FLIR A3 F series User manual

Getting started
FLIR A3xx f series

Important note
Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal
disclaimers.
Důležitá poznámka
Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim
rozumíte, a řiďte se jimi.
Vigtig meddelelse
Før du betjener enheden, skal du du læse, forstå og følge alle anvisninger, advarsler, sikkerhedsforanstaltninger og
ansvarsfraskrivelser.
Wichtiger Hinweis
Bevor Sie das Gerät in Betrieb nehmen, lesen, verstehen und befolgen Sie unbedingt alle Anweisungen, Warnungen,
Vorsichtshinweise und Haftungsausschlüsse
Σημαντική σημείωση
Πριν από τη λειτουργία της συσκευής, πρέπει να διαβάσετε, να κατανοήσετε και να ακολουθήσετε όλες τις
οδηγίες, προειδοποιήσεις, προφυλάξεις και νομικές αποποιήσεις.
Nota importante
Antes de usar el dispositivo, debe leer, comprender y seguir toda la información sobre instrucciones, advertencias,
precauciones y renuncias de responsabilidad.
Tärkeä huomautus
Ennen laitteen käyttämistä on luettava ja ymmärrettävä kaikki ohjeet, vakavat varoitukset, varoitukset ja lakitiedotteet
sekä noudatettava niitä.
Remarque importante
Avant d'utiliser l'appareil, vous devez lire, comprendre et suivre l'ensemble des instructions, avertissements, mises
en garde et clauses légales de non-responsabilité.
Fontos megjegyzés
Az eszköz használata előtt figyelmesen olvassa el és tartsa be az összes utasítást, figyelmeztetést, óvintézkedést és
jogi nyilatkozatot.
Nota importante
Prima di utilizzare il dispositivo, è importante leggere, capire e seguire tutte le istruzioni, avvertenze, precauzioni ed
esclusioni di responsabilità legali.
重要な注意
デバイスをご使用になる前に、あらゆる指示、警告、注意事項、および免責条項をお読み頂き、その内容を理解し
て従ってください。
중요한 참고 사항
장치를 작동하기 전에 반드시 다음의 사용 설명서와 경고,주의사항,법적 책임제한을 읽고 이해하며 따라야 합니다.
Viktig
Før du bruker enheten, må du lese, forstå og følge instruksjoner, advarsler og informasjon om ansvarsfraskrivelse.
Belangrijke opmerking
Zorg ervoor dat u, voordat u het apparaat gaat gebruiken, alle instructies, waarschuwingen en juridische informatie
hebt doorgelezen en begrepen, en dat u deze opvolgt en in acht neemt.
Ważna uwaga
Przed rozpoczęciem korzystania z urządzenia należy koniecznie zapoznać się z wszystkimi instrukcjami,
ostrzeżeniami, przestrogami i uwagami prawnymi. Należy zawsze postępować zgodnie z zaleceniami tam zawartymi.
Nota importante
Antes de utilizar o dispositivo, deverá proceder à leitura e compreensão de todos os avisos, precauções, instruções
e isenções de responsabilidade legal e assegurar-se do seu cumprimento.
Важное примечание
До того, как пользоваться устройством, вам необходимо прочитать и понять все предупреждения,
предостережения и юридические ограничения ответственности и следовать им.
Viktig information
Innan du använder enheten måste du läsa, förstå och följa alla anvisningar, varningar, försiktighetsåtgärder och
ansvarsfriskrivningar.
Önemli not
Cihazı çalıştırmadan önce tüm talimatları, uyarıları, ikazları ve yasal açıklamaları okumalı, anlamalı ve bunlara
uymalısınız.
重要注意事项
在操作设备之前，您必须阅读、理解并遵循所有说明、警告、注意事项和法律免责声明。
重要注意事項
操作裝置之前，您務必閱讀、了解並遵循所有說明、警告、注意事項與法律免責聲明。

