AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
INSTALLATION GUIDE
AXISS
Digital Smartflow®Thermostatic Shower Mixer
FD-SFCSMC

2
FELTON

3
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
Control Unit Pre-Line Installation 7
Measurements 5
Tools Required 4
Notice 4
Scope of Application 6
Digital Mixer Installation 8
Control Housing Final Fit Installation 12
Operational test 17
Troubleshooting 18
Warranty 19
CONTENT
Connecting the Flow Controller 11

4
FELTON
WATER PATH
Input   2 × M10×1
Output 1/2˝BSP
Flow   max.22l/minat300kPa
Pressurerange  Min150kPa-Max500kPa
Dierenceofpressure Max.100kPa/14.5psi
Maximum outlet temperature 45°C
Hotinlettemprange 55°C-80°C
Cold inlet temp range 5°C - 25°C
ELECTRONICS
Powersupply  100V-240VAC/50-60Hz
Power consumption Standby <0.5 W,max.18W
PLEASE READ THE MANUAL CAREFULLY BEFORE STARTING THE INSTALLATION. AFTER COMMISSIONING AND TESTING THE
SYSTEMS FUNCTIONALITY, THIS DOCUMENT MUST BE GIVEN TO THE END USER OF THE SYSTEM.
PRODUCT TO BE DISCONNECTED BEFORE LINE TEST
In case of a power cut, the unit will remain inactive until the power is back on.
GENERAL
This installation manual contains instructions for the correct installation of the Axiss Smartow product. The warranty will be invalidated
if the product is not installed according to these instructions.
Installationmustbecarriedoutbyqualiedinstallersinaccordancetothisinstallationmanual.Country-specicstandards,rulesandsafety
regulation do apply.
PLACE OF INSTALLATION
The Axiss Smartow product must be installed in an accessible place and in accordance to this installation manual. This ensures a
problem-free service and maintenance procedure.
NOTICE
TOOLS REQUIRED
7. Drill
4. Torx screwdriver
(included in box 1)
3. Crosshead screwdriver
2.Drillbitø 5mm
1. Pencil
5.ø 70mmholesaw
8. Spirit level6.Utilityknife
DANGER OF ELECTRIC SHOCK!
ELECTRICAL INSTALLATION
Beforeopeningthehousing,themainsconnectionmustbeswitchedo.Workonelectricalpartsandconnectionsmustbe
carriedoutbyqualiedelectrician.Country-specicstandardsandregulationsdoapply.
PRECAUTIONS
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a
hazard.
4. This appliance contains battery that are only replaceable by skilled persons.
5. An electronic copy of the installation and user guides are available on the Felton website – please visit www.felton.co.nz
MAINTENANCE
Felton products are made of high quality materials and require only minimal maintenance. The following maintenance tips help to preserve
the surface and prevent damage through incorrect cleaning. Fittings and control parts should be wiped dry after used. Only use mild cleaning
productsthatcontainsoap.Thefollowingmustnotbeused:Scourers,abrasivesponges,hydrochloricacid,lime,plasterorcementremovers,
solutionsorcleaningagentscontainingacid(pH ≤ 4),limescaleremoverorvinegar-basedcleaner–andcleaningagentswherethechemical
solutionisnotknownwhichmaybesoldasspecialcleanerforttings.

5
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
BOX 1
DIGITAL MIXER
BOX 2
CONTROL UNIT
1. Control Housing
& Data Control Cable
3. Control Mounting Tube
5.BlackFoamSeal
4. Set of Screws: 6x 2.5x16mm
8. White Foam Seal6. Chrome Flange 7. Mounting Ring
2. Control Wheel
MEASUREMENTS
1. Temperature Control Unit
4.SetofScrews:2x5x50mm
2.12VACAdapter(Cablelength:1m)
3. Flow Control Unit
5. Adapter Set 6. 2x Inlet hoses (supplied)
155mm
55mm
115mm

