Focal Point F820586 Programming manual

ASSEMBLY & INSTALLATION INSTRUCTIONS
Please note : Except where otherwise stated, all rights, including copy-
right in the text, images and layout of this booklet is owned by Focal
Point Fires Ltd. You are not permitted to copy or adapt any of the
con-tent without the prior written permission of Focal Point Fires Ltd.
1
All instructions must be handed to the user for
safekeeping.
Revision D- 07/21
© 2021 Focal Point Fires Ltd.
MODELS COVERED BY THESE INSTRUCTIONS
F820586 FPFBQ388 NEBRASKA SURROUND WALNUT VENEER
F820587 FPFBQ389 NEBRASKA SURROUND OAK VENEER
F820628 FPFBQ410 NEBRASKA SURROUND WHITE
F820879 FPFBQ832 NEBRASKA SURROUND PINE
Focal Point Fires Ltd
Christchurch,
Dorset BH23 2BT
Tel: [phone]
Fax: [phone]
www.focalpointfires.co.uk
e : [email protected]
Focal Point Fires Ltd
RBK House, Irishtown, Athlone,
Co. Westmeath, N37 XP52,
Ireland Tel: [phone]
Fax: [phone]
www.focalpointfires.co.uk
e: [email protected]

ASSEMBL Y INSTRUCTIONSGB IE
1.0 IMPORTANT NOTES
Section
1.0
2.0
3.0
4.0
5.0
6.0
7.0
Contents
Important notes
Tools required
Hardware & parts list
Assembly
Installation
Cleaning/ finishing
Guarantee - terms and conditions
Page No.
2
2
2
3
5
5
5
2.0 TOOLS REQUIRED
CODE NAME FIGURE QUANTITY
A
WOOD
DOWELS
(8X20mm)
19PCS
B CAM LOCKS
(15X9mm)
12PCS
C CAM BOLTS
(6X40mm)
12PCS
D
WOOD
SCREWS
(3.5X25mm)
13PCS
E
WALL
SCREWS
(4X30mm) 2PCS
F
WOOD
SCREWS
(3X12mm)
4PCS
G WALL PLUGS
(6X30mm)
2PCS
3.0 HARDWARE & PARTS LIST
CODE NAME FIGURE QUANTITY
①TOP PANEL 1PC
②FRONT PANEL 1PC
③LEFT SIDE
LEG
1PC
④RIGHT SIDE
LEG
1PC
⑤INSIDE LEGS 3PC
⑥LEFT SIDE
PANEL
1PC
⑦RIGHT SIDE
PANEL
1PC
To ensure safe and stable installation:
1.The assembled Fire Surround must be fixed / secured to wall.
2.The wall must be sturdy and in good repair.
3. Some walls require alternative fixings (not included).
4.When drilling into the wall, check for hidden pipes and cables.
Cross head screwdriver PZ2 (3 inches in length or greater)
Drill, 6mm and a 2mm suitable drill bit
Pencil
Tape measure
H
MIRROR
PLATES
(45X43mm)
2PCS
IGLUE
(10g)
1PCS
2© 2021 Focal Point Fires Ltd.
J1PCS
ALLEN KEY

4.0 ASSEMBLY
3
GB IE
© 2021 Focal Point Fires Ltd.
Fixings Parts
A x 4 PCS 2
D x 4 PCS 3
4
A
A
DD
D③
Gently lay both legs you have prepared onto a suitable protected surface. Be extremely careful not to scratch the front edges
of the legs. DO NOT DRAG THE LEGS! Make sure that the legs are lifted everytime they are moved to avoid them from being
damaged.
Using a drop of glue (I) in each dowel hole, insert two dowels (A) in to the left leg (3). Again, using a drop of glue (I) in the
dowel holes take the front panel (2) and push them on to the dowels (A). Use 2x wood screws (D) to screw the parts togeth-
er. Repeat the process for the right leg using the right leg (4) and front panel (2).
④
STEP 1
STEP 2
Using a drop of glue (I) in each dowel hole, insert 2x dowels (A) in to the left leg (3).Again, using a drop of glue (I) in the
dowel holes take the inside leg (5) and push them on to the dowels of the leg (3). Use 3x wood screws (D) to screw the right
side panel (5) to the right leg (4). Repeat the process to secure the third inside panel (5) to the front panel (2).
Fixings Parts
A x 6 PCS 2
D x 9 PCS 3
4
5
④
A
D
②
D
A
A
A
D
③
②
A
A
A
AA
A
D
D
D
D
D
D
D
D
D
⑤
⑤
⑤

