FlowLine EchoPulse LR10 Series User manual

 RevA1



EchoPulse™
RadarLevelTransmitter
LR10,LR15,LR20,LR25&LR30SeriesManual



FlowlineInc.
10500HumboltStreet
LosAlamitos,CA90720
Tel:(562)598‐3015
Fax:(562)431‐8507
www.flowline.com

Page2of72MN301700RevA1
INTRODUCTIONSectionOne
TableofContentsPage
SectionOne|Introduction:..................................................................................................................................................2
TableofContents:.....................................................................................................................................................2
SensorModels:..........................................................................................................................................................4
OperatingPrinciple:..................................................................................................................................................4
Features:...................................................................................................................................................................4
Benefits:....................................................................................................................................................................4
Limitations:................................................................................................................................................................4
Specifications:...........................................................................................................................................................5
Dimensions:...............................................................................................................................................................8
SafetyPrecautions:.................................................................................................................................................11
SectionTwo|GettingStarted:...........................................................................................................................................12
SetupOverview:......................................................................................................................................................12
PartNumber:...........................................................................................................................................................14
SectionThree|InstallSensor:............................................................................................................................................16
InstallationRequirements:......................................................................................................................................16
LR15AntennaPreparation:.....................................................................................................................................17
MountingPosition:..................................................................................................................................................18
FlangeRiserInstallation:.........................................................................................................................................20
BeamAngle:............................................................................................................................................................21
StandPipeInstallation:...........................................................................................................................................22
SightGlassInstallation:...........................................................................................................................................23
LR30SensorInstallation:.........................................................................................................................................24
LR98DisplayInstallation:........................................................................................................................................25
SectionFour|WireSensor:................................................................................................................................................26
TerminalWiring:.....................................................................................................................................................26
LR30SensortoLR98Display:..................................................................................................................................27
WiringtoDisplays,Controllers&PLCs:...................................................................................................................28
SectionFive|Configuration:..............................................................................................................................................30
BasicConfigurationOverview:................................................................................................................................30
UsingtheDisplay:....................................................................................................................................................31
ChangingDisplayValues:........................................................................................................................................32
Step1‐MeasuretheTank:.....................................................................................................................................33
Step2‐SettheUnitsofMeasurement:.................................................................................................................34
Step3‐SettheEmptyConfiguration(4mA):..........................................................................................................35
Step4‐SettheFullConfiguration(20mA):............................................................................................................36
Step5‐SettheRange(MaximumRange):.............................................................................................................37
Step6‐SettheDeadBand:....................................................................................................................................38
Step7‐ChecktheEchoCurve:...............................................................................................................................39
SectionSix|ProcessAdjustments:.....................................................................................................................................40
ProcessAdjustmentsOverview:.............................................................................................................................40
FastFillingorEmptyingofLiquid:...........................................................................................................................41
LiquidSurfaceisTurbulentorAgitated:.................................................................................................................42
FoamontheSurfaceoftheLiquid:.........................................................................................................................43
SensorInstalledinaStandPipeorSightGlass:......................................................................................................44

RevA1MN301700Page3of72
INTRODUCTIONSectionOne
SectionSeven|AdvancedAdjustments:...........................................................................................................................45
AdvancedAdjustmentsOverview:..........................................................................................................................45
4‐20mAReverseOutput:........................................................................................................................................46
Fail‐SafeOutput:.....................................................................................................................................................47
MinimumCurrentOutput:......................................................................................................................................48
CreateaNewFalseEchoCurve:.............................................................................................................................49
UpdateanExistingFalseEchoCurve:.....................................................................................................................50
SectionEight|Troubleshooting:.........................................................................................................................................51
TroubleshootingOverview:.....................................................................................................................................51
MeasurementStatus:..............................................................................................................................................52
PeakValues:............................................................................................................................................................53
Simulation:..............................................................................................................................................................54
FirstEchoAdjustment:............................................................................................................................................55
EchoCurveZoom:...................................................................................................................................................56
FalseEchoCurveDelete:.........................................................................................................................................57
Reset:......................................................................................................................................................................58 
SectionNine|Appendix:.....................................................................................................................................................59
ConfigurationMenu:...............................................................................................................................................59
EmptyConfiguration:..............................................................................................................................................60
FullConfiguration:...................................................................................................................................................60
Medium:..................................................................................................................................................................61
LowDielectricMedium:..........................................................................................................................................62
Dampen:..................................................................................................................................................................63
ScaledUnits:............................................................................................................................................................63
Range:.....................................................................................................................................................................63
DeadBand:..............................................................................................................................................................63
DisplayMenu:.........................................................................................................................................................64
DisplayValue:..........................................................................................................................................................64
LCDContrast:..........................................................................................................................................................64
DiagnosticsMenu:...................................................................................................................................................65
PeakValues:............................................................................................................................................................65
MeasurementStatus:..............................................................................................................................................65
EchoCurve:.............................................................................................................................................................66
Simulation:..............................................................................................................................................................66
ServiceMenu:.........................................................................................................................................................67
FalseEcho:...............................................................................................................................................................68
OutputSettings:......................................................................................................................................................68
Reset:......................................................................................................................................................................69
UnitsofMeasurement:...........................................................................................................................................69
Language:................................................................................................................................................................69
Information:............................................................................................................................................................70
FactorySettings:......................................................................................................................................................70
UserConfiguration:.................................................................................................................................................70
Notes:......................................................................................................................................................................71
Warranty:................................................................................................................................................................72

