Foma SA702i User manual

’06.5

Making/receiving a call
Making/receiving
a videophone call
Phonebook
Safety settings
Camera
i-mode/
i-motion
Mail
GPS function
Displaying/editing/
managing data
Network service
Data communication
Character input
Appendix/External device linkage/
Troubleshooting
Index/
Quick reference manual
Before using
SA702i
Quick search/
Contents/Precautions
Sound/Display/
Light settings
Other convenient
functions
Music Player/
FM radio
Manual for
i- ppli
i-channel

DoCoMo W-CDMA System
Thank you for choosing "FOMA SA702i" mobile terminal.
Both before and during the use of FOMA SA702i mobile terminal, be sure to thoroughly
read this manual and instruction manuals that come with the battery pack and other
devices, to ensure you for correct use of FOMA SA702i mobile terminal. Contact
"DoCoMo Information Center" on the back of this manual for details.
FOMA SA702i mobile terminal will be your trusted partner. Treat it with care, for long-
term use.
Before using FOMA mobile terminal
・ Since FOMA terminal uses radio waves, it may not function in locations where it is difficult for radio waves to
reach, such as tunnels, underground and inside buildings, in areas where radio wave signals are weak, or
outside the service area. FOMA terminal may not be able to receive or transmit signals, even when you are high
up in a tall building or condominium and nothing blocks your view outside, in some cases. In addition,
communication might be interrupted even when the signal meter on FOMA terminal indicates a good radio wave
condition, and even when you are not moving.
・ Use FOMA terminal in a way that does not disturb others in public places, crowded locations or quiet places.
・ Since FOMA terminal uses radio waves to communicate, there is a possibility that third parties may attempt to
intercept your calls. However, the W-CDMA system automatically performs a confidential communication
function for all calls. Even if someone should somehow be able to tap a call, the signals are modified so that the
eavesdropping party will hear only noise.
・ FOMA terminal encodes voice communication as digital signal. When you are using FOMA terminal while
moving to a location subject to weaker radio wave signals, the transmitted digital signal may not be correctly
decoded. The decoded voice may differ somewhat from the actual voice.
・ Keep a separate written record of the data you register in FOMA terminal. If the data should be erased, DoCoMo
assumes no responsibility for the loss of any data.
・The user hereby agrees to be solely responsible for the use of SSL. Neither DoCoMo nor the certifier as
listed below makes any representation and warranty as for the security in the use of SSL, and assumes no
responsibility for the loss of any data. Certifier: VeriSign Japan K.K., Betrusted Japan Co., Ltd., GeoTrust
Japan, Inc.
・ This FOMA terminal supports FOMA plus area.
・ The FOMA terminal can be used only via the FOMA network provided by DoCoMo.
For new users of FOMA terminal
・ If you are a new user of FOMA terminal, it is recommended to read this manual in the following order. It provides
you with the basic understandings for preparation and operations to use FOMA terminals.
1. Place the battery pack and charge it. JP41, 42
2. Turn the power on, make the initial settings, and check your phone number. JP48, 49, 51
3. Check the functions of each key on the terminal. JP28
4. Check the meaning of the icons etc. on the screen. JP30
5. Check the operation procedures of the menus. JP34
6. Check the operation to make/answer a call. JP53
The latest information on this manual can be downloaded from DoCoMo Internet site.
・  User's Manual Download  (in PDF format)
http://www.nttdocomo.co.jp/english/support/manual/index.html
＊
URL and the contents of this manual may be subject to change without a prior notice.

1
How to read/refer to this manual
In this manual, instructions are described with illustrations or marks, to use FOMA
terminal properly.
Referring to this manual
You can search the appropriate page for desired information of functions or services as below:
・ Note that in this "Manual for FOMA SA702i", "FOMA SA702i" is usually referred to as "FOMA terminal". Please
be forewarned.
・ This manual describes the functions performed with a miniSD memory card. A miniSD memory card is not
included in the basic package of FOMA terminal. miniSD memory card
J P287
・ Descriptions in this manual are based on the default settings. Contents displayed on screens may differ from
the description on this manual, depending on setting changes.
・ The images or illustrations provided in this manual are for information purposes only and may differ from the
actual screens.
・ Unauthorized copy of all or part of this manual is prohibited.
・ The contents of this manual may be subject to change without a prior notice.
Refer to the next page for more details.
From Index JP406
Start to search the function name on the screen of FOMA terminal, or the names of
functions/services which you know.
From Quick search JP4
Search the frequently-used or convenient functions with easy words.
From Side index on the top page JTop page
Refer to the side index of the top page to search.
From Contents JP6
Search from the terms of contents with categorized functions.
From Features JP8
Start to search the featured new/convenient functions of FOMA terminal.
From Menu list JP360
Lists the menus displayed on the menu screen of FOMA terminal.
From Quick reference manual JP412
The basic functions are explained briefly. Cut out from the manual, to take it with you.