Getting started
FLIR A3xx f series
#T810156; r. AA/34429/34429; mul

Table of contents
1 List of contents ...................... . .. . . . . . . . . . . . . ...................... .. . .. 1
2 Illustrations . . . . . ...................... ... . . . . . . . . . . . . . . . ..................... .. 2
3 EN-US English ................................... .. . .. . . . . . . . . . . . . ............. 3
#T810156; r. AA/34429/34429; mul vii

1 List of contents
• Infrared camera with lens and environmental housing
• Lens cap
• Printed documentation
• Small accessories kit
• ThermoVision System Tools & Utilities CD-ROM
Note FLIR Systems reserves the right to discontinue models, parts or acces-
sories, and other items, or to change specifications at any time without prior
notice.
#T810156; r. AA/34429/34429; mul 1

2 Illustrations
Note Explanations of the illustrations are provided in each language section.
Figure 2.1 Back cover
Figure 2.2 Rear view after the back cover has been removed
#T810156; r. AA/34429/34429; mul 2

3 EN-US English
3.1 Thank you!
Thank you for choosing a product from FLIR Systems. We hope that the product
will meet your expectations and that you will consider us again for your future
needs.
3.2 Read the manual before use
Go to the following website to read or download the
manual:
http://support.flir.com/resources/96jw
3.3 Register your product now
Be the first to receive advance notice on new product updates, software up-
grades, and special offers.
Go to the following website to register your product:
http://www.flir.com/thg/register
3.4 Download FLIR Tools
FLIR Tools lets you quickly create professional inspection reports that clearly
show decision makers what you’ve found with your IR camera.
Import, analyze, and fine-tune images easily. Then incorporate them into concise
documents to share findings and justify repairs.
Go to the following website to download FLIR Tools:
http://support.flir.com/tools
#T810156; r. AA/34429/34429; mul 3

3 EN-US English
3.5 Quick start guide
Follow this procedure:
1. Connect the power and video cables to the camera.
2. Connect the video cable from the camera to a display/monitor, and connect
the power cable to a power supply. The camera operates on 12/24 VDC, 9 W
max. (allowed range: 10–30 VDC) and heaters on 24 VDC, 25 W max. In to-
tal: 34 W. Verify that video output is displayed on the monitor.
3. Use an Ethernet cable to connect the camera either directly to a computer or
to a router that is connected to the same network as the computer.
4. Close down all applications on the computer.
5. Insert the ThermoVision System Tools & Utilities CD-ROM into the CD drive
on the computer. The installation should start automatically.
Should the installation not start automatically, start Windows Explorer and
double-click SETUP.HTM on the CD-ROM.
6. Click one of the following:
•Install FLIR IP Config (for all FLIR A3xx f series cameras).
•Install FLIR IR Monitor ( for FLIR A310f series cameras).
•Install AXXX Control & Image Interfaces (for FLIR A300f and FLIR A310f
series cameras).
Note For FLIR A315f series cameras, you can use FLIR Tools to set up
and control the camera. For more information, see section 3.4 Download
FLIR Tools, page 3. Use FLIR IP Config to identify the unit in the network and
set the IP address if necessary.
7. Follow the on-screen instructions.
3.6 Back cover
See Figure 2.1 Back cover, page 2.
1. Breather valve.
2. Ground lug.
3. Shipping plug.
4. Mounting screw (×4).
5. Shipping plug.
#T810156; r. AA/34429/34429; mul 4

3 EN-US English
3.7 Rear view after the back cover has been removed
See Figure 2.2 Rear view after the back cover has been removed, page 2.
1. Camera power.
2. Camera heater.
3. Video.
4. I/O ports.
5. Ethernet.
3.8 Training
Let the Infrared Training Center help you maximize your investment in thermal
imaging:
www.infraredtraining.com [email protected]
www.irtraining.eu [email protected]
www.irtraining.com [e-mail]
3.9 Customer support
Do not hesitate to contact our Customer Support Center at http://support.flir.com
if you experience problems or have any questions about your product.
#T810156; r. AA/34429/34429; mul 5