Page4of72MN301700RevA1
INTRODUCTIONSectionOne
SensorModels
Offeredinfivedifferentmodels,EchoPulse™isageneral‐purpose,two‐wire,pulseradarlevelsensorthatprovidesa
continuous4‐20mAcurrentoutputthat’sproportionaltotheliquidlevelinatankorsump.Makesurethatthemodel
purchasedisappropriateforyourapplication.
OperatingPrinciple
Thesensoremitsamicrowavepulsefromitsantenna,whichtravelsatthespeedoflighttothesurfaceofthemedium
below.Aportionofthatenergyreflectsoffthemediumandreturnstotheantenna.Thetimegapbetweenenergy
emissionandreceiptiscalledthe“timeofflight”,andisproportionaltothedistancebetweenthemediumsurfaceand
thesensorsmeasurementlocation,whichistypicallylocatedatthebottomoftheantenna.Thesensormeasuresthe
timeofflightandtranslatesthisvalueintoacontinuous4‐20mAsignaloutputthat’sproportionatetolevelwithina
definedmeasurementspan.
Features
EasyconfigurationwithLCDpushbuttondisplaymodule
Adjustableloopfail‐safe,nochange,20.5mA,22mA
Small12”(30.48cm)deadbandenablesfulltankmeasurement
Recognition,storageanddeletionoffalseechosignalreturns
Benefits
Unaffectedbyphysicalprocessandenvironmentalconditions
Idealforapplicationswithhighertemp,pressure,foamandvapor
Strongsignalpenetrabilitywithminimalattenuationoverdistance
Limitations(factorsthatcouldinfluenceperformance)
Airparticulateswithahighdielectricconstantvaluesuchasleadorferroalloy
Highlydenseairparticulatesthatattenuatemicrowaveemissionandreceipt
Materialbuild‐upontheantennathatdegradesmicrowaveemissionandreceipt
Mediumswithanextremelylowdielectricconstantvaluewithlittlereflectivity

SeriesMax
RangeBeamAngleMaterialMountingFCC ComplianceApplication
LR1032.81’
(10m)22°PTFE1‐1/2”NPTPart15.209,ClassACorrosiveliquidsunder simpleprocessconditions
LR1598.42’
(30m)
18°(2”horn)
316LSS1‐1/2”NPT
Part15.209,ClassAStoragetanks&process
tanksunderdifficult
processconditions
12°(3”horn)Part15.256,ClassB
8°(4”horn)Part15.256,ClassB
LR2065.61’
(20m)
12°(3”Flange)316LSS
withPTFE
cover
3”ANSIflange
Part15.256,ClassB
Aggressiveliquidsunder
extremelydifficultprocess
conditions
8°(4”flange)4”ANSIflange
LR25114.83’
(35m)20°
316LSS
withPTFE
cover
4”ANSIflange
6”ANSIflange(pending)
Storagetank&process
tanksunderextremely
difficultprocessconditions
LR3098.42’
(30m)12°PA66
Bracketortop
mounted(1”)
conduit
Part15.256,ClassB
Waterprocessing,lift
stations,stormwaterand
sumpprocessconditions

