Firesense LIP-10A-TGG User manual

1
Outdoor Patio Heater
INFRARED BURNER
Model # LIP-10A-TGG
Item # 60951
ATTACH YOUR RECEIPT HERE
Serial Number ___________ Purchase Date ______
Manufacturer: Changzhou Wellife Furnace Co., Ltd.
Questions, problems, missing parts? Before returning to your
retailer, call our customer service hotline at 1-866-985-7877,
9 a.m. –6 p.m., EST, Monday –Friday or email at
[e-mail].

2
Table of Contents………………………………….....................Page 2
Before You Begin............................................................Page 2
Safety Information.........................................................Page 3-4
Package Contents………………………………….....................Page 5
Hardware Contents..........................................................Page 6
Assembly.........................................................................Page 6-11
Operating Instructions……………......................................Page 11-14
Care and Maintenance……………………..............................Page 14-15
Troubleshooting……………………………………......................Page 16
Replacement Parts List.....................................................Page 17
Warranty Information…………….....................................…Page 18
BEFORE YOU BEGIN
Please read and understand this entire manual before attempting to assemble, operate or install this appliance.
If you have any questions regarding the product, please call customer service 1-866-985-7877, 9 a.m. –
6 p.m., EST, Monday –Friday.
This manual contains important information about the assembly, operation and maintenance of this patio
heater. General safety information is presented in the first few pages and is also located throughout this manual.
Keep this manual for future reference and to educate new users of this appliance. This manual should be read
in conjunction with the labeling on the appliance. Safety precautions are essential when any mechanical or
propane fueled equipment is involved. These precautions are necessary when using, storing, and servicing.
Using this appliance with the respect and caution demanded will reduce the possibilities of personal injury or
property damage. The following symbols shown below are used extensively throughout this manual. Always
heed these precautions, as they are essential when using any mechanical or propane fueled equipment.
TABLE OF CONTENTS

3
SAFETY INFORMATION

4
SAFETY INFORMATION

5
PACKAGE CONTENTS
ASSEMBLY
PART
DESCRIPTION
QTY
A
Reflector Panel and
Center Cap
5 pcs (packed in 2
inner ctns)
B
Head and Upper
Post Assembly
1
C
Gas Hose
1 (attached to
Head Assembly)
D
Regulator
1
E
Lower Post
1
F
Post Support Plate
1 (packed under
Tank Housing
Assembly)
G
Tank Housing
Assembly
1
H
Tank Housing
Support Bar
1 (contains 2 –
M4x10
countersunk
screws)
I
Tank Housing Door
1
J
LED Control Box
w/hardware
1 (packed in top
of styrofoam
around tank
housing)

6
PREPARATION
Before beginning assembly of this appliance, make sure all parts are present. Compare all parts with package
contents list and hardware contents as listed on pages 5 and 6 of this manual. If any part is missing or damaged,
do not attempt to assemble this product. Contact customer service for replacement parts.
ESTIMATED ASSEMBLY TIME: 60 minutes
Tools Required for Assembly (NOT included):
Phillips screwdriver w/medium blade
Leak Test Solution
Adjustable wrench (2) (Note: 10mm wrench or socket should fit M6 bolt; 13mm wrench or socket should fit M8
bolt.)
NOTE: This heater has an Electronic Ignition and will require the installation of 1 - AAA battery. The battery
should be installed by unscrewing the RED IGNITER BUTTON.
The LED control box also requires the use of 8 - AA batteries. BATTERIES ARE NOT INCLUDED.
HARDWARE CONTENTS
ASSEMBLY
ASSEMBLY

7
1. Locate Tank Housing Assembly (G) and Tank Housing
Support Bar (H). Attach Tank Housing Support Bar (H) to
the top front edge of the Tank Housing Assembly (G)
with 2 M4x10 (GG) Countersunk Head Screws (screws come
pre-assembled in the Tank Housing Support Bar.)
Hardware Used: 2 x GG, Countersunk Head Screw M4x10
2. Attach the Lower Post (E) to the Post Support Plate (F) using
4 M8x16 (AA) Bolts and 4 M8 (FF) Washers.
(Note: Turn the post and support plate upside down to secure the bolts.)
Align the Post Support Plate (F) with the holes in the Lower Post (E),
and insert 1 M8x16 (AA) Bolt through 1 M8 (FF) Washer and through the
aligned holes. Tighten with a wrench.
Hardware Used: 4 x AA, Bolt M8x16
4 x FF, Washer M8
ASSEMBLY
1
2

