Focal Point F820583 Programming manual

ASSEMBLY & INSTALLATION INSTRUCTIONS
Please note : Except where otherwise stated, all rights, including copy-
right in the text, images and layout of this booklet is owned by Focal
Point Fires Ltd. You are not permitted to copy or adapt any of the
con-tent without the prior written permission of Focal Point Fires Ltd.
1
All instructions must be handed to the user for
safekeeping.
Revision A- 01/22
© 2022Focal Point Fires Ltd.
MODELS COVERED BY THESE INSTRUCTIONS
F820583 FPFBQ385 CHARLOTTESVILLE PINE FIREPLACE
Focal Point Fires Ltd
Christchurch, Dorset BH23 2BT
Tel: [phone]
Fax: [phone]
www.focalpointfires.co.uk
e : [email protected]
Focal Point Fires Ltd
RBK House, Irishtown, Athlone,
Co. Westmeath, N37 XP52,
Ireland Tel: [phone]
Fax: [phone]
www.focalpointfires.co.uk
e: [email protected]
F820585 FPFBQ387 CHARLOTTESVILLE WHITE FIREPLACE
F820584 FPFBQ386 CHARLOTTESVILLE OAK FIREPLACE

ASSEMBL Y INSTRUCTIONS
2
GB IE
1.0 IMPORTANT NOTES
© 2022Focal Point Fires Ltd.
Section
1.0
2.0
3.0
4.0
5.0
6.0
7.0
Contents
Important notes
Tools required
Hardware & parts list
Assembly
Installation
Cleaning/ finishing
Guarantee - terms and conditions
Page No.
2
2
2
3
5
5
5
2.0 TOOLS REQUIRED
CODE NAME FIGURE QUANTITY
A
WOOD
DOWELS
(8X30mm)
8PCS
BCAM LOCKS
(15X9mm) 4PCS
CCAM BOLTS
(6.5X40mm) 4PCS
D
WOOD
SCREW
(3.5X25mm)
17PCS
E
WALL
SCREW
(4X30mm) 2PCS
F
WOOD
SCREW
(3X12mm)
4PCS
GWALL PLUG
(6X30mm) 2PCS
3.0 HARDWARE & PARTS LIST
CODE NAME FIGURE QUANTITY
①BACK
BOARD
1PCS
②TOP PANEL 1PCS
③NARROW
INSIDE TOP
1PCS
④NARROW
INSIDE LEG 2PCS
⑤WIDE INSIDE
TOP 1PCS
⑥WIDE INSIDE
LEG
2PCS
⑦LEFT SIDE
PANEL
1PCS
⑧RIGHT SIDE
PANEL
1PCS
To ensure safe and stable installation:
1.The assembled Fire Surround must be fixed / secured to the wall.
2.The wall must be sturdy and in good repair.
3. Some walls require alternative fixings (not included).
4.When drilling into the wall, check for hidden pipes and cables.
5.There are three options for construction of this surround.
Option A - without a rebate, this option is similar to option B, but allows for a 95mm of space behind the surround.
Option B - with narrow rebates - If using this surround with an electric fire and a flat wall do not use with rebates, instead use
the spacer frame from the fire, this option will give you 75mm of space behind the surround.
Option C - with wide rebates -if you are installing this surround with a gas fire, or an electric fire where there is space in the
wall to recess the fire use parts 5 & 6, this means the back panel is against the wall.
Cross head screwdriver PZ2 (3 inches in length or greater)
Drill, 6mm and a 2mm suitable drill bit
Pencil
Tape measure
H
MIRROR
PLATES
(45X43mm)
2PCS
IGLUE
(10g) 1PCS
J
K
1PCS
ALLEN KEY
SCREWS
(4X30mm) 2PCS

