Fisher & Paykel 7 Series User manual

USER GUIDE
NZ AU
INTEGRATED INSERT RANGEHOOD
WITH EXTERNAL BLOWER
CONTEMPORARY
HP60IDCHEX & HP90IDCHEX

3
CONTENTS
Safety and warnings 4
Using your rangehood 6
Control panel 7
Care and cleaning 8
Parts and accessories 9
Troubleshooting 10
Manufacturer’s Warranty 11
Customer care 13
Registration
To register your product visit our website: fisherpaykel.com/register

4
SAFETY AND WARNINGS
!WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• Always disconnect the appliance from the
mains power supply before carrying out any
maintenance or repairs. Failure to do so can
result in death, electric shock, fire or injury to
persons.
• Do not immerse cord or plugs in water or
other liquid.
!WARNING!
Weight Hazard
Failure to follow this advice may result in
personal injury.
• The appliance is heavy. Please ensure adequate
care is taken when installing the appliance to
prevent personal injury.
• Product weight: 6.4kg (HP60) and 8.4kg (HP90).
READ AND SAVE THESE INSTRUCTIONS

5
SAFETY AND WARNINGS
WARNING!
When using this appliance always exercise basic safety precautions including
the following:
z This product is for use with a compatible Fisher & Paykel external blower. Failure to
comply could void your warranty.
z Please read the entire set of instructions before installing or using this appliance.
z The room must have adequate ventilation when the rangehood is used at the same time
as appliances burning gas or other fuels.
z This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliance by
a person responsible for their safety.
z Children should be supervised to ensure they do not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
z You must read the details concerning the method and frequency of cleaning.
z There is a fire risk if cleaning is not carried out in accordance with the instructions.
z Never leave frying food unattended since grease can overheat and catch fire. The risk of
fire is even greater in the case of used oil.
z Do not flambé under the rangehood.
z Never use the rangehood without the filters in place.
z CAUTION: accessible parts may become hot when used with cooking appliances.
z Remove all packaging, including protective wrappings, before use.
z Unplug or disconnect the appliance from the power supply before servicing or cleaning.
z The rangehood may stop working during an electrostatic discharge (eg lightning).
Switch off the electricity supply to the rangehood and reconnect after one minute.
z Never use abrasive or oil based cleaners.

6
USING YOUR RANGEHOOD
This rangehood should be turned on for a few minutes before cooking in order to establish
air currents upward through the rangehood. This will also enable hot air removal from
your kitchen and keep the rangehood surface cool. When heat, smoke, moisture, grease
and cooking odours are produced, they will be carried outside instead of drifting into
other rooms.
Use the low fan speeds for normal use and the higher fan speeds for high heat, strong
odours or fumes.
Induction cooking considerations
Induction cooktops use energy efficient technology that only heats the contents of a
cooking pot. Unlike gas or traditional electric cooktops, the surrounding air does not get
heated when using an induction cooktop. As a result, rangehood filters, splashbacks and
surrounding cabinetry do not get warmed up, increasing the likelihood of condensation on
these cooler surfaces. Other factors like ambient temperature, humidity, natural ventilation
of the room, size of the cookware and how the induction cooktop is being used also
influence condensation. For example, rapid boiling on high cooktop heat settings like
PowerBoost increases the rate at which water is evaporated, increasing the likelihood of
condensation. It is important to understand that neither the rangehood nor the induction
cooktop are faulty as a result of this phenoenon.
Condensation can be minimised by:
z Using the rangehood on a lower speed setting when boiling.
z Using the induction cooktop on a lower heat setting when boiling.
z Switching the rangehood on 5 minutes before cooking and letting it run for at least
5minutes after cooking.
Gas cooking considerations
Using a powerful gas cooktop or multiple gas burners operating at the same time can cause
the rangehood surfaces to become hot. This effect can be reduced by:
z Using the maximum speed setting to enable hot air to be extracted quickly.

