Users’ Manual
24-MAXX®First Call Cover
24-MAXX®and 24-miniMAXX® First Call Pouch
December 2009 GLO
Pub. No. 234-3320-01
Read this Manual
and Retain for
Future Reference
FERNO®
Mortuary
24MAXX® AND
24MINIMAXX® POUCH
24MAXX® COVER

2© Ferno-Washington, Inc 234-3320-01 December 2009
24-MAXX® First Call Cover and Pouch
© Copyright Ferno-Washington, Inc. All Rights Reserved.
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.
Disclaimer
This manual contains general instructions for the use, operation
and care of this product. The instructions are not all-inclusive. Safe
and proper use of this product is solely at the discretion of the
user. Safety information is included as a service to the user. All
other safety measures taken by the user should be within and under
consideration of applicable regulations. It is recommended that
training on the proper use of this product be provided before using
this product in an actual situation.
Retain this manual for future reference. Include it with the product
in the event of transfer to new users. Additional free copies are
available upon request from Customer Relations.
Proprietary Notice
The information disclosed in this manual is the property of Ferno-
Washington, Inc., Wilmington, Ohio, USA. Ferno-Washington, Inc.
reserves all patent rights, proprietary design rights, manufacturing
rights, reproduction use rights, and sales use rights thereto, and
to any article disclosed therein except to the extent those rights
are expressly granted to others or where not applicable to vendor
proprietary parts.
Ferno Technical Support
Customer service and product support are important aspects of each
Ferno product. Please have the product serial number available
when calling, and include it in all written communications. For
technical support questions:
Telephone (Toll-free) 1.800.733.3766 ext. 1010
Telephone [phone] ext. 1010
Email quality[email protected]
Ferno Customer Relations
For ordering assistance or general information:
CANADA AND THE U.S.A.
Telephone (Toll-free) 1.877.733.0911
Telephone [phone]
Fax (Toll-free) 1.888.388.1349
Fax [phone]
Internet www.ferno.com
ALL OTHER LOCATIONS
For assistance or information, please contact your Ferno distributor.
If you do not have a Ferno distributor, please contact Ferno
Customer Relations:
Ferno-Washington, Inc.
70 Weil Way
Wilmington, Ohio 45177-9371, U.S.A.
Telephone [phone]
Fax [phone]
Internet www.ferno.com
Limited Warranty Statement
The products sold by Ferno are covered by a limited warranty,
which is printed on all Ferno invoices. The complete terms and
conditions of the limited warranty, and the limitations of liability
and disclaimers, are also available upon request by calling Ferno at
1.800.733.3766 or 1.937.382.1451.

3
© Ferno-Washington, Inc 234-3320-01 December 2009
24-MAXX® First Call Cover and Pouch
TABLE OF CONTENTS
Ferno Customer Relations______________________ 2
Ferno Technical Support _______________________ 2
1 - Safety Information___________________________ 4
1.1 Warning________________________________ 4
1.2 Important_______________________________ 4
1.3 Bloodborne Disease Notice_________________ 4
1.4 Symbol Glossary_________________________ 4
2 - About the Cover and Pouch ___________________ 4
2.1 Cover and Pouch Descriptions ______________ 4
2.2 GeneralSpecications ____________________ 5
2.3 Components ____________________________ 5
Section Page Section Page
3 - Using the Cover or Pouch _____________________ 6
3.1 Before Placing the Cover or Pouch In Service __ 6
3.2 Using the Cover with a Cot_________________ 6
3.3 Using the Pouch with a Cot ________________ 6
4 - Maintenance ________________________________ 7
4.1 Maintenance Schedule ____________________ 7
4.2 Disinfecting and Cleaning the _______________
Cover or Pouch __________________________ 7
4.3 Inspecting the Cover or Pouch ______________ 7

