Fly Sky FS-G4P-BS User manual

Copyright ©2021 Flysky Technology co., ltd
USER MANUALUSER MANUAL
Digital Proportional Radio
Control System
This product is only for 15 years
old or above.
FS-G4P-BS

Thank you for purchasing our products.
Read the manual carefully to ensure your personal safety as well as the safety of your
equipment.
If you encounter any problems during using, please refer to this manual rst. If the
problem is still not resolved, please contact the local dealer directly or contact the
customer service sta󰀨 via the website below:
www.ysky-cn.com

Contents
1.Safety ...................................................... 1
1.1 Safety Symbols .......................................................1
1.2 Safety Guide..........................................................1
Mandatory .................................................... 1
2.Introduction..............................................2
2.1 Transmitter overview...................................................2
2.2 Receiver overview ....................................................4
3.Getting Started ............................................... 5
3.1 Transmitter Battery Installation ..........................................5
4.Instructions..............................................6
4.1 Power On ............................................................6
4.2 Binding ..............................................................6
4.3 Stick Calibration ......................................................7
4.4 Power O󰀨 ............................................................7
5.System Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.1 Channel Description ...................................................8
5.2 Channel Reverse ......................................................8
5.3 Trims ................................................................8
5.4 D/R..................................................................9
5.5 Mode switching.......................................................9
5.6 Failsafe .............................................................9
5.7 Beginner Mode........................................................10
6. Product Specications ....................................11
7. Package Contents ........................................12
8. Certications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8.1 DoC Declaration.......................................................13
8.2 CE Warning...........................................................13
8.3 Appendix 1 FCC Statement ................................... 13
8.4 Environmentally friendly disposal ............................. 14
8.5 IC STATEMENT .......................................................14

1
• Misuseofthisproductmayleadtoseriousinjuryordeath.Toensurethesafetyofyou
andyourequipment,readthismanualandfollowtheinstructions.
• Makesuretheproductisproperlyinstalledinyourmodel.Failuretodosomayresultin
seriousinjury.
• Makesuretodisconnectthereceiverbatterybeforeturningo󽗈thetransmitter.Failure
todosomayleadtounintendedoperationandcauseanaccident.
• Ensurethatallmotorsoperateinthecorrectdirection.Ifnot,adjustthedirection
first.
• Makesurethemodelstayswithinthesystemsmaximumrangetopreventlossof
control.
• Donotusetheproductatnightorinbadweatherlikerainorthunderstorm.Itcan
causeerraticoperationorlossofcontrol.
• Donotusetheproductwhenvisibilityislimited.
• Donotusetheproductonrainorsnowdays.Anyexposuretomoisture(waterorsnow)
maycauseerraticoperationorlossofcontrol.
• Interferencemaycauselossofcontrol.Toensurethesafetyofyouandothers,donot
operateinthefollowingplaces:
• Near any site where other radio control activity may occur
• Near power lines or communication broadcasting antennas
• Near people or roads
• On any body of water when passenger boats are present
• Donotusethisproductwhenyouaretired,uncomfortable,orunderthein󽗊uenceof
alcoholordrugs.Doingsomaycauseseriousinjurytoyourselforothers.
• The2.4GHzradiobandislimitedtolineofsight.Alwayskeepyourmodelinsightasa
largeobjectcanblocktheRFsignalandleadtolossofcontrol.
• Donottouchanypartofthemodelthatmaygenerateheatduringoperation,or
immediatelyafteruse.Theengine,motororspeedcontrol,maybeveryhotandcan
causeseriousburns.
Prohibited Mandatory
1.Safety
1.1SafetySymbols
Pay close attention to the following symbols and their meanings. Failure to follow these warnings could cause damage,
injury or death.
1.2SafetyGuide
Warning • Notfollowingtheseinstructionsmayleadtomajorinjuries.
Danger • Notfollowingtheseinstructionsmayleadtoseriousinjuriesordeath.
Attention • Notfollowingtheseinstructionsmayleadtominorinjuries.