7
CONTROL PANEL
1 Filter cleaning alert Illuminates to alert the need to clean filters. Can be reset with a
single button press.
2 Timer Press to turn the timer on. The fan operates for 5 minutes at the
current speed and each desceding speed before turning off.
3 Lights Press to turn the lights on/off. The lights are dimmable. Press
and hold to adjust the brightness level.
4 Power on/off Press to turn the rangehood on/off. The fan automatically turns
on to operate at level 1.
5 Fan speed 1 Press to select the lowest fan speed 1. The fan speed level icon
illuminates red when selected.
6 Fan speed 2 Press to select fan speed 2.
7 Fan speed 3 Press to select fan speed 3.
8 Boost
Press to turn the fan onto boost speed. The icon flashes red
when it is on. The rangehood will operate on boost speed for 5
minutes and will then revert to speed 3.
1 2 3 4 5 6 7 8

8
This rangehood should be cleaned regularly using a mild, liquid detergent and a clean soft
cloth to avoid a build-up of grease occurring. Avoid the use of corrosive chemicals, abrasive
cleaning products, hard brushes and steel wool pads. Grease deposits are corrosive which
can cause damage.
In areas of high humidity or coastal environments, cleaning should be carried out more
frequently. Disconnect the product from the power source before undertaking any cleaning.
Do not operate the hood without filters in place.
Aluminum filters
z Clean the filters at least once a month. Filters may need to be cleaned more frequently
depending on the cooking methods used and frequency of use.
z Aluminum filters should be removed and cleaned with hot soapy water or in
a dishwasher.
z If washed in a dishwasher, the filter should be placed in an upright position to prevent
food from falling on them.
z After rinsing and drying, refit the filters.
CARE AND CLEANING
Open the perimeter plate.
Pull the catch and tilt the filter downwards until
it disengages from thesupports.
Place the filter into the support at the rear of
the rangehood. Push the filter back into place.
Close the perimeter plate.
1
2
Removing the aluminium filters
Replacing the aluminium filters

9
CARE AND CLEANING
Replacing LED lights
z To replace the LED lights please contact your Fisher & Paykel trained and supported
service technician. Refer to fisherpaykel.com or your seperate service and warranty
book provided with your rangehood for contact details.
External blower maintenance and cleaning
z Before roof restoration or cleaning, completely cover the outside motor system to
avoid any chemical contact.
z Regularly clean the area surrounding the external blower to ensure it is not blocked
by debris.
ITEM REFERENCE NUMBER
Aluminium filter 60cm 792942
Aluminium filter 90cm 792943
PARTS AND ACCESSORIES

10
TROUBLESHOOTING
If there is a problem with your rangehood, please check the following points before
contacting your local Fisher & Paykel trained and supported service technician or the
Customer Care Centre.
PROBLEM POSSIBLE CAUSES WHAT TO DO
The external blower
shuts off during use.
The external blower is
equipped with a thermal
protector to avoid
overheating conditions.
Turn off the rangehood. Wait
approximately 60 minutes
and then attempt to restart
the hood.
Airflow is lower
than expected.
The ducting or the external
blower is blocked.
Check the external blower
is clear of debris. Check
the ducting for kinks or
other blockages.
Rangehood is loud. Incorrect installation. External blower should
be installed as per the
installation guide.
Excessive
condensation forms
on the rangehood.
Using an induction cooktop. Condensation can be
minimised, refer to ‘Using
your rangehood’.
High ambient temperature,
humidity or low natural
ventiliation in the room.
Height of rangehood
installation.

