ASSEMBLY & INSTALLATION INSTRUCTIONS
All instructions must be handed to the user for
safekeeping.
Please note : Except where otherwise stated, all rights, including copy-
right in the text, images and layout of this booklet is owned by Focal
Point Fires plc. You are not permitted to copy or adapt any of the con-
tent without the prior written permission of Focal Point Fires plc.
1
Revision A - 09/15
© 2015 Focal Point Fires plc.
Focal Point Fires plc.
Christchurch, Dorset BH23 2BT
Tel: [phone]
Fax: [phone]
www.focalpointfires.co.uk
e : [email protected].uk
Questions or problems with your appliance?
Don’t take it back to the store
just give us a call on 01202 588601 we’re here to help
lines open between 9am and 5pm, onday to Friday
MODELS COVERED BY THESE INSTRUCTIONS
F820680 FPFB 553 MONTANA FIRE SURROUND WHITE

A S S E M B L Y I N S T R U C T I O N S
2
GB IE
1.0 IMPORTANT NOTES
© 2015 Focal Point Fires plc.
Section
1.0
2.0
3.0
4.0
5.0
6.0
7.0
Contents
Important notes
Tools required
Hardware & parts list
Assembly
Installation
Cleaning/ finishing
Guarantee - terms and conditions
Page No.
2
2
2
3
4
5
5
2.0 TOOLS RE UIRED
CODE NA E FIGURE QUANTITY
ASCREWS
(8x 25mm)
16PCS
B SCREWS
(8x 45mm)
9PCS
C
WOOD
DOWELS
(8x 30mm)
16PCS
D SCREWS
(6x 20mm)
4PCS
E
WALL
SCREWS
(6x 38mm) 2PCS
F
WALL
PLUGS
(6x 25mm)
2PCS
G
IRROR
PLATES
(45x 43mm)
2PC
3.0 HARDWARE & PARTS LIST
CODE NA E FIGURE QUANTITY
①TOP PANEL 1PC
②LEFT LEG 1PC
③RIGHT LEG 1PC
④
NARROW
INSIDE
PANEL
3PCS
⑤
CONNECT-
ING
BLOCK 4PCS
To ensure safe and stable installation:
1. The assembled Fire Surround must be fixed / secured to wall.
2. The wall must be sturdy and in good repair.
3. Some walls require alternative fixings (not included).
4. When drilling into the wall, check for hidden pipes and cables.
5.There are two options for construction of this surround.
A - with rebates - If you are installing this surround with a gas fire, or an electric fire where there is space in the wall to recess
the fire, this means the laminate / marble is up against the wall.
B - with out rebates - If using this surround with an electric fire and a flat wall you will need to remove the rebates, instead use
the spacer frame from the fire.
Cross head screwdriver PZ2 (3 inches in length or greater)
Drill, 6mm and a 2mm suitable drill bit
Pencil
Tape measure

4.0 ASSEMBLY
3
GB IE
© 2015 Focal Point Fires plc.
Screw the 4x connecting blocks (5) onto the rear of the left leg (2) and the right leg (3) with the 8x 25mm screws (A) provid-
ed.
Fixings Parts
A x 8 PCS 2
3
5
STEP 1
Fixings Parts
A x 8 PCS 1
C x 4 PCS 2
3
5
Next insert the 4x wood dowels (C) into the top of the left leg (2) and the right leg (3). Carefully place the top panel (1) on to
the top of the left and right hand legs (2 and 3). Ensuring the top (1) lines up with the 4x connecting blocks (5) and the 4x
wooden dowels (C). Once in place, screw the 8x 8x 25mm screws (A) through the connecting blocks (5) and into the top
panel (1) securing it into position.
STEP 2
⑤
⑤
⑤
⑤
⑤
⑤

4.0 ASSEMBLY
4
GB IE
© 2015 Focal Point Fires plc.
Fixings Parts
B x 9 PCS 1
C x 12 PCS 2
3
4
5
STEP 3
If using option A only. If rebates are not being used go to section 5.
If a 75mm rebate (4) is required. CAREFULLY! lay the surround on a soft flat surface, taking extra care that you do not scratch
the front of the surround. NEVER DRAG THE SURROUND! Insert the 12x wooden dowels (C) into the rear of the top panel
(1), the left leg (2) and the right leg (3). With the rebates (4) in the correct orientation, place the 3x rebates (4) into position
over the wooden dowels (C). Screw the 9x 8x 45mm screws (B) through the rear of the rebates (4) connecting them to the
surround.
5.0 INSTALLATION
With a pencil mark out the desired height where you would like the mirror brackets (G) to be situated on the rear of the legs. To avoid
splitting the leg, pre drill the bracket holes with a 2mm drill bit. Now attach the brackets to the legs using the screws (D). Once the
brackets are in position, centre and level the hearth into its final fitting position. Position the surround on the hearth to correspond with
the header/fireplace lintel, mark with a pencil on the wall where you wish to drill. Remove the surround and prepare the wall from the
marked positions. If using the fixings supplied, drill a hole in the wall using a 6mm drill bit. If not, use a suitable drill bit for the wall plugs
you are using. Insert the wall plugs (F) into position. Offering the surround back up into position against the wall, you are now able to
secure the surround to the wall using the screws (E).
Fixings
D x 4 PCS
E x 2 PCS
F x 2 PCS
G x 2 PCS
①
②
③
⑤
⑤
⑤
⑤

5© 2015 Focal Point Fires plc.
Before carrying out any of the following operations, ensure that the appliance is OFF and completely cold. Regularly clean
around the appliance to ensure that dust, fluff, pet hair etc, are kept to a minimum. There are no other specific requirements for
care, other than regular cleaning of the general appliance.
A wipe with a dry cloth is normally sufficient. DO NOT use abrasive cleaners as they can damage the finish. Test on a hidden
part before cleaning. Clean only in the direction of the grain. Regularly check the surround is securely fixed in position.
6.0 CLEANING/ FINISHING
7.0 GUARANTEE - TERMS AND CONDITIONS
The 3 year guarantee commences from the date of purchase, provided that the terms and conditions are adhered to:
Registration is not required.
1. For any claim to be made within the 3 years from date of purchase you will be required to provide and supply us with your
proof of purchase.
Making a claim is easy.
If you wish to make a claim under our 3 year guarantee and all the terms and conditions for your product have been met then
please submit the following information for the attention of the 3G Service Department to the address below. Alternatively, you
can email or fax. Please note that this does not affect your statutory rights.
Focal Point Fires plc, 3G Service Department, Reid Street, Christchurch, Dorset, BH23 2BT.
Alternatively email: [e-mail] or fax. [phone].
Details required:
1. Name, full address including post code and contact telephone number.
2. Receipt of purchase or credit card statement.
F861316
As our policy is one of continuous improvement and development, we hope therefore you understand we must retain the right to amend details and/or specifications without prior notice.