8
3. Attach the Post Support Plate (F)/Lower Post (E) to the Tank
Housing Assembly (G/H). (NOTE: Make sure Firesense®logo is facing
forward directly over the Tank Housing Support Bar.)
Align the holes in the Post Support Plate (F) With the holes in the top of
the Tank Housing Assembly (G/H) and insert a total of 12 M4x10 (CC)
bolts into the holes and loosely tighten.
Once all bolts have been inserted, tighten with a wrench.
Hardware Used: 12 x CC, Bolt M4x10
4. Attach Tank Housing Door (I) to the Tank Housing Assembly (G)
by sliding the pins on the side of the door into the hinges located on
the right side of the Tank Housing Assembly (G). (NOTE: Make sure
you hold door to the SIDE of the Tank Housing Assembly before
trying to align pins. If you hold door to the FRONT of the Tank
Housing Assembly, you will NOT be able to align pins correctly.)
ASSEMBLY
3
4

9
5. Carefully route the Gas Hose (C) that comes attached to
Head and Upper Post Assembly (B) completely through the
Lower Post/Post Support Plate Assembly (E/F).
(Hint: Control knob on Head Assembly should be located over the Tank
Housing Door.)
6. Attach Head Assembly and Upper Post Assembly (B) to the
Lower Post (E) by aligning the 4 small holes located on
the Upper Post with the 4 small holes located on the
Lower Post (E). Insert 4 M6x12 (EE) bolts through
4 M6 lock washers and into holes and tighten with a wrench.
Hardware Used: 4 x EE, Bolt M6x12 and Lock Washer M6
7. Assemble Reflector Panels and Center Cap (A). Reflector
Panels and Center Cap (A) come packaged in two brown boxes with
two panels in each box. Hardware for assembly is already affixed to
each panel. Place two panels side by side and remove the two cap
nuts and washers that are affixed to one panel. Insert the affixed
bolts into the open holes on the adjacent panel. Place the washer
over the bolt and screw on cap nut. Repeat these steps until all four
panels are assembled. Then locate the Center Cap. You will need to
remove the cap nuts and washers located at the top of each Reflector
Panel to allow assembly of the Center Cap on each panel. Align the
holes in the Center Cap with the bolts on each panel and affix washer
and cap nut to complete assembly. (Note: It is easiest to assemble
reflector panels if you turn panels upside down. Once 4 panels are
assembled, turn reflector right side up and then attach the cap.)
ASSEMBLY
7
6
5

10
8. While supporting heater, tilt the Head and Upper Post Assembly (B) and screw in
the 3 M8x66 Stud Bolts (BB) into the holes on top of the Head Assembly. Slide the
assembled Reflector over the 3 bolts that now extend from the Head Assembly. Use
the 3 M8 Wing Nuts (DD) and 3 M8 Washers (FF) to secure the assembled Reflector
to the Head Assembly of the heater. Once you have tightened the Wing Nuts,
return the heater to an upright position.
Hardware Used: 3 x BB, Stud Bolt with Nut
3 x DD, Wing Nut M8
3 x FF, Washer M8
9. Connecting the LED feature:
This heater comes equipped with LED rope lights preassembled in the base and Post support plate (See Fig.1 and
2 below):
Attach the LED Control Box to the Tank Housing Door by inserting 2 - M4x10 screws through holes and into nuts
and tighten with a screwdriver. Then secure the LED wire to the door by placing it under the latch on the door.
To connect the LED feature, once the heater is assembled, locate the two connectors—one will be inside the Tank
housing assembly on the right side by the Tank housing door and the other will be at the right front corner at the
bottom of the Post support pate. The LED control box is located on the back side of the Tank housing door (NOTE:
Before attaching the LED connectors to the LED control box, you must insert 8 - AA batteries (NOT included) by
sliding the top of the LED control box back towards you to release the top. Once the top is removed, insert the
batteries and then replace the top by sliding it back on the box away from you.) Connect both sets of connectors
and control LED feature with On/Off switch located on LED control box.
ASSEMBLY
8