4.0 ASSEMBLY - CONTINUED GB IE
4© 2021 Focal Point Fires Ltd.
STEP 3
Use the Glue (I) in the dowel holes before inserting 2x dowels (A) into the left and right hand legs (3 and 4). Position the cam
bolts (B) in to left and right side panels (3 and 4).
Take the left side and the right side panels (6 and 7), put some glue (I) in to the dowel holes. Insert the cam locks (B). Screw
the cam bolts (C) in to the left and right legs (3 and 4). Position the left and right sides (6 and 7) onto the dowel joints (A) and
cam bolts (C) in the legs (3 and 4). Now turn the cam locks (B) clockwise to lock the parts together.
Fixings
A x 4 PCS
B x 6 PCS
C x 6 PCS
Insert 6x cam locks (B) and glue (I) 5x dowels (A) into the legs and front panel (2,3&4). Next prepare the top panel (1) by
screwing all 6x cam bolts (C) into position.The dowel joints (A) need to be glued in at both ends of the top panel. Connect
the top panel to the surround, making sure all 11x inserts are in the correct position. Once home, all 6x cam locks (B) can be
tightened into position.
Fixings Parts
A x 5 PCS 1
B x 6 PCS 2
C x 6 PCS 3
4
②
A
A
A
A
④
③
STEP 4
①
④
③
②
B
C
B
B
B
C
C
C
C
C
⑥
⑦
BB
BBB
B
CC
CCC
CC
A
A
A
A
Parts
2
3
4
6
7
A
B
B
⑤
⑤
⑤
B
A
A
B
C

5.0 INSTALLATION GB IE
5© 2021 Focal Point Fires Ltd.
Fixings
E x 2 PCS
F x 4 PCS
G x 2 PCS
H x 2PCS
With a pencil mark out the desired height where you would like the mirror brackets (H) to be situated on the rear of the legs. To
avoid splitting the leg, pre drill the bracket holes with a 2mm drill bit. Now attach the brackets to the legs using the 3x12mm screws
(F). Once the brackets are in position, centre and level the hearth into its final fitting position. Position the surround on the hearth to
correspond with the header/fireplace lintel, mark with a pencil on the wall where you wish to drill. Remove the surround and prepare
the wall from the marked positions. If using the fixings supplied, drill a hole in the wall using a 6mm drill bit. If not, use a suitable drill
bit for the wall plugs you are using. Insert the wall plugs (G) into position. Offering the surround back up into position against the wall,
you are now able to secure the surround to the wall using the 4x30mm screws (E).
6.0 CLEANING/ FINISHING
Before carrying out any of the following operations, ensure that the appliance is OFF and completely cold. Regularly clean
around the appliance to ensure that dust, fluff, pet hair etc, are kept to a minimum.There are no other specific requirements for
care, other than regular cleaning of the general appliance.
A wipe with a dry cloth is normally sufficient. DO NOT use abrasive cleaners as they can damage the finish.Test on a hidden
part before cleaning. Clean only in the direction of the grain. Regularly check the surround is securely fixed in position.
7.0 GUARANTEE - TERMS AND CONDITIONS
The 3 year guarantee commences from the date of purchase, provided that the terms and conditions are adhered to:
Registration is not required.
1. For any claim to be made within the 3 years from date of purchase you will be required to provide and supply us with your
proof of purchase.
Making a claim is easy.
If you wish to make a claim under our 3 year guarantee and all the terms and conditions for your product have been met then
please submit the following information for the attention of the 3G Service Department to the address below.Alternatively, you
can email or fax. Please note that this does not affect your statutory rights.
Focal Point Fires Ltd, 3G Service Department, Reid Street, Christchurch, Dorset, BH23 2BT.
Alternatively email: [e-mail] or fax. [phone].
Details required:
1. Name, full address including post code and contact telephone number.
2. Receipt of purchase or credit card statement.