FS-G4P-BS
Digital Proportional Radio Control System
2
2.Introduction
The FS-G4P-BS is a simple 4-channel transmitter using the latest 2.4GHz 2A-BS Automatic Frequency Hopping
Digital System. Designed to be sleek, passionate and powerful for entry level enthusiasts.
2.1Transmitteroverview
[2]
[1]
[3]
[4]
[5]
[8]
[6]
[9]
[11]
[13]
[15]
[14]
[7]
[12]
[10]

3
[18]
[19]
[16]
[17]
[1] Panel Flip Cover [11] Steering Trim (ST.TRIM +)
[2] Steering Reverse Switch (ST.REV) [12] Throttle Trim (TH.TRIM +)
[3] Power indicator LED (R. LED) [13] Steering D/R (ST.D / R +)
[4] Steering Trim (ST.TRIM-) [14] Lanyard Eye
[5] Status indicator green LED (G.LED) [15] Base, 4 * AA battery compartment
[6] Throttle Trim (TH.TRIM-) [16] Three-position switch (CH3)）
[7] Steering D/R (ST.D / R-) [17] Button (CH4)
[8] Power Switch [18]
Wheel Angle, the maximum rotation of the
steering wheel is 35 degrees from center to left
or right (CH1)
[9] Bind Button (BIND) [19]
Throttle trigger, has a total throw of 12 degrees,
12.5 degrees forward, and 12.5 degrees
backward (CH2)
[10] Throttle Reverse (TH.REV)

FS-G4P-BS
Digital Proportional Radio Control System
4
2.2Receiveroverview
CH4
CH3
CH2
CH1
LED
Antenna
Note • Toensurethebestsignalqualitymakesurethattheantennaismountedperpendicular
tothemodelbodyinanuprightposition.
+ - VCC
GND

5
3.GettingStarted
Before operation, install the battery and connect the system as instructed below.
3.1TransmitterBatteryInstallation
Danger • Onlyusespeci󽗉edbattery(X4AAbatteries).
Danger • Donotopen,disassemble,orattempttorepairthebattery.
Danger • Donotcrush/puncturethebattery,orshorttheexternalcontacts.
Danger • Donotexposetoexcessiveheatorliquids.
Danger • Donotdropthebatteryorexposetostrongshocksorvibrations.
Danger • Alwaysstorethebatteryinacool,dryplace.
Danger • Donotusethebatteryifdamaged.
Battery Type: AA
Battery Installation:
1. Open the battery compartment cover.
2. Insert 4 fully-charged AA batteries into the compartment. Make sure that the battery makes good contact with
the battery compartment's contacts.
3. Replace battery compartment cover.
Low battery alarm: When the battery is lower than 4.2v, the G.LED on the panel will flash slowly.

FS-G4P-BS
Digital Proportional Radio Control System
6
4.Instructions
After setting up, follow the instructions below to operate the system.
Follow the steps below to turn on the transmitter:
1. Check to make sure that that battery is fully charged and installed correctly.
2. Toggle the switch to the [ON] position. When active the R.LED will be lit.
3. Power on the receiver.
• For safety always power on the transmitter before the receiver.
4.2Binding
The transmitter and receiver have already been bound at the factory.
1. Turn on the transmitter while holding the bind button to enter bind mode. G.LED will start 󽗊ashing quickly.
• Once in bind mode release the bind button.
2. The receiver will enter bind mode atomically when powered on.
3. Once binding is successful the receiver's LED will 󽗊ash slowly and the transmitter's LED will remain solid after
being rebooted.
Note: When binding, put the transmitter into bind mode 󽗉rst, then the receiver.
4.1PowerOn
However if the receiver needs to be replaced or additional receivers bound follow these steps:
Note • Operatewithcautioninordertoavoiddamageorinjury.
Note • Makesurethatthethrottleisatitslowestpositionandtheswitchesaresettotheirup
position.
• ApplicabletotheFS-G4P-BStransmitterandtheFS-R4P-BSreceiver.Di󽗈erentreceivershavedi󽗈erent
bindprocedures.FormoreinformationvisittheFLYSKYwebsiteformanualsandotherrelated
information.
• Productinformationisupdatedregularly,pleasevisitourwebsiteformoreinformation.