RevA1MN301700Page5of72
INTRODUCTIONSectionOne
Specifications
MeasurementRange:
SeriesLR10LR15LR20LR25LR30
Range(Max)32.81ft
(10m)
98.42feet
(30m)
65.61feet
(20m)
114.83feet
(35m)
98.42feet
(30m)
DeadBand:12”(30.48cm)/FactorySet
Note:Canbeloweredto2”fromthebottomoftheantenna
MeasurementAccuracy:(seechartsonPage7)
SeriesLR10LR15LR20LR25LR30
Accuracy±5mm±3mm±3mm±10mm±3mm
DisplayResolution:1mm
FrequencyRange:LR10,LR15,LR20,LR30:......26GHz
LR25:...................................6.3GHz
MeasurementInterval:About1sec(dependentonconfigurationsettings)
AdjustmentTime:About1sec(dependentonconfigurationsettings)
BeamAngle:
SeriesLR10LR15LR20LR25LR30
Beam
Angle22°
18°‐2”(48mm)Horn
12°‐3”(78mm)Horn
8°‐4”(98mm)Horn
12°‐3”ANSIFlange
8°‐4”ANSIFlange20°12°
ProcessConnection:Seepartnumberdescription
Material:
SeriesLR10LR15LR20LR25LR30
FlangeN/A316LSSN/A
EnclosureAluminumPA66
AntennaPTFE316LSS316LSSwithPTFECoverPA66
ExtensionPBT‐FRN/A
SealViton
SealRingSilicone(betweenhousingandcap)
WindowPolycarbonateN/A
GroundTerminalStainlessSteel
BracketN/A304SS
Weight:Dependsonprocessconnectionsizeandhousing
SeriesLR10LR15LR20LR25LR30
Weight2.20lbs
(1kg)
4.41lbs
(2kg)
6.61lbs
(3kg)
6.61lbs
(3kg)
2.2lbs
(1kg)
Temperature:
SeriesLR10LR15LR20LR25LR30
Process
Temp
F:‐40°to266°
C:‐40°to130°
F:‐76°to302°
C:‐60°to150°
F:‐40°to302°
C:‐40°to150°
F:‐40°to266°
C:‐40°to130°
F:‐40°to212°
C:‐40°to100°
Storage
Temp
F:‐40°to176°
C:‐40°to80°
RelativeHumidity:<95%


Page6of72MN301700RevA1
INTRODUCTION SectionOne
ProcessPressure:
SeriesLR10LR15LR20LR25LR30
Pressure‐14.5to43.5psi
(‐1to3bar)
‐14.5to150psi
(‐1to10.3bar)
‐14.5to72.5psi
(‐1to5bar)
‐14.5to580psi
(‐1to40bar)Atmospheric
VibrationProof:Mechanicalvibration10m/s,10m2/s,10‐150Hz
Output:
SignalOutput:4‐20mA
Resolution:1.6µA
Fail‐SafeSetting:20.5mA,22mAornochange
LoadResistance:Seechartbelow



IntegrationTime:0‐40sec,adjustable
Power:
PowerSupply:24VDC(16to26VDC)Thesametwo‐wireconnectioncablecarriespowersupplyand
currentsignal.
PowerConsumption:22.5mAmaximum
RippleAllowed:
<100Hz:<1V
100to100KHz:<10mV
EnclosureRating:LR10,LR15,LR20,LR25:…………IP67(NEMA6)
LR30:………………………………………IP68(NEMA6P)
CableConnection:Standard2‐wireshieldedcablewithearthgroundwireandoutsidediameterof5‐9mm
isrecommended.
CableEntry/Plug:LR10,LR15,LR20,LR25:.............Dualcableentry(½”NPTwithadapter,M20x1.5)
LR30:........................................Onecableentry(1”NPT)
SpringConnectionTerminal:Applicableforcableswithcrosssectionif2.5mm2
Certification:GeneralPurpose:cTUVus(UL61010‐1:2012&CAN/CSA‐C22.2No.61010‐1‐12)
Communication:FCC(US)
Part15.209,ClassA:LR10,LR15(2”horn)seriesonly
Part15.256,ClassB:LR15(3”&4”horn),LR20&LR30seriesonly
Compliance:CE[EN61326(1997w/A1:98,A2:01&A3:03)ClassA]
RoHS
Classification:GeneralPurpose



RevA1MN301700Page7of72
INTRODUCTIONSectionOne
AccuracyCharts







Page8of72MN301700RevA1
INTRODUCTIONSectionOne
LR10Series

LR15Series(Threaded)


