Franke SD5200 User manual

MAINTENANCE
1. With normal use, maintenance should not be necessary.
Should there be an extended period where the dispenser
isn’t used, it is possible the soap/lotion could harden
and clog the dispenser. In this event, submerge the entire
dispensing head with pump into hot water for several
minutes. Next pump hot water through the assembly.
Repeat as necessary to remove the clog.
2. To clean the dispenser, use a soft cloth or sponge with
soap and water only. Do not use any abrasive cleaners or
pads.
Dry with a cloth or paper towel.
3. Replacement Parts
1 - SD5201 - Pump
2 - SD5202 - Bottle
3 - SD5203 - Fill Tube
PRODUCT WARRANTY
Congratulations on the purchase of this Franke product!
Franke is one of the world’s largest manufacturers of
kitchen systems. Our products are manufactured using
the highest degree of technology, quality, and design.
As a result, we are proud to offer the following warranty.
Franke warrants the quality of its soap/lotion dispensers
to be free from manufacturing defects for a period of five
years from the date of purchase.
This warranty applies only to the original owner, providing
the product has been installed in accordance with these
installation instructions, used as recommended, and in
normal residential application. In the event of a warranty
claim, the owner will be required to provide proof of
purchase - SAVE ORIGINAL SALES RECEIPT!
This warranty covers all components which make the
product operational. Franke reserves the right to inspect
the installation prior to the replacement of the product or
component part.
This warranty does not cover misuse or abuse, accidental
damage, scuffs, or scratches, abnormal usage, negligence
or damage caused by improper maintenance or cleaning.
Normal wear of parts is excluded from the warranty.
Damage caused by impurities or acts beyond Franke’s
control are not covered. Any product or part which has
been repaired or altered in any manner outside of Franke’s
factory, unless previously authorized in writing by Franke,
will void the warranty.
Any replacement excludes transportation and any labor
reinstallation costs. This warranty doesn’t allow recovery
of incidental or consequential damages such as loss of
use, delay, property damage, or other consequential
damage, and Franke accepts no liability for such damages
The Franke warranty is limited to the above conditions and
to the warranty period specified herein and is exclusive.
Franke DISCLAIMS all other warranties, expressed or
implied, including the IMPLIED WARRANTIES OF
MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR
PURPOSE. This warranty gives you specific legal rights
which may vary from state to state.
Further Information
For any further information about Franke products, about
the installation of them, or about the guarantee, please
contact our Customer Service Department:
Franke Kitchen Systems, LLC
800 Aviation Parkway
Smyrna, TN 37167
Phone: [phone]
Fax: [phone]
www.franke.us/ks
INSTALLATION GUIDE
Soap dispenser SD5200, SD5220 SD5270&SD5280
1
2
3

INSTALLATIONS INSTRUCTIONS
NOTE:
Contact us immediatly if you see inconsistencies.
Phone: [phone])
website: www.franke.us/ks
email: [e-mail]
CONTENTS IN BOX
INSTALLATIONS INSTRUCTIONS
Remove all contents from package and check for
completeness.
Cut a 1-1/8” hole in the desired position in the
mounting surface if one isn’t available
Connect fill tube (3) to pump (2) in dispensing
head (1) as shown in Figure 1 and sit aside
Unscrew connecting sleeve (6) from base
assembly shank (4) and remove mounting nut (5)
Insert base assembly (4) into the hole as shown
Figure 2
Screw mounting nut (5) and connecting sleeve (6)
onto base assembly shank (4)
Screw bottle into connecting sleeve (6) as show in
Figure 3
Fill bottle from top with soap or lotion
Insert dispensing head (1) with fill tube (2) into the
base assembly (4) as shown in Figure 4
Pump dispensing head several times until soap/lotion
is discharged
1 - Dispensing Head
2 - Pump
3 - Fill Tube
4 - Base assembly
(includes washer and shank)
5 - Mounting Nut
6 - Connecting sleeve
7 - Bottle
1.
2.
3.
4.
5.
6.
7.
8.
Tip: to minimize clogging, fill bottle 1/3 with water
and 2/3 soap and mix well using fill tube.
9.
10.
1
3
5
6
7
2
4
INSTALLATION INSTRUCTIONS
Remove all contents from the package and check for completeness.
1
NOTE:
Call immediately if you see inconsistencies.
(1-800-626-5771)
or visit
www.frankeksd.com
[e-mail]
Package Contents:
1 - Fill Tube
2 - Dispensing Head
(Pre assembled with pump)
3 - Mounting Washer (Rubber)
4 - Base Flange
5 - Mounting Nut
6 - Bottle
Installation Tools:
None
1
2
3
5
6
4
1
FIG. 1
FIG. 2
FIG. 3
FIG. 4
