Fracarro FRPRO EVO HD User manual

PROGRAMMABLE CLUSTER HEADEND
FRPRO EVO HD
OPERATING INSTRUCTIONS
It is possible to download the FRPRO EVO HD manual on the relative product’s page on www.fracarro.com web site
PRODUCT DESCRIPTION
The Fracarro FRPRO EVO HD is an high selective programmable compact headend for filter, convert and amplify the
VHF/ HF Digital Terrestrial channels as well as mix the FM signal. The headend is a complete Digital Channel Processor
that can be used on small, medium or high installation plants as well as in hospitality environments.
Can process and convert more than 50 independent RF channels with very high selectivity on adjacent multiplexes.
AGC automatic gain control circuit on all individual VHF and HF input multiplexes.
Isofrequency or converted channel filtering for every multiplex coming from VHF or HF input.
Security code available to avoid incidental settings.
5 independent inputs: 1 FM input and 4 VHF/ HF flexible inputs; with selectable 12-24V remote power on VHF and
HF inputs.
SD slot to save or copy a configuration to another headend.

2
PRODUCT INSTALLATION
Connect the device to the grounding electrode of the antenna system and fix the FRPRO EVO HD in vertical position
to guarantee the correct ventilation and heat dissipation.
Connect the power cord to the power supply socket and check the
STATUS
LED for DC power presence.
Connect FM, VHF and HF aerial’s coaxial cables to the FRPRO EVO HD headend.
Connect the RF output coaxial cable to the RF coaxial distribution network.
If necessary, connect a field meter to the -30dB test port to check the signal quality.
Configure the device using the three settings buttons available on the top of the FRPRO EVO HD headend; press the
confirm
button for two seconds to access to the main menu and use the
left/ own
or
right/up
arrows to scroll the
sub-menu; otherwise the configuration could be imported from another headend, using SD card.
If necessary, the power adapter can easily be replaced, without unmount the product, by open the top left plastic cover;
please refer to the Safety Warnings chapter before proceed.
FACTORY SETUP: before starting the configuration, it is advised to set the correct VHF and HF frequency plan.
Power off the device,
Push the
confirm
button and keep it pushing while you turn-on the FRPRO EVOT HD.
Release the button when
RESET FINISHED
message is shown on display.
To activate the correct frequency plan, select the
REGION
where the headend is situated and save with the
confirm
button; Europe (
EU
) is the default setting.
HEADEND CONFIGURATION
Power up the FRPRO EVO HD by using the 220V power cord included in the package; the headend will need
approximately 5 seconds to initialize itself; the configuration can be performed by using the three settings buttons
and the display available on the top front.
Press the
confirm
button for two seconds to access the different menus or for confirm the selection; scroll all the
menu by using
left/ own
or
right/up
arrows for move through the different settings.
INPUT CONFIGURATION
Select
INPUT FM
to setup the desired FM input signal gain.
Select
INPUT V/U 1 … 4
to enter on VHF/ HF input settings; the first channel defines if the port will works on VHF or
HF band.
If the input level is too low, it is possible to activate a pre amplification by turning
ON
the
PRE-AMPLI.
Set
12V
or
24V
on
DC
if it is necessary to insert the power supply to feed the external mast amplifiers; 100mA is the
total available current for all VHF/ HF inputs; on advanced settings it is possible to set 12V or 24V.
Select
ADD CHANNEL
to add the RF channel on the list of the managed filtered multiplexers by the relative input; to
delete the unwanted RF channel, move on the position of the channel by using
left/ own
or
right/up
arrows
buttons and press the
confirm
button for 3 seconds until
CHANNEL DELETED
message is shown on the display. p
to 6 channels can be added and converted at once; first select the channels you want to add, then you can convert
them. For example:
oTo add CH5 and convert to CH6, select as follows: 5: 5 -> 6: 6
oTo add CH21-22-23 and convert to CH31-32-33, select as follows: 21:23 -> 31:33
The value dBµV in the bottom right corner indicates the incoming level of the channel.
For E , Italy and New Zealand region, Channel 13 (230-240MHz) can be used for DAB; CH13 cannot be converted.

