SERVICE
Tool service and maintenance must be performed only by qualified
repair personnel.
When servicing a tool, only use identical replacement parts available
from FEIN.
Repairs on FEIN Power Tools required the use of special tools (pulling devices
and bearing press). Authorized repair centers have trained repair technicians
andequipmentnecessarytoper-formtheserepairs.Serviceorrepairsperformed
by unqualified persons could result in operator injury.
For the location of the repair center near you, please call 1-800-441-9878.
Monday thru Friday, 9AM to 5PM EST. Or, look on our web site at
www.feinus.com and follow the link to “AuthorizedWarranty Repair Centers”
Phone: [phone] Fax: [phone] Toll Free: 1-800-441-9878
FEIN Power Tools
1030 Alcon Street
Pittsburgh, PA 15220
November 3, 2006
SCT 5-40
Drywall Screwdriver

FEIN Power Tools
SCT5-40 Parts List
Item Item Number Description Reqd
10 3-19-01-138-01-1 MOTOR HOUSING 1
20 3-07-01-234-00-2 SWITCH 1
21 4-30-13-052-03-3 SCREW 2
40 3-07-01-249-00-4 SWITCH REPAIR SET 1
60 3-07-12-089-02-3 BRUSH HOLDER 2
65 3-07-11-134-00-5 CARBON BRUSH 2
80 4-30-70-018-00-9 SCREW 2
90 5-1-274-004-11-7 FIELD WITH WINDING 1
100 4-30-70-014-00-0 SCREW 2
110 3-14-28-149-00-8 AIR CONDUCTING RING 1
120 3-24-31-041-00-5 CLAMPING PIECE 1
130 4-30-70-006-00-8 SCREW 1
160 3-07-19-565-01-6 CONNECTION CABLE 1
170 3-07-19-566-01-9 CONNECTION CABLE 1
180 3-07-19-630-01-4 CONNECTION CABLE 1
190 3-12-01-123-00-3 HANDLE LOWER PART 1
200 3-12-01-124-00-1 HANDLE UPPER PART 1
210 3-28-05-191-00-2 SWITCH LEVER 1
220 4-30-66-009-03-8 SCREW 1
240 4-30-16-003-00-9 SCREW 2
250 4-30-70-007-00-2 SCREW 1
270 3-07-06-327-01-7 CABLE ASSEMBLY 1
280 3-14-13-224-00-9 PROTECTIVE SLEEVE 1
301 5-3-274-004-11-9 ARMATURE 1
310 3-26-12-063-00-5 PACKING RING 1
340 4-17-01-001-17-2 BALL BEARING 2
355 3-15-06-367-01-4 INTERM HOUSING 1
360 3-15-08-251-00-2 FRONT HOUSING 1
370 4-17-19-026-00-7 AXIAL DISC 1
380 4-17-15-029-00-9 NEEDLE BEARING 1
390 3-24-08-395-00-0 DISC 1
400 3-36-57-161-00-7 SPUR WHEEL ASSEMBLY 1
410 3-26-24-094-03-2 WASHER 2
420 3-09-01-139-00-7 COMPRESSION SPRING 1
440 3-01-04-131-00-9 TOOL HOLDER 1
445 3-01-02-101-01-3 CAM RING 1
450 3-09-06-025-00-8 RETAINING RING 1
460 4-17-08-014-00-1 BALL 1
470 3-16-03-045-00-5 BUSHING 1
480 4-06-12-093-00-4 O RING 1
705 3-05-05-069-01-1 SLEEVE ASSEMBLY 1
710 4-17-08-019-00-4 BALL 2
720 4-06-12-071-00-9 PACKING RING 1
730 3-21-27-057-00-8 DEPTH STOP 1
960 4-30-72-010-00-9 SCREW 3
1000 3-02-40-257-00-1 CLAMPING PIECE 1
1010 6-39-01-011-05-9 HANDBELT 1
1040 3-02-32-046-00-8 BOW 1
