Bradley Express SS Series User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX [phone]
bradleycorp.com
Installation
215-1575 Rev. J; ECN 17-08-026
© 2018 Bradley
Page 1 of 15 5/15/2018
SS-3N/ndt/STD
SS-3N/ndt/WH
Express®Lavatory System SS-Series
Table of Contents
Pre-Installation Information .................2
Components.............................3
Supplies Required ........................4
Dimensions............................... 4–5
Rough-Ins ...................................6
Installation ...........................7–11
Solenoid Valve Troubleshooting .............12
Navigator®Mixing Valve Troubleshooting ......13
Stop Valve Troubleshooting ................14
Cleaning and Maintenance for Terreon®. . . . . . .14
Soap Dispenser Maintenance ..............15
Express Lavatory Systems are ADA and TAS compliant
U.S. Pat. Nos. 5,611,093, D447,224
Other Patents Pending
SS-3N/ndt/STD/LSD-3
SS-3N/ndt/WH/LSD-3
DISCONTINUED

SS-3N/ndt/STD, SS-3N/ndt/WH Installation
25/15/2018 Bradley • 215-1575 Rev. J; ECN 17-08-026
IMPORTANT!
Read this entire installation manual to ensure proper installation. When finished with the
installation, file this manual with the owner or maintenance department. Compliance and
conformity to local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding
any packaging material. If any parts are missing, do not begin installation until you obtain the
missing parts.
Make sure that all water supply lines have been flushed and then completely turned off
before beginning installation. Debris in supply lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to
installation. Electrical power MUST remain off until unit and optional water heater have
been plumbed. After installation is complete, turn on the water supply first, then turn on the
electrical power.
Hardware supplied by installer must be appropriate for wall construction. Wall anchors must
have a minimum pull-out rating of 1,000 lbs. Follow appropriate dimensions for standard or
juvenile height based on configuration and required rim height. Overtightening fasteners can
damage the Terreon®material. Use caution when tightening bowl and sprayhead fasteners.
Product warranties may be found in the “Products” section on our Web site at www.
bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•
Special Note for Sprayhead/Bowl retrofit
to retrofit new SS-3N sprayhead onto existing SS-3 bowl
1½" (38mm)
Drill hole Ø 1" (25mm)
to 1½" (38mm).
Existing Hole
2¼" (57mm)
DISCONTINUED

Installation SS-3N/ndt/STD, SS-3N/ndt/WH
Bradley • 215-1575 Rev. J; ECN 17-08-026 5/15/2018 3
#8-32 SCREW
(160-319)
STRAINER
(P16-075)
DRAIN PLUG
(P16-072)
1/8" RUBBER WASHER
(125-001DP)
WASTE SHOE
(111-062)
P-TRAP (POLYPROPYLENE)
(269-1697)
OPTIONAL P-TRAP
(CHROME-PLATED BRASS)
(S29-094)
DRAIN ASSEMBLY
WASTE TEE
(111-063)
Components
1/4"-20 x 1/2"
PAN HEAD
SCREW (qty. 4)
(160-389)
1/4"-20
WASHER
(qty. 4)
(142-002DB)
BOWL MOUNTING
HARDWARE
WASHER
142-002BJ
LOCKWASHER
142-002BK
NUT, 5/16-18
161-036
BOLT 5/16-18
160-371
SCREW 10-24
160-386
MAIN FRAME
(S17-323)
SCUFF BASE
(17-324)
(USED WITH STANDARD
HEIGHT FRAME ONLY)
SCUFF PANEL FASTENERS (160-450)
WASHERS (142-002CA)
(4) PLACES
SCUFF BASE PANEL
(185-033) - GRAY
(185-033A) - PUTTY
(185-033B) - COAL
PEDESTAL PANEL
(186-1454) - GRAY
(186-1454A) - PUTTY
(186-1454B) - COAL
PANEL FASTENERS (160-450)
WASHERS (142-002CA)
(8) PLACESS
SPRAYHEAD COVER ndite
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
SPRAYHEAD BODY
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
BOWL
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
DISCONTINUED

