Felton DESIGNER III User manual

INSTALLATION GUIDE
DESIGNER III SHOWER HEAD CHROME GREY DELUXE D3SHCGD
WHAT IS IN THE PACK
Wall Flange
D3 Shower Head
Shower Head Stem
Oxijet Water Saving Product
for Mains Pressure situation
Female Threaded
Ball Joint Fitting
D3 Screw Cap
CLEANING THE SHOWER HEAD DESIGNER III SHOWER HEAD
1. 2.
Hot Water
Vinegar
1:1
15 - 20 mins
Your Feltonmix shower head is manufactured
from self-cleaning plastic materials but if cleaning
is required use a combination of vinegar and
water and by following the steps below is usually
sucient.
1. Remove shower rose from the shower
head stem.
2. Place shower rose in a mixed solution of
vinegar and hot water for between
15 – 20 min. (Note: the face of the
shower rose cannot be removed for
cleaning purposes.)
If extra cleaning is still required use a soft brush.

HOW TO INSTALL
Screw shower head stem with
wall flange fitted into outlet.
Fit female threaded ball joint fitting
with screw cap and hand tighten
to the shower head stem.
Check that there is no leak at
this connection if so tighten
nut until the leak ceases.
1. 2. 3.
FOR MAINS PRESSURE ONLY
Screw shower head to the
shower cap and hand tighten. 4.
Screw shower head stem with
wall flange fitted into outlet.
FOR MAINS PRESSURE ONLY
Fit the Oxijet™ to the shower head
stem then fit female threaded ball
joint fitting with screw cap to the
end of the Oxijet™ and hand
tighten.
Check that there is no leak at
this connection if so tighten
nut until the leak ceases.
1. 2. 3. Screw shower head to the
shower cap and hand tighten. 4.
Warranty, Maintenance and Care
Felton Industries Limited guarantees these mixers to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase.
This warranty is eective for 5 years from the date of purchase and covers supply of replacement parts only, not including installation. You must retain proof of
purchase of the Mixer (such as an invoice or receipt) and provide this to Felton on request.
This warranty is for manufacturing defects only and does not cover any damage to product due to abuse, negligence or improper installation. This warranty is given
on the understanding that the product is installed and operated according to Felton’s installation guide and the Australian/New Zealand standard AS/NZS3500. This
warranty is provided to persons who are a “consumer” under the Consumer Guarantees Act 1993 only and for use in domestic/residential dwellings only (not for
commercial use).
At no stage should plated surfaces be cleaned with cleaning agents that contain a corrosive acid or a scouring additive. Plated surfaces should be
cleaned with liquid detergent or soap and water. Any damage caused through the use of an unsuitable cleaner will not be covered by warranty.
This warranty is subject to any other rights or remedies that you may have under the Consumer Guarantees Act 1993 (or any other applicable
legislation) and to Felton’s Terms of Trade.
Please fill in the details below, attach your receipt to this installation guide and keep as your proof of purchase.
Purchased at: ....................................................................................................................................................................................................................................................................................................
Date of purchase: ............................................................................................................................................................................................................................................................................................
Product name/code: ........................................................................................................................................................................................................................................................................................
- YOUR COPY TO KEEP
For technical assistance please ring: 0800 743 358 or [phone]
Felton Industries Limited www.felton.co.nz8 Farmhouse Lane, Glen Innes, Auckland 1072 New Zealand
030316HM
