felton industries FELEPG5T9 User manual

DESCRIPTION Qty
FELEPG5T6_BASE FRAME 7
FELEPG5T9_GROUND CHANNEL L8000 3
FELEPG5T9_GROUND CHANNEL L1300 3
FELEPG5T6_PLANK L3400 4
FELEPG5T6_PLANK L4575 22
FELEPG5T6_SKIRTING BOARD L3000 18
FELEPG5T6_SKIRTING BOARD L1510 6
FELEPG5T6_STAIR PLANK L1432 4
AS-NZS 2465 Bolt - 1/4" x 1" 348
AS-NZS NYLON Nut - 1/4" 348
AS-NZS 2465 Bolt - 1/2" x 7.5" 3
AS-NZS 2465 Bolt - 1/2" x 3.5" 45
AS-FLAT WASHER - 1/2" 128
AS-NZS NYLON Nut - 1/2" 64
AS-Screw-ST4.5x25 132
AS 1112 Bolt - 3/8" x 3" 16
AS 1112 Nut - 3/8" 16
Page 1 of 2
5
6
7
8
9
10
13
14
16
17
15
11
12
ITEM
1
2
3
4
9mtr ELITE PORTABLE GRANDSTAND
[Code No: FELEPG5T9]
2
WARNING: This assembly required two or more people as lifting is involved. Please ensure bolts and nuts are only finger-tightened throughout assembly for flexibility in lining
up components. Bolt and nuts should be securely tightened in place when instructed to do so. Please check all components are included before proceeding with the assembly
ASSEMBLY INSTRUCTION
Thank You
FOR CHOOSING FELTON INDUSTRIES
1800 22 00 55
[email protected]
www.felton.net.au
1800 05 91 58
Felton Industries Pty Ltd | ABN: 17 130 687 240
1
3
4
Attach three long ground channels and three short ground channels together by using bolts
, washers and nuts . Then attach seven base frames onto ground channels &
by using bolts , washers and nuts as illustrated.
Attach four stair planks onto base frames by using bolts and nuts as illustrated.
Attach four short planks and twenty-two long planks onto seven base frames by using
bolts and nuts as illustrated. Note that all planks should be attached from top to bottom.
Fasten eighteen long skirting boards and six short skirting boards firmly onto virtical tubes on
all base frames by using self-tapping screws . Ensure that boards & are fastened from
joining points as inllusrated towards outer ends to avoid length shortage.
4
"This product has been
manufactured in Australia to the
highest quality standard,
guaranteeing proven quality,
durability and low maintenance"
5
6
7
5
11
12

DESCRIPTION Qty
FELEPG5T6_MAIN UPRIGHT BAR 4
FELEPG5T6_AL TUBE 25x25xL3210 6
FELEPG5T6_BACK RAILING 3
FELEPG5T6_ LEFT SIDE RAILING 1
FELEPG5T6_RIGHT SIDE RAILING 1
AS-NZS 2465 Bolt - 1/2" x 4.5" 8
AS-NZS 2465 Bolt - 1/2" x 5.5" 4
AS-NZS 2465 Bolt - 1/2" x 6.5" 4
Page 2 of 2
24
25
20
21
22
23
ITEM
18
19
9mtr ELITE PORTABLE GRANDSTAND
[Code No: FELEPG5T9]
6
WARNING: This assembly required two or more people as lifting is involved. Please ensure bolts and nuts are only finger-tightened throughout assembly for flexibility in lining
up components. Bolt and nuts should be securely tightened in place when instructed to do so. Please check all components are included before proceeding with the assembly
ASSEMBLY INSTRUCTION
Thank You
FOR CHOOSING FELTON INDUSTRIES
1800 22 00 55
[email protected] www.felton.net.au
1800 05 91 58
Felton Industries Pty Ltd | ABN: 17 130 687 240
5
7
8
Attach four upright bars to the back of base frames by using bolts , washers and
nuts as illustrated. Ensure all fasteners are attached at the right positions on upright bars.
Attach six tubes 25x25 onto base frames and upright bars to support the assembly structure
by using bolts , bolts , washers and nuts as illustrated.
24
25
Attach three back railings , left side railing , and right side railing to base frames by using
bolts , washers and nuts as illustrated.
Tighten completely all bolts and nuts with spanners and appropriate tools.
The grandstand is now ready to be used.
"This product has been
manufactured in Australia to the
highest quality standard,
guaranteeing proven quality,
durability and low maintenance"
