Franke ANMX Series Manual

EN
COD: 5561499
REV:1 10-2016
ANMX 308
ANMX 309
ANMX 311
ANMX 312
Installation, use and maintenance handbook
ANMX

2
CONFORMANCE
STATEMENT
This appliance has been manufac-
tured with suitable materials for use
with drinking water.
The device conform to L.D. 108
dated 25.01.1992. (87/308/CEE)
and has been approved by the
WRAS (WATER REGULATION AD-
VISORY SCHEME) .
This product has been designed,
manufactured and placed on the
market complying with the following
EC conformities:
• Safety objectives of the “Low Volt-
age” of Directive 2014/35/UE (Ex
2006/95/EEC).
• Protection requirements of Direc-
tive, 2014/30/UE (Ex 2004/108/
EEC) .
1 Model
2 Supply voltage
3 Quantity of cooling gas
4 Class
5 Total absorption
6 Frequency
7 Serial number
8 Construction year-month
APPLIANCE DATA PLATE
1 BEFORE USING THE APPLIANCE
1.1 WARNINGS
In order to use your appliance to its best, we advise reading
these instructions carefully as they contain useful information.
• Keep this book for later use.
• When you have removed the packaging, make sure that the appliance
is not damaged. Any damage must be reported to your carrier within
24 hours.
If the machine has been put down or turned upside down,
wait for at least 8 hours before putting it into operation.
• Make sure that installation and electrical wiring are carried out
byaqualiedtechnicianaccordingtothemanufacturer’sinstruc-
tions and to the local norms in force. The electrical system must
be equipped with an effective earth according to the law (46/90).
1.2 GENERAL PRECAUTIONS AND SUGGESTIONS
Before carrying out any maintenance or cleaning
operation, remove the plug from the mains socket.
• Do not pull on the supply cable in order to remove the plug from the socket.
• When the appliance has been installed, make sure it is not resting on
the mains supply cable.
The data and characteristics indicated in this manual do
not bind the manufacturer, who reserves the right to
make all the modications deemed necessary, without
having to give prior notice or replacement.
EN
Failure to comply with any of these safety regulations
could cause res, electric shocks or damage the machine.
PLACE OF INSTALLATION
• This appliance is designed for household and similar uses such as :
- Kitchenareasofpersonnelinshops,ofcesandotherworkingenvironments;
- Rural houses and hotel customers, motels and other residential type environments;
- Areas like bed & breakfast and guest houses;
- Food services and use at similar retailers.
• Do not place the machine near inammable solvents such as alcohol
or diluents.
• Do not install the machine in excessively damp and dusty places, ex-
posed to direct sunlight, outdoors or near to heat sources. Machine in-
stallationintheseplacescouldcauseresorelectricshocks.
• The appliance is not suitable for use in open places.
• During connection of the appliance to the mains water supply, all pre-existing
tubes, gaskets and joints placed between the appliance and the water mains
connection must be replaced with new material to avoid contamination.
• No obstructions the ventilation openings.
ELECTRIC POWER SUPPLY
• Do not connect or disconnect the machine from the socket with wet hands .
• Inserttheplugintothewallsocketrmly.
• Do not damage, modify, stretch, bend or twist the power cable.
• Do not place heavy objects on the power cable.
• Do not connect the machine to a socket to which other equipment is con-
nected (extensions, 2 or 3 plug adaptors, etc.).
• Do not use the machine if the power cable is tied or knotted.
• If smoke, unusual smells or strange noises are found coming from the
machine, disconnect it immediately from the socket and contact the lo-
cal retailer or technical service assistance. Use of the machine in these
conditionscouldcauseresorelectricshocks.
• Periodically disconnect the machine from the socket and clean the plug
and socket with a dry cloth. If the machine is connected in a place ex-
posed to dust, smoke or high humidity, the dust accumulated on the plug
willabsorbhumidityandthiscouldaftertheinsulationandtriggerare.
• D onotspraywateronthedevice;thiscouldcauseelectricshocksorres .
• The appliance must not be installed where water jets can be generated.
• Use a damp cloth to clean the machine. Do notuseinammablesol-
vents such as alcohol, benzene or diluents. Ifinammablesubstances
come in contact with the electrical components inside the machine, they
cancauseresorelectricshocks.
• Before cleaning the machine, switch it off and disconnect it from the
socket. Not being switched off or accidental switching on during cleaning
could cause injuries to persons or damages to the machine.
• The device can be used by children under the age of 8 and by people with re-
duced physical, sensory or mental capabilities, or lack of experience or knowl-
edge, provided under supervision or after the same have been instructed on the
use ensure safe and understanding of the dangers inherent in it. Children should
not play with the appliance. Cleaning and maintenance meant to be performed
by the user must not be performed by unsupervised children
5
4
2
1
3
6
7 8

