AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
INSTALLATION GUIDE
AXISS
Smartview®Digital Thermostatic Shower Mixer
FD-SVCSMC

2
FELTON

3
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
Vision Wheel Interface Pre-Line Installation 8
Operational Test 19
Notice 5
Measurements 6
Tools Required 5
Scope of Application 7
Digital Mixer Installation 9
Vision Wheel Interface Final Fit Installation 14
Troubleshooting 20
Warranty 21
Processor Template 23
CONTENT

4
FELTON

5
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
WATER PATH
Input   2 × 1/ 2˝BSP
Output   2 ×1 / 2˝BSP
Flow   max.36l /minat300kPa
Pressurerange  Min150kPa-Max500kPa
Dierenceofpressure Max.100kPa/14.5psi
Maximum outlet temperature 45°C
Hot inlet temp range 55°C - 80°C
Cold inlet temp range 5°C - 25°C
ELECTRONICS
Powersupply  100-240VAC / 50–60Hz
Power consumption Standby <0.5 W,max.45 W
TOOLS REQUIRED
5. Drill
3. Crosshead screwdriver 4. Spanner
2.Drillbitø 8mm
1. Pencil
6. 70mm holesaw 8. Spirit level
7.Utilityknife
PLEASE READ THE MANUAL CAREFULLY BEFORE STARTING THE INSTALLATION. AFTER COMMISSIONING AND TESTING THE
SYSTEMS FUNCTIONALITY, THIS DOCUMENT MUST BE GIVEN TO THE END USER OF THE SYSTEM.
PRODUCT TO BE DISCONNECTED BEFORE LINE TEST
In case of a power cut, the unit will remain inactive until the power is back on.
GENERAL
This installation manual contains instructions for the correct installation of the Axiss Smartview product. The warranty will be invalidated
if the product is not installed according to these instructions.
Installationmustbecarriedoutbyqualiedinstallersinaccordancetothisinstallationmanual.Country-specicstandards,rulesandsafety
regulation do apply.
PLACE OF INSTALLATION
The Axiss Smartview product must be installed in an accessible place and in accordance to this installation manual. This ensures a
problem-free service and maintenance procedure.
NOTICE
DANGER OF ELECTRIC SHOCK!
ELECTRICAL INSTALLATION
Beforeopeningthehousing,themainsconnectionmustbeswitchedo.Workonelectricalpartsandconnectionsmustbe
carriedoutbyqualiedelectrician.Country-specicstandardsandregulationsdoapply.
PRECAUTIONS
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a
hazard.
4. This appliance contains battery that are only replaceable by skilled persons.
5. An electronic copy of the installation and user guides are available on the Felton website – please visit www.felton.co.nz
MAINTENANCE
Felton products are made of high quality materials and require only minimal maintenance. The following maintenance tips help to preserve
the surface and prevent damage through incorrect cleaning. Fittings and control parts should be wiped dry after used. Only use mild cleaning
productsthatcontainsoap.Thefollowingmustnotbeused:Scourers,abrasivesponges,hydrochloricacid,lime,plasterorcementremovers,
solutionsorcleaningagentscontainingacid(pH ≤ 4),limescaleremoverorvinegar-basedcleaner–andcleaningagentswherethechemical
solutionisnotknownwhichmaybesoldasspecialcleanerforttings.

6
FELTON
BOX 1
DIGITAL MIXER
BOX 2
CONTROL UNIT
1. Control Housing
& Data Cable
5. Set of Screws
6x 2.5x16mm 6. Control Wheel
1. Temperature & Flow
Control Unit
3. Set of Screws
2x 5x50mm
2.BackUpBattery
4. Connecting Adapters
2. Display Unit
(blackorwhite)
4. Fastening
& Seal Kit
silicone seal
black
foam
seal
wall plug
steel clip
screws
250 mm
75 mm
256 mm
MEASUREMENTS
3. Control Mounting Tube
110mm
10 mm
43 mm
56mm

7
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
A Ceiling Mounted Showerhandset(Recommended)
B Wall Mounted Shower handset
SCOPE OF APPLICATION
Cable length
6m max.
Cold inHot in
Handset &
fixed head
outlets
Digital Mixer
Pipework in
Control cable
Pipework out
Power supply
CONTROL UNIT
Note: The wheel
can be fitted
anywhere in the
showering area.
Power
supply must
be within 1m
from the
digital mixer
Cable length
6m max.
Hot inCold in
Digital Mixer
Handset & fixed
head outlets
CONTROL UNIT
Pipework in
Control cable
Pipework out
Power supply
Note: The wheel
can be fitted
anywhere in the
showering area.
Power
supply must
be within 1m
from the
digital mixer
Warning
Pleasemakesurethepowersourceis
installedbyaqualiedelectricianand
compliestoElectricalstandard/NZlaws.
Important: The TLC Temp Flow must
have an access panel.
Important: The TLC Temp
Flow must be accessible
and should not be sealed
in the wall