LR15Series(Flange) LR15Series(Threaded)AntennaDimensions
Diameter(X)Length(Y)
2”(48mm)5.51”(140mm)
3”(78mm)8.94”(227mm)
4”(98mm)11.34”(288mm)






LR15Series(Flange)Dimensions
Flange(A)Diameter(B)Thickness(C)
3”ANSI7.5”(190.5mm)0.88”(22.3mm)
4”ANSI9.0”(228.6mm)0.88”(22.3mm)
6”ANSI11.0”(279.4mm)0.94”(23.9mm)

LR15Series(Flange)AntennaDimensions
Diameter(D)Length(E)
2”(48mm)6.36”(161.5mm)
3”(78mm)9.78”(248.5mm)
4”(98mm)12.18(309.5mm)


RevA1MN301700Page9of72
INTRODUCTIONSectionOne
LR20Series

LR25Series









LR20SeriesFlange/AntennaDimensions LR25SeriesFlange/AntennaDimensions
Flange
(A)
Diameter
(B)
Thickness
(C)
Length
(D)
3”
ANSI
7.5”
(190.5mm)
0.88”
(22.3mm)
6.50”
(165mm)
4”
ANSI
9.0”
(228.6mm)
0.88”
(22.3mm)
8.00”
(203mm)

Flange
(A)
Diameter
(B)
Thickness
(C)
Length
(D)
4”
ANSI
9.0”
(228.6mm)
0.57”
(14.5mm)
5.71”
(145mm)
6”
ANSI
11.0”
(279.4mm)
0.63”
(16.1mm)
9.75”
(247.7mm)





Page10of72MN301700RevA1
INTRODUCTIONSectionOne
LR30SeriesBracket(TopView)

LR30Series(SideViewA)









LR30Series(SideViewB)

LR98SeriesDisplay
(FrontView)

LR98SeriesDisplay
(BottomView)
LR98SeriesDisplay
(SideView)

Note:BothconduitportsfeatureM20x1.5threads.LR98shipswithLiquidTightFitting(LM90‐1051)andLR97‐S003
Adapter(½”FNPTtoM20x1.5).Usetheadaptertointerfacetoany½”MNPTconnection.

RevA1MN301700Page11of72
INTRODUCTIONSectionOne
SafetyPrecautions
AboutthisManual:PLEASEREADTHEENTIREMANUALPRIORTOINSTALLINGORUSINGTHISPRODUCT.This
manualincludesinformationontheEchoPulse™RadarLevelTransmitterfromFLOWLINE.Pleaserefertothepart
numberlocatedonthesensorlabeltoverifytheexactmodel,whichyouhavepurchased.
User’sResponsibilityforSafety:FLOWLINEmanufacturesabroadrangeoflevelsensingtechnologies.Whileeach
ofthesesensorsisdesignedtooperateinawidevarietyofapplications,itistheuser’sresponsibilitytoselectasensor
modelthatisappropriatefortheapplication,installitproperly,performtestsoftheinstalledsystem,andmaintainall
components.Thefailuretodosocouldresultinpropertydamageorseriousinjury.
ProperInstallationandHandling:Onlyprofessionalstaffshouldinstalland/orrepairthisproduct.Neverover
tightenthesensorwithinthefitting.Alwayscheckforleakspriortosystemstart‐up.
WiringandElectrical:Asupplyvoltageof16to26VDCisusedtopowertheEchoPulse™.Electricalwiringofthe
sensorshouldbeperformedinaccordancewithallapplicablenational,state,andlocalcodes.
MaterialCompatibility:TheenclosureismadeofeitherAluminumor316StainlessSteel(refertosensorpart
number).TheantennaismadeofStainlessSteel(SS),Polytetrafluoroethylene(PTFE)orNylon(PA66)withaVitonseal
(refertosensorpartnumber).Makesurethatthemodel,whichyouhaveselected,ischemicallycompatiblewiththe
applicationmedia.
Enclosure:Thesensorhousingisliquid‐resistant,butisnotdesignedtobeoperationalwhenimmersed(LR30series
isdesignedforsubmersionbutwillnotprovideatruelevelreadingwhilesubmersed).Mountthesensorinsuchaway
thattheenclosureandantennadonotcomeintocontactwiththeapplicationmediaundernormaloperational
conditions.Theenclosurehasacoverthatprovidesaccesstothepushbuttondisplaymoduleandterminalstripfor
wiring.Toopentheenclosure,youwillneedtotwistthecovercounter‐clockwise.Beforeclosingtheenclosure,make
surethattheenclosuregasketisproperlyseated,andthatanyconduitfittings,cableconnectorsorplugsareinstalled
correctlyandsealed.Note:IfusingtheFlowlineLM90‐1001(liquidtightfitting)onthe½”conduit,thecableminimumis
0.170”(4.3mm)andthemaximumis0.450”(11.4mm).
MakeaFail‐SafeSystem:Designafail‐safesystemthataccommodatesthepossibilityofsensorand/orpower
failure.FLOWLINErecommendstheuseofredundantback‐upsystemsandalarmsinadditiontotheprimarysystem.
Flammable,ExplosiveorHazardousApplications:EchoPulse™isapprovedforusewithingeneralpurpose
applicationsONLYandshouldNOTbeusedwithinclassifiedhazardousenvironments.
HandlingStatic‐SensitiveCircuitsandDevices:Whenhandlingtheinstrument(part),thetechnicianshouldfollow
thebelowguidelinestoreducethepossibilityofanelectrostaticchargebuild‐uponthetechnician’sbodyfrombeing
transferredtotheelectronicpart.Alwaystouchaknowngoodgroundsourcebeforehandlingapart.Thisshouldbe
repeatedwhilehandlingthepartandmorefrequentlyaftersittingdownfromastandingposition,slidingacrosstheseat
orwalkingadistance.Avoidtouchingelectricalterminalsofthepartunlessmakingconnections.DONOTopentheunit
coveruntilitistimetoworkonthepart.

