brackets "[ ]" marks a control byte (command).

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 4 of 17 N61100-2e-ID-B.doc
Content
1. Safety Instructions / Warning - Read before start-up ! 5
2. Introduction 6
3. System Requirements 7
3.1.1 Smartshelf (Embedded Linux) HF.....................................................................................7
3.1.2 Smartshelf (Embedded Linux) UHF..................................................................................7
3.2 SmartShelfDemo (Windows XP/2000) .................................................................................7
3. Installation 8
4. Settings 9
4.1 ISC.ANT.MUX / ISC.ANT.UMUX Configuration ...................................................................9
4.2 SmartShelfDemo ...................................................................................................................9
4.3.1 Antenna organisation HF-Reader...................................................................................11
4.3.2 Antenna organisation UHF-Reader.................................................................................13
4.3.3 Antenna numeration ........................................................................................................14
5 Connection Information 15
APPENDIX: XML conventions 16

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 5 of 17 N61100-2e-ID-B.doc
1. Safety Instructions / Warning - Read before start-up !
•The device may only be used for the intended purpose designed by for the manufacturer.
•The operation manual should be conveniently kept available at all times for each user.
•Unauthorized changes and the use of spare parts and additional devices which have not been
sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such
unauthorized measures shall exclude any liability by the manufacturer.
•The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid
for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,
or omissions in the manual or automatically set parameters for a device or for an incorrect
application of a device.
•Repairs may only be executed by the manufacturer.
•Installation, operation, and maintenance procedures should only be carried out by qualified
personnel.
•Use of the device and its installation must be in accordance with national legal requirements
and local electrical codes .
•When working on devices the valid safety regulations must be observed.
•Special advice for carriers of cardiac pacemakers:
Although this device doesn't exceed the valid limits for electromagnetic fields you should keep
a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in
an immediate proximity of the device respective the antenna for some time.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 6 of 17 N61100-2e-ID-B.doc
2. Introduction
The software package Smartshelf Demo consists of two programs.
The first program is called Smartshelf. This program is an executable binary file for the i-scan
Readers ID ISC.LR2000 and ID ISC.LRU2000.
This program was developed as an example for registering and managing the current stock of a
warehouse. For instance an possible application is to check the availability of a product, or the
availability of books in a library.
With this program it is possible to use up to 512 antennas with max. 73 multiplexers of type ID
ISC.ANT.MUX for Reader ID ISC.LR2000 or ID ISC.ANT.UMUX for Reader ID ISC.LRU2000.
The program makes inventory commands and if there is a transponder in field it inserts this trans-
ponder with its attributes into a taglist. Furthermore there is a notification function implemented
which generates status messages if a transponder is detected or lost. The application then sends a
message to the client side Windows program called SmartShelfDemo, which is the second pro-
gram. SmartShelfDemo let’s you also change reader settings, i.e. the number of antennas and the
threshold.
The number of antennas value is (obviously) how many antennas are connected. You need to set
the number of antennas only if you use the HF-Reader ID ISC.LR2000, because it can not detect
antennas automatically. Threshold means how often a transponder could not respond until it will be
deleted from the taglist (the reader will then send a “LOST” notification). There is even a possibility
to connect FEIG’s demo application ISOSTART to change the configuration of the reader. In this
case the protocols are forwarded to the reader and the received protocols are returned to
ISOSTART.
With the SmartshelfDemo program it is possible to show the complete contents of the taglist from
the embedded program Smartshelf. Event messages are received when there is a new trans-
ponder in field or a transponder was lost. The messages are sent as standard XML documents.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 7 of 17 N61100-2e-ID-B.doc
3. System Requirements
3.1.1 Smartshelf (Embedded Linux) HF
•Reader ID ISC.LR2000 with ACC
•ACC Firmware V1.09.00
•ID ISC.ANT.MUX Rev. FE 553/3 with Firmware V1.05
•Ethernet connection
3.1.2 Smartshelf (Embedded Linux) UHF
•Reader ID ISC.LRU2000 with ACC
•ACC Firmware V1.09.00
•ID ISC.ANT.UMUX Rev. FE 623/1 with Firmware V00.11.00 or higher
•Ethernet connection
3.2 SmartShelfDemo (Windows XP/2000)
•Windows 2000/XP
•Ethernet connection

