Fluke T5-600 User manual

PN 1629509 (English) July 1997, Rev. 2, 9/01
© 2001 Fluke Corporation, All rights reserved. Printed in U.S.A.
®
T5-600/T5-1000
Electrical Tester Instruction Sheet
W Read First: Safety Information
If this product is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
W Warning
•Do not use the tester if it is damaged or operating abnormally.
Protection may be impaired.
•Before each use:
•Make sure the battery door is closed and latched.
•Inspect the tester and test leads. Look for cracks, missing
plastic, exposed metal, or damaged insulation. Replace
damaged test leads before using the tester.
•Verify the tester’s operation by measuring a known voltage.
•Replace the batteries as soon as the low battery indicator (
M )
appears.
•Do not use the tester around explosive gas, vapor or dust.
•Do not apply more than the rated voltage, as marked on the
tester, between terminals or between any terminal and earth
ground.
•Refer servicing to qualified personnel.
•Use caution when working above 30 V ac rms, 42 V ac peak, or
60 V dc.
•When using the probes, keep your fingers behind the finger
guards on the probes.
•Connect the common test lead before you connect the live test
lead. Disconnect the live test lead first.
•The display will not display hazardous voltages in display hold.
The voltage indicator LED ( ) continues to operate.
Symbols
BAC (alternating current) JEarth ground
FDC (direct current) TDouble insulated
MBattery
WCaution, risk of danger
(refer to the manual.) XCaution, shock hazard
Voltage Indicator
While the tester is on, the LED glows when more than 30 V ac or 60 V
dc is present across the leads. (The LED can also glow at lower
voltages.) Be aware that such voltages pose a shock hazard.
Measuring Voltage (V)
The tester automatically selects dc (DC) or ac (AC) voltage mode based
on the peak values of the measured signal.
The tester defaults to ac voltage when turned on.
DC Voltage
T5-600 maximum: 600 V CAT III
T5-1000 maximum: 1000 V, also
600 V CAT IV
AC Voltage
45 Hz to 66 Hz
T5-600 maximum: 600 V rms
T5-1000 maximum: 1000 V rms,
also 600V rms CAT IV
DC
AC
V
AC/DC
Automatic
Selection
V
AC/DC
Automatic
Selection
ex2.eps

Measuring Continuity and Resistance (Ω)
Continuity Resistance
1000 Ω
Range
Greater than
400 Ω
Open Short
Less than
25 Ω
ex3.eps
Beeper indicates shorts lasting 10 ms (1/100 second) or longer.
Measuring AC Current (A)
0.5"(12.9 mm)
maximum
A
AC
ex1.eps
•Range: 0 A to 100.0 A;
45 Hz to 66 Hz
•
W Do not connect test
probes to voltages while
measuring current.
•Place conductor
anywhere within the
sensor zone (shaded
area shown below).
OKOK
OK OK
Sensor
Zone
ex5.eps
Display Hold
To hold the reading on the display, press and release HOLD. The
display will not display hazardous voltages in display hold. The voltage
indicator LED ( ) continues to operate.
To exit the display hold mode, press and release HOLD again, or turn
the rotary switch to a new position.
Automatic Power Down
The tester turns off automatically if you do not turn the rotary switch or
press HOLD for approximately 45 minutes. To resume operation, turn
the tester off, then turn the tester on.
Low Battery Indicator M
W
Warning
To avoid false readings, which could lead to possible
electric shock or personal injury, replace the battery as
soon as the low battery indicator (
M )appears.
Maintenance
Clean the case with a damp cloth and detergent. Do not use abrasives
or solvents.
Because the inputs are electronically protected, no fuses are required.