Page12of72MN301700RevA1
GETTINGSTARTEDSectionTwo
SetupOverview
Thebelowhighlightstheinitialstepsinsettingupyoursensorforoperation.
1. PartNumber(SectionTwo)
1. Priortopurchasingthesensor,youshouldhavesubmittedaLevelApplicationQuestionnaire
(www.flowline.com/LAQ),whichbasedupontheinformationprovided,mayhaveresultedina
suggestedpartnumber.Whereso,confirmthatthesuggestedpartnumbermatchesthepartnumber
ofthepurchasedsensor.Ifanyoftheabovedoesnotmatchand/ormeetyourapplication
requirements,pleasecontactyourdistributor.
2. InstallSensor(SectionThree)
1. Informationonthelocationandmechanicalinstallationofthesensor.
3. WireSensor(SectionFour)
1. Informationontheelectricalwiringandpowerrequirementsofthesensor.
4. BasicConfiguration(SectionFive)
1. Beginbymeasuringthetankforallkeydimensions.
a. Accuracyinmeasurementwillresultinaccuracyofsensorperformance.
2. SettheUnitsofMeasurementforthesensor.
a. Unitscanbeconfiguredinbasicengineeringunitsoflength:Feet,Meters
3. SettheEmptyConfigurationforthesensorinthetank.
a. Thisisthe4mAsettingfortheoutput.
4. SettheFullConfigurationforthesensorinthetank.
a. Thisisthe20mAsettingfortheoutput.
5. SettheRange(MaximumRangeorMaxR)forthesensorinthetank.
a. Thesensorwillignoreanyechosignalreturnsbeyondthissetting.
6. SettheDeadBand(MinimumRangeorMinR)forthesensorinthetank.
a. Thesensorwillignoreanyechosignalreturnscloserthanthissetting.
7. ChecktheEchoCurve
a. Thisisaquickchecktodetermineifthesensorisreadingthecorrectlevel.
5. ProcessAdjustments(SectionSix)
1. InformationonOPTIONALadjustmentsforspecificprocessconditionsthatmayexistinyourapplication.
a. Fastfillingoremptyingofliquid.
b. Liquidsurfaceisturbulentoragitated.
c. Foamonthesurfaceoftheliquid.
d. Sensorinstalledinastillwellorsightglass.









