©Fluke 2008 FPM Oscilloscope Calibration Techniques 1
Techniques for Oscilloscope
Calibration
Using either dedicated or multiproduct calibrators
Teleconference:
US & Canada Toll Free Dial-In Number: 1-[phone]
International Dial-In Number:[phone]
Conference Code: 1010759559

©Fluke 2008 FPM Oscilloscope Calibration Techniques 2
Welcome
Greetings from –
Fluke Corporation
Everett, Was ington, USA
We are very pleased to bring you
t is presentation on tec niques for
oscilloscope calibration.

©Fluke 2008 FPM Oscilloscope Calibration Techniques 3
Welcome
T is presentation is based on
Fluke’s extensive experience wit :
– Use and design of calibration
instruments and oscilloscopes
– Our experience and understanding of
t e problems faced w en performing
calibration of oscilloscopes
T anks for your time, we ope you
find it bot valuable and useful.
Welcome and Thanks!

©Fluke 2008 FPM Oscilloscope Calibration Techniques 4
Presented by
Fluke’s Precision Measurement
Business Unit
and Jack Somppi
Electrical Calibration Instruments
Product Line Manager
[email protected]

©Fluke 2008 FPM Oscilloscope Calibration Techniques 5
Fluke Precision
Measurement
Web eminar eries
For information & reservations to
attend our seminars, go to
www.fluke.com, click on t e
sidebar “Events, Seminars &
Training”, and click on FPM Seminar
Series selection,
or directly go to:
www.fluke.com\fpmseminars
Our eminar Topics Include:
•Precision Measurement Tec niques
•Oscilloscope Calibration
•General Metrology
•Temperature Calibration
•Metrology Software
•RF Calibration

©Fluke 2008 FPM Oscilloscope Calibration Techniques 6
Web seminar etiquette
• C oice of Audio – VOIP or Teleconference
–VOIP receives audio only while teleconference
is two way sound
• Don’t mute your p one if you ave background
music enabled
• Use Q&A or c at to send me questions or
request clarification
• T ere will be an opportunity t roug out t e
discussion to pause and ask questions.
• You can view t e material using eit er full
screen or multi window met ods

©Fluke 2008 FPM Oscilloscope Calibration Techniques 7
Techniques for Oscilloscope
Calibration
Using either dedicated or multiproduct calibrators

©Fluke 2008 FPM Oscilloscope Calibration Techniques 8
Objectives for today’s session
• Review t e calibration
requirements of oscilloscopes
• Examine t e basic calibration
tec niques for scope
calibration
• Study scope calibration
instrumentation alternatives
• Consider automation and it’s
benefits
• Identify additional reference
sources for furt er study

©Fluke 2008 FPM Oscilloscope Calibration Techniques 9
 Simplify oscilloscope calibration
–Allow for full automation
–All signals should be
through single output
–Make procedures available
 Reduce calibration times
 Reduce cost of ownership
–All functions integrated in a single unit
–Allow for upgradeability
(workloadkeeps changing)
–Simplify calibrator support
Benefits with modern scope
calibration

©Fluke 2008 FPM Oscilloscope Calibration Techniques 10
An Introduction to Oscilloscope
Calibration

©Fluke 2008 FPM Oscilloscope Calibration Techniques 11
Oscilloscope calibration trends
• Perceived as complex
– Modular based calibration systems
– Multiple outputs means many lead c anges
– Hig skill level required
– Time consuming to calibrate
– Automated systems still require manual intervention
• ISO9000 driven manufacturing systems
• Newer measurement functions & accuracy
require formal calibration
• Increasing bandwidt to 1GHz and beyond

©Fluke 2008 FPM Oscilloscope Calibration Techniques 12
Oscilloscope calibration
workload (The Bandwidth Perspective)
Installed Base (% Units)
Cal’ Workload (% of Base)
20% 40%
<100MHz
55%
<250MHz
30%
90%
>250MHz
15%

©Fluke 2008 FPM Oscilloscope Calibration Techniques 13
Oscilloscope Architectures
… and what needs to be calibrated

©Fluke 2008 FPM Oscilloscope Calibration Techniques 14
Timebase with
sawtooth generator
switch
V/cm
+
-
dY dX
R
1
R
2
Trigger
Mode
Level sec/cm
ALT/CHOP
X-Pos
AC/DC
A
B
Ext
Line
AB
Y-Pos
Delay
Analog oscilloscope

©Fluke 2008 FPM Oscilloscope Calibration Techniques 15
One A/D for each vertical channel
Digital Sampling Scopes use fast
sample and hold with slower A/D.
- no ALT/CHOP mode
- channel skew is a common test
Memory
A
D
A
D
CRT/Display
Ext
Trigger control
Oscillator-
Timebase
Channel 1
Channel 2
µP
Digital storage oscilloscope
(D O)

©Fluke 2008 FPM Oscilloscope Calibration Techniques 16
Digital phosphor oscilloscope
(DPO)
A
D
Display
Digital
Phosphor
Acquisition
Rasterizer
Display
Memory
µP

©Fluke 2008 FPM Oscilloscope Calibration Techniques 17
What to calibrate?
•Vertical Channels
–Channel switching
–Deflection range and accuracy
–Bandwidth, pulse response and risetime
•Horizontal Channels
–Timebase accuracy including delay, magnification
and jitter
–Trigger functions
–X-Axis deflection accuracy and X-Y phasing
•Internal calibration signals
•Cursors and measurement readouts
•Z-Axis bandwidth

©Fluke 2008 FPM Oscilloscope Calibration Techniques 18
 Insure the voltage
amplitude is measured
& displayed properly
Peak-to-
Peak
Voltage
Applied
Pulse
a
Voltage
Applied
DC
DC
Voltage
0V
a
Vertical channel accuracy

©Fluke 2008 FPM Oscilloscope Calibration Techniques 19
typical frequency 1kHz
Input coupling DC
Any internal 50Ω
ΩΩ
Ω
setting also calibrated
measurement
function V
pp
Number of measurements for averaging
DSO
analog & DSO
Trigger level 50%
Vertical channels verification

©Fluke 2008 FPM Oscilloscope Calibration Techniques 20
 Insure all measurable
frequencies respond
properly
100%
100%
Vertical channel bandwidth
