Feig Electronic ID ISC.MR102 User manual

MANUAL
final –public (B)
2018-07-24 –H01113-4e-ID-B.docx
ID ISC.MR102
Standard Reader
from Firmware-Version 2.10 or higher

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 2 of 153
H01113-4e-ID-B.docx
Note
Copyright 2011-2018 by
FEIG ELECTRONIC GmbH
Lange Strasse 4
D-35781 Weilburg-Waldhausen
Tel.: [phone]
http://www.feig.de
With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.
Copying of this document, and giving it to others and the use or communication of the contents thereof are
forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved
in the event of the grant of a patent or the registration of a utility model or design.
Composition of the information in this document has been done to the best of our knowledge. FEIG
ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this
manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,
despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC
GmbH does not give any guarantee promise for perfect function in cross environments and does not give
any guaranty for the functionality of the complete system which incorporates the subject of this document.
FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed
with components and testing methods for a level of reliability suitable for use in or in connection with surgical
implants or as critical components in any life support systems whose failure to perform can reasonably be
expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application
designer must take reasonably prudent steps to protect against system failures.
FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this docu-
ment and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does
not convey any license under its patent rights nor the rights of others.
I-CODE®is a registered trademark of Philips Electronics N.V.
Tag-itTM is a registered trademark of Texas Instruments Incorporated.

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 3 of 153
H01113-4e-ID-B.docx
General information's regarding this document
If bits within one byte are filled with "-", these bit spaces are reserved for future extensions or
for internal testing- and manufacturing-functions. These bit spaces must not be changed, as this
may cause faulty operation of the reader.
The following figure formats are used:
0...9: for decimal figures
0x00...0xFF: for hexadecimal figures,
b0...1 for binary figures.
The hexadecimal value in brackets "[ ]" marks a control byte (command).

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 4 of 153
H01113-4e-ID-B.docx
Contents
ID ISC.MR102 1
Standard Reader 1
1. Safety Instructions / Warning - Read before start-up ! 8
Revision History of documentation ........................................................................................9
Abbreviations ......................................................................................................................... 10
2. Data Transmission between OBID i-scan®ID ISC.MR102 and Host 11
2.1. Configuration Commands and Control Commands...................................................... 11
2.2. ISO15693 Host Commands............................................................................................. 12
2.3. Scan Mode ....................................................................................................................... 15
3. Interface 17
3.1. Protocol Frames of TCP/IP protocol ..............................................................................17
3.2. Serial Data Format and Protocol Frames....................................................................... 18
3.3. CRC16 Calculation Algorithm.........................................................................................20
4. Configuration Parameters (CFG) 21
4.1. CFG0: Passwords............................................................................................................ 23
4.2. CFG1: Interface................................................................................................................ 25
4.3. CFG2: Inputs / Outputs general...................................................................................... 29
4.4. CFG3: RF-Interface..........................................................................................................32
4.5. CFG4: Transponder Parameters.....................................................................................34
4.6. CFG5: Anticollision .........................................................................................................37
4.7. CFG6: Customer Command Option Bytes..................................................................... 38
4.8. CFG7 - 10: Reserved .......................................................................................................39
4.9. CFG11 Read Mode Data.................................................................................................. 40
4.10. CFG12: Read Mode - Filter............................................................................................ 44
4.11. CFG13 Scan Mode.........................................................................................................45
4.12. CFG14-15: Reserved......................................................................................................48
4.13. CFG16: Persistence Reset............................................................................................ 49