3
2 REMOVAL OF PACKAGING
Product
This appliance is marked according to the European directive 2012/19/
UE on Waste Electrical and Electronic Equipment (WEEE). By ensuring
this product is disposed of correctly, you will help prevent potential nega-
tive consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the
product, indicates that this appliance may not be treated as house-
hold waste. Instead it shall be handed over to the applicable collec-
tion point for the recycling of electrical and electronic equipment.
D isposal must be carried out in accordance with local environmental regu-
lations for waste disposal. For more detailed information about treatment,
recoveryandrecyclingofthisproduct,pleasecontactyourlocalcityofce,
your household waste disposal service or the shop where you purchased
the product.
EN
• Place the appliance in its installation site (chap. 5 - INSTALLATION).
• Cut straps Rand remove carton C, polystyrene Fand external plastic
bag S.
• Do away with plastic bags Sand polystyrene Fimmediately as they are
a danger for children.
• Once the appliance is free from its packaging, remove the base B.
2.1 ADVICE ON HOW TO PROTECT THE ENVIRONMENT
Packaging
Packaging material is 100% recyclable.
For its disposal follow your local regulations.
The packaging material (plastic bags, polystyrene parts etc.) must be
keptoutofchildren’sreachasitcouldbedangerous.
Information
This appliance does not contain CFCs (the cooling circuit contains a
gas that is not harmful to the ozone layer).
For further details, please refer to the serial data plate on the appliance.
C
R
R
B
F
S
1

4
2 43
5
3 DESCRIPTION OF THE APPLIANCE
These water coolers were designed to offer maximum hygiene and easy maintenance.
They are sturdy and have a high level of performance.
The direct cooling system (made from non-oxidising steel aisi 316L) guarantees an
optimalhygieneforfactories,ofces,communitiesandpublicplaces.
Themachinemustbeconnectedtoasourceofpotablewaterandttedwithspe-
ciallteringkits.
The machine must be installed in a room where the environmental conditions are
asspeciedinthechapter“TECHNICALCHARACTERISTICS”.
1 G61 valve (ANMX 309 & 312)
2 G62 valve
3 Door closure
4 Door
5 Water lter
6 Water inlet ø8 mm
7 Power connection
8 Water outlet
9 Temperature control Thermostat
10 Bracket for Wall
EN
ANMX ANMX 308 - 309
308 - 309 311 - 312
1
9
5
3
4
2
8
67
8
67
5
9
10

5
4 TECHNICAL CHARACTERISTICSEN
ROOM TEMPERATURE:
Min 10°C
Max 45°C
Dimensions
ANMX RANGE
ANMX 308 - 309 ANMX 311 - 312
Water production
Lt/h
usg
25
6,6
25
6,6
Water outlet temperature
°C
°F
8 ÷ 12
46 ÷ 53
8 ÷ 12
46 ÷ 53
Compressor HP 1/6 1/6
Rated input Watt 190 190
Packing dimensions mm 40x42x106
(V. 0,18)
51x44,5x67
(V. 0,18)
Net weight
kg
Ibs
29
63,9
26
57,3
Gross weight
kg
Ibs
31
68,3
27
59,5
Charge
FREON
R134A
g
oz
100
3,5
100
3,5
4.1 CONDITIONS OF THE SURROUNDINGS
ANMX 308 - 309
ANMX 311 - 312
6

