Fimco UTL-60-7-TSC User manual

60 Gallon Corrosion-Resistant Polyethylene Tank •
Deluxe Pistol-Grip Handgun w/25 Ft. Hand Gun Hose •
7-Nozzle Boom Assembly - 140" Spray Coverage •
Adjustable Boom Height •
12 Volt, 3.8 GPM Diaphragm Pump •
Technical Specifications
Form No. 1855 [5008178 (09/11)] Printed in the U.S.A.
Model: UTL-60-7-TSC (2152366)
(60 Gallon Utility Sprayer w/ 7-Nozzle Boom Assembly)
Owner's Manual
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your utility
cart sprayer. Please read it carefully, as it furnishes information
which will help you achieve years of trouble-free operation.
Warranty/Parts/Service
For home usage, products are warranted for one year from date
of purchase against manufacturer or workmanship defects.
Commercial users have a 90 day warranty.
Your authorized dealer is the best source of replacement parts
and service. To obtain prompt, efficient service, always
remember to give the following information...
- Correct Part Description and/or part number.
- Model number/Serial number of your sprayer.
Part descriptions and part numbers can be obtained from the
illustrated parts list section(s) of this manual.
Whenever you need parts or repair service, contact your
distributor/dealer first. For warranty work, always take your
original sales slip, or other evidence of purchase date, to your
distributor/dealer.
Assembly
The sprayer is fully assembled at the factory. The only
assembly necessary is to thread the pressure gauge in
place, and to hook up the wiring to an existing 12 volt power
source.
The red wire of the two wire set must be connected to the
positive post on the battery or the “Hot” connection on a
switch or to the ammeter. The brown wire may be grounded
or connected to the negative battery post. Install all parts of
the boom assembly to the boom brackets as shown in the
exploded view drawing. The in-line switch turns the unit on
and off. Running the pump dry will not harm the pump for
short periods of time.
Read the operating instructions and then run the sprayer
using only water for testing. When everything tests all right,
add the desired chemical mixture and water combination
and start the spraying operation.
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: [phone] : Toll Free Fax: [phone]
www.fimcoindustries.com

After Spraying
After use, fill the sprayer tank part way with water. Start the
sprayer, and allow the clear water to be pumped through the
plumbing system and out through the spray nozzles.
Refill the tank about half full with plain water and use FIMCO
Tank Neutralizer and Cleaner, and repeat cleaning instructions
above.
Flush the entire sprayer with the neutralizing/cleaning agent,
then flush out one more time with plain water. Follow the
chemical manufacturer's disposal instructions of all wash or
rinsing water.
For the boom, (if applicable) remove the tips and screens from
the nozzle assemblies. Wash these items out thoroughly. Blow
the orifice clean and dry. If the orifice remains clogged, clean it
with a fine bristle (NOT WIRE) brush, or with a toothpick. Do
not damage the orifice. Water rinse and dry the tips before
storing.
WARNING: Some chemicals will damage the pump valves
if allowed to soak untreated for a length of time! ALWAYS
flush the pump as instructed after each use.
Time Required in seconds to travel a distance of:
17 344.0
5.0
6.0
7.0
9.0
8.0
10.0
7.6
6.8
9.7
8.5
14
11
15
14
19
17
23
27
100 Ft.
68 sec.
2.0
3.0
1.0
(Miles per Hour)
Speed in M.P.H.
Speed Chart
136 sec.
34
23 45
68
200 Ft.
51
23
20
26
29
41
34
205 sec.
300 Ft.
102
68
Page 2
Operation & Calibration
The performance of any agricultural chemical depends upon
the proper application of the correct amount.
Be sure that your equipment has been calibrated before
spraying.
Initially begin spraying by opening the handgun. This will
enable the air in the line to be eliminated through the tip,
while building pressure.
The pumping system draws solution from the tank, through
the strainer, and to the pump. The pump forces the solution
under pressure to the handgun or boom nozzles.
Pressure may be decreased by opening the bypass valve
to the tank. When it is closed the highest spraying pressure
will be reached.
• Open the handgun by squeezing the handle lever
• Rotating the adjustable nozzle tip on the handgun will
change the tip from a straight stream to a cone pattern (finer
mist). Be sure the thumb nut on the adjustment nozzle is
tight.
