Flex FT161 User manual

Model:
Modelo:
Modèle:
OPERATOR’S MANUAL
MANUAL DEL OPERADOR
MANUEL DE L’UTILISATEUR
833-FLEX-496
(833-3539-496)
For English
Version
See page 2
◆
Version
française
Voir page 11
◆
Versión en
español
Ver la página 21
www.Registermyflex.com
Contact Us /
Nous contacter /
Contáctenos
COLLATED SCREW MAGAZINE
MAGASIN D’APPROVISIONNEMENT EN VIS ASSEMBLÉES EN BANDES
CARGADOR PARA TORNILLOS INTERCALADOS
FT161

-2-
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols
and the explanations with them deserve your careful attention and understanding. The symbol
warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are
no substitutes for proper accident prevention measures.
WARNING Be sure to read and understand all safety instructions in this Operator’s Manual,
including all safety alert symbols such as “DANGER,” “WARNING,” and
“CAUTION” before using this tool. Failure to follow all instructions listed below may result in electric
shock, re, and/or serious personal injury.
The denitions below describe the level of severity for each signal word. Please read the manual and
pay attention to these symbols.
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation
which, if not avoided, will result in minor or moderate injury.
Damage Prevention and Information Messages
These inform the user of important information and/or instructions that could lead to equipment or
other property damage if they are not followed. Each message is preceded by the word “NOTICE”,
as in the example below:
NOTICE: Equipment and/or property damage may result if these instructions are not followed.
WARNING The operation of any power tools can result in foreign
objects being thrown into your eyes, which can result in
severe eye damage. Before beginning power tool operation, always wear
safety goggles or safety glasses with side shields and a full face shield when
needed. We recommend a Wide Vision Safety Mask for use over eyeglasses
or standard safety glasses with side shields. Always use eye protection which
is marked to comply with ANSI Z87.1.

-3-
SAFETY RULES FOR COLLATED SCREW MAGAZINE
WARNING Read all safety warnings, instructions, illustrations and specications
provided with this power tool. Failure to follow all instructions listed below may
result in electric shock, re and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
The collated screw magazine is designed to
only be used with the FLEX FX1611 drywall
screwdriver.
Observe all operating instructions and
safety regulations contained in the manual
for the FLEX FX1611 drywall screwdriver.
Before use, ensure that the magazine is
properly attached to the power tool.
Avoid body contact with grounded (or
earthed) surfaces such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your body is
grounded.
Detach the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
When driving screws, never reach into
the magazine. Keep hands clear of the
advancing mechanism and the spot where
the screw is being driven.
Do not use the magazine as a gripping
surface.
Hold power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring. Fasteners contacting a “live” wire may
make exposed metal parts of the power tool
“live” and could give the operator an electric
shock.
Use only screw strips with screw sizes #6,
#7 and #8 with this magazine. Only insert
screw strips when the screwdriver is turned
off and the trigger is locked.
WARNING
• Some dust created by power sanding, sawing,
grinding, drilling and other construction
activities contains chemicals known to the
State of California to cause cancer, birth
defects or other reproductive harm. Some
examples of these chemicals are:
– Lead from lead-based paints.
– Crystalline silica from bricks, cement, and
other masonry products.
– Arsenic and chromium from chemically-treated
lumber.
• Your risk from these exposures varies,
depending upon how often you do this type
of work. To reduce your exposure to these
chemicals:
– Work in a well-ventilated area.
– Work with approved safety equipment, such
as dust masks that are specially designed to
lter out microscopic particles.
– Avoid prolonged contact with dust from power
sanding, sawing, grinding, drilling, and other
construction activities. Wear protective clothing
and wash exposed areas with soap and water.
Allowing dust to get into your mouth or eyes or
to lie on the skin may promote absorption of
harmful chemicals.

-4-
FUNCTIONAL DESCRIPTION AND SPECIFICATIONS
Collated Screw Magazine
Fig. 1
Screw Length
Adjustment Tab
Shoe
Advancing
Mechanism
Release
Button
Presetting
Indicator for
Screw-in Depth
Large Spring
Pin
Release Button
Dial for
Screw-in
Depth
Screw-in
Depth
Indicator
Depth Locking Pin
Small Spring Pin Screw Guide
Collated-Screw Bit
Model No. FT161
Magazine Length 8-5/16 in. (211 mm)
Collated Screw Length 1 – 2 in (25 – 51 mm)
Collated Screw Size #6, #7 and #8
Screws per strip (max.) 50 pcs
NOTICE: Use only collated screws marked “CS Collated Screws” on the package. Other
screws are not compatible with this magazine.

