Ferno 24 MAXX User manual

Mortuary Cots
24•MAXX™
24•miniMAXX™
24H•miniMAXX™
Users’ Manual
November 2008 GLO
Pub. No. 234-3307-02
Read this Manual
and Retain for
Future Reference

2© Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
Disclaimer
This manual contains general instructions for the use,
operation and care of this product. The instructions are not
all-inclusive. Safe and proper use of this product is solely at
the discretion of the user. Safety information is included as
a service to the user. All other safety measures taken by the
user should be within and under consideration of applicable
regulations. It is recommended that training on the proper
use of this product be provided before using this product in
an actual situation.
Retain this manual for future reference. Include it with the
product in the event of transfer to new users. Additional free
copies are available upon request from Customer Relations.
Proprietary Notice
The information disclosed in this manual is the property of
Ferno-Washington, Inc., Wilmington, Ohio, USA. Ferno-
Washington, Inc. reserves all patent rights, proprietary design
rights, manufacturing rights, reproduction use rights, and
sales use rights thereto, and to any article disclosed therein
except to the extent those rights are expressly granted to
others or where no applicable to vendor proprietary parts.
Limited Warranty Statement
The products sold by Ferno are covered by a limited
warranty, which is printed on the invoice you received when
you purchased the product. Please refer to the warranty
terms as printed on your invoice. The complete terms and
conditions of the limited warranty, and the limitations of
liability and disclaimers, are also available upon request by
calling Ferno at 1.800.733.3766 or 1.937.382.1451.
Ferno Customer Relations
Customer service and product support are important aspects
of each Ferno product. For assistance or information, contact
your Ferno distributor or Ferno Customer Relations.
Please have the product serial number available when calling
Ferno Customer Relations, and include it in all written
communications.
Ferno-Washington, Inc.
70 Weil Way
Wilmington, Ohio 45177-9371, U.S.A.
Telephone (U.S.A. and Canada) 1.800.733.3766
Telephone (Worldwide) +1.937.382.1451
Fax (U.S.A. and Canada) 1.888.388.1349
Fax (Worldwide) +1.937.382.6569
Internet www.ferno.com
European Representative
Ferno (UK) Limited
Stubs Beck Lane, Cleckheaton
West Yorkshire BD19-4TZ, United Kingdom
Telephone [phone]
Fax [phone]
Internet www.ferno.co.uk
© Copyright Ferno-Washington, Inc. All Rights Reserved.
Serial Number _________________________
Location: On cot crosstube at loading end of cot.
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.