3
OUTPUT CONFIGURATION
By selecting
OUTPUT
and
LEVEL
menu it is possible to define the total RF output level from 98dBµV to 118dBµV
depending on the total multiplexes amount managed by the headend;
108 BµV
is the default level.
By selecting
SLOPE
it is possible to compensate cable losses by setting the slope from 0dB to -15dB, between the
VHF and latest HF channel,
0 B
is the default value.
By selecting
VHF ATTN
: it is possible to further compensate cable losses by decreasing VHF and DAB output level
from 0dB to 15dB (comparing to HF level)
0 B
is the default value.
ADVANCED SETTINGS: select
ADVANCED
menu to:
LANG
: set the language (English, Italian, French or Spanish).
REGION
: read the channel plan configured on factory setup procedure.
DC VOLTAGE:
set 12V or 24V remote power available on VHF and HF inputs.
BW:
the filter bandwidth can be changed from -2000 kHz to 0 KHz in steps of 250 KHz; this allows you to optimize
the bandwidth of your filter; the default setting is
-1000 kHz
.
FW VERSION
and
SERIAL NUMBER
: to read firmware version and product serial number.
LOAD SD
and
SAVE SD:
to import or export a configuration using an external SD card
Select
EXIT
menu to exit and protect the headend, if it is necessary, setting a lock code with
LOCK
menu.
SW version and product updates could modify this menu structure.
TECHNICAL SPECIFICATIONS
Fracarro code 287434
Inputs
Input number 5 (FM, 4 flexible VHF/ HF)
Bandwidth MHz FM: 88-108; VHF: 174-240; HF: 470-862
AGC range dBµV FM: 37-77; VHF: 40-109; HF: 40-109
LTE filtering MHz Automatic selection: 694, 790 or disabled
Outputs
Output number 1, Test (-30dB)
Maximum level dBµV FM: 113 (60dB/IM3); VHF/ HF 118 (per 30 transp.)
Level adjustment dB 20
Gain (Adjustment) dB FM: 35 (20); VHF: >75 (auto AGC); HF: >75 (auto AGC)
Slope adjustment/FM+DAB atten. dB 15
Selectivity dB@1MHz 50
Typical MER dB VHF: 35; HF: 35
General characteristics
Mains voltage V, Hz 100-240, 50/60
Consumption W 15
Remote power V, mA 12 or 24, 100 total (for 4 VHF/ HF inputs)
Dimensions (l x h x w) mm 217 x 165 x 59
Operating temperature °C -5 to 50
Weight Kg 0,8
The technical data are nominal values and refer to an operating temperature of 25° C, they may vary without notice.

4
SAFETY WARNINGS
The product must only be installed by qualified persons, according to the local safety standards and regulations. Fracarro Radioindustrie is free
from all civil and criminal responsibilities due to breaches of the current legislation derived from the improper use of the product by the installer,
user or third parties. The product must be used in full compliance with the instructions given in this manual in order to protect the operator
against all possible injuries and the product from being damaged. Don’t open the product case: components under dangerous
voltage may be accessible when the case is opened.
Installation warnings
The product must not be exposed to any dripping or splashing and thus it should be installed indoors and in a dry location.
Humidity and condensation could damage the product. In case of condensation, wait until the product is dry before using it.
Handle the product carefully. Impacts can damage the product.
Leave enough space around the product to ensure sufficient ventilation.
Excessive temperatures and/or an overheating may affect the performance and the life of the product.
Don’t install the product above or near any heat sources, in dusty places or where it might come into contact with corrosive substances..
In the event that the unit is fixed to the wall, use the proper screw anchors suitable to the characteristics of the fixing support. The wall and
the anchoring system must be able to support at least 4 times the weight of the unit.
Warning: to avoid injury, this appliance must be secured to the wall depending on the installation instructions. For "PERMANENTLY INSTALLED
APPLIANCES", an easily accessible cutting device must be added to the exterior of the appliance; for "APPLIANCES WITH A POWER PL G", the
socket must be installed close to the appliance and easily accessible. The product must be connected to the grounding electrode of the antenna
system in compliance with standard EN 60728-11. The screw provided for this purpose is marked with the symbol
It is recommended to comply with the provisions of the standard EN60728-11 and to connect this screw to the main earth node of the plant (do
not connect to intermediate points).
•
Earth screw symbol
Class II symbol
General warnings: In the event of a malfunctioning, do not try to fix the product as the guarantee would be invalidated. Only use the power
supply supplied with the product. Although the information given in this manual has been prepared carefully and thoughtfully, Fracarro
Radioindustrie S.r.l. reserves the right to modify it without notice and to improve and/or modify the product described in this manual. See the
website www.fracarro.com to have information relevant to the technical support and product guarantee.
The recycling of materials will help to conserve natural resources.
CONFORMITY TO EUROPEAN LAWS
Fracarro declares that the product complies with E Directive 2014/53 and 2011/65/ E. The full text of the E Declaration of Conformity is
available on the following website ce.fracarro.com.
USER’S INFORMATION
Disposal of Ol Electrical & Electronic Equipment
Applicable in the European Union an other European countries with separate collection system
This symbol on the product or on its packaging indicates that this product shall not b
e treated as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, wh
ich could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this
product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
Guaranteed by Fracarro Radioindustrie SRL Via Cazzaro n. 3, 31033 Castelfranco Veneto (Tv) – Italy
Fracarro Ra ioin ustrie SRL: Via Cazzaro n.3 - 31033 Castelfranco Veneto (TV) - ITALIA - Tel: +39 0423 7361 - Fax: +39 0423 736220
Fracarro France S.A.S.: 7/14 rue du Fossé Blanc Bâtiment C1 - 92622 Gennevilliers Cedex - FRANCE Tel: +33 1 47283400 - Fax: +33 1 47283421
Fracarro (UK) – Lt : nit A, Ibex House, Keller Close, Kiln Farm, Milton Keynes MK11 3LL K - Tel: +44(0)1908 571571 - Fax: +44(0)1908 571570
www.fracarro.com - [email protected] - [email protected] - chat whatsapp +39 335 7762667
FRPRO EVO HD-EN
27-11-2019 - rev.2