2
Describes how to search Sound setting information as an example.
JP406
Start to search the function name on the screen of FOMA terminal, or the names of
functions/services which you know.
From Index
Go to
P116
"Sound".
Ｓｏｕｎｄ １／３
Ｖｉｄｅｏｐｈｏｎｅ ｉｎｃｏｍｉｎｇ
Ｐａｙｐｈｏｎｅ ｉｎｃｏｍｉｎｇ
Ｕｓｅｒ ｕｎｓｅｔ ｉｎｃｏｍｉｎｇ
Ｎｏｔ ｓｕｐｐｏｒｔ ｉｎｃｏｍｉｎｇ
Ｒｅｃｅｉｖｅ ｍａｉｌ
Ｒｅｃｅｉｖｅ ｃｈａｔ ｍａｉｌ
Ｒｅｃｅｉｖｅ ｍｅｓｓａｇｅＲ
Ｒｅｃｅｉｖｅ ｍｅｓｓａｇｅＦ
Ｐｈｏｎｅ ｉｎｃｏｍｉｎｇ
Ｓｅｌｅｃｔ
x
e
d
nI
l
a
u
n
a
m
e
c
ne
r
ef
er
k
c
i
u
Q
/
x
e
dn
I
p
Send .................................. 235
Setting ............................... 236
SMS Center ....................... 237
SMS report request ........... 236
Storage period................... 208
SMS report request............... 236
Software auto start
Auto start .. ......................... 244
Store Auto start ................. 245
Software update .................... 387
Reserved update ............... 390
Start................................... 388
Update immediately........... 389
Sound.................................... 116
Speaker................................... 29
SSL certificate ....................... 199
SSL communication .............. 180
SSL page connection ........ 184
Stamp
JP4
Search the frequently-used or convenient functions with easy words.
From Quick search
ChangingMelody and Call illumination
Mutingkey operation sound . . . . . . . . .P120 Keypad sound
ChangingMelody played on receiving. . . P116 Sound
ChangingVolume on receiving. . . . . . .P119 Volume
SettingManner mode . . . . . . . . . . . . . . .P123 Manner mode
SettingVibrator on receivingbesidesRingtone
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P119 Vibrator
ChangingLamp color/Lamp pattern on receiving
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P133 LED
ChangingRingtone for each phone number
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P98
Go to
P116
"Sound".
JTop page
Search the page of the function desired to set by the following order; "Top page" J"Top
page of each chapter" J"Detailed information page". You can find the detailed list of
contents on the top page of each chapter.
From Side index on the top page
Making/receiving a call
Making/receiving
a videophone call
Phonebook
Safety settings
Camera
i-mode/
i-motion
Mail
Before using
SA702i
Sound/Display/
Light settings
Sound/Display/Light settings
Sound settings
ChangingFOMA terminal Ringtone . . . . . . . . . . . . . . . . . <Sound> 116
Changingtone volume of FOMA term inal. . . . . . . . . . . <Volume> 119
Notifyingincomingcallsetc. with Vibration . . . . . . . . . . <Vibrator> 119
Notifyingwith vibration that the other party answersthe call
................................ ..<Connection vibrator> 120
Settingsound of key operation . . . . . . . . . . . . . . .
<Keypad sound> 120
SettingOK tone/NG tone . . . . . . . . . . . . . . . . . .
<OK tone/NG tone> 121
Go to P116 "Sound".

3
・The page shown is an example. Contents may differ from the actual page.
116
d
n
u
o
Ssgnit
t
e
s
thgi
L
/
y
a
l
p
siD/d
nu
o
S
Sound
Sound
ChangingFOMA terminal Ringtone
You can set the Ringtonesfor the reception of calls/mails, confirmation tonesfor
operation, or Location provide notify/check tone.
・When i-motion is set as Ring tone, the imageand sound of the i-motion plays when receiving
calls/mails (Chaku-motion).
ChangingRingtone or Chaku-motion
1
Press C
s
s1
s
2.
2
Press one of 1to 9.
Information
●Some i-motion, such as Video only i-motion, cannot be set as Ring tone.
● When setting i-motion including image and sound as Ring tone, the image set for Receive display is
changed to the i-motion automatically. However, when Sound only i-motion data (i-motion without video,
such as vocal of a singer) is set as Ring tone, the image set for Receive display is not changed but the
●When several settings of Ring tone conflict, priority is set as follows.
aThe setting for individual settings in Phonebook
bThe setting for group settings in Phonebook
cRing tone set in Sound settings
However, if you subscribe to Multinumber service andset Additional number, the setting follows the Ring
tone setting of the Additional number. P342
●When i-motion with image and sound is set as Ring tone, the i-motion is displayed for incoming calls,
having a priority over the still image of the caller set in Phonebook basic information. However, registered
still image is displayed if the i-motion is Sound only (i-motion without video, such as vocal of a singer).
Default Phone/Videophone incoming : The Space
Payphone/User unset/Not support incoming : パターン 4 <Pattern 4>
Receiving mail/message R/F :
エレクトリック <Electric>
Receive chat mail : ハープ <Harp>
Phone incomingSets Ring tone for incoming phone calls.
Videophone incomingSets Ring tone for incoming videophone calls.
Payphone incomingSets Ring tone for incoming calls from such as payphone.
User unset incomingSets Ring tone for incoming user unset calls.
Not support incoming Sets Ring tone for incoming international phone calls or calls
via forwarding services from fixed-line phones. (Caller ID may
be displayed depending on the telecommunication career.)
Receive mail Sets Ring tone for receiving mails.
Receive chat mail Sets Ring tone for receiving chat mails.
Receive messageR Sets Ring tone for receiving MessageR.
Receive messageF Sets Ring tone for receiving MessageF.
Ｓｏｕｎｄ   １／３
Ｖｉｄｅｏｐｈｏｎｅ ｉｎｃｏｍｉｎｇ
Ｐａｙｐｈｏｎｅ ｉｎｃｏｍｉｎｇ
Ｕｓｅｒ ｕｎｓｅｔ ｉｎｃｏｍｉｎｇ
Ｎｏｔ ｓｕｐｐｏｒｔ ｉｎｃｏｍｉｎｇ
Ｒｅｃｅｉｖｅ ｍａｉｌ
Ｒｅｃｅｉｖｅ ｃｈａｔ ｍａｉｌ
Ｒｅｃｅｉｖｅ ｍｅｓｓａｇｅＲ
Ｒｅｃｅｉｖｅ ｍｅｓｓａｇｅＦ
Ｐｈｏｎｅ ｉｎｃｏｍｉｎｇ
Ｓｅｌｅｃｔ
set image is displayed.
Page number
Name of function:
Function names in the Index
are based on this name.
The default setting is
shown here. Refer to
"Menu List" for the list of
default setting.
General
notices for
using each
function
Search each
chapter and
function from
this Side index.
Instructions and
operations for
each article
Useful information
for using each
function
Options
displayed on the
screen and the
details
This is a typical screen for
the operation in the step.
Refer to the screen of your
FOMA terminal. (Numbers,
settings or optional entries
in this figure are just an
example.)
JP360