© Ferno-Washington, Inc. 234-3307-02 November 2008 3
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™
Ferno Customer Relations______________________ 2
1 -Safety Information___________________________ 4
1.1 Warning________________________________ 4
1.2 Important_______________________________ 4
1.3 Bloodborne Disease Notice_________________ 4
1.4 Cot and Fastener Compatibility _____________ 4
1.5 Safety and Instruction Labels _______________ 5
1.6 Symbol Glossary_________________________ 5
2 - Operator Skills And Training __________________ 6
2.1 Skills __________________________________ 6
2.2 Training ________________________________ 6
2.3 Height and Strength Considerations __________ 6
3 - About The Cot ______________________________ 7
3.1 Description _____________________________ 7
3.2 Cot Options _____________________________ 7
3.3 Components ____________________________ 8
3.4 Specications ___________________________ 9
3.5 Cot Positions ___________________________ 10
4 - Using The Features _________________________ 11
4.1 Bed Panel Slots _________________________ 11
4.2 Restraints______________________________ 12
4.3 Control Handles ________________________ 13
4.4 Mattress_______________________________ 14
4.5 Wheel Locks ___________________________ 14
4.6 Sidearms (Optional) _____________________ 14
4.7 Side Lift Handles (Optional)_______________ 15
5 - Using The Cot______________________________ 16
5.1 Before Placing the Cot in Service___________ 16
5.2 General Guidelines for Use________________ 16
5.3 Changing Cot Levels With Two Operators ____ 17
5.4 Changing Cot Levels With One Operator_____ 18
5.5 Rolling the Cot _________________________ 19
5.6 Transferring the Body Onto the Cot _________ 20
5.7 ManeuveringtheCotInaConnedArea _____ 20
5.8 Loading the Cot_________________________ 21
5.9 Unloading the Cot_______________________ 22
5.10 Loading or Unloading
With Two Trained Operators_______________ 23
5.11 Using Additional Help ___________________ 24
Load Limit_________________________________ 24
6 - Maintenance _______________________________ 25
6.1 Maintenance Schedule ___________________ 25
6.2 Disinfecting and Cleaning the Restraints _____ 25
6.3 Disinfecting and Cleaning the Mattress ______ 25
6.4 Disinfecting and Cleaning the Cot __________ 25
6.5 Waxing the Cot _________________________ 26
6.6 Inspecting the Cot _______________________ 26
6.7 Lubricating the Cot ______________________ 27
7 - Accessories And Related Products _____________ 28
8 - Parts And Service___________________________ 28
7.1 U.S.A. and Canada ______________________ 28
7.2 Worldwide_____________________________ 28
7.3 Parts List 24 MAXX _____________________ 29
7.4 Parts List 24-miniMAXX _________________ 30
7.5 Parts List 24-H miniMAXX _______________ 30
Training Record ______________________________ 31
Maintenance Record___________________________ 31
TABLE OF CONTENTS

4© Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™Safety Information
1 SAFETY INFORMATION
1.1 Warning
Warning notices indicate a potentially hazardous situation
which, if not avoided, could result in injury or death.
1.2 Important
Important notices emphasize important usage or maintenance
information.
Important
1.3 Bloodborne Disease Notice
To reduce the risk of exposure to bloodborne diseases
such as HIV-1 and hepatitis when using the cot, follow the
disinfecting and cleaning instructions in this manual.
1.4 Cot and Fastener Compatibility
Forthepurpose ofthisnotice, the24-MAXX,24-miniMAXX,
and 24H-miniMAXX cots and all Ferno transporters are
included under the generic term, “cot.”
Combining different manufacturers’products into a “mixed-
component” cot/cot fastener system can increase the user’s
risk of injury and damage.
Ferno-Washington, Inc. strongly recommends that only
Ferno-manufactured cots be used in Ferno-manufactured cot
fasteners, and that only Ferno-manufactured cot fasteners be
used for securing Ferno-manufactured cots in ambulances.
ANY COMBINATION OF A FERNO COT OR COT
FASTENER WITH A NON-FERNO COT OR COT
FASTENER IS MISUSE OF THE FERNO PRODUCT.
Responsibility for the outcome of know, intentional misuse
rests squarely on the misuser.
WARNING
Untrained operators can cause injury or be injured. Permit
only trained personnel to operate the cot.
Improper use of the cot can cause injury. Use the cot only
for the purpose described in this manual.
Improper operation can cause injury. Operate the cot only
as described in this manual.
An unrestrained body can fall o the cot. Use restraints to
secure the body on the cot.
Helpers can cause injury or be injured. Maintain control
of the cot, operate the controls, and direct all helpers.
Improper maintenance can cause injury. Maintain the cot
only as described in this manual.
Attaching improper items to the cot can cause injury. Use
only Ferno-approved items on the cot.
Improper parts and service can cause injury. Use only
Ferno parts and Ferno-approved service on the cot.
Modifying the cot can cause injury and damage. Use the
cot only as designed by Ferno.