RevA1MN301700Page13of72
GETTINGSTARTEDSectionTwo
6. AdvancedAdjustments(SectionSeven)
1. Reverse4‐20mAOutput
a. Reversesthecurrentoutfrom4mA@bottomand20mA@topoftankto20mA@bottomand
4mA@topofthetank.
2. Fail‐SafeSetting
a. Allowsforthepresettingofthecurrentoutputwhenasensorfailureoccurs.
3. MinimumCurrentSetting
a. Setstheminimumcurrentoutputforthesensor.
4. CreateaNewFalseEchoCurve
a. Amethodtomapoutfalseechosignalreturnswithinthetank.
5. UpdateanExistingFalseEchoCurve
a. Amethodtoupdatefalseechosignalreturnsforasectionofthetankthatwasnotexposed
duringthecreationoftheoriginalFalseEchoCurve.
7. Troubleshooting(SectionEight)
1. MeasurementStatus
a. Determinesthemeasurementreliabilityandgeneralstatusofthesensor.
2. PeakValues
a. Displaysthelowestandhighestlevelheightthatthesensorhasmeasuredindistance(d).
3. Simulation
a. Simulatesandhelpstodeterminetheaccuracyandlinearityofthesensor.
4. FirstEchoAdjustment
a. Increasesordecreasesthestrengthofthefirstechosignalreturn.
5. EchoCurveZoomIn
a. AmethodtozoominandviewtheEchoCurveoveraspecificrange.
6. FalseEchoCurveDelete
a. AmethodtodeleteapreviouslysavedFalseEchoCurvefrommemory.
7. Reset
a. Amethodtoresetthesensor’sconfigurationtotheoriginalfactorysetting.


Page14of72MN301700RevA1
GETTINGSTARTEDSectionTwo
PartNumber
Priortopurchasingthesensor,youshouldhavesubmittedaLevelApplicationQuestionnaire(www.flowline.com/LAQ),
whichbasedupontheinformationprovided,mayhaveresultedinasuggestedpartnumber.Whereso,confirmthatthe
suggestedpartnumbermatchesthepartnumberofthesensor.Thepartnumbercanbefoundontheoutsidelabelon
thesensorasshownbelow:
LR10Series
 LR15Series  LR20Series  LR25Series  LR30Series 




Thepartnumberwillindicatethesizeandtypeofmountingfittingrequiredforinstallingthesensor.Refertothebelow
partnumberdescriptionforspecificinformation.Ifanyoftheabovedoesnotmatchand/ormeetyourapplication
requirements,pleasecontactyourdistributor.

LR10‐0010
HousingMaterial
0‐Aluminum
ProcessConnection
0‐Thread1½"NPT
Output
1‐4‐20mA
Approval
0‐GeneralPurpose(cTUVus)

LR15‐0010‐_0
HousingMaterial
0‐Aluminum
ProcessConnection
0‐Thread1½"NPT
Output
1‐4‐20mA
Approval
0‐GeneralPurpose(cTUVus)
AntennaSize
2‐2"(48mm)Horn
3‐3"(78mm)Horn
4‐4"(98mm)Horn
FlangeSize
0‐ThreadedConn.


RevA1MN301700Page15of72
GETTINGSTARTEDSectionTwo

LR20‐031 0‐_0
HousingMaterial
0‐Aluminum
ProcessConnection
3‐ANSIFlange
Output
1‐4‐20mA
Approval
0‐GeneralPurpose(cTUVus)
FlangeSize
3‐3"Flange(ANSI)
4‐4"Flange(ANSI)

LR25‐031 0‐_0
HousingMaterial
0‐Aluminum
ProcessConnection
3‐ANSIFlange
Output
1‐4‐20mA
Approval
0‐GeneralPurpose(cTUVus)
FlangeSize
4‐4"Flange(ANSI)
6‐6"Flange(ANSI)

LR30‐0010‐10
HousingMaterial
0‐Nylon (PA66)
Mount
0‐Bracket
Output
1‐4‐20mA
Approval
0‐GeneralPurpose(cTUVus)
Display(LI98‐1001)
1‐WithDisplay