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 5 of 153
H01113-4e-ID-B.docx
4.14. CFG17-19: Reserved......................................................................................................50
4.15. CFG20: RF-Parameter ...................................................................................................51
4.16. CFG21: Reserved........................................................................................................... 52
4.17. CFG22-23: Selection mask for ISO18000-3M3............................................................. 53
4.18. CFG24-32: Reserved......................................................................................................56
4.19. CFG33-34: LAN-Hostname............................................................................................ 57
4.20. CFG35-39: Reserved......................................................................................................58
4.21. CFG40: LAN Settings, Part 1 (only for MR102-PoE, SPAD102-E).............................. 59
4.22. CFG41: LAN Settings, Part 2 (only for MR102-PoE, SPAD102-E).............................. 60
4.23. CFG49: Notification Channel (only for MR102-PoE, SPAD102-E) .............................62
4.24. CFG63: Customer Parameter........................................................................................ 64
5. Protocols for Reader Configuration 65
5.1. [0x80] Read Configuration..............................................................................................65
5.2. [0x81] Write Configuration..............................................................................................66
5.3. [0x83] Set Default Configuration (Reset) .......................................................................67
6. Protocols for Reader Control 68
6.1. [0x52] Baud Rate Detection ............................................................................................68
6.2. [0x55] Start Flash Loader................................................................................................ 68
6.3. [0x63] Software Reset ..................................................................................................... 69
6.4. [0x64] System Reset........................................................................................................ 69
6.5. [0x65] Get Software Version...........................................................................................70
6.6. [0x66] Get Reader Info.....................................................................................................72
6.7. [0x69] RF Reset................................................................................................................ 74
6.8. [0x6A] RF ON/OFF........................................................................................................... 74
6.9. [0x6D] Get Noise Level.................................................................................................... 75
6.10. [0x6E] Reader Diagnostic ............................................................................................. 76
6.11. [0x72] Set Output...........................................................................................................78
6.12. [0x85] Set System Timer ............................................................................................... 80
6.13. [0x86] Get System Timer...............................................................................................80
6.14. [0xA0] Reader-Login......................................................................................................81
7. Protocols for ISO15693 Host Commands 82

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 6 of 153
H01113-4e-ID-B.docx
7.1. [0xB0] Host commands for ISO15693 Mandatory and Optional Commands...............83
7.1.1. [0x01] Inventory .........................................................................................................84
7.1.2. [0x02] Stay Quiet .......................................................................................................86
7.1.3. [0x22] Lock Multiple Blocks........................................................................................87
7.1.4. [0x23] Read Multiple Blocks....................................................................................... 89
7.1.5. [0x24] Write Multiple Blocks....................................................................................... 92
7.1.6. [0x25] Select..............................................................................................................95
7.1.7. [0x26] Reset to Ready................................................................................................96
7.1.8. [0x27] Write AFI.........................................................................................................97
7.1.9. [0x28] Lock AFI..........................................................................................................98
7.1.10. [0x29] Write DSFI.....................................................................................................99
7.1.11. [0x2A] Lock DSFI................................................................................................... 100
7.1.12. [0x2B] Get System Information...............................................................................101
7.1.13. [0x2C] Get Multiple Block Security Status.............................................................. 105
8. [0xB3] Host commands for EPC Transponders 107
8.1. ISO18000-3M3 Commands [0xB3]................................................................................ 108
8.1.1. [0xB3] [0x18] Kill......................................................................................................108
8.1.2. [0xB3] [0x22] Lock ...................................................................................................110
8.2. [0xBF] ISO15693 Transparent Command.................................................................... 112
Supported ISO15693 Host commands 115
8.3. Supported ISO15693 Host commands for ISO15693 Transponders......................... 115
8.3.1. Fujitsu (MB89R116)................................................................................................115
8.3.2. Fujitsu (MB89R118)................................................................................................115
8.3.3. Fujitsu (MB89R118)................................................................................................117
8.3.4. Fujitsu (MB89R119)................................................................................................118
8.3.5. Infineon (ISO address mode) 0xE0......................................................................... 119
8.3.6. Infineon (My-d Light)...............................................................................................120
8.3.7. NXP (I-Code SLI)..................................................................................................... 121
8.3.8. NXP (I-Code SLI-S).................................................................................................. 122
8.3.9. NXP (I-Code SLI-L)..................................................................................................123
8.3.10. NXP (I-Code SLIX)................................................................................................ 124
8.3.11. NXP (I-Code SLIX-S) ............................................................................................ 125