7
4.3StickCalibration
This function is used to set the neutral position for throttle trigger and steering wheel.
Every transmitter is calibrated before leaving the factory, however if recalibration is required, please follow these
steps:
1. Turn and hold the wheel as far clockwise as it will turn, hold the throttle all the way forward, then turn on the
transmitter in calibration mode.
• The R.LED and G.LED will be in a state of two-time 󽗊ashing and on o󽗈.
2. Calibrate wheel: Turn the wheel completely clockwise, then completely counterclockwise.
• When calibration is completed the R.LED will be o󽗈.
3. Trigger calibration: Pull the trigger back then forward as far as it will go.
• When calibration is completed the G.LED will be o󽗈.
4. Once calibration is complete press the bind to save and exit.
4.4PowerO󽗈
Danger • Makesuretodisconnectthereceiverpowerbeforeturningo󽗈thetransmitter.Failure
todosomayleadtodamageorseriousinjury.
Follow the steps below to turn o󽗈 the system:
1. Disconnect the receiver power.
2. Toggle the transmitter's power switch to the [OFF] position.

FS-G4P-BS
Digital Proportional Radio Control System
8
5.SystemFunctions
This section focuses on the functions and how to use them.
5.1ChannelDescription
5.2ChannelReverse
The transmitter outputs a total of 4 channels, which are allocated as follows:
• CH1：Steering Wheel
• CH2：Throttle Trigger
• CH3：Three-position Switch
• CH4：Reset Button
Note: By default the output of CH4 is 1000us, after which pressing the button will toggle between 1000 and
2000us.
5.3Trims
This function is used to adjust each channels direction of movement in relation to its input.
The ST.REV / TH.REV switches are the reverse buttons for CH1 and CH2. If the switch is up it indicates reverse, and
the down indicates normal.
The ST.TRIM is the trims for CH1 (steering),and can be multiplexed as trims of CH3 and CH4. For multiplexing
switching mode, refer to [5.5 Mode Switching].
TH.TRIMis the trims for CH2(throttle).
Adjustment range: -120us- + 120us, each step is 4us;
ST.TRIM + / TH.TRIM +: Increases adjustment step;
ST.TRIM- / TH.TRIM-: Decreases adjustment step.
LED Indicator:
• When using the trim keys the G.LED will 󽗊ash slowly on short presses and quickly on long presses.
• When the trim adjustment value is at the netrual position, the G.LED will 󽗊ash twice slowly.
• When the trim adjustment value is at both ends (+ 120us / -120us), the trim adjustment is at its maximum and
as such G.LED will not 󽗊ash(If the 󽗉ne adjustment value has been adjusted to + 120us, then press ST.TRIM + /
TH.TRIM + key is invalid and G.LED has no indications.)

9
5.4D/R
ST.D / R is for servo travel adjustment, which can be multiplexed as CH2 (throttle), CH3, CH4 servo travel
adjustment, refer to [5.5 Mode Switch] for multiplex switching mode;
Adjustment range: 0-120%(the default is 100%), the step is 5%.
ST.D / R +: Increases servo travel.
ST.D / R -: Decreases servo travel.
LED Indicator:
• When using the trim keys the G.LED will 󽗊ash slowly on short presses and quickly on long presses.
• When the ratio value is at both ends (0/120%), the ST.D / R button is at its maximum and as such G.LED
will not 󽗊ash(if the ratio value has been adjusted to 120%, then press ST.D/R+ key is invalid and G.LED has
Instructions)
5.5Modeswitching
This function is for reusing the ST.TRIM and ST.D / R buttons for di󽗈erent channels (Refer to [5.3 Trims] and [5.4 D/R).
Function settings:
Under normal power-on, quickly press the Bind button twice (within 1 second) to cycle through modes 1, 2, 3, and
4. The default setting when powering on is mode 1.
Mode 1: G.LED 󽗊ashes slowly once, ST.TRIM is CH1 trim adjustment, ST.D / R is servo travel adjustment.
Mode 2: G.LED 󽗊ashes twice slowly, ST.TRIM is CH1 trim adjustment, ST.D / R is CH2 servo travel adjustment.
Mode 3: G.LED 󽗊ashes three times slowly, ST.TRIM is CH3 trim adjustment, ST.D / R is CH3 servo travel adjustment.
Mode 4: G.LED 󽗊ashes slowly four times, ST.TRIM is CH4 trim adjustment, ST.D / R is CH4 servo travel adjustment.
This function dictates what the receiver will do in the event that it loses signal from the transmitter, this includes
servo position etc.
Function settings:
1. Turn on the transmitter and make sure it is connected to the receiver.
2. Hold the control surface at the desired failsafe position.
3. Press and hold the bind button for 3 seconds, if the G.LED starts 󽗊ashes for 2 seconds, indicating that the
settings are successful.
Note: The fail-safe function has not set at the factory by default. If no failsafe setting has been set, then the
receiver will maintain the output of the last signal when the signal is lost.
5.6Failsafe

