felton industries FELIGB3 Installation guide

WARNING: READ THE ASSEMBLING INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING THE IN-GROUND BENCH SEAT WITH BACK REST.
Make sure to wear protecve gloves and foot protecon when installing and assembling this product. Unpack the unit and make sure all the components are
included before proceeding. This acvity requires two o more people as liing is involved. Please ensure bolts are only nger-ghtened during the assembling
process for exibility in lining up components. Securely ghten the bolts before anchoring the product to the ground.
3m- IN GROUND BENCH SEAT WITH BACK REST
(CODE No. FELIGB3)
ITEM PART DESCRIPTION QTY
IGBR1 SEAT FRAME 3
IGBR2 3000 mm.—SEAT ALUMINIUM PLANK 1
IGBR3 3000 mm.—ALUMINIUM BACK REST 1
IGBR4 M6x25mm. HEXAGONAL HEAD BOLT 18
IGBR5 M6 LOCKNUT 18
-
-
IGBR1 IGBR2 IGBR5
IGBR4
1
2
A. Place the three seat frames [IGBR1] and aached
them to the seat plank [IGBR2], by using hexagonal
bolts [IGB4] and locknuts [IGB5] — nger ghten.
[IGBR1]
[IGBR1]
[IGBR4x4]
[IGBR5x4]
A. Aach the back rest plank [IGBR3] to the top of the seat frame plate
(IGBR1), by using hexagonal bolts [IGBR4] and locknuts [IGBR5], as
illustrated - nger ghten.
B. Tight both, the back rest and seat bolts with spans, wrench and /or a
proper tool.
IGBR3
[IGBR2]
[IGBR4x2]
[IGBR5x2]
[IGBR3]
[IGBR1]
P1
Hex bolt Lock nut
Back rest
ASSEMBLED BACK REST
[IGBR1]

WARNING: READ THE ASSEMBLING INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING THE IN GROUND BENCH SEAT WITH BACK REST.
Make sure to wear protecve gloves and foot protecon when installing and assembling this product. Unpack the unit and make sure all the components are
included before proceeding with the assembling. This acvity requires two o more people as liing is involved. Please ensure bolts are only nger-ghten during
the assembling process for exibility in lining up components. Securely ght the bolts before anchoring the product to the ground.
3
GENERAL INSTALLATION RECOMMENDATIONS:
A. Turn the enre assembly upright and mark the locaon of the leg supports, according to the illustraon above.
B. Prepare the leg foundaon as necessary. Install seat legs accordingly.
C. We recommend to place at minimum 300 mm. of the seat legs in concrete.
P2