4
Quick search
Quick search/
Contents/Precautions
Quick search
Quick search
Use this index to search from the desired function or operation.
Using convenient functions during a call
Notifying/not notifying your Caller ID. . . P51 Caller ID notification
Facing to the screen while talking . . . . P83 Hands-free
Adjusting volume of the other party's voice
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P68Earpiece volume
Holding a call. . . . . . . . . . . . . . . . . . . . . .P55 Call-on-hold
Hi!
Handling a call when you cannot answer
Recording the other party's message . . . P76 Record message
Recording the message on Voice mail . . P338 Voice mail
Holding a call to answer. . . . . . . . . . . . .P70 On-hold
Changing Melody and Call illumination
Muting key operation sound . . . . . . . . .P120 Keypad sound
Changing Melody played on receiving . . . P116 Sound
Changing Volume on receiving . . . . . . .P119 Volume
Setting Manner mode . . . . . . . . . . . . . . .P123Manner mode
Setting Vibrator on receiving besides Ring tone
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P119 Vibrator
Changing Lamp color/Lamp pattern on receiving
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P133 LED
Changing Ring tone for each phone number
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P98
Changing/reading display
Changing Stand-by display . . . . . . . . . .P125 Stand-by display
Displaying Calendar on Stand-by display. . P126 Clock/Calendar
Setting Time and date. . . . . . . . . . . . . . .P50
Time and date setting
Changing Font size. . . . . . . . . . . . . . . . .P135Fontsize
Looking up meanings of Marks (Icons) on screen
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P30
＊
miniSD memory cards are optional accessories.JP287

5
Quick search
Quick search/
Contents/Precautions
Refer to "For new users of FOMA terminal" on the back of the cover page, for viewing other operations
and functions. Quick manual provides frequently used procedures to refer.
J P412
Making full use of Mail
Sending Deco-mails . . . . . . . . . . . . . . . .P211 Deco-mail
Sending images . . . . . . . . . . . . . . . . . . .P214 Melody/Still image/
Movies/i-motion mail
Sorting and saving mails automatically . . . P223Auto sort
Confirming/changing E-mail address . . . P205
Using Chat mail. . . . . . . . . . . . . . . . . . . .P232
Compose/send Chat mail
Making full use of Camera
Changing shooting size . . . . . . . . . . . . .P168
Changing Shutter sound . . . . . . . . . . . .P171
Turning Light on . . . . . . . . . . . . . . . . . . .P168
Saving to miniSD memory card directly . . . P171 Save to:
Displaying shot images . . . . . . . . . . . . .P275
Using FOMA terminal with security settings
Hiding Phonebook data . . . . . . . . . . . . .P148Secret mode
Rejecting calls with no Caller ID notified . . . P150 Reject calls by reasons
for User unset
Rejecting calls from numbers not registered in Phonebook
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P152 Reject calls from
unregistered numbers
Locking Side key . . . . . . . . . . . . . . . . . .P147 Side key
Valid/Invalid
Other convenient functions
Searching the route to the destination . . . P258Navigation
Starting frequently used functions with simple operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P326 Shortcut menu
Using as Calculator . . . . . . . . . . . . . . . .P329 Calculator
Scanning QR codes or JAN codes . . . . . . . P172 Bar code reader
Transferring information with Infrared communication
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P298
Using as alarm clock . . . . . . . . . . . . . . .P316 Alarm
Using GPS . . . . . . . . . . . . . . . . . . . . . . . .P255
Using miniSD memory card. . . . . . . . . .P287
Using FM radio . . . . . . . . . . . . . . . . . . . .P309
Updating software. . . . . . . . . . . . . . . . . .P387 Software update
Updating Security function . . . . . . . . . .P392 Scanning function