© Ferno-Washington, Inc. 234-3307-02 November 2008 5
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™
1.5 Safety and Instruction Labels
Safety and instruction labels place important information from the users’ manual on the cot. Read and follow label instructions.
Replace worn or damaged labels immediately. New labels are available from EMSAR (in the U.S.A. and Canada, page 28) or
fromyourFernodistributor.Thefollowinglabelsareafxedtothecot.
Safety Information
Identication and Load-Limit Label:
This label shows the model of your cot and
its load limit.
Cot may be Operated
by One Trained Operator
Read the Users’ Manual Do Not Lubricate Lubricate
Load Limit
LockedUnlockedGeneral Warning - Potential Injury
1000 lb
454 kg
Loading Handle
(at operator end):
This handle unlocks
the loading-end leg
and allows it to fold
loading the cot into
a vehicle.
Loading-End Leg
Control Handle
(at loading end):
This handle unlocks
the loading-end leg
to raise or lower the
cot.
Operator-End Leg
Control Handle (at
operator end): This
handle unlocks the
operator-end leg to
raise or lower the cot.
Users’ Manual Label:
This label reminds the
operator to read the
users’ manual and
tells how to obtain
additional manuals.
1.6 Symbol Glossary
Thesymbolsshownanddenedbelowareusedonthecotand/orinthisusers’manual.Fernousessymbolsrecognizedby
the International Standards Organization (ISO), the American National Standards Institute (ANSI), and the mortuary services
industry.

6© Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
2  OPERATOR SKILLS AND TRAINING
Operator Skills and Training
2.3 Height and Strength Considerations
The cot is designed so that during unloading, the
operator lifts the cot only until the rear set of legs unfolds
and locks.
However, if the vehicle is parked in a low area or on an
incline, the operator (and any helpers) may need to lift the
operator end of the cot off the ground to provide clearance
for the rear legs to unfold completely and lock (see
illustration above). When the legs have locked, set the cot
on the ground.
After the front legs unfold, test that they have locked by
pushing them against the bumper — the legs should not
fold. If they do, lift the cot high enough to allow both sets of
legs to unfold completely and lock.
Supporting the weight of the cot and load requires
greater strength from a short operator than from a tall
operator, because a short operator must raise his or her arms
higher in relation to the shoulders.
Note: Use additional help as needed to lift the weight of the
cot and load (see Using Additional Help, page 24).
Clearance
WARNING
Untrained operators can cause injury or be injured.
Permit only trained personnel to operate the cot.
2.2 Training
Operator trainees need to:
read and understand this manual.●
be trained on the use of the cot.●
practice with the cot before using it with a patient.●
record their training information. A sample training●
record sheet is provided on page 31.
2.1 Skills
Operators using the cot need:
a working knowledge of mortuary-service●
procedures.
a complete understanding of the procedures described●
in this manual.
2
1
1
2

© Ferno-Washington, Inc. 234-3307-02 November 2008 7
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™
3  ABOUT THE COT
3.1 Description
The Models 24-MAXX™Cot, 24-miniMAXX®Cot, and
24H-miniMAXX™are mortuary-service products designed
for body transport.
In this manual, the term “cot” refers to all three versions of
the cot. Use of all three versions is identical. The cots differ
only in width and loading height. Where width or loading
height is discussed, the model name of the cot is used.
The cot is for professional use by one or more trained
operators. The cot is designed for use with a Ferno® Model
5 Mortuary Cot Fastener (not included). Two 7-foot, 2-piece
restraints and a 1-inch-thick locking mattress are included
with the cot.
COT FEATURES:
1,000 lb (454 kg) load capacity●
Extra-wide 25" (63 cm) bed surface for a large●
body (24-MAXX)
Standard-width 22" (56 cm) bed surface●
(24-miniMAXX and 24H-miniMAXX)
Higher 32" (81 cm) loading height (24H-miniMaxx)●
Standard 26" (65 cm) loading height (24-MAXX and●
24-miniMaxx)
Independent locking legs reduce the lifting required●
for loading and unloading
7 transfer positions●
Legs can be locked at different heights at each end of●
cot
Burgundy powdercoat on legs (24-MAXX)●
Gloss-black powdercoat on legs (24-miniMAXX and●
24H-miniMAXX)
6" Swivel transport wheels with wheel locks (operator●
end)
6" Fixed transport wheels (loading end)●
5" Loading wheels at loading end; loading posts at●
operator end
Footrest●
VEHICLE INFORMATION
If the vehicle has a bumper extension, the extension should
not exceed 14" (35.6 cm). The rear compartment should have
aleveloorlargeenoughforthefoldedcot,andaFerno®
cot fastener installed.
About the Cot
3.2 Cot Options
The cot may be ordered from Ferno with the accessories
shown below factory-installed. The accessories are also
available separately. To order, see Accessories and Related
Products, page 28.
A Pair of
Side Lift Handles
May Be
Factory-Installed
On Your Cot
Sidearms May Be
Factory-Installed On
Your Cot
WARNING
Improper use of the cot can cause injury. Use the cot
only for the purpose described in this manual.
LOAD LIMIT
Inspect the cot if the load limit has
been exceeded (See Inspecting the
Cot, page 26).
1000 lb
454 kg

8© Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™About the Cot
Restraints (Set of 2 Included)
Mattress (Bottom Side Shown)
Anchor (4)
24miniMAXX and 24HminiMAXX
All components of these two models are the same
as the 24-MAXX. The cots differ only in width and
loading height (see Specications, page 9).
3.3 Components
Footrest
Loading
Wheel (2)
Fixed Transport
Wheel (2)
Loading Post (2)
Loading-End Leg
Control Handle (black)
Operator-End Legs
Bumper Glide (2)
Swivel Transport Wheels
with Wheel Locks (2)
Loading Handle
(black)
Operator-End Leg
Control Handle (red)
24MAXX COT COMPONENTS
LOADING END OPERATOR END
Loading-End
Legs
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.

© Ferno-Washington, Inc. 234-3307-02 November 2008 9
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™
3.4 Specications
24miniMAXX and 24H-miniMAXX
Mostgeneralspecicationsareroundedtothenearestwhole
number. Metric conversions are calculated before rounding
the Imperial measurements. For more information, contact
Ferno Customer Relations (page 2) or your Ferno distributor.
Ferno reserves the right to change specications without
notice.
Note: To see how dimensions are determined, please refer to
Specication Reference Points on page 10.
GENERAL DIMENSIONS
Load Limit 1000 lb (454 kg)
Weight* 72 lb (33 kg)
Cot Width (overall) 23-5/8 in (60 cm)
Bed Surface Width 22 in (56 cm)
* Without mattress and restraints.
LENGTH
Overall Frame Length 76 in (192 cm)
Bed Surface Length 72 in (182 cm)
Overall Folded Length 79 in (201 cm)
OVERALL HEIGHT
Highest Position 40 in (100 cm)
In Folded (Vehicle) Position 14 in (34 cm)
LOADING HEIGHT
Loading Height: 24-miniMAXX 26 in (65 cm)
Loading Height: 24H-miniMAXX 32 in (81 cm)
BED HEIGHT
Highest position 34 in (85 cm)
Lowest transfer position 13 in (32 cm)
Folded (vehicle) position 9 in (23 cm)
24MAXX
Mostgeneralspecicationsareroundedtothenearestwhole
number. Metric conversions are calculated before rounding
the Imperial measurements. For more information, contact
Ferno Customer Relations (page 2) or your Ferno distributor.
Ferno reserves the right to change specications without
notice.
Note: To see how dimensions are determined, please refer to
Specication Reference Points on page 10.
GENERAL DIMENSIONS
Load Limit 1000 lb (454 kg)
Weight* 74 lb (34 kg)
Cot Width (overall) 26 in (66 cm)
Bed Surface Width 25 in (63 cm)
* Without mattress and restraints.
LENGTH
Overall Frame Length 76 in (192 cm)
Bed Surface Length 72 in (182 cm)
Overall Folded Length 79 in (201 cm)
About the Cot
OVERALL HEIGHT
In Highest Position 40 in (100 cm)
In Folded (Vehicle) Position 14 in (34 cm)
LOADING HEIGHT
Loading Height 26 in (65 cm)
BED HEIGHT
Highest position 34 in (85 cm)
Lowest transfer position 13 in (32 cm)
Folded (vehicle) position 9 in (23 cm)

