USER GUIDE
US CA
WALL OVEN
WODV0 & WOSV0
models

This user guide is an accompaniment to your ‘Quick start guide’ which is included
with your oven.
For operating instructions, see your ‘Quick start guide’. If you no longer have your
‘Quick start guide’, you can download it from our website, listed on the back cover.
Refer to your ‘Quick start guide’ for information on:
● Setting the clock
● Controls
● Positioning the shelves
● Conditioning the oven before first use
● Using the timer

1
CONTENTS
Safety and warnings 2
Cooking guide 6
Oven functions 9
Cooking charts 14
Automatic cooking 20
Using the meat probe 25
User preference settings 28
Sabbath mode 30
Care and cleaning 32
Using the Self Clean function 38
Troubleshooting 41
Alert codes 45
Warranty and service 47
IMPORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are subject
to change at any time. For current details about model and specification availability
in your country, please go to our website fisherpaykel.com or contact your local
Fisher & Paykel dealer.

2
Your oven has been carefully designed to operate safely during normal cooking
procedures. Keep the following safety instructions in mind when you are using it:
WARNING!
HOT SURFACE HAZARD
Accessible parts may become hot when in use.
To avoid burns and scalds, keep children away.
Use oven mitts or other protection when handling hot surfaces such
as oven shelves or dishes.
Use care when opening the oven door.
Let hot air or steam escape before removing or replacing food.
Do not touch heating elements or interior surfaces of the oven.
Heating elements may be hot even though they are dark in colour.
Interior surfaces of an oven become hot enough to cause burns.
During and after use, do not touch, or let clothing or other flammable
materials contact heating elements or interior surfaces of the oven until
they have had sufficient time to cool.
Other surfaces of the appliance may become hot enough to cause burns
– among these surfaces are the oven vent,
the surface near the oven vent, and the oven door.
Failure to follow this advice could result in burns and scalds.
WARNING!
ELECTRICAL SHOCK HAZARD
Turn the oven off at the wall before replacing the oven lamp.
Failure to follow this advice may result in electrical shock or death.
WARNING!
FIRE HAZARD
Follow the instructions on starting a Self Clean cycle carefully.
Items made from combustible materials (eg wood, fabric, plastic)
may catch fire if left in the oven during a Self Clean cycle.
Do not place aluminium foil, dishes, trays, water or ice on the oven
floor during cooking, as doing so will irreversibly damage the enamel;
lining the oven with aluminium foil may even cause fire.
Never use your appliance for warming or heating the room.
Persons could be burned or injured or a fire could start.
Storage in or on appliance: flammable materials should not be stored
in an oven or near its surface.
Failure to follow this advice may result in death or serious injury.
SAFETY AND WARNINGS

3
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electrical shock, injury to persons or damage when using
the oven, follow the important safety instructions listed below:
● Read all the instructions before using the oven. Use the oven only for its intended
purpose as described in these instructions.
● Proper installation: be sure your appliance is properly installed and grounded by
a qualified technician.
● Isolating switch: make sure this oven is connected to a circuit which incorporates
an isolating switch providing full disconnection from the power supply.
● Household appliances are not intended to be played with by children.
● Do not leave children alone. Children should not be left alone or unattended in the
area where the appliance is in use. They should never be allowed to sit or stand on
any part of the appliance.
● Children of less than 8 years old must be kept away from the appliance unless
continuously supervised. This appliance can be used by children aged from 8 years
and above, and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, if they have been given supervision or instruction
concerning the use of the appliance in a safe way and they understand the hazards
involved. Cleaning and user maintenance shall not be done by children without
supervision.
● Do not place heavy objects on the oven door.
● Wear proper apparel. Do not wear loose fitting or hanging garments when using
the appliance. They could ignite or melt if they touch an element or hot surface
and you could be burned.
● User servicing: do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be referred to a qualified
technician.
● Do not use water on grease fires. Smother the fire or flame or use a dry chemical
or foam type extinguisher.
WARNING!
CUT HAZARD
Take care – some edges are sharp.
Failure to use caution could result in injury or cuts.

