Reison Clamp armboard 10019 User manual

1
Clamp armboard 10019 including versions
Version
Description
Pole type
10019
Clamp (EU 25x10 mm rail) with 10 mm spacer
10019-S30
Clamp (EU 25x10 mm rail) with 30 mm spacer
Ø20 mm
10019-UK
Clamp (UK 1¼ ” x ¼ ” rail) with 10 mm spacer
Ø18 mm
10019-US
Clamp (US 1⅛ ’’ x ⅜ ’’ rail) with 10 mm spacer
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-14
Document number: M10019EN rev.01
Clamp armboard 10019
ENGLISH

2
Intended use
Clamp intended to attach and position accessories, with a pole size Ø 16 mm or plane Ø 20 mm, to
the accessory rail on operating and examination tables. The product is to be used by medical
professionals within a medical facility.
Safety regulation
Maximum load: 10 kg inward load over the OR-table and 20 kg outward load away from the OR-table,
according to EN 60601-1 and EN 60601-2.
Before use, ensure correct function!
When loosening the lock handle to adjust the height, support the accessory, to prevent it from
uncontrolled descend into the bottom position.
Service and preventive maintenance shall be performed by authorized personnel.
MAX 20 kg
MAX 10 kg

3
User instruction
Installation
Usage
A.
B.
A.
B.
90o

4
Maintenance
Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel
only. Altering the construction without a written consent from the manufacturer, is strictly forbidden.
Cleaning
Clean with antiseptic detergent with pH 6 –8 and warm water. Ethanol can be used. Wipe dry with
soft cloth. Do not use strong acidic or alkaline detergent.
Control
Check that there are no loose parts and that there is no damage to any part. Check the clamp lock
function and the function for positioning and locking the accessory pole in the clamp.
Annual service
Once a year the clamp shall be carefully cleaned, moving parts shall be lubricated, the locking function
shall be tested

5
Spare parts
Version:
10019
10019-S30
10019-UK
10019-US
Description
Pcs.
Article no.
Article no.
Article no.
Article no.
1.
House
1
10031
10031
10543
10547
2.
Guide
1
10053
10053
10053
10053
3.
Adjustable handle
1
6-593-65
6-593-65
6-593-65
6-593-65
4.
Spacer
1
10526-A
10526-30
10526-A
10526-A
5.
Screw MC6S M6x45 FZ
2
-
-
-
-
6.
Shaft
1
10009
10009
10009
10009
7.
Spring
1
10013
10013
10013
10013
8.
Pressure pin
1
10012
10012
10012
10012
9.
Plunger
1
10711
10711
10711
10711
10.
Eccentric
1
11165
11165
11165
11165
11.
Lock lever
1
10014
10014
10014
10014
12.
Ball
1
K20M8S
K20M8S
K20M8S
K20M8S

6
Technical specification
Maximum workload
10 kg inward load over the OR-table and 20 kg outward load away from the
OR-table, according to EN 60601-1 and EN 60601-2.
Weight
0,65 kg
Material clamp
Aluminum
Version
UDI-DI
Dimension
(H x W x L)
10019
07350111830281
155 x 65 x 145
10019-S30
07350111830298
155 x 65 x 165
10019-UK
07350111830304
155 x 65 x 145
10019-US
07350111830311
155 x 65 x 145

7
Reison Medical AB
Eriksbergsvägen 32A
734 92 Hallstahammar
SWEDEN