10 © Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™About the Cot
3.5 Cot Positions
Transfer Positions
Legs
Vehicle Position (Folded)
Legs
7 Level Positions
REFERENCE POINTS FOR
SPECIFICATIONS ON PAGE 9
Bed Height
Loading Height
Overall Folded Length
Overall Frame Length
Bed Surface Length
Loading Height
24-miniMAXX and 24-MAXX
24H-miniMAXX
Overall Height

© Ferno-Washington, Inc. 234-3307-02 November 2008 11
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™
4  USING THE FEATURES
Using the Features
4.1 Bed Panel Slots
Several slots and notches have been cut into the cot bed
panel. They are designed for attaching the restraints and
accessories to the cot.
Figure 1 shows a top-down view of the cot bed panel and
main frame.
The four slots for the restraints are narrow and are●
designed for only the restraints.
The optional sidearms attach to the four large slots●
nearest the operator end and loading end of the cot.
The optional side-lift handles attach to any of the six
●
large slots (Figure 1).
Note: The sidearm slots are large enough to allow sidearms
AND side-lift handles to be attached if desired. Cots before
serial number 07041779 have smaller slots that allow only
one accessory at these locations.
Figure 1 - Restraint and Accessory Slots
Slot for Side-Lift Handle
Slot for Sidearm AND/OR
Side-Lift Handle
Slot for Sidearm AND/OR
Side-Lift Handle
Slot for Sidearm AND/OR
Side-Lift Handle
Slot for Sidearm AND/OR
Side-Lift Handle
Slot for Side-Lift Handle
Restraint SlotRestraint Slot
Restraint SlotRestraint Slot

12 © Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
Using the Features
4.2 Restraints
A set of two 7-foot, 2-piece restraints is supplied with the cot
(Figure 2). Always use both restraints to secure the body to
the cot. Attach and adjust restraints so they properly secure
the body without damaging it. Use additional restraints if
needed.
Keep restraints fastened when not in use to prevent them
from interfering with cot operation (Figure 3).
To attach, use, and maintain restraints, see the restraint
users’ manuals included with the restraintst. Additional free
manuals are available from Ferno Customer Relations (page
28).
The cot bed panel has four slots for use with the two
restraints provided (Figure 1, page 11).
Restraints may also be attached to any unused sidearm or
side lift handle slots. This allows for different strapping
congurationsorfortheuseofadditionalrestraints.Follow
your protocols to properly restrain the body on the cot.
Figure 3 - Restraints Attached
Figure 2 - Restraints

© Ferno-Washington, Inc. 234-3307-02 November 2008 13
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™Using the Features
4.3 Control Handles
The cot has three control handles. Use the controls to unlock
the legs to raise or lower the cot, to load the cot into a vehicle,
or to unload the cot from a vehicle.
RAISING OR LOWERING THE COT
To raise or lower the loading end of the cot, stand at the
loading end and use the (black) loading-end leg control
handle (Figure 4).
To raise or lower the operator end of the cot, stand at the
operator end and use the (red) operator-end leg control
handle located on the left side (Figure 5).
When two operators raise or lower the cot, they use both
leg-control handles simultaneously. See Changing Cot
Levels With Two Operators, page 17.
LOADING/UNLOADING THE COT
When loading the cot into a vehicle, use the black loading
handle located on the right side at the operator end of the
cot (Figure 5) to fold the front legs, followed by the rear-leg
control handle. See Loading the Cot, page 21.
When unloading the cot from a vehicle, only the red
operator-end leg control handle is used. See Unloading the
Cot, page 22.
Figure 4 - (Loading End) Loading-Leg Control Handle
Loading-End
Leg Control Handle
(Black)
Important
CONTROLHANDLE REMINDER
Both control handles for the loading-end legs are black.
The control handle for the operator-end legs is red.
Figure 5 - Operator-End Control Handles
Operator-End Leg Control
Handle (Red)
Loading Handle (Black)
Used to Load Cot Only