• The pump motor's demand switch shuts off the motor
when the handgun, bypass valve and boom lines are fully
closed.
The system remains pressurized, and the pump motor will
restart automatically when the handgun or boom line is
opened. If, however, the bypass line is open, the pump will
not shut off automatically.
• The 7 nozzles are fixed on 20" spacing.
• All seven nozzles spraying at the same time will allow a
maximum coverage of 140 inches.
Adjusting Pressure
- When the bypass line valve is closed, pressure is at the
highest point.
- Opening the valve will decrease pressure.
Testing the Sprayer
It is important to test the sprayer with plain water before
actual spraying is attempted. This will enable you to check the
sprayer for leaks in the plumbing system.
1. Open tank lid and be sure the tank is clean and free of
foreign material. Fill the tank about half full with plain
water.
2. Open the valve on the filter/valve assembly next to the
pump and allow water to flow to the pump. The valve is
located at this point to enable the strainer to be taken apart
for cleaning.
3. There are two valves located on the valve and handgun
bracket. One of these is a shut-off for the boom and the other
is for pressure adjustment. Open the valve that controls flow
to the boom and open the bypass control valve.
4. You may now start the sprayer.
5. The pressure should now be increased to as desired by
closing the bypass valve.
6. During this testing period be sure to observe the spray
pattern given by the spray nozzles. Each nozzle should
overlap the next nozzle approximately 30%. If there is any
pattern distortion, it will be necessary to remove and clean the
affected tips.
CAUTION: Never use a metal object or other sharp item
for cleaning a nozzle tip. It is better to use a nozzle brush
(not wire brush) or compressed air for tip cleaning.
Drain all water out of your sprayer, paying special attention to
the pump, handgun, and valve(s). These items are especially
prone to damage from chemicals and freezing weather.
The sprayer should be winterized before storage by pumping a
solution of RV antifreeze through the entire plumbing system.
This antifreeze solution should remain in the plumbing system
during the winter months. When spring time comes and you
are preparing your sprayer for the spray season, rinse the
entire plumbing system out, clearing the lines of the antifreeze
solution. Proper care and maintenance will prolong the life of
your sprayer.
Winter Storage
Using the Boom Nozzles
Four things must be considered before spraying with the boom:
How much chemical must be mixed in the tank. 1.
Rate of spray (gallons per acre to be sprayed) 2.
What pressure (p.s.i.) will be used. 3.
Speed traveled (mph) while spraying. 4.
- Refer to the chemical label to determine your chemical
mixture.
- See the tip chart to determine the pressure to be used. The
chart will also show the speed used when spraying.
- Start the pump and open the valve(s) to the boom nozzles.