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 7 of 153
H01113-4e-ID-B.docx
8.3.12. NXP (I-Code SLIX-L).............................................................................................126
8.3.13. NXP (I-Code SLIX2).............................................................................................. 127
8.3.14. NXP ICode ILT-M (ISO18000-3M3) ......................................................................128
8.3.15. STMicroelectronics (LRI64).................................................................................. 129
8.3.16. STMicroelectronics (LRI2k / LRIS2k)....................................................................130
8.3.17. STMicroelectronics (M24LR64-R) ........................................................................ 131
8.3.18. STMicroelectronics (ST25DVxxK-IE/JF)............................................................... 132
8.3.19. Texas Instruments (Tag-it HFI Pro / Standard)..................................................... 134
8.3.20. Texas Instruments (Tag-it HFI Plus)..................................................................... 136
9. Protocols for Notification Mode 138
9.1. The Notification Mode Procedure................................................................................. 138
9.1.1. DATA Structure in Notification Mode........................................................................139
9.2. [0x31] Read Data Buffer Info......................................................................................... 139
9.3. [0x32] Clear Data Buffer................................................................................................ 140
9.4. [0x33] Initialize Buffer.................................................................................................... 140
ANNEX 141
ANNEX A: Codes of Transponder Types............................................................................ 141
ANNEX B: Codes of Identifier Data Types (IDDT) .............................................................. 141
ANNEX C: Time Behavior of the Asynchronous Interface................................................. 141
ANNEX D: Time Behavior of ISO15693 Host Commands .................................................. 142
Time Behavior for [0x01] Inventory and ISO15693 Transponders......................................142
ANNEX E: Index of Status Bytes........................................................................................ 144
ANNEX F: Transponder Error Codes .................................................................................. 147
ANNEX G: Codes of Reader Types ..................................................................................... 148
ANNEX H: Examples for Read Data ................................................................................... 149
ISO15693 Host Command (DB-Size of the Transponder = 4 bytes)................................... 149
ISO15693 Host Command (DB-Size of the Transponder = 8 bytes)................................... 149
ANNEX I: Labeling of configuration parameter.................................................................. 150

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 8 of 153
H01113-4e-ID-B.docx
1.
Safety Instructions / Warning - Read before start-up !
The device may only be used for the intended purpose designed by for the manufacturer.
The operation manual should be conveniently kept available at all times for each user.
Unauthorized changes and the use of spare parts and additional devices which have not been
sold or recommended by the manufacturer may cause fire, electric shocks or injuries. Such
unauthorized measures shall exclude any liability by the manufacturer.
The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid
for the device. The manufacturer shall not be held legally responsible for inaccuracies, errors,
or omissions in the manual or automatically set parameters for a device or for an incorrect
application of a device.
Repairs may only be executed by the manufacturer.
Installation, operation, and maintenance procedures should only be carried out by qualified
personnel.
Use of the device and its installation must be in accordance with national legal requirements
and local electrical codes .
When working on devices the valid safety regulations must be observed.
Special advice for carriers of cardiac pacemakers:
Although this device doesn't exceed the valid limits for electromagnetic fields you should keep
a minimum distance of 25 cm between the device and your cardiac pacemaker and not stay in
an immediate proximity of the device respective the antenna for some time.

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 9 of 153
H01113-4e-ID-B.docx
Revision History of documentation
Revi-
sion
Date
Page
Description
0e
12.04.11
Initial version
1e
04.06.12
32
CFG03: Tag detect, blue LED for ID ISC.ANTS370/270-A
14.11.12
several
Support of ISO18000-3m3 implemented
40
Read Complete Bank added in CFG11
2e
15.04.15
57
CFG33/34: TCP/IP Hostname implemented
60
CFG41: Additional parameter for LAN settings
127
NXP SLIX 2 integrated
3e
05.09.17
40; 139
CFG11: Notification Mode with MAC output configurable
4e
16.02.18
70
Get Reader Info, new Hardware Version
132
ST25 Transponder implemented
06.07.18
25
CFG1: HID Delay
06.07.18
51
CFG20: RF-ON Holdtime
06.07.18
76
Reader Diagnostic Mode 0x01: Temperature
06.07.18
101
Extended Get System Information
06.07.18
105
Extended Get Multiple Block Security Status