14 © Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
4.4 Mattress
The four hooks on the bottom of the mattress (Figure 6) are
used to anchor the mattress to the cot and limit its movement
during body transfer.
Attach the mattress by laying it on the cot and feeding each
of the hooks through holes in the bed panel.
To remove the mattress, slide one hand under the mattress
and apply a little upward pressure while removing each
hook from the bed surface with your other hand.
Figure 6 - Mattress
Using the Features
4.5 Wheel Locks
Theoperator-endswivelwheelsarettedwithwheellocks.
Use the wheel locks to help keep the cot stationary while
transferring a body on or off the cot.
The wheel locks are not designed for use as brakes. Remain
with the cot and maintain control of it at all times.
To engage a wheel lock, press down on the red lock lever
with your toe (Figure 7). To release, slide your toe under the
lock lever and left it up.
4.6 Sidearms (Optional)
If installed, the two sidearms (Figure 8) provide additional
security by helping to keep the body from sliding on the cot.
Keep the sidearms raised except when transferring a body
onto or off from the cot.
Sidearms may be factory-installed, or are available as an
accessory. See Accessories and Related Products, page 28,
to order accessory equipment.
To lower, pull the sidearm release pin (Figure 8) and lower
the sidearm. To raise, rotate the sidearm upward until the pin
locks in place.
Figure 7 - Engaging a Wheel Lock
Figure 8 - Pulling the Sidearm Release Pin
Important
Sidearms are not designed for lifting. Grasp only the
main frame or side handles to lift the cot.
Hook (4)

© Ferno-Washington, Inc. 234-3307-02 November 2008 15
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™
4.7 Side Lift Handles (Optional)
The optional side lift handles (Figure 9) provide additional
grasping points for helpers to assist raising or lowering
the cot, loading the cot into a vehicle or unloading it from
a vehicle. The handles can also be used to help steer and
maneuver the cot. Up to six side lift handles (3 pairs) may
be attached to the cot.
Side lift handles may be factory-installed, or are available as
an accessory. See Accessories and Related Products, page
28, to order accessory equipment.
LOCKING POSITIONS
Each handle locks in three positions:
unfolded, perpendicular to the cot frame (for use)●
folded, parallel with the cot frame, toward the operator●
end of the cot (for storage)
folded, parallel with the cot frame, toward the loading●
end of the cot (for storage)
Note: Interference with cot structures may limit folding to
only one storage position.
Remember that the overall width of the cot increases when
the handles are unfolded. Fold the handles when working in
narrow areas.
OPERATING THE HANDLES
To unfold a handle for use: in a continuous motion, pull
the spring-loaded handle in line with the cot frame to
release the lock (Figure 10, Step 1), then swing the handle
perpendicular to the cot frame (Figure 10, Step 2). Release
the handle to lock it in the unfolded position.
To fold a handle for storage: in a continuous motion, pull
the spring-loaded handle outward to release the lock (Figure
11, Step 1), then swing the handle right or left until it is
parallel with the cot frame (Figure 11, Step 2). Release the
handle to lock it in the folded position.
Using the Features
Figure 9 - Using the Side Lift Handle
Important
Be aware of the cot width when the handles are
unfolded. If necessary, fold the handles before entering
doorways, the vehicle, or other narrow spaces.
Figure 10 - Unfolding the Handle
1
2
Figure 11 - Folding the Handle
1
2

