Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 1/40

ASW 10-6, 10-10, 14-14

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 2/40

1. Models described

2. Technical data

3. Provisions

4. Tools required

5. Lubricants and auxiliary substances required

6. Disassembly

7. Assembly

8. Connection diagram

Contents

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 3/40

These instructions describe how to repair the following models:

Model Order no.

ASW 10-6 711240

ASW 10-6-2ST 711241

ASW 10-10 711242

ASW 10-10-2ST 711243

ASW 10-10-250 711244

ASW 14-14 711245

1. Models described

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 4/40

2. Technical data

Technical data

The complete technical data can be found in the operating instructions for the model.

Test data

Up-to-date test data for all models can be found on the FEIN Extranet.

Lubricants

Lubricants and container sizes available from FEIN can be found on the FEIN Extranet.

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 5/40

3. Provisions

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained

electrician, as improper repair can result in serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

Only use original FEIN spare parts!

The relevant accident prevention regulations of the employers’ liability insurance associations are

to be observed when commissioning.

The German Equipment and Product SafetyAct applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed!

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 6/40

4. Tools required

Standard tools

Torx 10 and 15 screwdrivers

Small slotted screwdriver

Cable hooks

Circlip pliers

Circlip pliers (ground)

Open-ended spanner 26 mm

Flat-nose pliers

Feeler gauge

Special tools

Torque wrench (supplied)

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 7/40

5. Lubricants and auxiliary substances required

Lubricants

Grease 0 40 123 01000 3.5 g

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 8/40

6. Disassembly

1. Undo the retainer nut.

2. Remove angled head and take out drive.

3. Prise off the coloured ring.

Tools:

-Open-ended spanner 26 mm

- Slotted screwdriver

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 9/40

6. Disassembly

1. Loosen screws and take off upper housing section.

Tool:

-Torx 15 screwdriver

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 10/40

1. Carefully remove the electronic strip.

2. Use a screwdriver to lift up the clutch slightly.

NOTE

The small spring can easily fall out when the slide switch is dismantled.

3. Remove the slide switch.

4. Remove the spring.

6. Disassembly

Tools:

-Slotted screwdriver

-Flat-nose pliers

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 11/40

1. Remove the clutch.

2. Detach the straight pins from the flange.

6. Disassembly

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 12/40

1. Tension the spring fully to allow better access to the circlip.

2. Remove circlip.

NOTE

You need modified circlip pliers to dismantle the circlip.

The upper side of the pliers must be ground flat.

6. Disassembly

Tools:

- Torque wrench

(supplied)

-Circlip pliers

(ground)

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 13/40

NOTE

The compensating discs in front of and behind the ball bearings must be replaced in

the same position on assembly. The discs are used to adjust the play between the

slide switch and the switch ring on the clutch.

1. Remove the flange and take the disc(s) out of the flange.

2. Remove circlip.

NOTE

Always use a new circlip for reassembly.

3. Remove the ball bearings.

4. Remove discs.

5. Remove circlip.

6. Disassembly

Tool:

- Circlip pliers

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 14/40

1. Release all the tension on the spring so that the adjusting ring can be unscrewed.

2. Unscrew the adjusting ring (left-handed thread).

3. Remove the ring and the spring.

6. Disassembly

Tool:

-Torque wrench

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 15/40

1. Remove the large balls (9) from the inner clutch ring.

2. Shake the small balls (9) out of the hole in the outer clutch ring.

3. Remove both clutch rings.

NOTE

Degreasing the clutch before disassembly makes it easier to remove the balls.

6. Disassembly

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 16/40

6. Disassembly

Tool:

-Flat-nose pliers

1. Remove both switch pushbuttons.

2. Remove the leaf spring.

3. Remove the rocker switch.

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 17/40

6. Disassembly

1. Carefully remove the ribbon cable from the plug on the motor circuit board.

2. Remove the electronics circuit board.

3. Carefully pull the ribbon cable from the electronics circuit board.

4. Detach the connecting bridge from the ribbon cable.

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 18/40

6. Disassembly

Tool:

-Flat-nose pliers

1. Holding the electronic strip by the reinforcement, gently pull it out of the plug.

2. Unclip the LED with the electronic strip from the holder.

NOTE

If the electronic strip is defective, the replacement strip must be kinked slightly at the same

place. The kink is located between the two notches on the electronic strip.

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 19/40

6. Disassembly

1. Remove the motor/gearbox unit from the lower section of housing.

2. Remove the bush from the gearbox.

3. Pull the the gearbox from the flange.

Repair instructions

FEIN retains all rights of disposal, such as copying and circulation. C-SC_CSSM 2012.07 20/40

6. Disassembly

Tool:

-Torx 10 screwdriver

1. Remove the disc from the gearbox.

2. Unscrew the flange.