6
Termsof contents
Quick search/
Contents/Precautions
Terms of contents
Before using FOMA mobile terminal . . . . . . . . . Back of the cover page
For new users of FOMA terminal . . . . . . . . . . . . . . Back of the cover page
How to read/refer to this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Quick search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features of FOMA SA702i . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Making full use of FOMA SA702i! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Precautions (ALWAYS FOLLOW THESE DIRECTIONS) . . . . . . . . . . . . 12
Handling instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Intellectual property rights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Basic package and optional accessories . . . . . . . . . . . . . . . . . . . . . . . . 26
Before using SA702i 27
Names and functions of parts Display Select Menu Use UIM (FOMA card)
Insert/remove battery pack Charge Battery level Power ON/OFF
Time/date setting Caller ID notification Profile Select language etc.
Making/receiving a call 53
Make a call Redial International call Answer a call Any key answer Open to talk
Closing action Received call On-hold Public mode (Drive mode)
Record message etc.
Making/receiving a videophone call 81
Make a videophone call Answer a videophone call Set image to send
Display setting for videophone call etc.
Phonebook 93
Store in Phonebook Edit Group Search Phonebook Secret Direct call etc.
Sound/Display/Light settings 115
Sound Vibrator Manner mode Stand-by display Backlight LED etc.
Safety settings 137
Security code Change terminal security code PIN code Lock all self mode PIM lock
Keypad dial lock Secret mode Call rejection etc.
Camera 155
Shoot still image Shoot movie Setting for shooting Bar code reader
Character reader etc.
i-mode/i-motion 177
i-mode Display site Change i-mode password Connect to Internet Bookmark
i-mode setting MessageR/F Certificate i-motion Download i-motion etc.
＊miniSD memory cards are optional accessories.JP287

7
Termsof contents
Quick search/
Contents/Precautions
Mail 203
Compose/send i-mode mail Deco-mail Attachment Save i-mode mail
Receive i-mode mail Check new message Reply to i-mode mail i-motion mail
Play/save melody Mail setting Chat mail Compose/send SMS etc.
i-gppli 239
Download Start i-gppli i-gppli To function i-gppli stand-by display etc.
i-channel 251
Display i-channel i-channel setting
GPS function 255
Position location Navigation GPS software Location provide Notify location etc.
Displaying/editing/managing data 273
Play still image/movie Edit still image/movie Play Melody miniSD memory card
Folder/data management Infrared communication Voice recorder etc.
Music Player/FM radio 305
Music Player FM radio
Other convenient functions 313
Multiaccess Multitask Alarm Schedule Shortcut menu
Profile Voice memo during a call Duration/Cost Calculator Text memo
Call maximum limit Reset settings Delete all data Dictionary etc.
Network service 337
Voice mail service Call waiting Call forwarding service Nuisance call barring service
Caller ID request status service Dual network service English guidance
In-call arrival act Remote access etc.
Data communication 345
Flow of data communication AT command
Character input 349
Character input Edit Common phrases/emoticons Copy character Input code
Store in user dictionary Download dictionary Input prediction 2-touch etc.
Appendix/External device linkage/Troubleshooting 359
Menu list Characters assigned to dial keys Input codes
Combination of Multiaccess/Multitask functions Optional and related device
Data link software Movie player software Troubleshooting Error message list
Warranty and After-sales service Software update Scanning function
Major specifications SAR certification information etc.
Index/Quick reference manual 405

8
Featuresof FOMA SA702i
Quick search/
Contents/Precautions
Featuresof FOMA SA702i
Features of FOMA SA702i
FOMA is the name of DoCoMo's service based on W-CDMA format, which is recognized
as one of the systems compliant with the global standard for the third generation
wireless communications (IMT-2000).
i-mode, its splendid service
i-mode is the online service providing useful information from i-mode Menu sites (programs) or
i-mode compatible sites. In addition, you can transfer mails easily using i-mode terminals.
SA702i main features
Wide variety of network services
Safety settings
・ i-mode J P178 ・ i-motion J P201
・ i-mode mail J P204 ・ i-shot J P206
・ i-motion mail J P207
Videophone J P81
You can talk to the other party in a distance
watching each other's face. Set the caller's voice
to come out from the speaker, or switch to Out-
camera to show surroundings to the other party.
Deco-mail JP211
Deco-mail allows you to compose and send more
expressive E-mail messages with varieties of font
color/size/background color, as well as inserting
Deco-mail pictures or images shot by built-in
Camera. You can also compose Deco-mail easily
using received Deco-mail or templates
downloaded from sites.
i-gppli/i-gppliDX JP239
You can download various i-gppli from sites for
your use, or set to Stand-by display etc.
i-gppliDX also allows you to broaden the use of
i-gppli in conjunction with the data such as
Phonebook or mails in i-mode terminal.
i-channel J P252
i-channel provides graphical information such as
latest news or weather reports. Information is
provided periodically. Latest information is
displayed as ticker on Stand-by display, or Channel
list which becomes available by pressing i-channel
key. In addition, you can retrieve enriched detailed
information by selecting your favorite channel from
Channel list. If you have not subscribed to i-channel
service yet, the trial service is available with free of
charge for a certain period.
＊1Optional subscription is required. ＊2Optional subscription is not required.
・ Voice mail service (charged)
＊
1
J P338 ・ SMS (Short Message)
＊
2
J P235
・ Call forwarding service
＊
1
J P340 ・ Dual network service (charged)
＊
1
J P341
・ Call waiting (charged)
＊
1
J P339
You can set the terminal security code to protect privacy, or Lock all/self mode not to be revealed or
connected by third parties without permission.
＊miniSD memory cards are optional accessories.JP287