- Check the spray pattern. Usually you can see the coverage
better on a solid concrete surface, such as a driveway.
- The spray nozzles should be approx. 17" to 22" above the
objects being sprayed.

27
11
3
18
19
13
13
35
18
23
3
3
30.1
19
30.3
30.4
30.2
30.5
30.4
31.2
31.1
20
31.3
22
7
8
17
27
11
12 2
2
29
28
11
2
34
26
14
11
34
11
2
14
12
2
21
16
32.4
32.5
32.6
32.3
32.2
32.1
9
5
8
3
33
6 4
15 15
15 15
1515
15 15
15 15
10
10
25
24.4
24.1
24.2
1
24.3.6
24.3.3
24.3.2
24.3.1
24.3.5
24.3.4
815
Page 3
Exploded View: UTL-60-7-TSC (2152366)

2.1
Item
No
Part
Number
Qty Description
List
Price
2.2 5020416 3 Hose, 1/2"-1 Brd. x 19 3/8" 2.71
2.3 5020144 2 Hose, 1/2"-1 Brd. x 10" 1.77
2.4 5051114 14 Hose Clamp (3/8"-1/2") .63
2.5 5275067 2 Standard "ELL" Nozzle Sub-Assembly 8.58
2.5.1 5056023 1 Nylon Elbow Assembly, 11/16" U.N.F. x 1/2" HB 1.57
2.5.2 5116019 1 Nozzle Strainer, Red (50 Mesh) 1.17
2.5.3 5046052 1 Nylon Nozzle Cap, 11/16" U.N.F. Thread .50
2.5.4 5273796 1 1 1/4" Square Boom Nozzle Clamp (BC114) 1.80
2.5.5 5018265 1 80 Degree Flat Spray Tip, Yellow .86
2.6 5275068 5 Standard "Tee" Nozzle Sub-Assembly 8.58
2.6.1 5273796 1 1 1/4" Square Boom Nozzle Clamp (BC114) 1.80
2.6.2 5116019 1 Nozzle Strainer, Red (50 Mesh) 1.17
2.6.3 5046052 1 Nylon Nozzle Cap, 11/16" U.N.F. Thread .50
2.6.4 5056027 1 Nylon Tee, 11/16" U.N.F. x 1/2" HB-1/2" HB 1.66
2.6.5 5018265 1 80 Degree Flat Spray Tip, Yellow .86
2.7 5086003 1 Nylon Hose Tee, 1/2" HB 1.08
(List Prices are Subject to Change)
Item
No
Part
Number
Qty Description
List
Price
1 5274507 1 Boom Sub-Assembly (7-Nozzle) 115.00
1.1 5006092 4 3/8"-16 Hex Locknut .25
1.2 5006307 2 5/16"-18 Hex Whiz (Flange) Locknut .25
1.3 5006345 2 3/8"-16 Flange Locknut (Grade F) .25
1.4 5034159 1 Square U-Bolt, 5/16" x 1 5/16" x 1 7/8" .99
1.5 5274458 1 Center Boom Weldment (BK-70) 40.55
1.6 5274459 2 Outer Boom Weldment 24.99
1.7 5046344 2 Square Cap, Black (1 1/4" Square Tube) .36
1.8 5019228 2 Extension Spring 5.50
1.9 5038620 1 Boom Retainer Bracket 3.49
1.10 5006054 4 3/8"-16 Hex Nut .25
1.11 5016030 8 Flatwasher, 3/8" .25
1.12 5034563 2 H.H.C.S., 3/8"-16 X 3 3/4" .84
2 5274555 1 Harness Assembly (BK-70) 83.95
2.1 5020307 2 Hose, 1/2"-1 Brd. x 23" 3.49
2.5.2
Elbow (2xs)
2.5.1
2.5.3
2.5.5
2.5.4
1.6
1.7
1.4
1.2
1.3
2.6.3
Tee (5xs)
2.6.1
2.6.2
2.6.5
2.6.4
1.9
2.6
1.12
2.1
1.5
2.2
1.3
1.12
1.6
2.3
2.7
2.6
2.6
2.2
7-Nozzle 'Standard' Boom Assembly
1.7
2.6 2.2
2.5
Spring Detail (2xs)
1.5
1.10
1.8
1.1
1.11
Page 4
Parts List: UTL-60-7-TSC (2152366)
(List Prices are Subject to Change)
Item
No
Part
Number
Qty Description
List
Price
1 5006186 4 #10-24 Hex Whiz (Flange) Locknut .25
2 5006259 16 3/8"-16 Hex Whiz (Flange) Locknut .25
3 5006307 10 5/16"-18 Hex Whiz (Flange) Locknut .25
4 5006351 1 1/2" Poly Nut .59
5 5010039 2 Nylon Elbow, 1/2" MNPT x 1/2" HB 1.06
6 5020122 1 Hose, 1/2"-1 Brd. x 48" 5.88
7 5020135 1 Hose, 3/8"-1 Brd. x 25 Ft. 17.25
8 5020307 2 Hose, 1/2"-1 Brd. x 23" 3.49
9 5020462 1 Hose, 1/2"-1 Brd. x 31" 2.77
10 5034079 4 H.H.C.S. 3/8"-16nc x 1" Long .25
