Force USA F-MR-BASE-SPACESAVER-V2 User manual

F-MR-BASE-SPACESAVER-V 2

IMPORTANT ASSEMBLY INFORMATION
NOTE: It is strongly recommended that this equipment is assembled by two or more
people to avoid possible injury.
FASTENING NUTS AND BOLTS
Only tighten all nuts and bolts after all components have been fully assembled.
Do not over tighten any component with pivoting function.
Make sure all pivoting components are able to move freely.
Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing
materials until you complete all assembly steps.
PLEASE NOTE: Descriptions of pieces as LEFT and RIGHT are from the point of view of standing
behind the equipment facing towards the front.
Highly recommended for two or more people to assemble the equipment
Assemble equipment on a flat surface
Consider placing a mat under equipment to protect your floor
Only tighten nuts and bolts by hand until whole equipment is assembled
Ensure all parts are in working order prior to use
Do not use equipment outdoors or around water
Keep hair, fingers and clothing away from moving parts
Only use attachments recommended by the manufacturer
Never operate if parts are not functioning correctly
Always stretch prior to using equipment
Stop immediately if you experience any pain, dizziness or nausea.
Before starting any exercise program consult your doctor
SAFETY PRECAUTIONS
1

ASSEMBLY MANUAL
BEFORE YOU START
Read all instructions in this manual before assembling or using this equipment.
Remove all parts from the packaging and separate and count each various component to ensure
everything has been correctly provided.
Follow the instructions and consult both the individual assembly pages and the overall expanded
views of the equipment.
It is the owner’s responsibility to ensure that all users of this unit have read the owner’s manual and
are familiar with the safety precautions.
We recommended you keep these instructions.
FORCE USA TRAINING APP
The Force USA Training App Offers Programs, Tutorials, Progress Tracking and More.
DOWNLOAD NOW
Not compatible with all Force USA equipment.
2

TABLE OF CONTENTS

3
NOTE: SOME PARTS MAY COME PRE ASSEMBLED, IN WHICH CASE CONTINUE ONTO THE
NEXT REQUIRED STEP OF ASSEMBLY
PARTS LIST

4
0 1 6 7 8 9 10 11 12 13 14 152 3 4 5 cm
PARTS LIST
MEASURING FOR BOTH LENGTH

5
NO.DESCRIPTION PICTURE QTY
1Back Left Stand Tube
Assembly 1
2Back Link Short Tube
Weldment Left
1
3Back Link Short Tube
Weldment Right 1
4Back Right Stand Tube
Assembly 1
5Back Link Tube Welding 1
10 Back Upper Link Tube
Assembly 1
12 Upper Link Tube Left
Assembly
1
13 Down Link Tube Left
Assembly
1
14 Down Link Tube Right
Assembly
1

6
NO. DESCRIPTION PICTURE QTY
15 Upper Link Tube Right
Assembly 1
16 φ12×160-M100
uter Wire Shaft 2
17 Decorative Aluminium Cover 2
22 Front Stand Pillar
Assembly 2
23
φ12.8×220-
M100 uter Wire
Shaft
1
24 Chin Up Bracket
Assembly 1
27 Ground Feet Assembly 2
28 φ22×φ18×φ12×1 3
Interval Cover 8
29 Down Fixing Plate 4

7
NO. DESCRIPTION PICTURE QTY
30 φ12x75-M8 Inner
Wire Shaft 4
31 Ground Foot Spring 2

8
1
2
9
69
6
6
7
8
6
86
6
8 5
4
68
9
63
6
9
8
6
8
6
67
ASSEMBLY STEP 1

9
1.Connect Back Link Short Tube Weldment Le�-2 and Back Le� Stand Tube
Assembly-1 use Hexagon Head Bolt-7, Flat Washer-6 and Lock Nut-8.
2.Connect Back Link Short Tube Weldment Right-3 and Back Right Stand Tube
Assembly-4 use Hexagon Head Bolt-7, Flat Washer-6 and Lock Nut-8.
3.Connect Right and Le� Back Link Short Tube with Back Link Tube Weldment
use Hexagon Head Bolt-9, Flat Washer-6 and Lock Nut-8.

10
（4）Back Right Stand Tube Assembly 1 pc/ Machine
36
35
37
39
39
38

11
（1）Back Left Stand Tube Assembly 1 pc/ Machine
36
38
39
39
37
35

12
11 6
68
10
86
6 11
ASSEMBLY STEP 2

13
Fix Back Upper Link Tube Assembly-10 on main frame use Hexagon Head
Bolt-11, Flat Washer-6 and Lock Nut-8.

14
41
42
43
43
43
43
43
43
（10）Back Upper Link Tube Assembly 1 pc/ Machine

15
19 18
16
15
18
19
21
20 17
14
19
18
16
19
18
12
13
17
20
21
ASSEMBLY STEP 3

16
1. Fix Upper Link Tube Le Assembly-12 on main frame, use Outer Wire Sha-16, Flat
Washer-18 and Lock Nut-19.
2. Fix Upper Link Tube Right Assembly-15 on main frame, use Outer Wire Sha-16, Flat
Washer-18 and Lock Nut-19.
3. Fix Down Link Tube Le Assembly-13 on main frame, use Decorave Aluminium
Cover-17, Spring Gasket-20 and Inner Hexagon Flat Round Head Screw-21.

17
45
39
4639
36
（15)Upper Link Tube Right Assembly 1 pc/ Machine

18
39
36
39
37
44
（12）Upper Link Tube Left Assembly 1 pc/ Machine
