FingerTec m-Kadex Operating and maintenance instructions

m-Kadex
Step 1
Determine the Location and Positioning
of the Installation
• Avoid installing the terminals in locations with high moisture or
condensation levels in the air
• The recommended installation height of the terminal from the
ground is 1.2 meters.
Step 2
Mounting Terminals on a Wall
• After determining the height of the terminal from the ground
level and have made the relevant marks on the wall, drill the
screws into the wall to hang the back plate.
Refer to Appendix II for dimensions and measurements of instal-
lation.
Step 3
Wiring for Power Supply
The power input ports for these models are located at the rear of
the terminals. There is no adapter plug supplied with the models,
instead you need to source for power cables (red and black cables)
to connect the power from the terminal to the AdapTec.
J7
AL-
AL+
NC
COM
NO
BUT
GND
SES
BELL+
BELL-
J2
RJ45-1
RJ45-2
RJ45-3
RJ45-6
J12
WDO
WD1
GND
RXD
TXD
GND
485A
485B
GND +12V
V3.6-09032
J1
USB
Port
Back Plate
4 feet / 1.2 meter
(recommended)
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
BEEP
GLED
RLED
INWD0
INWD1
GND
+12V
Wiegand
IN
Power
OUT
3rd party
controller with
26-bits wiegand
output
RJ45-1
RJ45-2
RJ45-3
RJ45-6
WD0
WD1
GND
RXD
TXD
GND
485+
485-
TCP/IP
Wiegand
OUT
RS232
RS485
3rd party controller
with 26-bits wiegand
input
RS232
cable
TCP/IP
RX+
RX-
1. RS485 Single Connection
RS232/RS485
Data Converter
485B
485A
RX+
RX-
RS232/RS485
Data
Converter
2. RS485 Network Connection
485B
485A
485B
485A
GND
+12V
DC12V 3A
Power
Supply
Door Lock connector.
Refer to Appendix I
Installation Guides
www.fingertec.com
m-Kadex & k-Kadex
Card Reader for Time Attendance &
Door Access Control System

Connection of k-Kadex to m-Kadex
Rear of k-Kadex Terminal Rear of Master Terminal
PWR
GND
WD0
WD1
BEEP
G LED
Bell +
Bell -
PWR
GND
INWD0
INWD1
BEEP
G LED
PWR
GND
External Power Supply
External
door bell
+
_
Power supply
for door bell
+
_
External doorbell system
*The doorbell is optional
Red
Black
White
Green
Purple
Grey
Blue
Yellow
k-Kadex
Step 4
Setting Up Data Communication
(Skip this step if you are using USB ash disk to transfer data)
The data communication ports are positioned at the rear of the
terminals, please refer to the diagrams shown on Step 3 to deter-
mine the wiring. Plug the communication jacks (TCP/IP, RS232 or
RS485) to the corresponding ports.
TCP/IP – LAN Connection
For TCP/IP connection, plug the special RJ45 jack into the TCP/IP
(LAN) Port of the master terminal. Connect the other end (normal
RJ45 jack) to the local area network hub or a PC. Configure the de-
vice ID, IP address, subnet mask and Gateway in the terminal (refer
to the hardware user manual for details).
RS232 – Serial Port Connection
Plug the communication jack that is provided in the package to
connect to the communication port of the master terminal. Select
wires with label RX, TX and GND, and connect the other end of
these wires to a DB9 female connector. Configure the device ID
Step 5
Finalizing the Installation
1. Check that all cable connections are done correctly.
2. Attach the terminal to the corresponding back plates and
tighten the screws to secure the terminal on the wall.
3. Switch on the power to the terminal.
4. Start using the terminal.
Other Accessories
Note: All Accessories are offered at http://accessory.fingertec.com
AdapTec Plus
AdapTec Plus
The AdapTec AC is a 12VDC power supply inclusive of a 110~240VAC
switching linear power. The AdapTec supplies 12VDC power to
the FingerTec terminal and door lock system as well as charges a
12VDC 7.0Ah backup battery simultaneously. During an event of
a power failure, the back up battery automatically provides power
to the terminal and maintains the door lock system. The AdapTec
Plus also prevents a secured door from being opened if it has been
tampered with.
Enclosures
FingerTec offers enclosures to protect the terminals from being
meddled with by unauthorized persons.
Door Lock Accessories
FingerTec offers various door locks accessories to complement Fin-
gerTec door access product range.
and baudrate of the terminal (refer to the hardware user manual for
details). Use the normal RS232 cable to plug into the RS232 port of the
terminal.
RS485 – Serial Port Connection
Plug the communication jack that is provided in the package to con-
nect to the communication port of the terminal. Select wires with label
RS485+, RS485- and GND, and connect the other end of these wires to
an RS232/485 data converter. Connect the other end of the data con-
verter to a DB9 female connector. Configure the device ID and baudrate
of the terminal (refer to the hardware user manual for details).

Diagram1 • Normally Close (NC)
Diagram 2 • Normally Open (NO)
Diagram 3 • Other Accessories
EM Lock (NO) +
---
Emergency Break 1
Glass (Type NO) 3
Overwrite Switch B
(Type NO) D
Release Button
DC12V 3A
Power Supply
ALM+
ALM-
NC
COM
NO
BUT
GND
SEN
BEL+
BEL-
GND
+12V
ALM+
ALM-
NC
COM
NO
BUT
GND
SEN
BEL+
BEL-
GND
+12V
Alarm device Type
NO or NC Dry contact
Door Sensor
Doorbell
DC12V 3A
Power Supply
EM Lock (NC) +
---
Emergency Break 2
Glass (Type NC) 3
Overwrite Switch A
(Type NC) C
Release Button
DC12V 3A
Power Supply
ALM+
ALM-
NC
COM
NO
BUT
GND
SEN
BEL+
BEL-
GND
+12V
35mm
35mm
14mm
7mm
10mm
7mm
4mm
10mm
111 mm
7mm
4mm
4mm
4mm
15mm
3mm
55.5 mm
