FingerTec FaceID 3 User manual

support @finger tec.com
3
RS232
RS485
485+
485-
485+
485-
485+
485-
485-
485+
GND
TXD
RXD
GND
WD1
WD2
RX+
RX-
RX+
RX-
GND
+12V
BEEP
GLED
RLED
INWD0
INWD1
GND
+12V
RJ45-1
RJ45-2
RJ45-3
RJ45-6
TCP/IP
Installation Guide
Face Recognition System for
Door Access
Step 1
Determine the Location and Positioning
of the Installation
• Avoid installing the terminals in locations that has contact with
a strong light source (e.g direct sunlight, spotlight, fluorescent
light, etc)
• Avoid installing the terminals in locations prone to high moisture
or condensation levels in the air
• The recommended installation height of the terminal from the
ground is 1.2 meter.
Step 2
Mounting Terminals
• After measuring the height accordingly and make relevant marking
on the wall, drill the screws into the wall to secure the back plate.
• Attach the terminal to the back plate and tighten the screws. Refer to
Appendix II for dimensions and measurements of installation.
INSTALLATION TIPS:
A good installation location of Face ID 4
must
1 - Avoid sunlight
2 - Be 2 meters away from any light source
e.g. ceiling direct flourescent light
3 - Suggested 1.2m from the ground level
(meas-ure from ground to the camera)
Step 3
Wiring for Power Supply
Use power cables (black and red) to connect to a linear power sup-
ply with specifications of 12VDC 3A (Marked A).
4 feet / 1.2 meter
(recommended)
© 2015 Timetec Computing Sdn Bhd. All rights reserved • 012015 Door Lock connector. Refer to Appendix I
DC12V3A
Power Supply
3rd party
controller with
26-bits wiegand
output
1. RS485 Single Connection
2. RS485 Network Connection
RS232/RS485
Data Converter
RS232/RS485
Data Converter
Wiegand OUT
3rd party controller with
26-bits wiegand input
RS232
cable
POWER
SUPPLY (A)
TCP/IP PORT
RS232/RS485 SERIAL PORT

BELL-
BELL+
SEN
GND
BUT
NO1
COM1
NC1
AL+
AL-
GND
+12V
+
_
2
3
A
C_
+
DC12V 3A
DC12V 3A
Step 4
Setting Up Data Communication
(Skip this step if you are using USB ash disk to transfer data)
The data communication ports are positioned at the rear of the ter-
minals, please refer to the diagrams shown on Step 3 to deter-mine
the wiring. Plug the communication jacks to the corresponding
ports.
TCP/IP – LAN Connection
For TCP/IP connection, plug the special RJ45 jack into the TCP/IP
(LAN) Port of the terminal. Connect the other end (normal RJ45 jack)
to the local area network hub or a PC. Configure the device ID, IP
address, subnet mask and Gateway in the terminal (refer to the
hardware user manual for details).
RS232 – Serial Port Connection
Plug the communication jack that is provided in the package to con-
nect to the communication port of the terminal. Select wires with
label RX, TX and GND, and connect the other end of these wires to
a DB9 female connector. Configure the device ID and baudrate of
the terminal (refer to the hardware user manual for details). Use the
normal RS232 cable to plug into the RS232 port of the terminal.
RS485 – Serial Port Connection
Plug the communication jack that is provided in the package to
connect to the communication port of the terminal. Select wires
with label RS485+, RS485- and GND, and connect the other end
of these wires to an RS232/485 data converter. Connect the other
end of the data converter to a DB9 female connector. Configure the
device ID and baudrate of the terminal (refer to the hardware user
manual for details).
Step 5
Finalizing the Installation
1. Check that all cable connections are done correctly.
2. Attach the terminal to the corresponding back plates and
tighten the screws to secure the terminal on the wall.
3. Switch on the power to the terminal.
4. Start using the terminal.
Other Accessories
FingerTec offers complementing accessories which can be used with
your terminals. These optional accessories are available at
http://accessory.fingertec.com
AdapTec Plus
The AdapTec Plus is a 12VDC power supply inclusive of a 110~
240VAC switching linear power. The AdapTec Plus supplies 12VDC
power to the FingerTec terminal and door lock system as well
as charges a 12VDC 7.0Ah backup battery simultaneously. Dur-
ing an event of a power failure, the back up battery automati-cally
provides power to the terminal and maintains the door lock system.
The AdapTec Plus also prevents a secured door from being opened if it
has been tampered with.
Door Lock Accessories
FingerTec offers various door locks accessories to complement
FingerTec door access product range.
Appendix I
Power Supply & Door Lock System Wiring
Diagrams
Diagram 1 • Normally Close (NC)
Diagram 2 • Normally Open (NO)
EMLock (NC)
Emergency Break
Glass (NC)
Overwrite
Keyswithch (NC)
Release Button
EMLock (NO)
Emergency Break
Glass (NO)
Overwrite
Keyswithch (NO)
Release Button

BELL-
BELL+
SEN
GND
BUT
NO1
NC1
COM1
AL+
AL-
DC12V 3A
Appendix I
Terminal Dimensions and Measurements
Front View of Back Plate
Diagram 3 • Other Accessories
Door Sensor
Alarm device Type
NO dry contact
Door Lock Connectors
WIRING PORT USAGE
Dry Contact
(independ-ent power supply for door lock)
• NO type door lock (NO1-COM)
• NC type door lock (NC1-COM)
Power Contact
(using power from terminal to power on door lock)
• NO type door lock (NO1-GND)
• NC type door lock (NC1-GND)
Dry Contact
(independ-ent power supply for door lock)
• NO type door lock (NO1-COM)
• NC type door lock (NC1-COM)
Power Contact
(using power from terminal to power on door lock)
• COM1 - +12V
Door Sensor (SEN-GND)
Release button (BUT-GND)
Alarm System
• NO output
To connect to schedule bell/siren
