Forest garden Overlap Apex User manual

Overlap Apex Shed
4' x 3''
Important :
Assembly of this
shed requires a
minimum of two
adults.
Issue 0215
B
ODA4PE
PLAIN END
8987658
ROOF SHEET
QTY 2
E
A
ODA43 PARTS LIST
11658668
FLOOR SHEET
QTY 1
SDRDT
DOOR
ODA4DE
DOOR END
20121695PDT
20 x 1695mm STRIP QTY 1
H
K
H
45280866
866mm BATTEN QTY 1
F
Place the corner strips so that they cover the joins
between the panels. Fix each in place using 3 x 30mm
screws
A
2
4
11
C
ODA3PS
PLAIN SIDE
QTY 2
J
3
REQUIRED TOOLS :
(NOT SUPPLIED)
POZI DRIVE SCREWDRIVER
SPIRIT LEVEL
TAPE MEASURE HAMMER
51120810PAII58DT
810mm BARGE BOARD QTY 4
I
A
Must Pre drill for
each screw used.
28280898
898mm BATTEN QTY 2
J
FELT
85062 Qty 1
C
Place the panels on top of the floor. Make sure that all of the panels are tight and flush before
fixing them to each other using 3x50mm screws.
Make sure that the panels are sitting flush before fixing to the floor. Use 2 x 50mm screws for
each panel. Make sure that all of the screws are positioned so that they screw in to the bearers
underneath.
Fixing Pack (OPA43FP)
This fixing pack is used for several products.
There may be additional fixings.
Not to Scale
Flush Hinge
Qty 2
50mm Screw Qty 22
30mm Nail Qty 36
25mm Screw Qty 17
Hasp &
Staple
30mm Screw Qty 17
10mm Felt tacks
Qty 60
GFIN20010512DTR
FINIAL
QTY 1
L
A
Fix the 20 x 1695mm strip
to the side of the door
frame so that it is tight with
the cladding and flush with
the frame. Use 3 x 30mm
screws.
L
SHARP KNIFE
D
AB
a
E
40mm Screw Qty 12
44161570DT
1570mm C/STRIP QTY 4
HM
28280866PT
28x28x866mm GREEN BEARER QTY 4
Place the floor sheet (larger) over the top of two of the 866mm green battens. Make sure that the
sheet is flush on all sides with the battens before fixing each in place using 4 x 30mm nails.
Position the two remaining battens underneath so that there is a 351mm between each bearer.
351mm 351mm
M
D
Place the hinge against the inside of the door frame and position the large section
of the hinge so that it is flush with the inside of the framing as shown. Fix with
25mm screws.
Open the hinge and fix the smaller section to the door framing. Again make sure
that the hinge is flush and that the holes are positioned so that the 25mm screws
locate correctly into the batten.
b
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
This building is pre-treated with a factory base coat for
protection during storage and transit. We recommend that
you treat your new building as soon as possible after
assembly using a wood preservative treatment. Apply in
accordance with the manufacturers instructions.
- This product must be built on a solid level base.
- The roof of this building is not a load bearing structure.
- Timber is a natural material. It will shrink and swell as a
result of varying moisture content.
- Due to the nature of the material the doors may need some
trimming for a neater fit.
- Please keep all plastic bags and small parts away from
children
Technical Helpline: 0333 7777 089 8.30 am and 5.00
pm Monday to Friday.
Please check all parts prior to assembly
Assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled
to.
If the product is not constructed in accordance with the
instructions, or is altered in any way (e.g. painted), the
manufacturer cannot be held liable for any resulting damage.

6
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products to give protection against wood destroying insects & wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)), Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off-cuts responsibly – do not burn.
7
Lift the roof sections into place making sure that they are in line with the apex and
the door and plain ends.
Fix the roof in place using 30mm nails spaced at approximately 300mm intervals.
(Make sure the nails locate into the framework of the panels)
Place the barge boards against the front and back of the
shed. Make sure that these are in line with the roof sheet
and meet at the apex. Fix each in place using 3 x 40mm
screws.
Place the finial over the top of where the barge boards
meet and fix it in place using 2 x 30mm screws.
Unroll the felt and cut it into two equal lengths. Place the sheets
on each side so that there is a 50mm overhang on the eaves
and they overlap at the apex. Fix these to the roof using felt
nails spaced at 150mm intervals. Cut and fold the corners
securing with a single felt nail for each.
8
5
I
9
Before fixing the Hasp to the door make sure that it is in line with the framing
on the reverse of the door and that it closes over the Staple. Fix this in place
using 3 x 25mm screws.
Position the Staple opposite, again making sure that it is in line with the
framing behind and fix it in place using 2 x 25mm screws.
Place the roof board on to one of the 898mm battens. Make sure that the
board is flush on all sides.
Fix each batten in place using 30mm nails spaced in 300mm intervals.
(Repeat for the other roof section)
JF
G
Attention
Take care when
cutting and
trimming the roof
felt.
Maintenance.
We recommend that you treat your shed at the beginning of each season with wood preservative treatment. Apply in
accordance with the manufacturers instructions.
Regularly check (1) All fixings are secure (2) Roofing felt is free of holes and tears (3) Sand off any rough/sharp edges.
H
Place the 866mm batten so that it connects the door end and plain end.
Fix this in position using a 50mm screw for each end as shown.
4
K