6
FELTON
SCOPE OF APPLICATION
Wire and Data Cable must be installed prior
to the wall lining.
It is recommended that the data cable is
installed in conduit for ease of maintenance.
Important: The Digital Mixer must
have an access panel and should
not be sealed in the wall
Warning: Please ensure that all electrical installations are installed by a registered
electrician and complies with the Electrical (Safety) Regulations of NZ.
Important: The Digital Mixer must have an access panel.
Cable length
6m max. Handset
outlet
Cold inHot in
Note: The wheel
can be fitted
anywhere in the
showering area.
Note: The Digital Mixer
must not be fitted
upside down.
Control unit
Digital mixer
Pipework in
Control cable
Pipework out
Power supply
Power
supply must
be within 1m
from the
digital mixer
Control unit
Digital mixer
Cable length
6m max.
Handset
outlet
Cold in
Hot in
Access
panel
Pipework in
Control cable
Pipework out
Power supply
Note: The wheel
can be fitted
anywhere in the
showering area.
Power
supply must
be within 1m
from the
digital mixer
Warning
Pleasemakesurethepowersourceisinstalledby
aqualiedelectricianandcompliestoElectrical
standard/NZ laws. Important: The TLC Temp Flow
must have an access panel.
A Ceiling Mounted Shower handset (Recommended)
B Wall Mounted Shower handset
Important: The TLC Temp Flow
must be accessible and should not
be sealed in the wall

7
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
2Attaching the Control Housing
PreparethewalltotaketheControlHousing.TheinstallationoftheControlHousingwilldependoneach
individual situation.
Control Housing is attached from the front: a 70mm diameter hole is required in a xing nog ush with face
of the timber framing. Conduits should be used in the walls where necessary to protect the cables and allow
maintenance. Attach the Control Housing using the screws supplied.
Control Housing attached
from the front
NOG
1Cutting down the Control Housing (OPTIONAL)
NOTE:WerecommendtheControlHousingiscutdownasshownusingahacksaw
CONTROL UNIT PRE-LINE INSTALLATION
3Draw wire through the Control Housing
Draw Wire
(Not supplied)
Conduit (Not supplied)

8
FELTON
5Inside the Temperature Control Unit
4Remove the cover
DIGITAL MIXER INSTALLATION
Outlet
Hot Cold
Inlets
Fixing holes
Fixing hole
Cover retaining
holes
Transformer12V/wallplug
Flow controller unit
TLI-W

9
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
MOUNTING OPTIONS
MOUNTING FOR NOG
2Install the Digital Mixer
99 mm
1 Markxingholes
56 mm
Ifinstalledvertically,useorientation
shown
*
Refer to Scope of Application on p6 for the plumbing layout
MOUNTING FOR CONCRETE
2 Drillxingholes
99 mm
56 mm
ø 5 mm
3Install the
Digital Mixer
99 mm
1 Markxingholes
56 mm
If installed
vertically,use
orientation
shown
*

10
FELTON
7.
6. ConnectthetwoInlethoseswiththeMFadaptorsandlterstothewatersupplyfeed
Large retaining bolt
A-Connectthebrassadaptorsintotheexihoses.
B-Fitbothexihoses(withthebrassadaptoron)rmlyintotheunitbox.
C- Fit the large retaining bolt with a torx screw driver supplied.
A
B
C
Hot water supply
Cold water supply
Hot inlet Cold inlet

11
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
CONNECTING THE FLOW CONTROLLER
8
A. Fit the outlet pipe and the brass
connector onto the Flow control unit.
B.PushaFlowcontrolunitwithoutlet
ttingbackintotheDigitalMixerandt
the short retaining bolt with torx screw
driver supplied.
ADVICE:
Pushinrmly!
Flow control unit
A
B
Short retaining bolt

12
FELTON
9 Fito-afternalwallliningisinstalled
Drawalinearoundthecollar,ushwiththewall.Cutdownthecollarasmarked.
Final wall lining Final wall lining
CONTROL HOUSING FINAL FIT INSTALLATION