4© Ferno-Washington, Inc 234-3320-01 December 2009
24-MAXX® First Call Cover and Pouch
1  SAFETY INFORMATION
1.1 Warning
Warning notices indicate a potentially hazardous situation
which, if not avoided, could result in injury or death.
WARNING
Improper use of the cover or pouch can cause injury. Use
the cover or pouch only for the purpose described in this
manual.
Improper maintenance can cause injury. Maintain the
cover or pouch only as described in this manual.
1.2 Important
Important notices emphasize important usage or maintenance
information.
Important
1.3 Bloodborne Disease Notice
To reduce the risk of exposure to bloodborne diseases such
as HIV-1 and hepatitis when using the cover or pouch, follow
the disinfecting and cleaning instructions in this manual.
1.4 Symbol Glossary
Thesymbolsdenedbelowareusedonthecoverorpouch
and/or in this users’ manual. Ferno uses symbols recognized
by the International Standards Organization (ISO),American
National Standards Institute (ANSI) and the mortuary
services industry.
General Warning of
Potential Injury
Read the Users’
Manual
Product meets European
Union Standards
Safety Information, About the Products
2  ABOUT THE COVER AND POUCH
2.1 Cover and Pouch Descriptions
The 24-MAXX®First Call Cover and Pouch (called the
“cover” and “pouch” in this manual) are designed for use
by providers of mortuary services. The cover is compatible
with Ferno’s 24-MAXX® Cot. The pouch is compatible with
Ferno's 24-MAXX®Cot and 24-miniMAXX®Cot.
COVER FEATURES
Adjustableside-drapelengthallowsdigniedtransport●
of bodies ranging in size from small to very large
Reversible end-to-end●
Slip-over styling●
Elasticizedendpanelsforsnugt●
Large pocket for documents or personal effects●
Binding on all edges●
WARNING
Improper use of the cover or pouch can cause
injury. Use the cover or pouch only for the purpose
described in this manual.
POUCH FEATURES
Extra width allows dignied transport of even very●
large bodies
Full-length brass zipper●
Secures to cot with snap-fastener tabs at each end●
Large pocket for documents or personal effects●
Restraint slots●

5
© Ferno-Washington, Inc 234-3320-01 December 2009
24-MAXX® First Call Cover and Pouch
2.3 Components
About the Products
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.
2.2 General Specications
COVER
Length 76 in./193 cm
Width (at ends) 19 in./47 cm
Depth 20 in./50 cm
Weight 5 lb 12 oz/2.6 kg
Generalspecicationsareroundedtothenearestwholenumber.MetricconversionsarecalculatedbeforeroundingtheImperial
measurements. For more information, contact Ferno Customer Relations (page 2) or your Ferno distributor.
Fernoreservestherighttochangespecicationswithoutnotice.
POUCH
Length 75 in./191 cm
Width (at ends) 24 in./61 cm
Depth (at ends) 14 in./36 cm
Weight 6 lb 5 oz/3 kg
COVER
Document Pocket
Length-Adjustment Snaps
(3 per side)
Elasticized
End Panel
Elasticized
End Panel
POUCH Zipper
Restraint Slot
(2 per side)
Document
Pocket
Snap-Fastener
Tab
(2 per end)
Snap-Fastener
Tab
(2 per end)

6© Ferno-Washington, Inc 234-3320-01 December 2009
24-MAXX® First Call Cover and Pouch
3  USING THE COVER OR POUCH
Using the Products
3.1 Before Placing the Cover
or Pouch in Service
Conrm that the cover or pouch functions properly.●
Follow instructions in Inspecting the Cover or Pouch,
page 7.
Personnel who will work with the cover or pouch need●
to read this manual and practice using the cover or
pouch with the cot before using it in service.
3.2 Using the Cover with a Cot
The length of the side drapes is adjustable to provide
coverage for a wide range of body sizes. Shorten the side
drapes (Figure 1) when transporting bodies in the small to
large range. Use the side drapes full length (Figure 2) when
transporting very large bodies.
If the body being transported is not large enough toNote:
raise the side drapes above the loading wheels, shorten the
side drapes before loading the cot and before folding it to
its lowest position.
To use the cover:
Place the body on the cot and secure it with restraints.1.
Center the cover over the body and cot.2.
Slide the elastic ends of the cover under both ends of3.
the cot.
Adjust the length of the side drapes as needed.4.
To shorten the side drapes, fold each side of the○
cover inward against itself and fasten the snaps.
To lengthen the side drapes, unfasten the snaps.○
Figure 2 - Side Drapes Lengthened
Figure 1 - Side Drapes Shortened
Important
If the body being transported is not large enough to
raise the side drapes above the loading wheels, shorten
the side drapes of the cover before loading the cot and
before lowering the cot to its lowest position. Failure to
shorten the side drapes may result in their interfering
with the cot wheels.
3.3 Using the Pouch with a Cot
Lay the pouch on the cot.1.
Loop the snap-fastener tabs around the end tubes of2.
the cot main frame (Figure 3) and fasten the snaps.
Attach both two-piece restraints to the cot main3.
frame at the pouch restraint slots. Follow attachment
instructions in the users' manual provided with the
restraints.
Unzip the pouch.4.
Slide the restraints through the side slots of the cover.5.
Place the body on the pouch.6.
Fasten the restraints around the body.7.
Zip the pouch closed.8. Figure 3 - Pouch Attached to Cot
Snap-Fastener
Tab
(2 each end)