FS-G4P-BS
Digital Proportional Radio Control System
10
5.7BeginnerMode
Beginner mode is designed for the people who is new to the hobby.
In this mode the throttle has been limited to 50 percent, The channel range defaults has been set to
1250~1500~1750us.
Function settings:
To switch between beginner and normal modes, press and hold the CH4 button while turning the steering wheel
completely counterclockwise as far as it can, and at the same time, power on the transmitter.
Note: By default, the system is set to normal mode. If the system has set to beginner mode.
The G.LED will be in a state of two-time 󽗊ashing and on o󽗈, and keep the state for 3 seconds during power on.

11
6.ProductSpeci󽗉cations
This section contains the speci󽗉cations of FS-G4P-BS transmitter.
Product Model FS-G4P-BS
Channels 4
Model Type Cars, Boats
RF 2.4GHz
Maximum Power <20dBm (e.i.r.p.) （EU）
2.4GHz Protocol 2A-BS
Distance >300m （Ground）
Channel Resolution 1024
Battery 6V DC 1.5AA*4
Charging Interface NO
Life time According to battery type
Low Voltage Warning <4.2V
Antenna Type Built-in single antenna
Data Interface NO
Temperature Range -10℃—+60℃
Humidity Range 20%—95%
Online Update NO
Color Black
Size 160*193*97mm
Weight 220g
Certi󽗉cation CE，FCC ID： N4ZG4P00

FS-G4P-BS
Digital Proportional Radio Control System
12
7.PackageContents
Transmitter*1(FS-G4P-BS)
Receiver*1(FS-R4P-BS)

13
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or televison reception, which can be determined by turning the equipment o󽗈 and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di󽗈erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modi󽗉cations not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modi󽗉cations to this
equipment. Such modi󽗉cations could void the user authority to operate the equipment.
1. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-lacated or operating in conjunction with any other transmitter.End-users
and installers must be provided with antenna installation instructions and transmitter operating conditions for
satisfying RF exposure compliance.
2. Move all your channels to the desired position.
3. Select [All channels] and then [Yes] in the con󽗉rmation box.
8.Certi󽗉cations
8.1DoCDeclaration
8.2CEWarning
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers
must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF
exposure compliance.
8.3Appendix1FCCStatement
Hereby, [Flysky Technology co., ltd] declares that the Radio Equipment [FS-G4P-BS] is in compliance with RED
2014/53/EU.
The full text of the EU DoC is available at the following internet address: www.󽗊ysky-cn.com.

FS-G4P-BS
Digital Proportional Radio Control System
14
8.4Environmentallyfriendlydisposal
8.5ICSTATEMENT
Old electrical appliances must not be disposed of together with the
residual waste, but have to be disposed of separately. The disposal at the
communal collecting point via private persons is for free. The owner of old
appliances is responsible to bring the appliances to these collecting points
or to similar collection points. With this little personal e󽗈ort, you contribute
to recycle valuable raw materials and the treatment of toxic substances.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science
and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 25584-G4PBS00
Figures and illustrations in this manual are provided for reference only and may di󽗈er from actual product appearance. Product design and speci󽗉catiions may be changed without notice.

Copyright ©2021 Flysky Technology co., ltd
www.󽗊ysky-cn.com
Release date: 2021-10-23
CE，FCC ID：N4ZG4P00
Manufacturer：FLYSKYTechnologyCo.,Ltd
Address:16F,HuafengBuilding,6006ShennanRoad,FutianDistrict,Shenzhen