Page16of72MN301700RevA1
INSTALLSENSORSectionThree
InstallationRequirements
EchoPulse™measuresthedistancebetweenthesensorandtheliquidsurfacebelow.Typically,allmeasurementsfrom
thesensororiginatefromthebottomoftheantenna.RefertotheMeasurementReferenceCharttodeterminethe
locationwheremeasurementoriginatesonyoursensor.Toensurereliablemeasurement,adheretothefollowing
minimuminstallationrequirements:
1. Therearenoobstructionsbetweenthebottomedgeoftheinstalledantennaandthesurfaceoftheliquidbelow
includingladders,walls,tankseams,liquidinflows,rails,othersensors,mixerblades,heatingcoils,pumps,struts
orapparatus.Note:Additionally,whenthesensortransmitsamicrowavepulse,theRFsignalspreadsinaconical
shape(determinedbyitsbeamangle)overdistance.RefertotheBeamAngleCharttodetermine,whatifany,
additionalmeasurementspaceisrequiredtobefreeofsuchobstacles.Ifsuchitemsarepresent,thenaFalse
EchoCurveconfigurationmustbedone(SectionSeven).
2. Thesensormustbeinstalledwiththeantennaperpendiculartothesurfaceoftheliquid.
3. Thesensormustbeinstalledwithadistance≥19.7”(500mm)fromthesidewallofthetank.
4. Theliquidlevelmustnotbeallowedtoenterintothedeadband(blankingzone)ofthesensor.
5. Thesensorinstallationmustbedoneinaccordancewithrelevantlocalorfederalsafetyregulations.
6. Thesensormustbeconnectedtoelectricalground.
7. Donotusethehousingtoscrewthesensorintotheinstallationfitting(LR10&LR15Series).
1. Applyingatighteningforceagainstthehousingmaydamagethesensor.
8. Makesurethatallpartsofthesensorexposedtotheapplication,specificallyanyportioninstalledwithinthe
tank,aresuitablefortheprocess.
1. Consideranyeffectsfromtheapplicationtemperature,pressureormedia.
FCCConformity
ThisinstrumentcomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)
thisinstrumentmaynotcauseharmfulinterference,and;(2)thisinstrumentmustacceptanyinterference
received,includinginterferencethatmaycauseundesiredoperation.
Changesormodificationsnotexpresslyapprovedbythemanufacturercouldvoidtheuser’sauthoritytooperate
theequipment.
Warning:Usermustkeepasafetydistanceofatleast20cmfromtheantenna.
Note:LR10,LR15(2”horn)seriesThisequipmenthasbeentestedandfoundtocomplywiththelimitsfora
ClassAdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferencewhentheequipmentisoperatedinacommercialenvironment.This
equipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructionmanual,maycauseharmfulinterferencetoradiocommunications.Operationofthis
equipmentinaresidentialareaislikelytocauseharmfulinterferenceinwhichcasetheuserwillberequiredto
correcttheinterferenceattheirownexpense.
Thisequipmentisnotallowedtobeconnectedtopublicutilitypowerlines.
NOTE:LR15(3”&4”horn),LR20&LR30series:Thisequipmenthasbeentestedandfoundtocomplywiththe
limitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgeneratesuses
andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,may
causeharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencetoradio
andtelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouraged
totrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
Reorientorrelocatethereceivingantenna.
Increasetheseparationbetweentheequipmentandthereceiver.
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

RevA1MN301700Page17of72
INSTALLSENSORSectionThree
LR15AntennaPreparation
TheLR15Seriesantenna(only)mayberemovedfromthesensortoallowaflangeorreducerbushingaccessorytobe
attachedtothe1½”NPTmountingthreadsand/or,theantennamaybeinsertedfromwithintheinsideofthetank
throughthebottomofanexistingfitting(wherethebaseoftheantennaistoowidetopassthroughthefittingfromthe
top).Referencingtheillustrations,followthebelowstepstodisconnect,mountandreattachtheantenna.

1) Loosenandremovethefour(4)socketscrewsusinga3mmAllenwrench.
2) Carefullyremovetheantenna.Note:Donotremoveordamagetheplasticconewithintheantennasocket.
3) Inserttheantennathroughthebottomofthefitting.Note:Ifdoingsofromtheinsideofthetank,makesureto
secureit,soastopreventtheantennafromfallingintothetank.
4) Connectthesensortotheantennasocketandreattachthefour(4)screwsusinga3mmAllenwrench.
5) Attachthesensortothefittingasnecessary.
AddaFlange
RemoveScrewsRemoveAntennaInsertAntennaConnectAntennato
Sensor,AttachScrews
ThreadSensorto
Flange

AddaReducerBushing
RemoveScrewsRemoveAntennaInsertAntennaConnectAntennato
Sensor,AttachScrews
ThreadSensorto
ReducerBushing



Page18of72MN301700RevA1
INSTALLSENSORSectionThree
MountingPosition
Theminimumdistance(independentofbeamangle)thatthe
sensorcanbemountednexttothestraightsidewallofthetank
is19.7”(500mm)asmeasuredfromthesensorcenterlinetothe
sidewall.Ifyouarenotabletoinstallthesensormorethan
19.7”(500mm)awayfromthesidewall,orifthereismaterial
builduponthesidewall(withinthebeamangle),performa
FalseEchoCurveduringinitialconfiguration.
Avoidmountingthesensorinthecenterofadometoptank.Thecenterofsuchatankwillmultiplytheechoes,making
sensoroperationdifficult.

