TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
INSTALLATION GUIDE
TATE
Digital Wall Mounted Mixer

2
FELTON

3
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
Control Unit Installation 8
Measurements 7
Tools Required 4
Notice 4
Scope of Application 7
Digital Mixer Installation 12
Operational Test 19
CONTENTS
Troubleshooting 20
Warranty 21
Wall Mounted Spout Installation 18

4
FELTON
WATER PATH
Input   2 × M10×1
Output 1/2˝BSP
Flow   max.22l/minat300kPa
Pressurerange  Min150kPa-Max500kPa
Dierenceofpressure Max.100kPa/14.5psi
Maximumoutlettemperature 45°C
Hotinlettemprange 55°C-80°C
Coldinlettemprange 5°C-25°C
ELECTRONICS
Powersupply  100V-240VAC/50-60Hz
Powerconsumption Standby<0.5 W,max.18W
PLEASE READ THE MANUAL CAREFULLY BEFORE STARTING THE INSTALLATION. AFTER COMMISSIONING AND TESTING THE
SYSTEMS FUNCTIONALITY, THIS DOCUMENT MUST BE GIVEN TO THE END USER OF THE SYSTEM.
PRODUCT TO BE DISCONNECTED BEFORE LINE TEST
In case of a power cut, the unit will remain inactive until the power is back on.
GENERAL
This installation manual contains instructions for the correct installation of the Tate Digital Controller. The warranty will be invalidated
if the product is not installed according to these instructions.
Installationmustbecarriedoutbyqualiedinstallersinaccordancetothisinstallationmanual.AS/NZS3500standards,rulesandsafety
regulations do apply.
PLACE OF INSTALLATION
The Tate Digital Controller must be installed in an accessible place and in accordance to this installation manual. This ensures a
problem-freeserviceandmaintenanceprocedure.
NOTICE
TOOLS REQUIRED
7. Drill
4. Torx screwdriver
(included in box 1)
3.Phillipsscrewdriver
2.Drillbitø 5mm
1.Pencil
5.ø 30-32mmholesaw
8. Spirit level6.Utilityknife
DANGER OF ELECTRIC SHOCK!
ELECTRICAL INSTALLATION
Beforeopeningthehousing,themainsconnectionmustbeswitchedo.Workonelectricalpartsandconnectionsmustbe
carriedoutbyqualiedelectrician.Country-specicstandardsandregulationsdoapply.
PRECAUTIONS
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a
hazard.
4. This appliance contains battery that are only replaceable by skilled persons.
5. An electronic copy of the installation and user guides are available on the Felton website – please visit www.felton.co.nz
MAINTENANCE
Felton products are made of high quality materials and require only minimal maintenance. The following maintenance tips help to preserve
the surface and prevent damage through incorrect cleaning. Fittings and control parts should be wiped dry after used. Only use mild cleaning
productsthatcontainsoap.Thefollowingmustnotbeused:Scourers,abrasivesponges,hydrochloricacid,lime,plasterorcementremovers,
solutionsorcleaningagentscontainingacid(pH ≤ 4),limescaleremoverorvinegar-basedcleaner–andcleaningagentswherethechemical
solutionisnotknownwhichmaybesoldasspecialcleanerforttings.

5
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
BOX 2
CONTROL UNIT
1. Control Mounting Tube
4. Cable Tie
5.ControlSleeve
8. Foam Seal
6.ControlWheel
7. Control Housing
2. Screw 3. Control Data Cable 10m
BOX 3
WALL MOUNTED SPOUT
1 x Key
1 x Flow Straightener
0-ringSeal
SpoutBase
Grub Screw x2
Sleeve
Spout
Aerator/Flow Regulator
3 x Aerators/Flow Regulators
(1xisprettedtothespout)
BOX 1
DIGITAL MIXER
1. Temperature Control Unit
3.SetofScrews:2x5x50mm
2.12VACAdapter(Cablelength:1m)
4. Adapter set
5.2xInlethoses(supplied)
Top
View
Side
View
Top
View
Side
View

6
FELTON
Install product as supplied.
IF YOU ARE INSTALLING AS A BASIN / SINK MIXER
IF YOU ARE INSTALLING AS A BATH MIXER
Removeowregulatorfromthespoutandreplacewithaowstraightener(fullow).
FLOW REGULATORS
PinkFlowRegulator4l/min
BlueFlowRegulator6l/min
WhiteFlowRegulator8l/min(factorytted)
Thereadditionalowregulatorssuppliedin
the box. Once the product is installed and has
beencheckedforleaks,youcantestthe
dierentowregulatorstoseewhichoneis
the best option for your situation.

