Flightcom E13 ANR User manual

One-Year Limited Warranty to Original Purchaser
Flightcom Corporation warrants to the original purchaser of this product that it will be free from defects in materials and
workmanship, under normal and proper use, for the period of one year from date of purchase. Flightcom Corporation
will repair or replace, at its sole option, any parts showing factory defects during this warranty period,
subject to the following provisions. This warranty applies only to a new product which has been sold through authorized
channels of distribution. All work under warranty must be performed by Flightcom Corporation. All returned products
must be shipped to our address, freight prepaid, accompanied by a dated proof of purchase. SAVE YOUR SALES SLIP!
The purchaser voids this warranty if he, she or others attempt to repair, service or alter the product in any way.
This warranty does not apply in the event of accident, abuse, improper installation, unauthorized repair, tampering,
modification, fire, flood, collision or other damage from external sources, including damage which is caused by user
replaceable parts (leaking batteries, etc.). This warranty does not extend to any other equipment or aircraft to which
this product may be attached or connected. The foregoing is your sole remedy for failure in service or defect. Flightcom
Corporation shall not be liable under this or any implied warranty for incidental or consequential damages, nor for any
installation or removal costs or other service fees. This warranty is in lieu of all other warranties, express or implied,
including the warranty of merchantability or fitness for use, which are hereby excluded. To the extent that this exclusion
is not legally enforceable, the duration of such implied warranties shall be limited to one year from date of purchase.
No suit for breach of express or implied warranty may be brought after one year from date of purchase.
Questions? Call 1-800-432-4342
FLIGHTCOM CORPORATION
7340 SW Durham Road, Portland, Oregon 97224 U.S.A.
503-684-8229 • FAX [phone] • ser[email protected] • www.flightcom.net
© 2003 Flightcom is a registered trademark of Flightcom Corporation.
All rights reserved. Printed in U.S.A.
Specifications subject to change without notice.
E13 ANR Low Impedance Headset
600-0064-00 RevD.
PRODUCT DESCRIPTION: High durability Active Noise Reduction communication
headset, designed for use with military-style low impedance inter-phone systems.
Product features include the following:
Active Noise Reduction: powered by standard 9 volt battery
Microphone: M-87, 5 ohm microphone
Speakers: 16 ohm
Plug: U-174/U style plug, 4 conductor
Cord: shielded coil-cord, plug molding resistant to 15kg pull force
Ear Seals: silicone gel
Headpad: washable fleece comfort headpad
Color: flat black domes, chrome-steel headband and stirrups
Volume Control: mono headset, dual-volume controls
Warranty: one-year warranty
MAINTENANCE AND SUPPORT: Ear seal replacement is recommended annually or on
an as-needed basis. Please contact Flightcom Corporation 800-432-4342 for warranty or
repair services and request a Return Material Authorization (RMA number).
Important Note: reduce volume on aircraft interphone system before engaging ANR circuit.
Aircraft interphone volume can be adjusted to a comfortable level after the ANR circuit has
been activated.
For optimum ANR performance, boom must be worn on the left side.

larger contact
on bottom
B
•The mic boom should always be worn from the
left side.
•To increase the size of the headset, slide the domes
in a downward direction. To decrease, slide the
domes in an upward direction.
•Properly fitting the headset to each wearer’s head
is crucial to performance. The headpad should fit
comfortably on top of the head, without a gap or
space between the head and headpad. The headset
should be centered on the head, and the ear seals
should comfortably cover the ears without being
placed too far forward on the jawbone or face.
Place the mic no more than 1/8” from the lips to
ensure clarity and peak performance of the noise
canceling mic.
•Volume control is provided for each ear dome.
FITTING INSTRUCTIONS
Feedback (squealing):
•The mic boom should always be worn from the left
side. Speaker placements in this ANR system are
calibrated for this configuration. Wearing the mic
boom from the right may result in feedback (squealing).
•Be sure the ear seals are against the head on both sides.
•The electronics and acoustical cavity of the ear cup
were tuned to the characteristics of the Flightcom
ear seals, and we recommend that you only use
Flightcom replacement parts when performing
recommended annual hygiene maintenance.
Installing incorrect ear seals may result in improper
fit and feedback (squealing).
Volume too loud (or soft) in one ear dome:
Adjust volume using control knob on each ear dome
to achieve comfortable volume balance.
Blinking red LED on battery pack:
Battery voltage is low and needs replacing.
No light on battery pack:
ANR is switched off, or battery needs replacing.
Caution:
Inside each ear cup of your headset you will notice an
oval fabric piece. This is intended to prevent debris from
entering the speaker element and to help prevent
feedback of the ANR system. Do not operate the ANR
modules without these fabric pieces in place.
TROUBLESHOOTING
WIRING DIAGRAM
Right
Left
Speakers
Mic.
4 Conductor Plug
ANR circuitry is not represented in this diagram. Questions? Call 1-800-432-4342
Replacing the battery:
Do not use rechargeable batteries.
To install or replace the ANR
battery, open the battery door
by sliding the door in a downward
motion until it unlatches, and
lift up as shown in diagram A.
Slide the 9-volt battery in
with the large battery contact
on the bottom. If you put the
battery in upside down, it will
not activate. See diagram B.
Battery life is dependent on
the ambient noise in the
aircraft, but should provide
an average of 20 hours of
continuous use.
A