CorrectMounting
Sensormountedoffcenterinadome
toptank.

IncorrectMounting
Sensormountedinthecenterofa
domedtoptankresultinginmultiple
echoes.
Inconebottomtanks,itcanbeadvantageoustomountthesensorinthecenterofthetank,makingitpossibleforthe
sensortomeasureclosertothebottomofthetank.Ifthesensorismountedoveranangledbottom,andthelevel
dropsbelowtheangle,theechowillbedeflectedawayfromthesensor,resultinginpooroperation.Thesensorcanbe
mountedoveranangledbottomaslongasthelevelismaintainedwithinthestraightsidewallsothesensorwillreceive
echoreturns.
CenterMount‐CorrectLevelBelowSideWall‐IncorrectLevelAboveSideWall–Correct



RevA1MN301700Page19of72
INSTALLSENSORSectionThree
MounttheSensorPerpendiculartotheLiquidLevel
Alwaysmountthesensorperpendiculartothesurfaceoftheliquid.Thiswill
enablethereturnechoestoreachthesensor.Mountingthesensoroff‐axiswill
resultinweakerreturnechoesornoreturnechoes,dependingonthedegree
ofangle.
ConsidertheDeadBand
Thesensorhasadeadband(blankingdistance)of12”(30.48mm)asitsdefault.
Thedeadbandcanbeloweredtowithin2”ofthebottomoftheantenna
(consultwithfactory).Thisisanupclosedistancewherethesensorisnot
abletomeasurethelevelwithinthisrange.Typically,themeasurement
locationforthesensorisatthebottomoftheantenna.Whenidentifyinga
locationforsensorinstallation,takeintoaccountthelengthoftheantenna
combinedwiththedeadbandofthesensor.
AvoidCondensationintheConduit
Youcangiveyourinstrumentadditionalprotectionagainstmoisture
penetrationbyleadingtheconduitconnectionorcabledownwardinfrontof
thecableentry.Condensationintheconduitwillthusnotenterthesensor
enclosure.






Page20of72MN301700RevA1
INSTALLSENSORSectionThree
AvoidObstructionsintheBeamPath
Donotmountthesensorinorabovethefillstream,otherequipment(ladders,pumps,mixers)orstructureswithinthe
beampathofthesensor.Suchitemscancreatefalseechoreturnsandpreventtheactuallevelfrombeingseenbythe
sensor.Findalocationwherethesensorhasaclearviewoftheliquidsurface.Ifyourtankhasotherequipmentnearor
withinthebeampathofthesensor,aFalseEchoCurveshouldbeperformedduringinitialconfiguration.

FillStreamMounting
Mountingonleftincorrectlypositions
sensorabovethetankfillstreaminlet.
Mountingonrightiscorrectasthe
sensorhasanunobstructedviewto
theliquidlevelbelow.
ReflectorInstallation
Mountingonleftincorrectlyallows
thesensortoreceivefalseecho
returnsfromthestep.
Mountingonrighthasanangled
baffle‐boardmountedoverthestep,
whichpreventsthefalseechofrom
returningtothesensor.Assuch,the
sensoronlyreceivescorrectecho
returnsfromtheliquidlevel.
FlangeRiserInstallation
Wheninstallingthesensoronaflangewithariser(oranyfittingthatistallandnarrow),theantennamustprotrudeat
least0.4”(10mm)fromthebottomoftheriser.Thesensorcanbeinstalledwithintheriseraslongastheliquidhasa
strongreflectiveproperty(dielectricconstant)providingastrongechoreturn.Thebelowinformationdescribesthe
maximumdistancethattheantennacanberecessedwithinariserbasedonthediameterandheightofthefitting.

AntennaExtension

LR15Series

LR10&LR15Series
Diameter(D)Height(H)
1‐½”7.9”(200mm)
2”(50mm)9.8”(250mm)
3”(80mm)11.8”(300mm)
4”(100mm)19.7”(500mm)
6”(150mm)31.5”(800mm)

LR20&LR25Series
Diameter(D)Height(H)
3”(80mm)11.8”(300mm)
4”(100mm)19.7”(500mm)
6”(150mm)31.5”(800mm)

LR20Series