7
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
SCOPE OF APPLICATION
Under Basin (Recommended)
Wire and Data Cable
must be installed prior
to the wall lining.
It is recommended
that the Data Cable is
installed in conduit for
ease of maintenance.
Warning: Pleaseensurethatallelectrical
installations are installed by a registered
electrician and complies with the Electrical
(Safety) Regulations of NZ.
Important: The Digital Mixer must have an
access panel.
Hot in
Cold in
Spout Outlet Cable length
10m max.
Digital Mixer
Control Unit
Power supply
must be within
1m from the
digital mixer
Control cable
Pipework in
Pipework out
Power supply
Important: The Digital Mixer must
be accessible and should not be
sealed in the wall
78mm
115mm
45mm
MEASUREMENTS

8
FELTON
1
CONTROL UNIT INSTALLATION
2
Fig. 2
Tightening lugs
Cutting slot
75mm
Min.
55mm
Wall
Mounting tube
ø 30-32mm
Pleasenote:TheDataCableis10metresinlengthandthereforetheControlUnitandDigital
Unit need to be positioned accordingly within this distance. It is recommended that the Data
Cable is installed in conduit for ease of maintenance. The Control Tube can be reduced in
length if required by cutting along the cutting slot (see Fig. 2).
PrepareaØ30-32mmhole
inthenishedwall,deckor
counter/vanity.Positionthe
drill/hole saw where the
Control Unit is to be located.
Conduit
Data Cable
CutPosition
Drill
Hole
saw
Data Cable must be
installed prior to the
wall lining.
It is recommended
that the Data Cable is
installed in conduit for
ease of maintenance.
*This Control Unit can also be installed as a Wall Mounted unit or a Deck Mounted unit

9
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
3
4
UsingtheDataCable,threadtheendwiththesmallconnectorthroughtheholeandControl
MountingTube.Thisendofthecableisprotectedwithaplasticsleeve,leavethisonuntillater
in the installation.
Control Mounting Tube
Data Cable
PushtheControlMounting
Tube into the hole until the
frontangesitsagainstthe
wall.
Apply a silicone bead on the
backoftheControlHousing,
then push the Control Housing
intothePlasticTubeuntilitis
rmlyttedontheunit.
Foam Seal
Control Housing
CLICK

10
FELTON
5
Tighten the screw inside the
Control Housing and ensure the
screwisalignedwiththePlastic
Mounting Tube.
This tightens the lugs on the
inside of the wall. Tighten until
there is no rotation of the
Control Housing.
6
7
Pulltheredstriptorelease
the connector from the plastic
sleeve.
Pushthefourpinconnector
into the socket on the back of
the Control Wheel.
Control Wheel
Data Cable

11
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
8
ThreadinthecableandttheControlWheelontotheHousing.
Fit the Control Sleeve onto the Control Wheel.
EnsurethatyouttheControlSleeveinthecorrectorientation.
SIDEVIEW

12
FELTON
10 Inside the Temperature Control Unit
9Remove the cover
DIGITAL MIXER INSTALLATION
Outlet
Hot Cold
Inlets
Fixing holes
Fixing hole
Cover retaining
holes
Transformer12V/wallplug
Control unit

13
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
MOUNTING OPTIONS
MOUNTING FOR NOG
MOUNTING FOR CONCRETE
2Install the Digital Mixer
99 mm
1 Markxingholes
56 mm
2 Drillxingholes
99 mm
56 mm
ø 5 mm
3Install the
Digital Mixer
Ifinstalledvertically,useorientation
shown
*
99 mm
1 Markxingholes
56 mm
If installed
vertically,use
orientation
shown
*

14
FELTON
12
11. ConnectthetwoInlethoseswiththeMFadaptorsandlterstothewatersupplyfeed
Large retaining bolt
A-Connectthebrassadaptorsintotheexihoses.
B-Fitbothexihoses(withthebrassadaptoron)rmlyintotheunitbox.
C-Fitthelargeretainingboltwithatorxscrewdriversupplied.
A
B
C
Hot water supply
Cold water supply
Hot inlet Cold inlet

15
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
DIGITAL MIXER INSTALLATION
AFit the outlet pipe on to the brass connectors
BPushtheoutletttingintotheDigitalMixerandtasmall
retaining bolt with torx screw driver supplied
Outlet pipe
Short retaining bolt
13.