13
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
10 Assemble/attachthechromeange
11 Remove the Control Wheel
Attachthebackplate/adaptorringtotheControlHousingusingthe15mmscrewssupplied.
Note:Theblackadaptorringmustbeush withthebrassbackplate.
Front mounting ring must be
facing towards you (installer)
MOUNTING RING
MOUNTING
RING
CHROME
FLANGE
BLACKFOAM
SEAL

14
FELTON
12 FeedControlHousing&DataControlCablethroughtothechromeangeassembly
14 TurnControlHousingclockwisetolockinposition&re-attachtheControlWheel
13 Insert white foam seal onto mounting ring
First feed the Data Control Cable through the white foam seal onto the Control Housing.
Feedthecablethroughthechromeangeassembly.
Note: AttachingalengthofstringorwiretotheControlDataCablewillmakeiteasiertopullthe
cable through to the Digital Mixer.
PositiontheControlHousingintothechromeangeassemblyandturnclockwisetolockinposition.
PushttheControlWheelontotheControlHousing.
INSERT
2
Leavethepackingwraponthe
data cable until pulled through.
Fit white foam seal through cable to
end of interface wheel.
Note: Do not stretch white foam seal
TLI
Pushandtwisttolock
1
1
2
Position white foam seal

15
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
16 Connect Data Control Cable from Control Wheel assembly to Digital Mixer
TLI
TLI
Flow Controller Unit
IMPORTANT:
Fit cables into slots
to allow cover to
properly close at end
of installation
15 Connect the Flow Controller Unit to the Digital Mixer

16
FELTON
17
FitthecoverbackontothebaseusingaPhillipsscrewdriversecurethecoverinposition.
The unit is now ready for commissioning. Please see User Guide.
IMPORTANT: Electrical supply must
beinstalledbyaqualiedelectrician
(if required).
Power cable
connection
IMPORTANT: Fit cables
into slots to allow cover
to properly close at end
of installation
BA
Digital Mixer with Flow Control Unit installed:
Please Note: Leave the torx taped to the box for future use
18
Connectthepowercablecomingfromthetransformer.Usetheconnectorandpushrmlyinto
thesocket.FeedthecablethroughtheguideslotinthefrontoftheDigitalMixer.
Connect the power cable coming from the transformer. Use the connector and push firmly into
the socket. Feed the cable through the guide slot in the front of the Digital Mixer.
Power cable
connection
Power cable
converter

17
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
2 Open
Push the Axiss Smartow Interface once.
The Digital Mixer opens and the
LED illuminates.
3 Close
Push the Axiss Smartow Interface again.
The Digital Mixer closes
andtheLEDgoeso.
1Ensure that the Digital Mixer is installed correctly installed according to the instructions above.
Turnonthewatersupplyandchecktheunitandplumbingforleaks.Oncetheplumbingisconrmedto
bewater-tight,connectthepowersuplyandconducttheoperationaltestbelow.
OPERATIONAL TEST
Digital Mixer with Flow Control Unit installed