11 5034099 10 H.H.C.S., 3/8"-16 x 3/4" .50
12 5034101 4 H.H.C.S., 3/8"-16 x 1 3/4" .50
13 5034159 2 Square U-Bolt, 5/16" x 1 5/16" x 1 7/8" .99
14 5038698 4 Plastic Tank Hold-Down Leg Clip 2.93
15 5051114 10 Hose Clamp (3/8"-1/2") .63
16 5058188 1 Tank Lid w/Lanyard 10.50
17 5075014 2 Rubber Grommet (Black) 2.79
18 5095176 2 Boom Mount, 40/60 Gallon Utility Sprayer 4.09
19 5117300 6 5/16"-18 x 1" Flange Whiz Lock Screw .25
20 5167007 1 Pressure Gauge, 0-100 p.s.i. 6.75
21 5169249 1 60 Gallon Elliptical Tank (White) 139.00
22 5273959 1 Deluxe Pistol-Grip Handgun w/X-26 Tip 24.95
23 5274443 1 96" Lead Wire Assembly 9.99
24 5274808 1 Pump Sub-Assembly 175.00
24.1 5275704 1 Gold Series 3.8 g.p.m. Pump 159.00
24.2 5010426 1 90 Deg. Port Elbow x 1/2" HB 2.25
24.3 5275570 1 Filter/Valve Sub-Assembly 11.38
24.3.1 5005241 1 Nylon Swivel Adapter Spud, 1/2" NPT 1.25
24.3.2 5116242 1 Strainer, 1" Filter Washer .31
24.3.3 5143188 1 Nylon Shut-Off Valve (3/4" GHT) 3.19
24.3.4 5010430 1 Port Kit Elbow, 1/2" FNPT 2.79
Item
No
Part
Number
Qty Description
List
Price
24.3.5 5006209 1 Poly Knurled Swivel Nut, 3/4" FGHT .70
24.3.6 5067121 1 Poly Hose Fitting, 3/4" MGHT 1/2" HB .81
24.4 5117166 4
#10-24 x 1 1/4" Phillips Truss Head Screw .25
25 5274880 1 Pkg. (2) Handgun Clips & (2) Screws 2.85
26 5274994 2 Slide Tube Weldment 8.99
27 5274997 2 Boom Mount Bracket Weldment 12.50
28 5275000 1 Upright Tube Weldment (L.H.) 12.01
29 5275001 1 Upright Tube Weldment (R.H.) 12.01
30 5275405 1 Valve Mount Sub-Assembly 36.33
30.1 5038704 1 Valve Mount Bracket 21.63
30.2 5038638 1 Handgun Holder Bracket 11.83
30.3 5006186 2 #10-24 Hex Whiz (Flange) Locknut .25
30.4 5075014 2 Rubber Grommet (Black) 2.79
30.5 5117234 2
#10-24 x 1/2" Phillips Truss Head Machine
Screw
.25
31 5275501 1 Top Valve Sub-Assembly 12.44
31.1 5010193 1 Nylon Tee, 1/2" FNPT w/1/4" Port (Gauge) 12.08
31.2 5010039 1 Nylon Elbow, 1/2" MNPT x 1/2" HB 1.06
31.3 5010038 1 Nylon Elbow, 1/2" MNPT x 3/8" HB 1.05
32 5275502 1 Bottom Valve Sub-Assembly 11.28
32.1 5010148 1 Nylon Street Elbow, 1/2" MNPT x 1/2" FNPT 3.12
32.2 5005021 1 Nylon Adapter, 1/2" MNPT x 3/4" MGHT .79
32.3 5143204 1 Dual Hose Shut-Off "Y" Valve 4.38
32.4 5016066 2 Garden Hose Washer .20
32.5 5149011 2 Nylon Swivel, 1/2" Flat Seat Hose Barb .58
32.6 5006055 2 Nylon Swivel Nut, 3/4" FGHT .64
33 5275756 1 40-60 Gallon Utility Frame Weldment (Red) 95.00
34 5277486 2 Clamp Arm
35 BK-70A 1 7-Nozzle Boom Assembly (BK-70A) 215.00

Description
Base Plate (Quad Pump)
Pkg. (4) Grommets
15 Amp Mini Fuse
Rocker Switch
Upper Housing
Pkg. (2) Clips (Port Fitting)
Pressure Switch Assembly
Check Valve Kit w/O-Ring & Ferrules
Diaphragm Kit w/Pistons & (4) Screws
Cam/Bearing Kit, w/Set Screw
If none of the above will work, try pulling wire terminal "A" off of the spade terminal of the pressure switch, and cross it over and touch terminal "B". (You will need to remove
the pressure switch cap before doing this) If your pump runs when you do this, you know you will need to replace your pressure switch.