9
Featuresof FOMA SA702i
Quick search/
Contents/Precautions
Other convenient functions
Multitask J P315
Multitask allows you to activate several functions at the
same time and to perform operations by switching the
screen. For example, you can confirm Phonebook
entries during a call, or compose a mail with referring to
a memo, etc.
High-qualified camera functions JP155
FOMA terminal equips CCD camera with approximately
1300K effective pixels (approximately 1200K maximum
effective pixels for shooting), and the available still image
is up to the SXGA size. You can shoot images with frame
decorations or special effects, or shoot continuously.
And the recordable movies with FOMA
terminal is up to the QCIF size.
Character reader J P174 /Bar code reader J P172
You can register Phonebook entries or
compose i-mode mails by reading phone
number or mail address with built-in camera. In
addition, scanned English words can be
translated. Scanning bar codes (JAN code,
QR code) is also available.
FM radio JP309
You can listen to FM radio or channel 1 to 3 of
television with only sound. Select an area
where you want to choose a station, and
favorite stations are available by pressing dial
keys. You can also record the sound.
Melody JP287
FOMA terminal equips melodies with 64
chords in PCM format, to set as Ring tone of
phone/mail. You can also download PCM
format melodies with surrounded-sound from
sites.
Infrared communication JP298
Phonebook data, mails, images, melodies and
other data can be exchanged between FOMA
terminals and mobile phones equipped with
infrared communication function.
Supporting Flash®JP181
Enjoy Flash movies and animations on i-mode
sites with FOMA terminal. And you can also
download Flash animation and set it as Stand-
by display.
Direct Call J P111
Register persons whom you contact frequently, to
make calls or send mails quickly with easy
operation. You can select and display the list of
Received calls/Redials or Received/Send mails only
between the registered persons.
Supporting miniSD memory card JP287
With supporting miniSD memory card standard, you
can use the data in FOMA terminal, such as images,
melodies or sound saved in external devices.
Movies or sound data saved in miniSD memory card
can be played with FOMA terminal. (Some data may
not be played properly in some conditions.)
Alternatively, images, Phonebook data or mails in
FOMA terminal can be saved to external devices by
using miniSD memory card.
GPS function JP255
Retrieves location information of FOMA
terminal by using radio waves transmitted
from GPS satellites. Following services are
available with retrieved location information.
・Displaying map or searching surrounding
information of the present location
You can send retrieved location information
to display a map, or search surrounding
information easily.
・Sending the present location or favorite
places by mails
Attach location information to mail message,
and i-mode users who received the mail can
confirm the location with maps.
・Registering location information onto
Phonebook or images
You can add location information of such as
shops to Phonebook etc., and confirm the
shop location with maps.
It is also available to add location information
of the shooting spot to the still image, and
confirm later with maps.
・ Using GPS applicable i- g ppli (GPS software)
Useful i- g ppli is available by location information.
・Using Navigation
Navigation to the destination is available by
using retrieved location information.

10
Making full use of FOMA SA702i!
Quick search/
Contents/Precautions
Making full use of FOMA SA702i!
Making full use of FOMA SA702i!
This section introduces various functions of FOMA SA702i with screen images.
Videophone JP82
Images to send can be switched easily in a videophone call. You can switch In-camera
and Out-camera, or display various images in Data box.
Displays your
image with
In-camera.
Sends surrounding
image to the other
party.
Sends image in Data
box as substitutive
image.
Available to
switch the
display size
Deco-mail JP211, 213
You can send colorful and enjoyable mails easily, by changing font color or background
color, and inserting pictures in Deco-mail picture or the ones shot with built-in camera.
Ｍｅｓｓａｇｅ
Ｃｈａｒ．  Ｐｉｃｔｕｒｅ／Ｍａｒｋ
Ｒ． ９９９５
Ｐｒｅｖｉｅｗ
Ｈｅｌｌｏ
Ｐｒｅｖｉｅｗ
Ｈｅｌｌｏ
． Ｃｏｎｔａｃｔ ｍｅ ａｔ ｎｅｗ
ａｄｄｒｅｓｓ ａｎｄ ｐｈｏｎｅ
；
ｈｔｔｐ ： ／／ｗｗｗ ． ａｂｃｄ１２３ ． ｃｏ ． ｊｐ
ｄｏｃｏｍｏ
． ｔａｒｏ△△＠ｄｏｃｏｍｏ ． ｎｅ ．
ｊｐ
０９０ＸＸＸＸＸＸＸＸ
Ｓｅｎｄｉｎｇ ｍｅｓｓａｇｅ
Ｓｅｎｄｍｅｓｓａｇｅ
Message entry Palette Preview Sending Deco-mail
Ｒ． ９９９５
Ｅｄｉｔ ｄｅｃｏｒａｔｉｏｎ
Ｐｒｅｖｉｅｗ
Ｍｅｓｓａｇｅ
Ｈｅｌｌｏ
Character reader JP174
You can scan phone number or E-mail address with FOMA terminal built-in camera. Various usages
of data are available, such as registering the scanned data to Phonebook or composing a mail.
Starts Character
reader.
Scans
characters.
Uses for
inputting
characters.
Ｃｈａｒａｃｔｅｒ ｒｅａｄｅｒ
Ｆｏｃｕｓ ｌｅｖｅｌ
Ｔｈｅ ｃｌｏｓｅｒ ｔｏ ｉｔ ｉｓ，
ｔｈｅ ｅａｓｉｅｒ ｔｏ ｒｅｃｏｇｎｉｚｅ
ｃｈａｒａｃｔｅｒｓ ｉｔ ｉｓ
ｄｏｃｏｍｏ＿ｔａｒｏ
２５６
Ｃｈａｒａｃｔｅｒ ｒｅａｄｅｒ
Ｆｏｃｕｓ ｌｅｖｅｌ
ｄｏｃｏｍｏ＿ｔａｒｏ
２4５
ＯＫＥｄｉｔ
ｄｏｃｏｍｏ＿ｔａｒｏ
Ｃｈａｒａｃｔｅｒ ｒｅａｄｅｒ
ｄｏｃｏｍｏ＿ｔａｒｏ
Ｆｕｎｃｔｉｏｎ Ｓａｖｅ