-5-
ASSEMBLY
WARNING Detach the battery pack
from the drywall
screwdriver before making any assembly,
adjustments or changing accessories. Such
preventive safety measures reduce the risk of
starting the tool accidentally.
WARNING Lock the variable-speed
trigger switch “OFF” by
placing the direction-of-rotation selector in
the center position. An accidental start-up can
cause injury.
FITTING THE COLLATED SCREW BIT (FIG. 2)
NOTICE: For proper operation only use the
collated screw bit with PH2 Ø 5 X 150.
Refer to and follow the instructions on
“Changing Bit Holder “ in your FLEX FX1611
drywall screwdriver manual to:
a. Remove the stop sleeve from the screwdriver.
b. Remove the installed bit holder from the
screwdriver.
c. Push the clutch backward and push the
provided collated screw bit into the gearcase.
d. Release the clutch and ensure the bit shank
is locked in the gearcase securely.
INSTALLING AND REMOVING THE
MAGAZINE
To Install the Magazine (Fig. 3)
With the stop sleeve removed and provided
collated screw bit installed:
a. Push forward and hold the release buttons on
both sides of the magazine.
b. Align the raised ribs on the screwdriver with
the grooves in the magazine, and push the
magazine over the bit onto the screwdriver
until the magazine audibly snaps into place
c. Let go of the release buttons and ensure that
the magazine does not disengage.
NOTE: This attachment has the ability to rotate
without being taken off the drywall screwdriver
along the drywall screwdriver axis. Refer to
the “Rotating the Magazine” chapter in this
manual.
To Remove the Magazine
Push forward and hold the release buttons
on both sides of the magazine and pull the
magazine off of the screwdriver.
Fig. 2
c
b
Fig. 3
b
a
Release button

-6-
INSERTING COLLATED SCREW STRIP
(FIG. 4)
NOTICE: Use only screw strips with screw sizes
#6, #7, and #8 with this magazine. Only insert
screw strips when the screwdriver is turned off
and the trigger switch is locked.
Proper use of collated strips will reduce the risk
of injury, reduce jams and prevent screws from
damaging the workpiece. For best performance
use new, undamaged strips free of debris.
a. Take a collated strip, holding the plastic
portion, and feed from the bottom of the screw
guide and into the bottom of the advancing
mechanism
b. Continue feeding the strip until the rst screw
is one slot below the driver bit.
REMOVING THE COLLATED
SCREW STRIPS (FIG. 5)
Pull the screw strip up to remove it.
NOTICE: Do not remove the screw strip by
forcibly pulling the screw strip downwards to
avoid damaging the product or even causing
personal injury.
Fig. 5
Fig. 4
a
b
Advancing
Mechanism Screw
Guide

-7-
ADJUSTMENTS
WARNING Detach the battery pack
from the drywall
screwdriver and lock the variable-speed
trigger switch “OFF” by placing the
direction-of-rotation selector in the center
position.
SETTING THE SCREW LENGTH
CAUTION Do not adjust the screw
length while a screw strip
is in the magazine. Remove the screw strip
prior to making adjustments.
This magazine is designed for screws that are
1 – 2 inches (25 – 51 mm) long. Failure to set
the correct screw length can cause screws to
not be driven accurately which can result in the
failure to advance the next screw or screws
not being screwed-in properly. The shoe has
the specic length marks for the most common
screw lengths. The arrow points at the length
mark indicating the current screw length
(Fig. 6a).
a. Slide the screw length adjustment tab to the
left (Fig. 6a).
b. While holding the screw length adjustment tab
in place, adjust the shoe to the desired length
by pulling the shoe out or pushing it into the
magazine until the arrow is aligned with the
desired length mark (Fig. 6a).
c. Release the screw length adjustment tab.
Make sure that the locking pin on the other
side of the magazine has fully returned and is
in the desired marked depth position (Fig. 6b).
SETTING SCREW-IN DEPTH (FIG. 7)
Use the dial for screw-in depth to set the
desired screw-in depth.
Turn the dial up (or clockwise) for driving
the screws deeper into the workpiece, or
down (counterclockwise) to allow more of the
screwhead to stick out from the workpiece. The
actual setting position is shown on the screw-in
depth indicator.
Upon setting, drive some screws for testing and
use the dial to adjust the depth, if required.
Fig. 7
Fig. 6a
a
b
Length marks
Arrow
Screw Length
Adjustment Tab
Fig. 6b
Locking Pin