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 10 of 153
H01113-4e-ID-B.docx
Abbreviations
ADR
Address
ASK
Amplitude Shift Keying
CB
Config Block
CFG
Configuration Parameter Block
CRC
Cyclic Redundancy Check
DB
data block
DIP
Dual Inline Plastic
FIFO
First in First out
frq
Frequency
FSK
Frequency Shift Keying
h
Hour
Hz
Hertz
ID
Identification
IN
Input
LEN
Length
LOC
Location
LSB
Least Significant Byte
min
Minutes
ms
Milliseconds
MSB
Most Significant Byte
N
Number
OUT
Output
R/W
Read / Write Access
RD
Read
REL
Relay
RF
Radio Frequency
RSSI
Received Signal Strength Indicator
RTC
Real Time Clock
TAB
Table
TR
Transponder
TS
Timeslot
UID
Unique Identifier (read only Serial Number)
WO
Write Only Access
WR
Write

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 11 of 153
H01113-4e-ID-B.docx
2.
Data Transmission between OBID i-scan®ID ISC.MR102 and Host
Different ways of data transmission between OBID i-scan®Readers and host (terminal, PC) are
possible. The ISO15693Host Commands are used for the data exchange between Transponder
and host, whereas the Configuration Commands and the Control serves for adapting the Read-
er parameters to the individual range of applications. The following chart shows which method of
data transmission is supported by which interface:
interface
asynchronous
(RS232 / RS485)
USB
LAN
Configuration and control commands



ISO Host Commands



Scan-Mode

(HID)
-
Notification Mode
-
-

2.1.
Configuration Commands and Control Commands
This method of data transmission is used for Reader configuration and the diagnosis via the asyn-
chronous interface or Ethernet Interface
The Reader-configuration parameters will be stored in the Reader memory. To store the current
configuration during a power down of the Reader the Reader-Configuration has to be stored in the
EEPROM. After power up the Reader reads the configuration out of the EEPROM.
The Reader control is immediately processed and the response from the Reader contains status or
data information of the control command.
Host (Terminal / PC / ....)
Reader
parameter- / control command

parameter received and stored / control
command processed
yes
no

status /
data
error status


Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 12 of 153
H01113-4e-ID-B.docx
2.2.
ISO15693 Host Commands
The ISO Host Commands provide the exchange of data between a host and Transponders via the
Reader as long as the Transponder remains in the detection range of the Reader.
Note:
During the writing of data on a Transponder, it must be ensured that the Transponder is
located within the detection range of the Reader during the entire process. If the Tran-
sponder is removed from detection range of the Reader during a writing process, this will
cause a loss of data.
The Reader distinguishes between three different modes:
Addressed mode:
Before reading or writing data in addressed mode, the UID of the Transponder has to be
known. This is executed by sending the protocol “7.1.1. [0x01] Inventory If a Transponder
is located within the detection range of the Reader at that time, it answers with its UID. For
all following read- / write orders the Transponder must be addressed with its correct UID.
The following chart will show the necessary steps for the communication with a Tran-
sponder in addressed mode:
Host (Terminal / PC / ....)
Reader
Inventory
to get the UID

Transponder in antenna field ?
Yes
No

status /
number of Tran-
sponders / UID
status =
no Transponder

read data from Transponder with UID

Transponder with
correct UID in antenna field ?
Yes
No

status /
Transponder read
data
status =
no Transponder
in Reader field

write data to Transponder with UID

Transponder with
correct UID in antenna field ?
Yes
No

OK status
status =
no Transponder
in Reader field


Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 13 of 153
H01113-4e-ID-B.docx
Non-addressed mode:
In non-addressed mode, it is not necessary to know the UID of the Transponder. This
mode is useful-, if only one Transponder is located within the range of the Reader.
The following chart will show the necessary steps for the communication with a Tran-
sponder in non-addressed mode:
Host (Terminal / PC / ....)
Reader
read data