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 8 of 17 N61100-2e-ID-B.doc
3. Installation
The embedded Smartshelf function is realized inside the Application Connectivity Controller
(ACC) of the reader. Thus, only the ACC must be updated with the firmware version 1.09.00. This
can be done with the OBIDFirmwareUpdateTool and it is recommended to use the ethernet con-
nection.
After the firmware update, the ACC reboots and the Smartshelf application is started 5 seconds
later. The green LED V6 signals a running ACC, the orange LED V3 signals communication ac-
tions between ACC and RFC and the blue LED V2 signals RF communication with tags.
The Smartshelf function is initialized for 3 antennas. This can be changed with the Windows appli-
cation SmartShelfDemo. For all other settings use ISOStart.
The Windows application SmartShelfDemo consists of three files (SmartShelfDemo.exe, Smart-
ShelfDemo.ini and FETCP.DLL) and can be copied to any directory of the target PC.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 9 of 17 N61100-2e-ID-B.doc
4. Settings
4.1 ISC.ANT.MUX / ISC.ANT.UMUX Configuration
For detailed information see M30201-xde-ID-B.doc for ID ISC.ANT.MUX or M71100-xde-ID-B.doc
for ID ISC.ANT.UMUX
4.2 SmartShelfDemo
After the first start of the program some settings for the smartshelf reader must be executed. Press
the button ‘Settings...’ and open the settings dialog. With this dialog, the smartshelf reader can be
configured.
After configuring, the handling of smartshelf notifications are enabled with the button ‘Start’.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 10 of 17 N61100-2e-ID-B.doc
•Threshold must be a value between 0...255. The threshold is for lost notifications. A 5 means,
that a tag is five times re-read after absent until a lost notification is sent. The re-read is real-
ized with a Read Multiple Blocks command and costs approximately 30ms.
•No. of antennas must be a value between 1...512. The no. of antennas is needed only if the
HF-Reader ID ISC.LR2000 is used. The combination of UHF-Reader ID ISC.LRU2000 and ID
ISC.ANT.UMUX multiplexers can detect multiplexers and connected antennas automatically.
•IP is the IP address of the reader. The addressed port is set to 10005, because it is fix.
•The button ‘Set reader configuration’ establish a connection to the reader, transfers the pa-
rameters and close the connection. The reader saves the parameters in its EEPROM and re-
boots, if the number of antenna is changed. When only the lost threshold is changed, then no
reboot is executed.
By pressing the button „Get List“ all transponders which are currently in field will be displayed.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 11 of 17 N61100-2e-ID-B.doc
4.3.1 Antenna organisation HF-Reader
Since detection of connected antennas is possible only with UHF-Reader and UHF-Multiplexer, it is
very important to follow specific rules considering the antenna organisation when using the HF-
Reader ID ISC.LR2000.
There has to be a gapless structure. It is not allowed to have a gap between two antennas.
General structure:
Until 8 antennas -> Cascade Level 1
From 9 antennas, till max. 64 antennas -> Cascade Level 2
from 65 antennas, till max. 512 antennas -> Cascade Level 3
The lowest level must always be fully equipped with antennas.
Additional multiplexers must always be connected to the smallest free output.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 12 of 17 N61100-2e-ID-B.doc
Example: 12 antennas
You need 2 multiplexers. The first is directly connected to the reader, the second MUX is conected
to output 1 of the first multiplexer.
7 antennas are installed at Level 1, 5 antennas at Level 2.
Level 2
OUT1
Level 1

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 13 of 17 N61100-2e-ID-B.doc
4.3.2 Antenna organisation UHF-Reader
The combination of UHF-Reader ID ISC.LRU2000 and UHF-Multiplexer ID ISC.ANT.UMUX has
the ability to detect connected multiplexers and antennas automatically. Because of that ability,
specific antenna organisation rules are not necessary.

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 14 of 17 N61100-2e-ID-B.doc
4.3.3 Antenna numeration
The number of an antenna, shown in the figure below, depends on the number of the output of the
multiplexer and the connection of that multiplexer in the structure. The decimal places of the an-
tenna number describes the active outputs of the multiplexers on all 3 levels to switch to the an-
tenna.
Example: Ant. No. A = 2*100 + 1*10 + 2*1 = 212
11 112
312
122
322
32 182 482 8
A222
A
nt. No.=[ Level 3 Mux Channel ]*100 + [ Level 2 Mux Channel ]*10 + [ Level 1 Mux Channel ]*1
Ant. No.:

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 15 of 17 N61100-2e-ID-B.doc
5 Connection Information
When the reader with the Smartshelf application is started you can connect to the reader with a
serial connection or via TCP/IP on the fix port 10005 and with the IP address of configuration block
40. Note, that only the TCP/IP connection is routed through the embedded Smartshelf application
and this connection is recommended to use for connection from other applications, like ISOStart.
This has the advantage, that the smartshelf activities are shortly interrupted for three seconds
while the host command is executed. Every next host command between the smartshelf idle time
re-triggers the idle state. For firmware update it is therefore a must to use only the TCP/IP connec-
tion.
Important:
There can only be one application connected to the reader. So when you are connected to the
smartshelf reader with ISOSTART you can’t connect with another application (for example Smart-
ShelfDemo).
CFG-Page 49 in ISO-Start
Port and IP from CFG 49
(for example: 192.168.3.216: 10002)
„ IP of reader “ : 10005

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 16 of 17 N61100-2e-ID-B.doc
APPENDIX: XML conventions
Notification messages for found or lost transponders have this structure:
<OBID>
<file-header>
<document-type>SmartShelf Notification File</document-type>
<document-version>1.0</document-version>
<reader-name>ID ISC.LR2000</reader-name>
<ip-address>192.168.3.205</ip-address>
<date>02/20/07</date>
<time>15:45:28</time>
</file-header>
<data>
<tag uid=1234…>
<event>NEW</event>
<tag-type>ISO15693</tag-type>
<antenna>123</antenna>
</tag>
<tag uid=1234…>
<event>LOST</event>
<tag-type>ISO15693</tag-type>
<antenna>123</antenna>
</tag>
</data>
</OBID>
The protocol which is generated and transmitted from SmartshelfDemo by pressing the button
“Get List” :
<OBID>
<command>get-list</command>
</OBID>

OBID i-scan®Application-Note Smartshelf Demo
FEIG ELECTRONIC GmbH Page 17 of 17 N61100-2e-ID-B.doc
The protocol which is generated and transmitted from SmartshelfDemo by pressing the button
“Save Settings” :
<OBID>
<command>set_config</command>
<config>
<antennas>1</antennas>
<threshold>1</threshold>
</config>
</OBID>
Note:
All protocols are conform to the XML conventions.