16
FELTON
14.
ConnecttheDataCablecomingfromtheControlUnit.Usethelarge6pinconnectorand
pushrmlyintothesocket.Feedthecablethroughtheoneoftheguideslotsinthefront
of the Digital Mixer.
Data Cable
connection
15.
Connectthepowercablecomingfromthetransformer.Usetheconnectorandpushrmlyinto
the socket. Feed the cable through the guide slot in the front of the Digital Mixer.
Powercable
connection

17
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
16.
Fitthecoverbackontothebase.UsingaPhillipsscrewdriversecurethecoverinposition.
Theunitisnowreadyforcommissioning.PleaseseeUserGuide.
IMPORTANT: Fit cables into slots to allow cover to properly close at end of installation

18
FELTON
WALL MOUNTED SPOUT INSTALLATION
Measure and cut 1/2” BSP thread to the
desired length keeping 20-25mm clearance
from the wall for the spout connection (use
fig 2 as reference).
After applying the appropriate sealer to the
thread, hand tighten the 1/2” BSP thread into
the wingback.
2B.
PARALLEL
1.
WINGBACK
90°
FIG 1.
2A.
FIG 3.
Fit the Spout Base onto the 1/2” BSP thread.
Check the o-ring is in place and thread the flange of the bath spout
onto the 1/2” BSP.
Ensure the base ts tightly and rmly against the wall and seals.
3A.
Fit the spout onto the base, ensuring the sleeve stays on the spout and
secure both grub screws using a 2.5mm allen key (not supplied).
4A. Fit Spout
secure grub screws
4B. Fit the cover sleeve.
Fit Sleeve
5. Connect spout to digital mixer.
Turn on the water supply, operate the mixer and check for leaks.
Fit Spout Base
3B.
20-25MM
Front of wall
FIG. 2
1. Remove the cover sleeve ensuring that it stays on the spout
Loosen the 2x Grub Screws
Remove the spout from the Spout Base
Ensure the wingback when
tted is parallel and square to
the nished wall lining as shown
(fig. 1).
2.

19
TATE DIGITAL WALL MOUNTED MIXER INSTALLATION GUIDE
1Ensure that the Digital Mixer is installed correctly installed according to the instructions above.
Turnonthewatersupplyandchecktheunitandplumbingforleaks.Oncetheplumbingisconrmedto
bewater-tight,connectthepowersupplyandconducttheoperationaltestbelow.
OPERATIONAL TEST
OPERATING THE CONTROL SYSTEM
1 Open
Pushtheinterfaceonce.Theinterfaceturnsonandthe
LED illuminates.
2 Close
Pushtheinterfaceagain.Theinterfaceturnsoandthe
LEDgoeso.

20
FELTON
If issue persists or is not covered in the above, please contact our Felton
Technical Team on 0800 743 358 or [email protected]
TROUBLESHOOTING
ISSUE PROBLEM TROUBLESHOOT
The device does not function
(i.e. the LED light is not on)
The AC adapter is not connected
to the mains Connect device to the mains power
Mains power failure Check household fuse box
The AC adapter is not connected to the Control
Unit Follow Step15 on Installation Guide
The digital mixer is not working Follow Step 14 on Installation Guide
The water temperature does not match
the indicated display
Hot and cold water connections reversed Check connections are correct
Hot or cold water stop valve closed or only half
opened Fully open both stop valves
Kink in supply hose Check connection hoses
Connecting pipe blocked Flushpipesandcleanlter
No hot water Check hot water tank and instantaneous
connections
Temperature sensor defect Carry out function «Diagnostic Test»
in User Guide
Dierenceinsupplypressurebetweenhot
andcoldwaterisgreaterthan100kPa Balancepressuretoeliminatedierence
Constant flow of water Unitwillnotturno Carry out function «Diagnostic Test»
in User Guide
The water shuts o before maximum run
time has been reached Flow sensor is defective Carry out function «Diagnostic Test»
in User Guide
The device is working but has
no water flow
Motors are not calibrated Carry out function «Diagnostic Test»
in User Guide
Stop valves closed Open stop valves fully
No water supply Restore water supply
Kink in supply hose Check connection hoses
Interface flashes green Cleaning mode active Wait45secondsorpressthedigitalmixer
to cancel
The Digital Control Unit is damp or wet Inlet and outlets of the digital mixer are
not properly sealed Inspectallconnections,resealifnecessary
The Control Unit does not respond to
temperature and flow adjustment*
The interface elements
are connected incorrectly Follow Step 14 on Installation Guide
The interface is defective Carry out function «Diagnostic Test»
in User Guide
The knob is not running smoothly Remove and clean knob
*Important: ControllingtheowrateisonlypossiblewiththeSmartowDigitalShowerMixer.
