Flight Model F127 Zlin-42 60 Operation instructions

Caution:this plane is not a toy!
Before use ,please carefully read this
manual.
Engine:2Cycle 60,4Cycle 90;
Radio:4channels 5servos;
Flying Weight:3100g;Wing Span:65in/1650mm;
Wing Area:43sq.dm;
Length:53.5in/1360mm;

Cut away covering film for
the servo.
Install the servo to the
servo cover.
Install the servo cover to
the bottom of the wings,and
Assemble aileron、servo arm
and pushrod.

Pull out the servo extention
from main wing.
Cut off the film for work hol
e
Prepare to install rudder
servo.
Fixup the steering block
to the nylon clevis.

Assemble rudder servo.
Insert the rudder steel into
the steering block
Securely screw the rudder
steel to the steering block.

The finished photo as shown.
Adjust rudder servo angle.
Glue the vertical fin to the
fuselage.
Fixup the work hole as shown.
Glue the elevator to the
fuselage by AB glue.

Install the elevator pushrod.
Fixup the adjustable tri-horn
by screws.
Assemble front wheel steering
block pushrod as shown.
Elevator
servo
Rudder servo,which Links
the front wheel steering
block.
Throttle
servo.

Fixup the front wheel steerin
g
block as shown.
Assemble noseleg and steering
pushrod.
Gather main landing gear,
wheels and screws as shown.

Install the landing gear
by 3pcs screws.
Assemble fuel tank as shown.

Gather engine mount and
screws as shown.
Install engine mount as shown.
Assemble 2cycle 61 engine
as shown.

Assemble throttle pushrod
as shown.
Assemble 4cycle 91 engine
as shown.
Install throttle pushrod
as shown.

Install cowling as shown.
Fixup the main wing to the
fuselage by nylon screw.
Install the switch in the
right postion.

Install the battery and
receiver in the right positio
n
Assemble the canopy by 2pcs
screws that can defend
electric shock.

CG POSITION

FINISHED PHOTO