SS-3N/ndt/STD, SS-3N/ndt/WH Installation
45/15/2018 Bradley • 215-1575 Rev. J; ECN 17-08-026
Supplies Required:
• (10) ³⁄₈" wall anchors, bolts and 1" min. O.D. washers to mount main frame and bowl to wall (minimum pull-out rating of 1,000 lbs.)
• STD. HEIGHT ONLY: (2) ³⁄₈" wall anchors, bolts and 1" min. O.D. washers to mount scuff base to wall
• ½" nominal copper tubing for hot and cold supplies and 1½" NPT drain piping
Dimensions - Front and Top Views
SOAP
SOAP SOAP
SOAP
Top View
80" (2032mm)
Front View
Standard Frame
Front View
Wall-Hung Frame
85⁄8" (219mm)
30" (762mm)
8" (203mm)
51¼" (1302mm)
58" (1473mm)
64" (1626mm)
68¼" (1734mm)
8" (203mm)
68¼" (1734mm)
58" (1473mm)
64" (1626mm)
8" (203mm) Radius 10" (254mm) Radius
30" (762mm)
DISCONTINUED

Installation SS-3N/ndt/STD, SS-3N/ndt/WH
Bradley • 215-1575 Rev. J; ECN 17-08-026 5/15/2018 5
Dimensions - Side Views
TAS
TAS
Wall Hung Mounted
at Standard Height
Standard
Height
Wall Hung Mounted
at Juvenile Height
Ages: 6 through 12
Wall Hung Mounted
at TAS Height
Grades: 6
through
8 or 9
Wall Hung Mounted
at TAS Height
Grades: Pre-K
through 5 or 6
211⁄8" (537mm)
38½"
(978mm)
34"
(864mm)
30"
(762mm)
13¼"
(311mm)
11½"
(292mm)
Scuff Base on
Standard Height Only
3" (76mm)
85⁄8"
(219mm)
38½"
(978mm)
34"
(864mm)
30"
(762mm)
85⁄8"
(219mm)
211⁄8" (537mm)
11½"
(292mm)
13¼"
(311mm)
85⁄8"
(219mm)
211⁄8" (537mm)
11½"
(292mm)
85⁄8"
(219mm)
211⁄8" (537mm)
11½"
(292mm)
85⁄8"
(219mm)
211⁄8" (537mm)
11½"
(292mm)
36½"
(927mm)
32"
(813mm)
28"
(711mm)
11¼"
(286mm)
35½"
(902mm)
31"
(787mm)
27"
(686mm)
10¼"
(260mm)
34½"
(876mm) 30"
(762mm)
26"
(660mm)
9¼"
(235mm)
DISCONTINUED

SS-3N/ndt/STD, SS-3N/ndt/WH Installation
65/15/2018 Bradley • 215-1575 Rev. J; ECN 17-08-026
1Rough-Ins
CODE DESCRIPTION QTY.
A³⁄₈" Wall Anchors with a minimum pull-out force of 1,000 lbs. for Bowl 2
B³⁄₈" Wall Anchors with a minimum pull-out force of 1,000 lbs. for Mainframe 6
C³⁄₈" Wall Anchors for Base Frame, Standard Frame option only, minimum pull-out force not required 2
D1 ½" nominal copper tubing for Hot Supply, stub-out 2" from wall 1
D2 ½" nominal copper tubing for Cold or Tempered Supply, stub-out 2" from wall 1
E 1½" NPT Drain, stub-out 2" from wall 2
F
On the bowl back, measure the distance between the ¾" bowl mounting holes. Divide this measurement
in half. Measure and mark this dimension on the wall to the left and the right of the centerline. Install two
³⁄₈" wall anchors with a minimum pull-out rating of 1,000 lbs (supplied by installer) at locations marked.
2
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FOR CODES
A–E, H, C and W FIXTURE STYLE
34" None Standard Height
34" None Wall-Hung
32" Subtract 2" TAS, Grades 6 through 8 or 9
31" Subtract 3" Juvenile Height
30" Subtract 4" TAS, Pre-K through Grades 5 or 6
MOUNTING FOR STANDARD AND WALL HUNG HEIGHTS ARE SHOWN
AA
B
B
B
B
B
B
CC
D1 D2 E
RIM HEIGHT
SEE CHART
1
24-3/8"
(619mm)
8"
(203mm)
2-3/4"
70mm)
4"
(102mm)
24-3/8"
(619mm)
32"
(813mm)
28-3/4"
(720mm)
15"
(381mm)
5-5/8"
(143mm)
34"
(864mm)
3-1/2" (89mm)
FLOOR
38-1/2" (978mm)
REF. DIM.
38-1/2" (978mm)
REF. DIM.
24"
(610mm)
DISCONTINUED