11
Making full use of FOMA SA702i!
Quick search/
Contents/Precautions
Direct Call JP111
Register persons whom you contact frequently, to make calls or send mails quickly with
easy operation.
ＯＫ
ＤｏＣｏＭｏ Ｈａｎａｋｏ
電話をかけます
Ｍａｋｅ ａ ｐｈｏｎｅ ｃａｌｌ！
０９０ＸＸＸＸＸＸＸＸ
０３ＸＸＸＸＸＸＸＸ
０４５ＸＸＸＸＸＸＸ
Registers a
Phonebook entry
as Direct Call.
Press n
to display Direct
Call screen.
Easy operation, only to
select the other party
and the function.
ＣｈｅｃｋＳｅｌｅｃｔ
ＤｏＣｏＭｏ Ｈａｎａｋｏ
Ｍａｋｅｓ ａ ｐｈｏｎｅ ｃａｌｌ
Ｓｔｏｒｅ
Ｎｏｎｅ ｓｔｏｒｅｄ
G
ガイド番組表リモコン
<G-guide TV Program Remote Control>
J
P244
"G ガイド番組表リモコン <G-guide TV Program Remote Control>", which is preinstalled in FOMA
terminal, provides you to retrieve program guides any time in response to your request. Remote
control of television is also available using infrared communication function of FOMA terminal.
・ The screen is an example. Contents may differ from the actual screens. Displayed channels vary
according to the area you live.
Check G-code®on
program guides.
Retrieve detailed
information of the
program by connecting
to the server.
i-channel JP252
Reception of various information periodically, without any operation. Press i-channel keys
and you can display Channel list. Channel list provides you more detailed information to
retrieve.
高気圧の勢力強ま
■ Before subscription ■ After subscription
tConnect

12
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Precautions(ALW AYSFOLLOW THESE DIRECTIONS)
Precautions (ALWAYS FOLLOW THESE DIRECTIONS)
■ Before using your FOMA terminal, read the following precautions to
ensure safe use and handling. Keep this manual carefully after reading.
■These precautions are intended to protect you and others. Read
and follow the cautions carefully to avoid injury, damage to a
person or the property.
■The following signs differentiate the levels of danger or damage
that may occur if the product is not used under the specified
guidelines.
■The following symbols show specific directions.
■"Precautions" contains the following 6 descriptions.
Handling FOMA terminal, battery pack, adapter (including battery charger) and
UIM (FOMA card) (Common) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Handling FOMA terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Handling battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Handling adaptors(including battery charger) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Handling UIM (FOMA card) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Handling mobile phone near electronic medical devices. . . . . . . . . . . . . . . . . . . . . . . . . 20
DANGER
WARNING
CAUTION
This sign denotes that high potential for death or
serious injury may be caused by improper use.
This sign denotes that potential for death or serious
injury may be caused by improper use.
This sign denotes that bodily injury or damage to
property may be caused by improper use.
This symbol denotes that the action is prohibited.
This symbol denotes that disassembling the terminal or its component is not
allowed.
This symbol denotes that using the terminal or its components with wet hands
is not allowed.
This symbol denotes that the instruction must be obeyed at all times.
This symbol denotes that the adapter must be unplugged.
This symbol denotes that using the terminal or its components near water or
getting the device wet is not allowed.