8
FELTON
2Attaching the Control Housing
PreparethewalltotaketheControlHousing.TheinstallationoftheControlHousingwilldependoneach
individual situation. Control Housing attached from the front: a 70mm diameter hole is required in a xing
nog ush with face of the timber framing. Conduits should be used in the walls where necessary to protect
the cables and allow maintenance. Attach the Control Housing using the screws supplied.
Control Housing attached
from the front
NOG
NOTE:Werecommendthein-wallboxiscutdownasshownusingahacksaw
1 CuttingdowntheControlHousing(OPTIONAL)
CONTROL UNIT PRE-LINE INSTALLATION

9
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
15V ACCU EXT RS-232 MOTOR TLI AUX
4Remove the cover
Wire(notsupplied)
Conduit(notsupplied)
Thedrawwireshouldbettedbeforethewallislined.
NOTE:FeedingastringorwirethroughtheControlHousingandconduitwillmakeiteasiertopullthe
cables through to the TLC 30 FTD.
3Draw wire through the Control Housing
DIGITAL MIXER INSTALLATION

10
FELTON
15V ACCU EXT RS-232 MOTOR TLI AUX
Outlet
HOT COLD
Inlets
Fixing holes
Cover
retaining
holes
Connectorblock
Power supply
Batterycompartment
12
Connects to hand shower
1
Connectstoxedhead
2
5Inside the Temperature & Flow Control Unit

11
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
15V ACCU EXT RS-232 MOTOR TLI AUX
MOUNTING FOR NOG (RECOMMENDED)
6 MarkthepositionoftheTemperature&FlowControlUnitxingholes
in the selected location
Important: The location of the Temperature & Flow
Control Unit must be acessible and dry. Use the
processortemplateonthelastpagetomarkthe
positionofthexingholesintheselectedlocation.
ORIENTATION FOR WALL SITUATION:
MOUNTING OPTIONS
MOUNTING FOR CONCRETE
1Install the Temperature & Flow Control Unit 1 Drillxingholes
99 mm
56 mm
ø 5 mm / 0.2˝
2Install the Temperature & Flow Control Unit
15V ACCU EXT RS-232 MOTOR TLI AUX
Refer to Scope of Application on p6 for the plumbing layout

12
FELTON
15V ACCU EXT RS-232 MOTOR TLI AUX
9Tighten adapter retaining bolt
15V ACCU EXT RS-232 MOTOR TLI AUX
Fullyinserttheinletadaptersintotheinletvalves(onelongandoneshortadapter).
8Connect hot and cold water supply
IMPORTANT: Flush the
pipeworkbeforeconnection
A
B
Connect hot and cold water supply
Insert inlet supply
A
B
HOT
COLD
LONG
SHORT
7Remove the inlet adapter retaining bolt
15V ACCU EXT RS-232 MOTOR TLI AUX

13
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
15V ACCU EXT RS-232 MOTOR TLI AUX
1
2
LONG
SHORT
15V ACCU EXT RS-232 MOTOR TLI AUX
1
2
LONG
SHORT
Insertoutletadaptersandconnectoutletpipeworks
Primaryoutlet(HandShower)
Secondaryoutlet(FixedHead)
1
2
If using two outlets:
Connect outlet and outlet
12
If only using single outlet:
Outlet to be connected.
Outlet to be plugged and sealed.
1
2
11 Connectoutletpipeworks
10 Remove the outlet adapter retaining bolts
15V ACCU EXT RS-232 MOTOR TLI AUX

14
FELTON
13 Fitoafternalwallliningisinstalled
Finish the wall by tiling etc.
40mmdiameterholesshouldbedrilledinthetileetctonish.
Drawalinearoundthecollar,ushwiththewall.Cutdownthecollarasmarked.
Final wall lining Final wall lining
12 Tighten adapter retaining bolt
15V ACCU EXT RS-232 MOTOR TLI AUX
DISPLAY UNIT AND CONTROL WHEEL FINAL FIT INSTALLATION

15
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
Fixthecontrolsteelcliptothewallwhereshownusingthexingssupplied.
Remove Control Wheel from the Control Housing.
Feeddatacablethroughsiliconesealandblackfoamseal
Secure both cables to the previously installed draw wire and
pull the cables to the Temperature & Flow Control Unit.
60 mm
ø 5 mm
40mm
56mm
60mm 110mm
Steel clip
A
D
C
C
D
B
14 Attach steel clip
15 Feed both cables through to Temperature & Flow Control Unit
A
Fitblackfoamseal
around groove
B

16
FELTON
17 PositiontheControlHousingintotheDisplayUnitandlockbyturningclockwise.
2
Fit Control Wheel
3
16 Position Display Unit and attach with screws
1Pushandtwisttolock
ADVICE:Pushinrmly!
Fit silicone seal
inside the Display
Unit