Transponder in antenna field ?
Yes
No

status /
Transponder read
data
status = no Tran-
sponder
in Reader field

write data

Transponder in antenna field ?
Yes
No

OK status
status = no Tran-
sponder
in Reader field


Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 14 of 153
H01113-4e-ID-B.docx
Selected:
In this mode the Reader communicates only with the one, selected Transponder.
Before reading or writing data in selected mode, the UID of the Transponder has to be
known. This is executed by sending at first the protocol “7.1.1. [0x01] Inventory“. In a se-
cond step the Transponder must be selected with the select command (see: 7.1.6. [0x25]
Select) which must include its UID.
The following chart will show the necessary steps for the communication with a Tran-
sponder in selected mode:
Host (Terminal / PC / ....)
Reader
Inventory
to get the UID

Transponder in antenna field ?
Yes
No

status /
number of Tran-
sponders / UID
status =
no Transponder

select Transponder with UID

Transponder with the
correct UID in antenna field ?
Yes
No

status /
Transponder read
data
status =
no Transponder
in Reader field

read data

selected Transponder in antenna field ?
Yes
No

status /
Transponder read
data
status =
no Transponder
in Reader field

write data

selected Transponder in antenna field ?
Yes
No

OK status
status =
no Transponder
in Reader field


Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 15 of 153
H01113-4e-ID-B.docx
protocol block
protocol cycle
ts+ tr
2.3.
Scan Mode
In this operation-mode the Reader autonomously sends out data to the host as soon as a Tran-
sponder is within the detection range and valid data could be read.
In Scan Mode the contents of the message block (UID, data block) can be adapted to each user-
application. Scan mode is available via the asynchronous Interface and the USB Interface.
If an USB-Reader is used in scan mode, the reader sends its data automatically over the HID inter-
face of the operating system. In this case, you cannot catch the data with the FEUSB.DLL or any
other libraries. The reader works like a USB keyboard.
The Reader starts the output of the protocol block as soon as all required data have been read
correctly from the Transponder. If the number of transmitted user data is too large, only the maxi-
mal number of transmitted data will be sent plus the end character.
Scan-Mode via asynchronous interface:
The data will be sent out depending on their configuration according to the following
scheme, the sequence of which cannot be changed.
Depending to the configuration and the number of Transponders in the detection range of
the Reader the transmitted protocols have a different format.
Example 1:
One Transponder in detection range and UID and data block should be read:
PR
SC
UID
SC
data
EC
PR
SC
UID
Example 2:
3 Transponder in detection range only UID should be read:
PR
SC
UID1
EC
UID2
EC
UID3
EC
Example 3:
3 Transponder in detection range only data block should be read:
PR
SC
data1
EC
data2
EC
data3
EC
Example 4:
2 Transponder in detection range UID and data block should be read:
PR
SC
UID1
SC
data1
EC
UID2
SC
data2
EC
PR:
Com-Prefix (optional)
ts:
SCAN-LOCK-TIME
UID:
Serial-Number. (fix)
tr:
time to the next new Transponder reading
data:
data blocks (free programmable)
SC
Separation character (optional)
EC
End character (optional)

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 16 of 153
H01113-4e-ID-B.docx
Example 5:
COM-
ADR
Separation
Character
Header
UID
Separation
Character
Data-
Blocks
END Character
COM-
ADR
SEP-CHAR
USR1
USR2
USR3
USR4
UID
SEP-CHAR
DB
USR
1
USR
2
USR
3
Scan-Mode via USB-Interface (HID-Mode):
If an USB-Reader is set to Scan-Mode the reader works like a keyboard. The data will be trans-
ferred as USB Key Code.
Different USB Key Code tables can be loaded into the reader using the demo program ISOStart.
USB Key codes for German and English are available. Other languages can be created by the
user and with the help of ISOStart.
If the number of transmitted user data is too large, only the maximal number of transmitted data will
be sent plus the end character.
Note:
If configuration protocols shall be sent to the Reader while the Scan-Mode is active,
no Transponder should be within the detection range of the Reader during this time.
Only read operations are available with the Scan Mode or Notification Mode.