13
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Use battery pack and adapter
(including battery charger) that are
specified by the DoCoMo group
companieswith your FOMA terminal.
Not using the terminal specified by the
DoCoMo group companies may cause
FOMA terminal, battery pack and other
parts to leak, heat, burst, catch fire or
malfunction.
＊
Contact DoCoMo shop etc. for more
information on other compatible products.
Do not wet the terminal.
Contact with water or other liquid may
cause heating, electric shock, fire,
malfunctions or injury. Take care where
and how you use the terminal.
Do not disassemble or remodel the
terminal. Also, do not solder the
device or components.
It may cause a fire, injury, electric shock
or malfunction.
Also battery pack may leak, overheat,
explode or catch fire.
Do not use or leave the battery pack in
locationssubject to high temperature,
such as near afireplace, heating
appliances, in direct sunlight or inside
acar on ahot day.
It may cause the terminal deformation/
malfunction or battery pack leak/
overheat/burst/ignite/catching fire/
performance loss/shorter life.
Also a part of the case may be heated
and may be the cause of burns.
Do not throw the terminal or give hard
shock to the terminal.
It may cause the battery pack to leak,
heat, burst or ignite, and the terminal to
malfunction or catch fire.
Do not put the battery pack, FOMA
terminal, the adapter (including battery
charger) or UIM (FOMA card) into
microwave ovensor other heating
appliancesor high-pressure containers.
It may cause the battery pack to leak,
heat, burst or ignite, FOMA terminal or the
adapter (including battery charger) to
heat, smoke, ignite, or damage circuits.
Do not use the terminal in an
environment liable to cause it to explode
or catch fire, such as agas station.
Explosions or fire may be caused if the
terminal is used in areas where dust or
flammable gas such as propane or
gasoline vapors are generated.
Do not allow an electrically conductive
material, such as metal piece or pencil
lead, contact to the charging terminals
or the external connection port. Also
do not put electrically conductive
material into the terminal.
It may cause fire or malfunction from short-out.
Operate following procedures
immediately when your terminal acts
differently from usual, such as strange
smell, heat generation, discoloration,
or deformation while using, charging,
storing.
1. Remove the power plug from the
outlet or a socket.
2. Turn off the power of FOMA terminal.
3. Remove the battery pack from
FOMA terminal.
The continued use in those conditions
may cause overheat, burst, ignite or
leak of battery pack.
HandlingFOMA terminal, battery pack, adapter (includingbattery charger) and UIM (FOMA card ) (Common)
DANGER
Battery pack SA03
Desktop holder SA03
FOMA AC adapter 01
FOMA DC adapter 01
FOMA AC adapter 01 for global use
FOMA dry battery adapter 01
WARNING

14
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Keep the terminal out of the reach of
infants.
The card or adapter can be accidentally
swallowed or cause injuries.
Do not keep the terminal in extremely
humid, dusty or hot areas.
It may cause malfunction.
Children using the terminal should be
instructed by adults. Do not allow
them to use the terminal without adult
supervision.
Or it may cause injuries.
Do not leave the terminal on unstable
or tilted surfaces.
It may fall off and cause malfunction or
injuries.
The temperature of FOMA terminal or
the battery pack/adapter (including
the battery charger) may become
higher for charging or repeating/
continuously using in, shooting/
playing movies, videophone, i-mode
or i-gppli.
If you touch the heated part for a long
time, your skin may get reddish, itchy or
irritated depending on the physical
constitution or condition.
Be careful especially when using FOMA
terminal on the adapter (including
battery charger) for a long time.
Do not use the terminal while driving a
vehicle.
According to the amendment of Road
Traffic Law, the punishment has been
charged by use of mobile phone while
driving vehicle since November 1st,
2004. Even when you use hands-free kit,
park your vehicle at the safe area to use
your mobile phone. While driving,
activate Public mode or Voice mail
service.
Be sure to keep FOMA terminal away
from your ear when youtalk with the
hands-free function set.
It may cause hearing loss.
Turn off the power of FOMA terminal
near high-precision electronic control
equipment or electronic equipment
using low-power signals.
It may affect electronic devices and
cause mechanical error or malfunction.
＊
Examples of electronic equipment to avoid:
Hearing aids, implanted pacemakers or
defibrillators, other electrical medical
equipment, fire alarms, automatic
doors, or other automatic control
equipments.
Users wearing implanted pacemakers
or defibrillators or other electrical
medical equipment should check with
the manufacturer or sales outlet about
the effect of radio waves on the terminal.
If youhave heart disease, be careful
of settingsof such as the vibrator and
the ring tone volume for incoming
calls.
It may affect heart function.
CAUTION
HandlingFOMA terminal, battery pack, adapter (includingbattery charger) and UIM (FOMA card ) (Common) (continued)
HandlingFOMA terminal
WARNING

15
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Turn off the power of FOMA terminal
in areas where mobile phone use is
prohibited, such as in an airplane or
hospital.
The use may affect the operation of
electronic equipment or medical
electric equipment.
If the function which automatically turns
on the power is set, release the setting
before turning off the power.
When using the terminal in a medical
facility, follow the regulations and
instructions of the facility.
With prohibited act, such as using the
terminal in an airplane, you may be
punished by law.
When youuse electric medical
equipment, do not keep the terminal in
your chest pocket or inside pocket.
Using your FOMA terminal near medical
electric equipment may cause the
failure on the equipment.
If youhear thunder while using the
terminal outdoors, turn off the power
immediately, and move to asafe
place.
The terminal may be subject to lightning
strike and could cause electric shock.
Do not point the infrared dataport
toward your eyeswhen youtransfer
the signals.
It may affect your eyes. In addition,
pointing to another infrared device to
send may cause mechanical error or
malfunction on the device.
Do not bring the light emitting part
close to human eyes, with the part lit
on.
Visual loss may be caused. Or a strong
light dazzles or surprise may cause
accidents leading to injury.
Do not put FOMA terminal at the place
where impact by blowing up of the air-
bag isexpected, such as dashboard
near the air-bag.
In case air-bag is blown up, FOMA
terminal may hit people and cause
injury, or may cause damage on the
terminal.
Do not point Flash/Light towards
driversof vehicles.
It may cause accidents from dizzy eyes.
Do not put liquid such as water, metal
piecesor flammable materialsinside
UIM (FOMA card) slot or miniSD
memory card slot of FOMA terminal.
It may cause fire, equipment failure or
electric shock.
Do not leave the lensof the built-in
cameraexposed to astrong light such
as direct sunlight for along time.
A light collection effect from the lens
may cause a fire.
Do not swing the FOMA terminal by
holding the strap or other partsof the
terminal.
It may hit you or other persons and
cause injury, or cause equipment
damage or failure.
WARNING
HandlingFOMA terminal (continued)
CAUTION