11
MANUFACTURER’S WARRANTY
You automatically receive a 2 year Manufacturer’s Warranty with the purchase ofthis
Built-In Integrated Rangehood covering parts and labour for servicing within the country
of purchase.
Fisher & Paykel undertakes to:
Repair or, at its option, replace without cost to the owner either for material or labour any
part of the product, the serial number of which appears on the product, which is found to
be defective within TWO YEARS of the date of purchase.
Note: this Manufacturer’s Warranty is an extra benefit and does not affect your legal rights.
This Manufacturer’s Warranty DOES NOT cover
A Service calls which are not related to any defect in the product. The cost of a service
call will be charged if the problem is not found to be a product fault. For example:
1 Correcting the installation of the product.
2 Instructing you how to use the product.
3 Replacing house fuses or correcting house wiring or plumbing.
4 Correcting fault(s) caused by the user.
5 Noise or vibration that is considered normal, eg drain/fan sounds, refrigeration noises
oruserwarning beeps.
6 Correcting damage caused by pests, eg rats, cockroaches, etc
7 Replacement light bulbs.
B Defects caused by factors other than:
1 Normal domestic use; or
2 Use in accordance with the product’s user guide.
C Defects to the product caused by accident, neglect, misuse or ‘act of God’.
D The cost of repairs carried out by non-trained and supported service technicians or
thecost of correcting such repairs.
E Normal recommended maintenance as set out in the product’s user guide.
F Repairs when the appliance has been dismantled, repaired or serviced by other than
aFisher&Paykel trained and supported service technician or the selling dealer.
G Pick-up and delivery.
H Transportation or travelling costs involved in the repair when the product is
installed outside the Fisher&Paykel trained and supported service technician’s
normal service area.
Nothing in this manufacturer’s warranty is intended to, or does, limit any rights you may
have under law to recover the costs of inspecting or returning the goods to us.
This product has been designed for use in a normal domestic (residential) environment.
This product is not designed for commercial use (whatsoever). Any commercial use by
acustomer will affect this product’s Manufacturer’s Warranty.
Service under this Manufacturer’s Warranty must be provided by a Fisher&Paykel trained
and supported service technician (refer to the ‘Customer Care’ section at the back of this
book). Suchservice shall be provided during normal business hours. ThisManufacturer’s
Warranty certificate should be shown when making any claim.

12
MANUFACTURER’S WARRANTY
For Australian Customers
This Manufacturer’s Warranty is an extra benefit and does not affect your legal rights. Our
goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure andforcompensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure.
Please keep this user guide in a safe place.

13
CUSTOMER CARE
Before you call for service or assistance
Check the things you can do yourself. Refer to your user guide and check that:
1 Your product is correctly installed.
2 You are familiar with its normal operation.
If after checking these points you still need assistance or parts, please refer to your nearest
Fisher & Paykel trained and supported service technician, Customer Care, or contact us
through our local website listed on the back cover.
In New Zealand if you need assistance*
Call your Fisher & Paykel retailer who is trained to provide information on your appliance, or
if we can be of any further help, contact our Customer Care Centre.
Toll free: 0800 FP CARE or 0800 372 273
Fax: [phone]
Website: fisherpaykel.com
Postal address: Fisher & Paykel Appliances Ltd, PO Box 58550, Botany, Auckland 2163
If you need service*
Fisher & Paykel has a network of Fisher & Paykel trained and supported service technicians
that can carry out any service necessary on your appliance. Our Customer Care Centre can
recommend a Fisher & Paykel trained and supported service technician in your area.
In Australia if you need assistance*
Call the Fisher & Paykel Customer Care Centre and talk to one of our
Customer Care Consultants.
Toll free: 1300 650 590
Fax: [phone]
Website: fisherpaykel.com
Postal address: Fisher & Paykel Appliances Ltd, PO Box 798, Cleveland QLD 4163
If you need service*
Fisher & Paykel has a network of Fisher & Paykel trained and supported service technicians
that can carry out any service necessary on your appliance. Our Customer Care Centre can
recommend a Fisher & Paykel trained and supported service technician in your area.
For rest of the world*
Call your Fisher & Paykel retailer/dealer from whom you purchased the product. Theyare
trained to provide information on your appliance. If we can be of any furtherhelp, contact
use on:
Phone: [phone]
Fax: [phone]
Website: fisherpaykel.com
Postal address: Fisher & Paykel Appliances Ltd, PO Box 58550, Botany,
Auckland 2163, New Zealand.

14
Complete and keep for safe reference:
Model
Serial No.
Purchase Date
Purchaser
Dealer
Suburb
To w n
Country
CUSTOMER CARE
*If you call, write or contact our website please provide:
your name and address, model number, serial number, date of purchase and a complete
description of the problem. This information is needed in order to better respond to your
request for assistance.
Product details can be found on the inside of the chassis.
The filter needs to be removed to be able to see them.
Registration
Register your product with us so we can provide you with the best service possible.
To register your product visit our website: fisherpaykel.com/register

FISHERPAYKEL.COM
105949A 05.20
© Fisher & Paykel Appliances 2020. All rights reserved.
The models shown in this guide may not be available in all markets
and are subject to change at any time.
The product specifications in this guide apply to the specific products and
models described at the date of issue. Under our policy of continuous product
improvement, these specifications may change at any time.
For current details about model and specification availability in your country,
please go to our website or contact your local Fisher&Paykel dealer.
