Flight 60® iO2
Quick Reference Guide
This quick reference guide does not replace the Flight
60 Operator’s Manual. The Flight 60 Operator’s Manual
containing instructions, warnings, cautions and other
important information for the safe and proper use of this
product must be carefully read prior to
using the Flight60 ventilator.
*
Not yet cleared for use in the USA
Alarms & Power Management
Patient Monitoring
Controlled Parameters
Alarm Reset
Circuit Connectors
Nebulizer Port *
ON/OFF
All manuals and user guides at all-guides.com
all-guides.com

A Circuit Test is to be performed each time a Patient Circuit or components
of a patient Circuit are replaced:
2
1. Connect an adult (500 ml) test lung with a 90 degree
elbow to the Flow Sensor’s patient side.
2. Press the Technical button once, and then
tap the Circuit TEST button.
3. Press Enter
Circuit TEST
All manuals and user guides at all-guides.com

3
Starting Ventilation
Turn on the ventilator by pressing
the On/Off button
Start ventilation by pressing and holding
the On/Off button for 2 seconds
Stopping Ventilation/
Shutting Down
Press the On/Off button once than
again for 2 seconds
All manuals and user guides at all-guides.com

4
Parameters Set Up
PEEPPtrig
-2.0 5
PSV above peep
10
Rate
14
PCV above peep
10
Ti
1.4
%O2Screen
ALARMS
21%
100% O2
OFF
Nebulizer
OFF SIMV PCV
Trigger (sensitivity)
setting
Pressure Support
setting
2 Minutes
100% O2
To Alarms Screen
Volume/Pressure
Setting
Nebulizer*
ON/OFF
Volume or
Pressure Ventilation
Selection
Ventilation Modes: ACMV, SIMV,
SPONT/CPAP, VtG/MVG, B-LEV
*
Not yet cleared for use in the USA
All manuals and user guides at all-guides.com

5
Extended Screen
Altitude Comp. SIGH
OFF OFF
NPPV
OFF
Trends
ON
PSV Flow Term. Rise Profile
3 15
PSV Ti
1.4
Waveform
Square
VG mode
VtG
Trigger Delay
OFF
Hold Length
3
Maneuvers
OFF
Altitude
Compensation
Non-Invasive
ON/OFF
MVG: Trigger Delay
ON/OFF
Inspiratory/
Expiratory Hold
Controls the length of
the maneuver
Square or
Descent
VtG : Tidal Volume Guarantee,
MVG: Minute Volume Guarantee
Flow Termination/Cycling -
from 10% to 70% of the
peak flow
Limit the
inspiratory time in
Pressure Support
All manuals and user guides at all-guides.com

Trigger Mode
Ptrig
NPPV
OFF
PSV Flow TermRise Profile
3 25
PSV Ti
1.0
Waveform
Square
ALARMS
Screen
High RateBuzzer
LOW OFF
LOW Rate
OFF
LOW Vte
OFF
LOW Vti
OFF
Apnea Interval
20
HIGH P LOW P
3 99
LOW MV
0.1
HIGH MV
20.0
FiO2 Low
OFF
FiO2 High
OFF
6
Alarms Screen
Buzzer Level
Selection
Apnea Interval
Setting
FiO2 Alarms ON/OFF
All manuals and user guides at all-guides.com
all-guides.com

7
Press the Technical button once, and
then tap the Set Load
LOW P SpontPress Units
cmH2O OFF
Language
English
Show
Info
Circuit
TEST
Set
Set
Load
Save
Set
Clock
Show Log
Alarm
Show Log
Change
Goto
More...
on-screen button
The control button turns orange, and a
pop-up list with the numbers of the saved
configurations appears.
Select the number of the saved configuration
Ventilation parameters will be adjusted to
the saved configuration under the selected
preset number
Preset Load
All manuals and user guides at all-guides.com

Flight Medical Innovations Ltd.
www.ight-medical.com
Local support: [phone]
LIT-0017-REV.A01