16
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Do not bring magnetic cardsetc. close
to FOMA terminal or place them in
between the folded terminal.
Magnetic data stored in cash cards,
credit cards, telephone cards and floppy
disks may be erased if the storage
medium is placed near the terminal.
Occasionally, using FOMA terminal in
some typesof vehicle may cause the
vehicle'selectronic malfunction or failure.
In this case, do not use FOMA terminal
not to hamper safe driving.
Do not use Flash/Light for other
purposesthan camerashooting.
Flash/Light is turned off with ending
camera. It gets dark suddenly and
accidents may be caused.
Do not inhale or put the crystalline
liquid leaking from the broken display
in your mouth or on your skin.
If the liquid getsinto your eyesor
mouth, rinse with clean water and see
adoctor immediately.
If the liquid adheresto skin or cloth,
use alcohol etc. to wipe off and wash
with soap.
It may cause loss of eyesight or skin
problems.
Be careful not to catch your fingersor
astrap in the terminal when opening/
closing FOMA terminal.
Accident such as injury or damage
may result.
■Confirm the battery type to match according to the description
on the battery pack label.
Do not connect awire or other metal
materialsto the battery pack
terminals. Do not carry or keep the
battery pack together with anecklace
or other metal materials.
It may cause the battery pack to leak,
heat, damage or ignite.
If the battery fluid contactsyour eye,
do not rub but flush your eye with
clean water and see adoctor
immediately.
Battery fluid in the eyes may cause
blindness.
HandlingFOMA terminal (continued)
CAUTION
Description Battery type
Li-ion Lithium ion battery
Handlingbattery pack
DANGER

17
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Do not bring the battery pack into fire.
It may cause the battery pack to leak,
heat, damage or ignite.
Do not nail, hit with ahammer or step
on the battery pack.
It may cause the battery pack to leak,
heat, damage or ignite.
Do not force to attach the battery pack
on FOMA terminal or the battery pack
charger. Alwaysconnect the battery
pack after confirming the direction to
attach.
It may cause the battery pack to leak,
heat, damage or ignite.
If the battery pack leaksliquid or gives
off astrange smell, stop using and
move the battery pack away from
flame immediately.
The liquid from leaking battery fluid may
ignite or explode.
If the battery pack isnot fully charged
after the specified time, stop charging
it.
It may cause the battery pack to leak,
heat, damage or ignite.
If the battery fluid contactsyour skin or
clothes, flush the contacted area
thoroughly with clean water
immediately.
The fluid may damage your skin.
Do not discard used battery packs
together with other garbage.
It may cause ignition or environmental
destruction. Bring used battery pack to
DoCoMo shops etc. with the terminals
taped for insulation, or follow the
instruction of the municipality collecting
used battery.
DANGER
Handlingbattery pack (continued)
WARNING
CAUTION

18
Precautions(ALWAYSFOLLOW THESE DIRECTIONS)
Quick search/
Contents/Precautions
Alwaysuse DC adapter in anegative-
ground vehicle. Never use it in a
positive-ground vehicle.
Fire may result.
Do not touch the cord or outletsof the
adapter (including battery charger)
with wet hands.
Electric shock may result.
Do not short out with the charging
terminalsconnected to an output or a
cigarette lighter socket.
Also, do not touch the charging
terminalswith apart of your body such
as ahand or afinger.
Fire, malfunction, electric shock, or
injuries may result.
Only use with the specified power
source and voltage.
Fire or malfunction may result if using
with different voltage. When using
FOMA terminal overseas, use FOMA AC
adapter 01 for global use.
AC adapter:
AC100V (Connect to 100V AC outlet for
internal household use only)
FOMA AC adapter for global use:
Between AC100V and 240V (Connect to
AC outlet for household use)
DC adapter:
12V or 24V DC (specific for negative-
ground vehicle)
Do not touch FOMA terminal or
adapter (including charger), if you
hear thunder while using.
The terminal may be subject to lightning
strike and could cause electric shock.
If the DC adapter/In-car adapter fuse
blows, be sure to replace with the
specified fuse.
Applying wrong fuse may cause fire or
terminal malfunction. For the specified
fuse, refer to each manual of the
terminal.
Do not use AC adapter and desktop
holder in abathroom or other highly
humid area.
Electric shock may result.
Remove the plug out of outlet or
cigarette lighter socket, if water or
other liquid get into the adapter.
Electric shock, smoke or fire may result.
When youconnect AC adapter to an
outlet, be careful of contactswith
metal materialssuch as metal straps,
and insert firmly.
It may cause electric shock, short-circuit
or fire.
Do not use the adapter (including
battery charger) cord or power cord if
it getsdamaged.
Electric shock, heat or fire may result.
Wipe off any dust around the plug.
Fire may result.
WARNING
Handlingadapters(includingbattery charger)