Battery Replacement
Observe the polarity markings inside the battery compartment.
+
+
Do not
overtighten screw
Disconnect probes
from Voltage
Switch OFF
2 AA
+
+
ex4.eps
Replacement Parts
Test Lead Assembly.
Replace only with Fluke double-insulated leads (
T )
See "Accessories" for available probes.
PN 648029
Battery Door PN 1626588
Battery Door Screw PN 1618578
Accessories
H5 Belt Holster
TP1 Probe Set, Flat-Blade
TP4 Probe Set, 4 mm round
Service Information Sheet , PN 686953
To contact Fluke, call:
USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: [phone]
Japan: [phone]
Singapore: [phone]
Anywhere in the world: [phone]
Visit Fluke’s Web site at www.fluke.com.
Specifications
Specifications subject to change without notice.
Calibration: One-year calibration cycle.
Maximum Voltage Between any Terminal and Earth Ground:
T5-600: 600 V rms, Overvoltage Category III; Pollution Degree 2
T5-1000: 1000 V rms, Overvoltage Category III, also 600 V rms
overvoltage Category IV, Pollution Degree 2
Maximum Voltage between Current Fork and Earth Ground: T5-600
and T5-1000: 1000 V rms, Overvoltage Category III, also 600 V rms,
Overvoltage Category IV, Pollution Degree 2, (This dual rating applies
to the current fork only.)
Temperature: Operating: -10 °C to +50 °C (14 °F to 122 °F);
Storage: -30 °C to +60 °C (-22 °F to +140 °F)
Altitude: Operating: 2000 m (6562 ft); Storage: 10,000 m (32808 ft)
Relative Humidity: 0 % to 95 %, 5 °C to 30 °C (41 °F to 86 °F); 0 % to
75 %, 30 °C to 40 °C (86 °F to 104 °F); 0 % to 45 %, 40 °C to 50 °C
(104 °F to 122 °F)
Battery Type and Life: AA (2); 360 hours continuous with alkaline;
125 hours continuous with zinc chloride
Shock, Vibration: 1 m drop at -10 °C to 50 °C (14 °F to 122 °F) per
ANSI/ISA-S82.01-1994 and EN 61010-1: 1995. Random vibration per
MIL-PRF-28800F for a Class 2 instrument (5 Hz to 55 Hz, 3 g
maximum).
Surge Protection: T5-600 6 kV per IEC 61010;
T5-1000 8 kV per IEC 61010
Enclosure Rating: IP 52 per IEC 60529, no vacuum applied
RF Field Specification: 0.5 % full scale + (specified accuracy) at
3 V / m
Safety: Complies with ANSI/ISA-S82.01-94, UL classified to IEC
61010, CSA/CAN C22.2 No.1010.1-92, and EN 61010-1: 1995.
EMC: EN 61326
Certifications: In accordance with
IEC 61010-1 54CJ

Accuracy is specified for 1 year after calibration, at 18 °C to 28 °C
(64 °F to 82 °F) with relative humidity to 90 %. AC conversions are ac-
coupled, average responding, and calibrated to the rms value of a sine
wave input.
Accuracy specifications are given as follows:
±( [ % of reading] + [number of least significant digits] )
Temperature coefficient of 0.1 x (specified accuracy) / °C for <18 °C
or >28 °C (< 64.4 °F or > 82.4 °F)
Function T5-600
Range T5-1000 Range Reso- lution Accuracy
K 600 V rms 1000 V rms 1 V ±(1.5 % + 2 digits)
L 600 V 1000 V 1 V ±(1 % + 1 digit)
?
100.0 A 100.0 A 0.1 A ±(3 % + 3 digits)
e 1000 Ω1000 Ω1 Ω± (1 % + 2 digits)
Input Protection
Function T5-600 T5-1000
Input Impedance
(nominal)
K
600 V rms 1000 V rms 1 MΩ, <100 pF ac-coupled
L
600 V rms 1000 V rms 1 MΩ, <100 pF
e
600 V rms 1000 V rms ---
Function Open Circuit Test
Voltage Short Circuit Current
e 1.65 V dc (nominal) <0.6 mA
CAT III protects against transients in a fixed equipment installation such
as a distribution panel, and lighting systems in large buildings.
CAT IV protects against transients from a
primary supply such as an
electricity meter or an overhead or underground utility service.