4.0 ASSEMBLY
3
GB IE
© 2022Focal Point Fires Ltd.
Fixings Parts
D x 8 PCS
K x 2 PCS 7
1
8
Gently lay both legs you have prepared onto a suitable protected surface. Be extremely careful not to scratch the front edges
of the legs. DO NOT DRAG THE LEGS! Make sure that the legs are lifted everytime they are moved to avoid them from being
damaged.
Use 2x4x30 screws (K) to screw the right leg (8) and left leg (7) to the back board (1).
Use 8x3.5x25 wood screws (D) to screw the right leg (8) and the left leg (7) to the back board (1).
STEP 1
STEP 2
Using a drop of glue (I) in each dowel hole, insert 2 dowels (A) in to the right leg (8), and repeat on the left leg (7).
Screw the cam bolts (C) into the top panel (2) and put a little glue (I) into the dowel holes.Place the top panel (2) onto the
surround, ensuring that the cam bolts (C) and dowels (A) line up with the relevant holes. Push down, check there are no gaps
then insert and tighten cam locks (B) into position. This surround now has a rebate depth of 95mm, proceed with step 3 for a
75mm rebate or step 4 for a 25mm rebate.
Fixings Parts
A x 4 PCS 1
B x 4 PCS 2
C x 4 PCS 7
8
A
A
C
C
B
B
②
⑦
⑧
①
K
⑦
⑧
①
D
D
D
D
D
D
KD
D
C
C
C
C
AA
A
A
BB
B
B
OPTION A

STEP 3
STEP 4
4.0 ASSEMBLY - CONTINUED GB IE
4© 2022Focal Point Fires Ltd.
OPTION B
Use the Glue (I) in the dowel holes before inserting 2 dowels (A) into the left and right hand legs. Now put a small amount of
glue (I) in the dowel holes of the narrow inside leg panels (4). Push the narrow inside leg panels (4) on to the dowels. Take the
narrow inside top (3) and mount this in place above the side panels, directly onto the back of the back board(1). Use 9 screws
(D) to secure all 3 narrow panels down.
Fixings Parts
A x 4 PCS 1
D x 9 PCS 2
3
4
7
8
Use the Glue (I) in the dowel holels before inserting 2 dowels (A) into the left and right hand legs. Now put a small amount of
glue (I) in the dowel holes of the wide inside leg panels (6). Push the inside wide leg panels (6) on to the dowels. Take the wide
inside top (5) and mount this in place above the side panels, directly onto the back of the back board(1). Use 9 screws (D) to
secure all 3 wide panels down.
Fixings Parts
A x 4 PCS 1
D x 9 PCS 2
5
6
7
8
②
A
A
A
A
④
③
A
①
⑤
⑥
②
D
D
D
D
⑧
⑦
D
A
A
A
D
D
D
D
④
①
⑥
D
D
D
D
D
D
DD
D
⑧
⑦
OPTION C

5.0 INSTALLATION GB IE
5© 2022Focal Point Fires Ltd.
With a pencil mark out the desired height where you would like the mirror brackets (H) to be situated on the rear of the legs. To avoid
splitting the leg, pre drill the bracket holes with a 2mm drill bit. Now attach the brackets to the legs using the 3x12mm screws (F). Once
the brackets are in position, centre and level the hearth into its final fitting position. Position the surround on the hearth to correspond
with the header/fireplace lintel, mark with a pencil on the wall where you wish to drill. Remove the surround and prepare the wall from
the marked positions. If using the fixings supplied, drill a hole in the wall using a 6mm drill bit. If not, use a suitable drill bit for the wall
plugs you are using. Insert the wall plugs (G) into position. Offering the surround back up into position against the wall, you are now able
to secure the surround to the wall using the screws (E).
6.0 CLEANING/ FINISHING
Before carrying out any of the following operations, ensure that the applaince is OFF and completely cold. Regularly clean
around the appliance to ensure that dust, fluff, pet hair etc, are kept to a minimum.There are no other specific requirements for
care, other than regular cleaning of the general appliance.
A wipe with a dry cloth is normally sufficient. DO NOT use abrasive cleaners as they can damage the finish.Test on a hidden
part before cleaning. Regularly check the surround is securely fixed in position.
7.0 GUARANTEE - TERMS AND CONDITIONS
The 3 year guarantee commences from the date of purchase, provided that the terms and conditions are adhered to:
Registration is not required.
1. For any claim to be made within the 3 years from date of purchase you will be required to provide and supply us with your
proof of purchase.
Making a claim is easy.
If you wish to make a claim under our 3 year guarantee and all the terms and conditions for your product have been met then
please submit the following information for the attention of the 3G Service Department to the address below. Alternatively, you
can email or fax. Please note that this does not affect your statutory rights.
Focal Point Fires Ltd, 3G Service Department, Reid Street, Christchurch, Dorset, BH23 2BT.
Alternatively email: [email protected].uk or fax. [phone].
Details required:
1. Name, full address including post code and contact telephone number.
2. Receipt of purchase or credit card statement.
F861611
Fixings
E x 2 PCS
F x 4 PCS
G x 2 PCS
H x 2 PCS