Installation SS-3N/ndt/STD, SS-3N/ndt/WH
Bradley • 215-1575 Rev. J; ECN 17-08-026 5/15/2018 7
3Install Bowl The sprayhead body has slotted holes for adjusting
the fit-up with the bowl and wall.
For clarity, the scuff base frame and drain are not
shown. Turn the tailpiece down to its proper position
before installing the bowl.
Secure the bowl to the
wall anchors with ³⁄₈"
bolts and 1" min. O.D.
washers, two places.
Do not overtighten.
B
Attach the bowl to the frame with
¼"-20 x ½" pan-head screws and
washers. Do not tighten.
A
Tighten the pan-head screws
Do not overtighten.
C
SCUFF PANEL
STANDARD HEIGHT
FRAME ONLY
SCUFF BASE FRAME
STANDARD HEIGHT
FRAME ONLY
2Mount Frame to Wall
Anchoring the frame to a wall that is not
flat may cause the frame to bend, making
it difficult to reinstall the access panels. If
necessary, use shims to compensate for
wall distortion.
Once you have positioned the frame such that it is
level and flat against the wall or shimmed, mount
the frame to the wall at six places using ³⁄₈" bolts
and 1" min. O.D. washers.
NOTE: When mounting the standard height frame,
mount the scuff base to the wall at the same time
using two additional ³⁄₈" bolts and washers.
B
AUsing a T20 torx key, remove
the fasteners securing the
access panel to the main
frame, and remove the panel.
DISCONTINUED

SS-3N/ndt/STD, SS-3N/ndt/WH Installation
85/15/2018 Bradley • 215-1575 Rev. J; ECN 17-08-026
45
45
45
45
4a Connect the Supply — Hot and Cold Supply
4b Connect the Supply — Single Tempered Supply
The letter “H” on the Navigator Mixing
Valve indicates hot water supply inlet.
Loosen but do not remove
the two mounting screws
holding the valve bracket
to the frame.
Slide the valve bracket up
and lift it from the frame.
A
Connect one end of each hose to the
Navigator valve (one on the hot side, one on
the cold side).
Connect the other swivel end to the stop
valves.
C
Attach the stops to the hot
and cold water wall stub-outs.
B
Loosen but do not remove the two
mounting screws holding the valve
bracket to the frame.
Slide the valve bracket up and lift
it from the frame.
A
Connect one end of flexible hose
to the tempered line adapter.
Connect the other swivel end to
the stop valve.
C
Attach the stop to the
tempered wall stub-out.
B
DISCONTINUED

Installation SS-3N/ndt/STD, SS-3N/ndt/WH
Bradley • 215-1575 Rev. J; ECN 17-08-026 5/15/2018 9
5Install the Drains
To Drain
Stub-Out
Snap the sensor
cable plugs from
the sprayhead
into the proper
valve’s circuit
board.
A
Loosen the compression nuts.
Push the sprayhead supply tubes firmly into
the tube connectors until they are fully seated.
Tighten the compression nuts by hand.
C
6Connect Electrical and Sprayhead Supplies
Connect the solar
cell plug from the
solar cover to the
power-in cable on the
power management
module.
B
WARNING: The SS-3N/NDT Express®must be connected to the NDITE®power management module.
Connection to 110 VAC can cause personal injury and will result in damage to the electronics.
Reinstall the valve bracket.
Connect the power supply cables
from the power management
module into the gang valve circuit
board plugs (any connection
order will work properly).
D
Red Supply Tubing
Green Supply Tubing
Black Supply Tubing
DISCONTINUED

SS-3N/ndt/STD, SS-3N/ndt/WH Installation
10 5/15/2018 Bradley • 215-1575 Rev. J; ECN 17-08-026
H
C
ALoosen the cap screw
about ¼" (4–6 turns)
and lift up the cover
(do not remove).
B
Using the cover, turn the
cartridge gently until
desired water temperature
is reached. Do not turn past
stops as this may damage
the unit. Push the cover
down and tighten the screw.
This valve is NOT factory preset. Upon installation, the temperature of this
valve must be checked and adjusted to ensure delivery of a safe water
temperature. Water in excess of 110°F (43°C) may cause scalding.
Turn on the water supply and check for leaks. After 60 minutes at 700 LUX, the system
should be ready to operate. Pass your hand in front of each station’s sensor until all the
air is purged from the lines and water is flowing smoothly. Reinstall the access panel.
C
7Adjust the Temperature
DISCONTINUED