7
© Ferno-Washington, Inc 234-3320-01 December 2009
24-MAXX® First Call Cover and Pouch Maintenance
4  MAINTENANCE
4.1 Maintenance Schedule
The cover or pouch requires regular maintenance. Set up and
follow a maintenance schedule. The table at right represents
minimum intervals for maintenance.
When using maintenance products, follow the manufacturers’
directions and read the manufacturers’ material safety data
sheets.
Important
Improper disinfecting and cleaning can damage the
cover or pouch. Disinfect and clean only as instructed
in this manual.
WARNING
Improper maintenance can cause injury. Maintain
the cover or pouch only as described in this
manual.
INSPECTION CHECKLIST
Is the cover or pouch free of cuts, deep abrasions●
and excessive wear?
Is all stitching tight and unbroken?●
If there is elastic, is it securely attached and is it●
functional?
Are all snaps securely in place and do they function●
properly?
If there is a zipper, does it function properly and●
smoothly?
4.3 Inspecting the Cover or Pouch
Inspect the cover or pouch at regular intervals. Follow the
checklist at right and work the cover or pouch through its
functions as described in this manual. If the inspection
shows damage or excessive wear, replace the cover or pouch
or remove it from service until repair is made.
Minimum
Maintenance Intervals
Each Use As Needed Each Month
Disinfecting (this page) •
Cleaning (this page) •
Inspecting (this page) • •
Important
The cover or pouch can be damaged by machine
drying for too long a time or at too high a setting. Use
the Low setting and remove the cover or pouch after
20 minutes. Remove any remaining moisture by line
drying.
4.2 Disinfecting and Cleaning the
Cover or Pouch
DISINFECTING
Use Crypton®Fabric Disinfectant and Deodorizer. Spray
a mist of the disinfectant on the inside and outside of the
cover or pouch and keep the surfaces wet for ten minutes,
then spot clean or machine wash as directed below.
CryptonNote:®products may be purchased at www.
cryptoncare.com or by calling toll free 1.800.279.7866.
SPOT CLEANING
Do not use solvent cleaners. Remove any excess residue,
then spray the spot with a solution of one part Tide®or
Cheer®tovepartswater.
Lightly brush the sprayed area with a soft-bristled upholstery
brush, allow the cleaner to sit for a minute, then blot with a
clean, dry towel, repeating if necessary. Spray-rinse the area
with clean water and blot with a clean, dry towel.
For stubborn stains, thoroughly wet the surface with the
solution, then brush and blot, spray-rinse and blot.
MACHINE WASHING
If the cover or pouch accumulates excessive soil, it may be
machine washed following the instructions below. However,
machine washing on a regular basis is not recommended for
this upholstery-quality fabric.
Machine wash the cover or pouch in cold water at the Gentle
setting. Use an enzyme detergent such as Tide®or Cheer®
and follow the detergent manufacturer's instructions.
Tumble dry the cover or pouch a maximum of 20 minutes
at the Low setting,then remove and hang the cover or pouch
tonishdrying.