Another thing you can try is to take apart the switch box on the lead wire assembly (#5274443) with the (2) phillips head screws, and 'hot-wire' it together. Take the (2) wires
that are screwed to the rocker switch, off of the switch and twist them together. This will insure you are getting the full 12 volts to the pump. If your pump runs after doing this,
- Check line strainer (screen) at the inlet location, at the tank. You will need to unscrew the knurled nut to access this screen. (see exploded view later in this manual) The
ON/OFF valve should be closed while performing this, to insure you do not lose any solution. Periodically take the screen at this location out and clean it.
- Unscrew the head portion of your pump and remove the check valve assembly from inside. You need to make sure the O-Ring comes out with this piece as well. (See the
exploded view to help identify these components) These pieces can be cleaned which, in most cases, will help restore some, if not most, of your prime. Soak this check valve
in a solution of hot, soapy water. A good name-brand dishsoap works well for this. A little bit of 'scrubbing' with perhaps an old toothbrush may be required to actually break up
any build-up that may be on the check valve. Rinse off the pieces and replace them back into your pump. Reassemble the pump. Hook it back up and test.
2
6
Troubleshooting a 3.8 g.p.m. Pump:
- Check inline fuse on the wires on the pump. If blown, replace with new fuse. (15 Amp mini-blade fuse #5157206)
- Make sure BOTH on/off switches are in the 'on' position (-).
- Make sure you 12 volt source (battery) is fully charged.
- Insure a tight connection at the battery clips.
you will know that your lead wire assembly needs to be replaced.
- Make sure the bypass line valve is closed, to allow the pressure to build up in your system.
Pump runs, but does not prime:
*
Pump will NOT run:
5.2
*
5
Fittings with an asterisk (*) by
them, come together in a bag,
(1) 5168832 - 1/2" MNPT
(1) 5168833 - 1/2" Hose Barb
5.1
part #7771831.
5.2 5157203 1
5168824
5168826
51688288
6
7
1
1
1
Number
5029092
5075019
5157206
5157207
5168821
20408-000
1
4
5
5.1
2
3
Item
No
1
1
1
1
1
1
Qty
Part
#5275704 Pump
(12 Volt, 11 Amp, 3.8 gpm, 45 psi)
7
"A"
8
"B"
23.95
12.95
24.99
19.96
9.25
6.99
39.95
3.41
2.99
3.99
List
Price
3
1
4
10.5
MPH
16.6
14.9
.24
.30
.38
.34
MPH
12.9
.024
MPH
.034
.038
.030
Gallons Per 100 Sq. Ft. - Based on Water
Gallons Per Acre - Based on Water
Rate Chart for (No. 2) Spray Tip (80°)
33.2 22.266.4.2350
Height
Spray
Spray
18"
18"
Height
2
2
Tip
No.
Tip
No.
.039
.032.096
.118
.14
.1730
20
.059
.048
.136
.152
40
50
.20
.23 .076
.068 .045
.051
1.18
1.52
1.36
MPH
MPH
.2040
Pressure
(psi)
50
Capacity
(GPM)
.23
Pressure
20
30
(psi)
.14
.17
Capacity
(GPM)
.68 .45
1
MPH
2
.76
MPH
3 4
.51
MPH
.96 .48
.59
1 2
MPH
.32
.39
3 4
Height
Spray
18" 2
Tip
No.
41.8
MPH
59.2
51.2
Pressure
20
40
30
(psi)
.14
.20
.17
Capacity
(GPM)
20.9
29.6
25.6
1 2
MPH
14.0
19.8
17.2
MPH
3 4
6.68.813.3
.010
.012
.013
.016.024
.019
.018
.020
.027
.031 .015
.014
.14.18.27
.20
MPH
7.5
MPH
5
.31
MPH
10
.15
7.5
.13
.16
MPHMPH
.19
.24
5
MPH
.12
.10
10
MPH
5.6
7.5
7.9
6.9
8.4
11.9
10.3
5
MPH
4.2
5.9
5.1
MPH
10
Gallons Per 1000 Sq. Ft. - Based on Water
Page 5