18
FELTON
If issue persists or is not covered in the above, please contact our Felton
Technical Team on 0800 743 358 or [email protected]
TROUBLESHOOTING
ISSUE PROBLEM TROUBLESHOOT
The device does not function
(i.e. the LED light is not on)
The AC adapter is not connected
to the mains Connect device to the mains power
Mains power failure Checkhouseholdfusebox
The AC adapter is not connected to the Control
Unit Follow Step 18onSmartowInstallationGuide
Thedigitalmixerisnotworking Follow Step 16onSmartowInstallationGuide
The water temperature does not match
the indicated display
Hot and cold water connections reversed Checkconnectionsarecorrect
Hot or cold water stop valve closed or only half
opened Fully open both stop valves
Kinkinsupplyhose Checkconnectionhoses
Connectingpipeblocked Flushpipesandcleanlter
No hot water Checkhotwatertankandinstantaneous
connections
Temperature sensor defect Carry out function «Diagnostic Test»
in User Guide
Dierenceinsupplypressurebetweenhot
andcoldwaterisgreaterthan100kPa Balancepressuretoeliminatedierence
Constant ow of water Unitwillnotturno Carry out function «Diagnostic Test»
in User Guide
The water shuts o before maximum run
time has been reached Flow sensor is defective Carry out function «Diagnostic Test»
in User Guide
The device is working but has
no water ow
Motors are not calibrated Carry out function «Diagnostic Test»
in User Guide
Stop valves closed Open stop valves fully
No water supply Restore water supply
Kinkinsupplyhose Checkconnectionhoses
Interface ashes green Cleaning mode active Wait 45 seconds or press the digital mixer
to cancel
The Digital Control Unit is damp or wet Inlet and outlets of the digital mixer are
not properly sealed Inspectallconnections,resealifnecessary
The Control Unit does not respond to
temperature and ow adjustment*
The interface elements
are connected incorrectly Follow Steps 15 & 16 on Installation Guide
The interface is defective Carry out function «Diagnostic Test»
in User Guide
Theknobisnotrunningsmoothly Removeandcleanknob

19
AXISS DIGITAL SMARTFLOW®INSTALLATION GUIDE
WARRANTY
Fortechnicalassistancepleasering:0800743358or(09)5280810
8 Farmhouse Lane, St Johns, Auckland 1072 New ZealandFelton Industries Limited www.felton.co.nz
5 year warranty applies to all Felton branded products including the electronic hardware and its components.
Whereproductsarepromotedashavinga“5yearwarranty”,FeltonIndustriesLimitedguaranteestheelectronic
componentsoftheseproducts(excludingbatteries)tobefreefromdefectsinmaterialsandworkmanshipunder
normalinstallation,useandserviceforaperiodofve(5)yearsfromthedateofpurchase.Fairwearandtearis
expressly excluded.
Thiswarrantyiseectiveforve(5)yearsfromthedateofpurchaseandcoverselectronicreplacementparts
only (excluding batteries) and 2 years from the date of purchase for plumber’s labour relating solely to repairing
orreplacingtheHardware,providedtheproductisinstalledbyaregisteredplumber.Youmustretainproofof
purchase of the Hardware (such as an invoice or receipt) and proof of installation by a registered plumber and
provide these to Felton on request.
Thiswarrantyisformanufacturingdefectsonlyanddoesnotcoveranydamagetoproductduetoabuse,
negligence or improper installation. This warranty is given on the understanding that the product is installed
by a registered plumber and operated according to Felton’s installation guide and the Australian/New Zealand
standardAS/NZS3500.Thiswarrantyisprovidedtopersonswhoarea“consumer”undertheConsumer
Guarantees Act 1993 only and for use in domestic/residential dwellings only (not for commercial use).
This warranty is subject to any other rights or remedies that you may have under the Consumer Guarantees
Act 1993 (or any other applicable legislation) and to Felton’s Terms of Trade.
This 5 year warranty does not cover:
1) anyconsumableitems(e.g.batteries,lters,installationttings)suppliedwiththeproducts.
2) damage,problemsorunsatisfactoryperformancecausedtotheelectronichardwareby:
 a. Faultyorincorrectelectricalwiring,incorrectpowersupply,voltageuctuations,overvoltage 
  transientspikesorelectromagneticinterferencenotoriginatingwithintheelectronichardware.
b. Incorrect or poor installation or application
 c. OperationatconditionsoutsidetheoperatingconditionsspeciedintheFeltontechnical 
or sales data applicable to that electronic hardware.
 d. Recongurationofthedigitalinterfacebytheuser–thisisconsideredaservicenotawarranty.
MAINTENANCE & CARE
PleaseseeUserGuideorvisitwww.felton.co.nz

/felton-industries-limited/FeltonIndustriesLimited @feltonltd/feltonltd@feltontapware
FELTON INDUSTRIES LTD
8 Farmhouse Lane St Johns Auckland 1072
[e-mail] | Find us on Social Media
150322EI