4
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
● Use only dry oven mitts or potholders. Moist or damp potholders on hot surfaces
could result in burns from steam. Do not let potholders touch hot areas or heating
elements. Do not use a towel or a bulky cloth for a potholder. It could catch fire.
● Do not heat unopened food containers. They can build up pressure that may cause
the container to burst and result in injury.
● Safe food handling: leave food in the oven for as short a time as possible before
and after cooking. This is to avoid contamination by organisms which may cause
food poisoning. Take particular care during warm weather.
● Always keep oven vents unobstructed.
● Do not operate your appliance by means of an external timer or separate
remote-control system.
● Caution: Hot air can blow from the vent at the base of the oven as part of the
oven’s cooling system.
● Placement of oven shelves: always position shelves in the desired location while
the oven is cool (before preheating). If a shelf must be removed while the oven
is hot, do not let the oven mitts or potholder contact hot heating elements in
the oven or the base of the oven.
● Do not clean the oven seal or use any oven-cleaning products on it.
It is essential for a good seal, which ensures that the oven operates efficiently.
Care should be taken not to rub, damage or move it.
● Do not use oven cleaners, harsh/abrasive cleaning agents, waxes, or polishes.
No commercial oven cleaner, oven liner, or protective coating of any kind should
be used in or around any part of the oven. Do not use harsh/abrasive cleaners,
scourers or sharp metal scrapers to clean the oven door glass since they scratch
the surface, which may result in the glass shattering.
● Clean only the parts listed in this manual.
● Do not use a steam cleaner to clean any part of the oven.
● Double oven models only:
● You can only Self Clean one oven at a time, and whilst in a Self Clean cycle,
the other oven cannot be used.

5
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
● Before starting a Self Clean cycle, remove oven shelves, side racks, and all other
cookware/utensils, and wipe up large food spills or grease deposits.
● Before starting a Self Clean cycle, make sure you move any pet birds to another,
closed and well-ventilated room. Some pet birds are extremely sensitive to the
fumes given off during a Self Clean cycle and may die if left in the same room
as the oven during such a cycle.
● During a Self Clean cycle, the oven reaches higher temperatures than it does for
cooking. Under such conditions, the surfaces may get hotter than usual and children
should be kept away.
● Do not store things children might want above the oven. Children could be burned
or injured while climbing on the oven to retrieve items.
● Do not install or operate the appliance if it is damaged or not working properly.
If you receive a damaged product, contact your dealer or installer immediately.
● Use only bakeware approved for oven use. Follow the bakeware manufacturer’s
instructions.
● The California Safe Drinking Water and Toxic Enforcement Act requires businesses
to warn customers of potential exposure to substances which are known by the
State of California to cause cancer or reproductive harm. Small amounts of harmful
chemicals are given off in the oven’s self-cleaning cycle from insulation and food
decomposition. Significant exposure to these substances can cause cancer and
reproductive harm. Venting with a hood or open window, and wiping out excess
food spills prior to self-cleaning the oven reduces exposure.

6
Setting an oven function
Turn the function knob to the right to
select a function. Turning the knob
to the following positions will select
the corresponding function, which
appears in the display:
PROBE: 100
TIMER: 2H 15M
SET: 175
BAKE VENT BAKE FAN BAKE GRILL
FAN GRILL FAN FORCED
ROAST CLASSIC BAKE
PASTRY BAKE
COOKING GUIDE
Congratulations on your new purchase. Your Fisher & Paykel oven has a number of
features to make cooking a great experience for you:
● a wide choice of oven functions
● a convenient Self-Clean function – see ‘Using the Self Clean function’
● intuitive controls and displays
● illuminated halos around the knobs for visual feedback
Before you start
● Make sure the installer has completed the ‘Final checklist’ in the Installation instructions.
● Read this guide, taking special note of the ‘Safety and warnings’ section.
● Remove all packaging and dispose of it responsibly. Make sure all cable ties used to
● secure the shelves during shipping have been removed. Recycle items that you can.
● Check that you have all the accessories listed in the separate ‘Quick start guide’.
● Make sure you follow the instructions under ‘Setting the clock and first use’ in the
separate ‘Quick start guide’ before using your oven.
General guidelines
This oven has been designed to utilise its four elements and rear fan in differing
combinations to provide you with enhanced performance and a wide range of functions,
allowing you to cook all types of food to perfection.
BAKE VENT BAKE FAN BAKE GRILL
FAN GRILL FAN FORCED
ROAST CLASSIC BAKE
PASTRY BAKE
Lower
Element
(concealed)
Rear Element
(concealed)
Outer
Element Shelf positions
Fan
OFF BAKE
CONV BAKE
TRUE CONV
BROIL
MAXI BROIL
CONV BROIL
CONV PASTRY
ROAST
PASTRY BAKE
WARM
SELF CLEAN
Inner
Element
1
2
3
4
5
6
7
8