-8-
ROTATING THE MAGAZINE (FIG. 8)
This collated magazine has the ability to rotate
without being taken off the drywall screwdriver.
To rotate, grip the top portion of the magazine
with one hand, while holding the drywall
screwdriver with the other hand, then rotate the
magazine. An audible “click” indicates that the
magazine is positioned at one of 12 detents
spaced 30° apart.
OPERATING INSTRUCTIONS
DRIVING IN SCREWS (FIG. 9)
a. Insert the collated screw strip.
b. Set the screw-in depth.
c. Set the direction of rotation, on your drywall
screwdriver, to forward rotation.
d. Grip the drywall screwdriver with both hands
on the handle and assume working position.
e. Place the shoe against the workpiece to be
screwed into. Hold the drywall screwdriver at
right angle to the workpiece surface
f. On your drywall screwdriver: depress and
hold down the trigger switch, then press the
lock-on button to lock the trigger switch. The
screw will be driven into the workpiece until
the set screw-in depth is reached. Check the
screw-in depth and change if required.
NOTE: When the preset screw-in depth is
reached, the drive is disengaged and the bit will
stop spinning while the motor is still running.
g. Repeat the operation to drive more screws.
h. When you have nished driving screws, turn
off the drywall screwdriver.
At the end of work, move the direction-of-
rotation selector, on the drywall screwdriver, to
the middle position.
Fig. 8
Fig. 9

-9-
MAINTENANCE
WARNING Disconnect the collated
screw magazine from the
drywall screwdriver prior to performing
maintenance or cleaning.
SERVICE
WARNING Preventive maintenance
performed by unauthorized
personnel may result in misplacing of internal
wires and components which could cause a
serious hazard. We recommend that all tool
service be performed by a FLEX Factory Service
Center or Authorized FLEX Service Station.
GENERAL MAINTENANCE
WARNING When servicing, use only
identical replacement
parts. Use of any other parts could create a
hazard or cause product damage. Periodically
inspect the entire product for damaged, missing,
or loose parts such as screws, nuts, bolts, caps,
etc. Tighten securely all fasteners and caps and
do not operate this product until all missing or
damaged parts are replaced. Please contact
customer service or an authorized service
center for assistance.
CLEANING
Use a brush and blow dust and debris out of the
main housing with dry compressed air as needed.
WARNING Wear appropriate eye
protection and dust mask
when using compressed air.
WARNING Never use solvents or
other harsh chemicals for
cleaning the non-metallic parts of the
magazine. These chemicals may weaken the
materials used in these parts.
To remove dust and debris from the interior of
the magazine, follow the steps below:
REMOVING AND INSTALLING THE
ADVANCING MECHANISM
CAUTION The advancing mechanism
is spring loaded. Always
use both hands to remove the advancing
mechanism. The return spring may eject from
the mechanism.
TO REMOVE THE ADVANCING MECHANISM
(FIG. 10a & 10b)
a. Disconnect the magazine from the
screwdriver.
b. Depress and hold the large spring pin.
c. Turn over the magazine and depress and hold
the small spring pin.
d. Pull the advancing mechanism off the
magazine
Fig. 10a
Large Spring Pin
b
Fig. 10b
Small Spring Pin
c
d

-10-
TO INSTALL THE ADVANCING MECHANISM
(FIG. 10c)
a. With the magazine attachment removed from
screwdriver, align the tabs on the shoe with
the slots in the magazine housing.
b. Push in slightly, then align the return spring
with the pocket in the advancing mechanism.
c. Push the advancing mechanism in and
depress the large spring pin and the small
spring pin on both sides at the same time,
until you hear the “click” of the two spring pins
releasing.
NOTE: The large spring pin should be in the
up position (as shown in Fig. 10c) before the
advancing mechanism is installed. If the large
spring pin is in the down position, the advancing
mechanism will be locked in place.
d. Cycle the advancing mechanism several
times by hand to ensure proper function
before installing the magazine onto your
screwdriver for use.
STORAGE
Store the collated screw magazine indoors in
a place that is inaccessible to children. Keep
away from corrosive agents.
ACCESSORIES
WARNING The use of any other accessories not specied in this manual may create a
hazard.
Collated screwdriver bit
Fig. 10c
Tabs
Large Spring
Pin Return Spring
Slots
