How to check Pro L/XL internal probe cables
10 May 2022
Revision 0
FELIX Pro L and XL
series

How to check Pro L/XL internal probe cables
May 10, 2022
1
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
1Introduction
This manual explains how to disassemble and assemble the printhead for an Pro L/XL to check the internal
probe cables. Only follow this guide if someone from FELIXprinters has told you to
2Tools
The tools you need:
•Allen key 2
•Allen key 2,5
•Allen key 3
•Tweezers (optional)
3Disassemble
Warning: Always turn off the printer and remove the power cable
before working on the printer.
1) Turn of the printer
-Turn off the printer and remove the power cable
from the printer.

How to check Pro L/XL internal probe cables
May 10, 2022
2
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
2) Remove the 2 top bolts
-Remove the 2 bolts using an allen key 2,5. Red circles.
3) Remove the side bolt
-Remove the bolt that holds the 2 printhead assemblies together using an allen key 3.
Red circle.

How to check Pro L/XL internal probe cables
May 10, 2022
3
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
4) Take off the printhead
-Carefully take off the left printhead. Watch out because the head is connected to the PCB
with cables.
5) Remove the servo
-Remove the buttonhead bold that holds the servo. Use an allen key 2 or 2,5. Red circle.

How to check Pro L/XL internal probe cables
May 10, 2022
4
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
6) Check probe cable connections
-Check the probe cable connection behind the servo. Tighten them and make sure the 2
ayes don’t touch each other, and touch the magnets properly. Keep in mind that they are
from plastic. Red circle.
7) Place back the servo
-Place back the servo. Make sure the orientation of the servo is the same as shown below
and the pusher pin is in the pocket. Also make sure to move the servo in the direction of
the red arrows when tightening the bolt. Red circle.

How to check Pro L/XL internal probe cables
May 10, 2022
5
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
8) Check tight printhead probe connections
-Check the probe cable connection from the right extruder. Tighten them and make sure
the 2 ayes don’t touch each other, and touch the magnets properly. Keep in mind that
they are from plastic. Red circle.

How to check Pro L/XL internal probe cables
May 10, 2022
6
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
4Assemble printhead
1) Place back the printhead
When slicing the printhead on the bracket make sure no cables get stuck. Red circle.
2) Place the right printhead
Start with sliding the left printhead on the bracket. Keep in mind when you slide the right
printhead on the bracked to get the servo pusher pin in the pocket. Red circle.

How to check Pro L/XL internal probe cables
May 10, 2022
7
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
3) Screw the side bolt
-Tighten the bolt that holds the 2 printhead assemblies together using an allen key 3.
Red circle.
4) Place the 2 top bolts
-Place and tighten the 2 bolts using an allen key 2,5. Red circles.

How to check Pro L/XL internal probe cables
May 10, 2022
8
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
5Printer check
1) Temperatures
Info: reinstall the ribbon cables into the connector if it doesn’t!
-Check if the printer can read the hotend temperatures.
2) Probe check
-Press “Advanced”.

How to check Pro L/XL internal probe cables
May 10, 2022
9
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
-Press “Console”.
-Press “Send G-code”.

How to check Pro L/XL internal probe cables
May 10, 2022
10
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
-Type in “M119”and send it to the printer.
-Look in the console. If the “Z-probe state”is “L”(Low) you can proceed in the manual and
try to home. If the state is “H”(High) contact Suppor[email protected]om.

How to check Pro L/XL internal probe cables
May 10, 2022
11
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
3) Homing
-Press “move”.
Hit “home all”.
If it doesn’t home correctly. Turn off the printer and contact [email protected]om.

How to check Pro L/XL internal probe cables
May 10, 2022
12
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
6Levelling
Info: Do all calibrations before staring a Dual head print!
1) Build plate leveling
-Press “printer calibration”.
-Press “bed leveling”.

How to check Pro L/XL internal probe cables
May 10, 2022
13
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
-Hit “yes” to start the bed leveling.
-The bed leveling is done when you see this message. Hit “ok”.

How to check Pro L/XL internal probe cables
May 10, 2022
14
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
2) Z-calibration
-Press “printer calibration”.
-Press “Calibrate Z”.

How to check Pro L/XL internal probe cables
May 10, 2022
15
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
-Press “Yes”.
-Press “Ok”.

How to check Pro L/XL internal probe cables
May 10, 2022
16
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
3) XY-calibration
-Press “printer calibration”.
-Press “Calibrate XY”.

How to check Pro L/XL internal probe cables
May 10, 2022
17
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
-Load in PLA in both hotends and hit “Yes”.
-Make sure line 5 matches both nozzles for the X and Y. Does it not? then enter the number
where the lines do match and start the calibration again.
You are now be able to use the FELIX Pro L or XL again.

How to check Pro L/XL internal probe cables
May 10, 2022
18
FELIX Pro L XL
www.FELIXprinters.com
Pro L XL series
If you are unable to continue or have any questions, you can check at the support section of our website or
you can contact us directly:
Website: www.felixprinters.com/support
Email: [e-mail]
Telephone: [phone]
Address: Zeemanlaan 15, 3401MV IJsselstein, The Netherlands
Kind regards,
FELIXprinters