16 © Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
5  USING THE COT
5.1 Before Placing the Cot in Service
Personnel who will work with the cot need to read this●
manual.
Set up the cot. Attach the mattress, restraints and any●
accessories.
Conrm that the cot operates properly. Follow the●
instructions in Inspecting the Cot, page 26.
5.2 General Guidelines for Use
The cot can be operated and maneuvered by one●
person, but operates and maneuvers more easily when
controlled by two operators.
The operator or operators must maintain control●
of the cot at all times.
Operator(s) may need help when working with heavy●
loads. See Using Additional Help, page 24.
Operator(s) and helpers must work together.●
Communicate with one another and operate the cot
using coordinated movements.
Follow standard mortuary-service procedures when●
operating the cot.
Stay with the cot at all times.●
Always use restraints.●
Read the cot fastener users’ manual for instructions on●
using the fastener.
Using the Cot
Read Users’ Manual For
Operating And Safety
Information
Cot May Be Operated
By One Trained Operator
WARNING
Improper operation can cause injury. Operate the
cot only as described in this manual.
WARNING
An unrestrained body can fall of the cot. Use
restraints to secure the body on the cot.
R

© Ferno-Washington, Inc. 234-3307-02 November 2008 17
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™Using the Cot
5.3 Changing Cot Levels
With Two Operators
When raising or lowering the cot with two operators,
communicate with one another and use coordinated
movements to change the cot from one level to another.
Maintain control of the cot at all times.
LOWERING THE COT WITH TWO OPERATORS
Both Operators:1. Stand at opposite ends of the cot,
facing each other. Grasp the cot main frame using an
underhand grip.
Both Operators:2. Slightly lift the cot to ensure you
are holding the weight of the body and cot (Figure
12), then squeeze the leg control handles and begin
lowering the cot (Figure 13).
Loading-End Operator:3. If the cot is empty or has a
light load, you may need to push downward slightly
to begin lowering the front legs.
Both Operators:4. Lower the cot until it nears the
desired height, then release the control handles and
continue lowering the cot until both sets of legs lock
into place.
Figure 13 - Work Together and
Use Coordinated Movements
Operator-End
Operator
Loading-End
Operator
RAISING THE COT WITH TWO OPERATORS
Both Operators:1. Stand at opposite ends of the cot,
facing each other. Grasp the cot main frame using an
underhand grip.
Both Operators:2. Slightly lift the cot to ensure you are
holding the weight of the body and cot (Figure 12),
then squeeze the leg control handles and begin raising
the cot (Figure 13).
Both Operators:3. Raise the cot until it nears the desired
height, then release the control handles and continue
raising the cot until the legs lock into place. Lift until
the wheels come off the ground to ensure both sets of
legs have locked at the new position, then set the cot
on the ground.
Important
Slightly lift your end of the cot before raising or lowering
it. This ensures that you have assumed the weight of
the cot before you squeeze a control handle.
Figure 12 - Lift the Cot Slightly
Before Squeezing the Control Handles

18 © Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
5.4 Changing Cot Levels
With One Operator
To change cot levels with only one operator, raise or lower
the cot in stages, repeating until the cot is at the desired
height.
Maintain control of the cot at all times.
Keep in mind that placing the cot at too great a tilt can cause
the body to slide off.
LOWERING THE COT WITH ONE OPERATOR
Begin at the1. loading end of the cot and grasp the cot
main frame using an underhand grip.
Slightly lift the end of the cot, then squeeze the2.
loading-end leg control handle and lower the loading
end of the cot one or two positions (Figure 14).
Note: If the cot is empty or has a light load, you may need
to push downward slightly to begin lowering the loading-
end legs.
Release the control handle and verify that the loading-3.
end legs have locked in the new position.
Move to the operator end of the cot and grasp the main4.
frame using an underhand grip.
Slightly lift the end of the cot, then squeeze the red5.
operator-end leg control handle and lower the operator
end of the cot the same number of positions as you
lowered the loading end during Step 2.
Release the control handle and verify that the operator-6.
end leg has locked in the new position.
Repeat Steps 1-6 as needed until the cot is at the7.
desired height.
Using the Cot
Important
Placing the cot at too great a tilt can cause the body to
slide o. Raise or lower the cot only one or two levels
at a time.
Important
When only one operator is present, lower the loading
end of the cot rst, before lowering the operator end.
Important
Slightly lift your end of the cot before raising or lowering
it. This ensures that you have assumed the weight of
the cot before you squeeze a control handle.
Figure 14 - Lower the Loading End First
Loading
End
Operator
End

