First Heating Basic Elegant Series User manual

14052012 - M-20120511-BASIC Elegant-ENG
Ceiling-Mounted Infrared Panel Heater
“Basic Elegant” Series BE 30/60/90/ 20/ 50
PRODUCT SPECIFICATIONS:
Model Number BE30 BE60 BE90 BE 20 BE 50
Dimensions* 630mm x 330mm x 28mm 592mm x 592mm x 28mm 592mm x 892mm x 28mm 592mm x 1192mm x 28mm 630mm x 1530mm x 28mm
Max. Wattage 230W 500W 800W 1000W 1300W
Panel Weight 4.5 kg 8,5 kg 11,5 kg 16,5 kg 22,5 kg
Input Power 230V~ 50-60Hz
Current 1A 2.2A 3.5A 4.4A 5.7A
Power Cable Length 2m with ut plug r c nnect r
Glass Tempered glass r tempered mirr r - Max. surface temperature 190°C
Frame Frameless
Effective Area 5m
2
10m
2
16m
2
20m
2
26m
2
* Dimensions without mounting hardware

2
PACKAGE CONTENTS:
Heating panel (Power cable 2 )
Mounting brackets (x4)
Mounting bracket screws (x4)
Screws/ plugs for ceiling (x4)
Washers (x4)
10 wrench (x1)
Installation Te plate
INSTALLATION:
For proper cli ate control and efficient electrical consu ption, a
ther ostat or other te perature-control apparatus must be
connected to the heating panel.
The appliance is suitable for use in bathroo s at ZONE 3
(please see illustrations). In all cases, be sure that the power
outlets are equipped with an RCD (Residual Current Device) to
protect the electrical circuit.
Because the panel radiates infrared waves, it should not be
obstructed by or placed behind furniture and other objects, it
could restrain its perfor ance and ay cause injury. The heater
should be installed at a position where occupants would
nor ally be at the sa e distance fro it.

14052012 - M-20120511-BASIC Elegant-ENG
Once the ost favorable installation position has been identified, please follow the steps:
Step 1: Place the installation te plate on the ceiling using tape and ark the 4 locations of the holes for the wall plugs and
ounting screws. Verify that there are no electrical cables in the ceiling where you will be drilling.
Step 2: Use a drill bit suitable for the ceiling aterial type. For concrete/ brick ceilings, use a drill bit with a dia eter of 8 .
Step 3: Wall plugs for solid (concrete, brick) ceilings are provided. Put the plugs in the holes and fix the screws with a washer until
each washer re ains about 1c below the ceiling. In case of doubt, please ask for assistance fro a professional.
Step 4: Hang the panel using its ounting brackets on the screws, rotate the two loose brackets 180 degrees, and then secure
the with the 10 wrench for stability.
Step 5: Plug the power cable into 230V, standard electrical outlet.
SAFETY NOTES:
• FIRST Heating BASIC Elegant panel odels are designed for ceiling installation and are equipped with ounting brackets to
provide support.
• The appliance is safe to touch; however, prolonged contact with the panel while it is in operation ay cause injury.
• S all children should not be left unattended near the heating panel as prolonged contact with the panel ay cause injury.
• The appliance can be used in bathroo s (zone 3) but it ust not co e into contact with water.
• If any fluids or foreign object ay beco e lodged within the panel, disconnect it fro power and have it checked by a service
technician.
• The appliance has an earthed power cord which is to be used with 230V power outlets. In case the power cord or the
appliance itself beco es da aged, it should be repaired by a professional.
• DO NOT atte pt to disasse ble the appliance. It contains any parts and the warranty will beco e void. Dis-asse bly and/or
reasse bly should not be done outside the factory or a specialized service center.
• TO AVOID ELECTROCUTION, re ove the power cord if a defect has been identified, or if the panel is to be oved.
• PROTECTION AGAINST OVERHEATING AND FIRE HAZARD: The panel can at instances reach surface te peratures of
190°C. DO NOT cover the panel at any ti e nor put easily fla able fabrics or other objects directly under the panel.
• If drilling into the ceiling for installation, first check that the area is free of electrical wires, gas, water pipes, or any other
obstacles that could be da aged.
• FIRST TIME USE: verify that all of the packaging aterials have been re oved. In case you notice an odor due to panel
operation, switch it off i ediately, then identify and re ove the source. In case the s ell persists, contact your point of sale.
• Install the panel where its plug will be easily accessible.
• DO NOT cover the power outlet with the panel.
• FIRST panels are designed to withstand oderate power drops/surges at voltages between 220V and 250V. Verify before use
that the panel you are installing is suited for your regional supply voltage. When this would not be the case, do not plug in the
appliance and contact your supplier. In case the panel is plugged into an outlet with the wrong voltage, or when power surges
are out of the range as described before, the warranty will NOT cover these da ages.
• Do not atte pt to clean the heating panel while it is connected to the electrical power supply. First unplug the power cord, and
then the appliance ay be cleaned with a soft, dry cloth.
• DO NOT COVER: To prevent the panel fro overheating, do not cover or conceal it with textiles, ite s of clothing, or
other objects of any type.
• WARNING: Be sure that the heating panel is installed above its electrical power outlet.
• WARNING: The heating panel ay not used if its glass cover is da aged. I ediately turn off the heating panel if da age to
the the glass occurs.
• The heating panel is not intended for use by persons (including children) with reduced physical, sensory or ental capabilities.
Those lacking experience concerning the use of heating panels should be given instruction by a person aware of their safe
use.
• Children should be supervised not to play with heating panels. They are NOT toys and children should be clearly instructed
and supervised by adults.