17
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
18 ConnecttheBackUpBattery
19 Connect the Control Wheel to the Temperature & Flow Control Unit port
15V ACCU EXT RS-232 MOTOR TLI AUX
TLI
15V ACCU EXT RS-232 MOTOR TLI AUX
15V ACCU EXT RS-232 MOTOR TLI AUX
15V ACCU EXT RS-232 MOTOR TLI AUX
Placebackupbatteryinshown
location within the Temperature
& Flow Control Unit and connect
cable to ACCU port.
Note:Afterinstallation,battery
may require 24 hours of charging
on mains power before battery
backupfunctionbeforefully
operational. Charging occurs
once unit is on mains power.
CONTROL WHEEL
GREY CABLE
1
Plug the TLI
-W
body cable to the
TLI port as shown
TLI-W BODY
GREY CABLE
15V ACCU EXT RS-232 MOTOR TLI AUX
Plug the Control Wheel cable
to the Temperature & Flow
Control Unit port as shown

18
FELTON
15V ACCU EXT RS-232 MOTOR TLI AUX
RS-232
15V ACCU EXT RS-232 MOTOR TLI AUX
15V ACCU EXT RS-232 MOTOR TLI AUX
15V ACCU EXT RS-232 MOTOR TLI AUX
15V ACCU EXT RS-232 MOTOR TLI AUX
15V ACCU EXT RS-232 MOTOR TLI AUX
21
20 Connect Display Unit to RS-232 port
Plug the Display Unit
to the RS-232 port as
shown
1
DISPLAY UNIT
BLACK CABLE
IMPORTANT: Electrical supply must
beinstalledbyaqualiedelectrician
(ifrequired).
FitthecoverbackontothebaseusingaPhillipsscrewdriversecurethecoverinposition.The
unit is now ready for commissioning. Please see User Guide.
1
Plug the TLI-W
body cable to the
TLI port as shown
TLI-W BODY
GREY CABLE
15V ACCU EXT RS-232 MOTOR TLI AUX

19
AXISS DIGITAL SMARTVIEW INSTALLATION GUIDE
OPERATIONAL TESTING:
2 Open
Push the Smartview™ Interface once.
The Digital Mixer opens and the LED illuminates.
3 Close
Push the Smartview™ Interface again.
 TheDigitalMixerclosesandtheLEDgoeso.
1Ensure that the Digital Mixer is installed correctly installed according to the instructions above.
Turnonthewatersupplyandchecktheunitandplumbingforleaks.Oncetheplumbingisconrmedto
bewater-tight,connectthepowersuplyandconducttheoperationaltestbelow.

20
FELTON
SMARTVIEW™ TROUBLESHOOTING
ISSUE PROBLEM TROUBLESHOOT
The device does not function
(i.e. the LED light is not on)
The AC adapter is not connected to the mains Connect device to the mains power
Mains power failure Checkhouseholdfusebox
Backupbatterynotconnected Follow Step 18 on Smartview Installation Guide
Visionwheelinterfaceisnotworking Follow Step 19-20 on Smartview Installation
Guide
Device does not operate during
a power failure
Batterynotconnected Connectbatterywithcontroller(ACCU)
Batteryat Charge for at least 24hours. Follow Step 18 on
Smartview Installation Guide
Batterydefective Replace(replaceevery3to5years)
The water temperature does not match
the indicated display
Hot and cold water connections reversed Checkconnectionsarecorrect
Hot or cold water stop valve closed or only half
opened Fully open both stop valves
Kinkinsupplyhose Checkconnectionhoses
Connectingpipeblocked Flushpipesandcleanlter
No hot water Checkhotwatertankandinstantaneous
connections
Temperature sensor defect Carryoutfunction«SelfCheckDiagnosis»
on Smartview User Guide
Dierenceinsupplypressurebetween
hotandcoldwatergreaterthan100kPa Balancepressuretoeliminatedierence
Constant ow of water Unitwillnotturno Carryoutfunction«SelfCheckDiagnosis»
on Smartview User Guide
The water shuts o before maximum run
time has been reached Flow sensor is defective Carryoutfunction«SelfCheckDiagnosis»
on Smartview User Guide
The device is working but has
no water ow
Motors are not calibrated Carryoutfunction«SelfCheckDiagnosis»
On Smartview User Guide
Stop valves closed Open stop valves fully
No water supply Restore water supply
Kinkinsupplyhose Checkconnectionhoses
Interface ashes green Cleaning mode active Wait 45 seconds or deactivate
via menu
The TLC 30 FTD is damp or wet Inlet and outlets of Temperature & Flow Control
Unit are not properly sealed Inspectallconnections,resealifnecessary
The vision wheel interface does not
respond to temperature and ow
adjustment
The interface elements are connected incorrectly Follow Step 19-20 on Smartview Installation
Guide
The interface is defective Carryoutfunction«SelfCheckDiagnosis»
On Smartview User Guide
Theknobisnotrunningsmoothly Removeandcleanknob
If issue persists or is not covered in the above, please contact our Felton
Technical Team on 0800 743 358 or [email protected]