© Ferno-Washington, Inc. 234-3307-02 November 2008 19
24-MAXX™, 24-miniMAXX®, 24H-miniMAXX™Using the Cot
5.5 Rolling the Cot
GENERAL GUIDELINES
Use help as needed to safely control the weight of the●
body and cot (Using Additional Help, page 24).
Maintain control of the cot at all times.●
Roll the cot on smooth, unobstructed surfaces●
whenever possible.
To cross a low obstacle such as a door sill, lift the cot●
slightly to take the weight off the wheels so the wheels
roll smoothly over the obstacle.
Two or more operators/helpers lift and carry the cot●
over a high obstacle such as a curb.
TO ROLL THE COT
Verify that the restraints are securely fastened around1.
the body.
Raise the cot to its highest position.2.
Grasp the main frame at the operator end of the cot and3.
push and steer the cot (Figure 16).
If a second operator is present: grasp the main frame at4.
the loading end of the cot and assist the operator-end
operator.
Note: Although the swivel wheels are only at the operator
end, steering may be easier from the loading end under
certain circumstances. Follow your mortuary protocols.
RAISING THE COT WITH ONE OPERATOR
Begin at the1. operator end of the cot and grasp the cot
main frame using an underhand grip.
Slightly lift the end of the cot, then squeeze the red2.
operator-end leg control handle and raise the operator
end by one or two positions (Figure 15).
Release the handle and verify that the operator-end leg3.
has locked in the new position.
Move to the loading end of the cot and grasp the main4.
frame.
Slightly lift the loading end of the cot, then squeeze5.
the control handle and raise the loading end the same
number of positions as you moved the operator end
during Step 2.
Release the control handle and verify that the loading-6.
end leg has locked in the new position.
Repeat Steps 1-6 as needed until the cot is at the7.
desired height.
Figure 16 - Rolling the Cot
Loading EndOperator End
Figure 15 - Raise the Operator End First
Important
Always raise the operator end of the cot before raising
the loading end.
Loading
End
Operator
End

20 © Ferno-Washington, Inc. 234-3307-02 November 2008
24-MAXX™, 24-miniMAXX® , 24H-miniMAXX™
5.6 Transferring the Body
Onto the Cot
Roll the cot as close to the body as possible.1.
Raise or lower the cot so it is level with the body.2.
Unfasten the restraints.3.
Place the body in a body pouch or use an accessory4.
such as a transfer board to ease transferring the body
onto the cot. For a list of accessories, see page 28.
Note: Ferno recommends that you position the body with
the head at the operator end of the cot, if possible. This
orientation will place the body in a ‘heads-up’ position if
youneedtotiltthecotinaconnedarea(see“Maneuvering
the Cot in a Conned Area,” below).
Fasten the restraints. Cover the body with a body cover5.
if desired.
Raise the cot to the highest position before rolling.6.
5.7 Maneuvering the Cot
In a Conned Area
The cot can be rolled in a tilted position for easier
maneuveringin conned spacessuch as narrowhallways,
elevators, or stairways.
Maintain control of the cot at all times.
To roll the cot in a tilted position:
Fasten and adjust the restraints to secure the body on1.
the cot. Use additional restraints if necessary (follow
your protocols).
Lower the cot to the lowest transfer position (Figure2.
17).
Stand at the operator end of the cot, grasp the main3.
frame, and lift the cot onto its loading wheels and front
transport wheels (Figures 18 and 19). Roll the cot in
this position.
Use additional help as needed to help lift, hold, and4.
push the cot (see Using Additional Help, page 24).
Figure 17 - Cot in Lowest Transfer Position
Using the Cot
Figure 18 - Rolling Using the Loading Wheels and Front
Transport Wheels
Figure 19 - Rolling in a Tilted Position