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 17 of 153
H01113-4e-ID-B.docx
3.
Interface
The Reader ID ISC.MR102 is available with 4 different interface ports (RS232; RS485; USB; LAN).
The protocol frame of this ports can be different. On the asynchronous serial interface the whole
protocol frame is described in 3.2. Serial Data Format and Protocol Frames. The TCP/IP protocol
frame is described below.
3.1.
Protocol Frames of TCP/IP protocol
If the Reader use the Ethernet Interface the data is packaged in a TCP/IP protocol frame. This
means the whole data format and protocol frame which is described in 3.2. Serial Data Format and
Protocol Frames is packaged as the data of a TCP/IP protocol frame. By using the FETCP.DLL
you can easily extract or package the application data you receive from or you sent to the Reader.
If you use the TCP/IP protocol please be aware that the data packaged in the TCP/IP frame is
transferred with Protocol frame: Advanced Protocol-Length as describe below.

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 18 of 153
H01113-4e-ID-B.docx
3.2.
Serial Data Format and Protocol Frames
The Reader ID ISC.MR102 can be configured by different interfaces and data may be written on
Transponders or read from Transponders. The communication between Reader and connected
host (terminal, PC, etc.) is executed by means of fixed protocols. The used protocol is intended for
data bus use and is equipped with a bus address.
During data transfer via the asynchronous interface the Reader supplies the required data or a
status byte. The reply contains the transmitted control byte.
There is no reply from the Reader if there is a protocol frame failure.
Protocol frame: Advanced Protocol-Length
Reader Host
1
2
3
4
5
(6...n-2)
STX
(0x02)
MSB
ALENGTH
LSB
ALENGTH
COM-ADR
CONTROL-
BYTE
(DATA)

n-1
n

LSB
CRC16
MSB
CRC16
Host Reader
1
2
3
4
5
6
(7...n-2)
STX
(0x02)
MSB
ALENGTH
LSB
ALENGTH
COM-ADR
CONTROL-
BYTE
STATUS
(DATA)

n-1
n

LSB
CRC16
MSB
CRC16
STX: If the responded protocol of the Reader starts with the STX sign (0x02) the proto-
col frame is Advanced Protocol-Length. Then the protocol length is defined by the
2 Byte Parameter ALENGTH.
ALENGTH (n = 8...65535):
Number of protocol bytes including STX, ALENGTH and CRC16
LENGTH (n = 6...255): Standard Protocol-Length (up to 255 Byte)
Number of protocol bytes including LENGTH and CRC16.

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 19 of 153
H01113-4e-ID-B.docx
COM-ADR:
0..254 address of device in bus mode
Note:
The Reader can be addressed via COM-ADR 255 at any time!
CONTROL-BYTE:
Defines the Command which the Reader should operate.
STATUS
1
:
Includes the status message or protocol data from or to the Reader.
DATA: Is a optional data field with variable length. The number of DATA byte depend on
the command. The data will be sent always as MSB first if the Reader is in the
ISO-Host Command Mode.
CRC16: Cyclic redundancy check of the protocol bytes from 1 to n-2, as specified by
CCITT-CRC16
Polynom: x16 + x12 + x5+ 1 (0x8408)
Start Value: 0xFFFF
Direction: Backward
1
see ANNEX E: Index of Status Bytes

Identification
Manual
ID ISC.MR102
FEIG ELECTRONIC GmbH
Page 20 of 153
H01113-4e-ID-B.docx
Data format:
Start bits:
1
Data bits:
8
Stop bits:
1
Parity:
even (default)
odd
none
3.3.
CRC16 Calculation Algorithm
Polynom: x16 + x12 + x5+ 1 CRC_POLYNOM = 0x8408;
Start Value: 0xFFFF CRC_PRESET = 0xFFFF;
C-Example:
unsigned int crc = CRC_PRESET;
for (i = 0; i < cnt; i++) /* cnt = number of protocol bytes without CRC */
{
crc ^= DATA[i];
for (j = 0; j < 8; j++)
{
if (crc & 0x0001)
crc = (crc >> 1) ^ CRC_POLYNOM;
else
crc = (crc >> 1);
}
}