6
HANDBOOK SECTION II
Reserved to qualied operators

7
Reservedtoqualiedoperators
Attention:
To carry out this or any other maintenance operation requiring the machine casing to be opened, use protective gloves to avoid
being cut by the sharp edges of the sheet steel.
5 INSTALLATION
5.2 ANMX 311 - 312
Unscrew the rear panel in order to get the get the power cord and pipes ( Fig.
6.3). Eventually replace the rear panel.
ThewallxingofANMX311-312(Fig.6.8)requiresthefollowingsteps:
• Applyasiliconlmontherearsideofthecooler(Fig.6.4).
• Intheinstallationkitthere’sametalbracketandfourscrews(Fig.6.5).Ifthe
wall is in particular material (wood, plaster), property screws are required.
Look for them in a dedicated shop.
• Apply the bracket to the wall (Fig. 6.6).
• Positioning the cooler to the wall, keep the bracket in contact with the open-
ing Aon the rear side of the cooler (Fig. 6.7).
EN
Place the appliance in the desired point of installation, away from heat
sources and protected from direct sunrays.
• Adjust foot 1 to level the appliance correctly and to avoid irritating noises
caused by vibration ( Fig. 7).
The device must not be used outside or in wet environments.
5.1 POSITIONING THE UNIT
• When handling and moving the cooler, use the handle recessed into the
cross support on the back of the unit.
• To ensure proper ventilation, position the cooler at a distance of at least
6-7 cm from the wall.
6.1 6.36.2
6.4
6.6
6.5
6.7 6.8
A

8
Reservedtoqualiedoperators
5 INSTALLATION
5.2 ASSEMBLY AND ADJUSTMENT OF THE FAUCETS
Faucet G61 -Inserttheleverandletitglideonthespecicguidingchannel,
attachthetube,andtightenit.Thewaterowispre-setbythemanufacturer.
If it needs to be adjusted, manipulate ratchet N(Fig. 8), tighten it to increase
theow,loosenittodecreaseit.Onlycarryoutonerevolutionatatime.
Faucet G62 (Fig. 9) - The faucets G62 are always assembled. To regulate
thewaterow,removeferruleGand manipulate screw V. Turning it clock-
wisewilldecreasetheow,anticlockwisemovementwillincreaseit.
Faucet G63 (Fig. 10) - This faucet is being controlled by a pedal, which must
be attached with a trigger device at the predetermined location. The water
owisregulatedbymanipulatingscrewS: turning it clockwise will decrease
theow,anticlockwisemovementwillincreaseit.
5.3 WATER CONNECTION TO THE MAINS
Before making the water connection, make sure the mains water pressure
EN
is between 1 and 3 bars:
• If the mains water pressure exceeds 3 bars, predispose a pressure re-
ducer capable of reducing the latter to the 1-3 range (Fig. 12).
• Connect the appliance to the water mains using the water inlet tting I
(Fig. 11).
ANMX 308 - 309
• The 3/8F connector or the fast coupling provided can be used for the 8
mm diameter pipe.
ANMX 311 - 312
• Connect with an 8 mm pipe.
• Predispose a stop tap Ron the water inlet pipe.
During connection of the appliance to the mains water supply,
all preexisting tubes, gaskets and joints placed between the
appliance and the water mains connection must be replaced
with new material to avoid contamination.
7 8
9 10
11
1
N
V
G
S
R

9
Reservedtoqualiedoperators
Connect the machine to a mains electrical network protected by a circuit breaker with a sensitivity equal to or less than 30 mA.
Warning!
If the power cable is damaged, it must be replaced by the manufacturer, by an authorized technical assistance provider or else by an
individual with similar qualications, in order to prevent any risks.
5 INSTALLATION
• This water dispenser can be equipped with a WATER BLOCK anti-
oodingdevice(optional)topreventanyaccidentalwaterleaks(Fig.13).
OncetheWATERBLOCKdevicehasintervened,ttingKshould be dis-
assembled and button Ppressed to reset the device.
• If instead of being connected directly to the aqueduct the machine is con-
nected to an autoclave pump, then it is necessary to install above the wa-
ter supply an ANTISHOCK device to prevent “water hammers” (Fig. 14).
5.4 DRAIN CONNECTION
The drain water is clean and it comes from the tray that collects any dripping
during dispensing.
Connect the drain pipe ( ext. ø24mm) to a drain with a drain-trap.
Ifnecessary,cutthepipesoastoavoidconstrictionsorbackowproblems.
EN
5.5 HYGIENIC CLEANING
• Once you have checked that the appliance operates correctly, proceed
with the “internal cleaning and hygienic cleaning” phase as described in
chap. 6.
5.6 ELECTRICITY CONNECTION
Connection to the mains electricity supply is carried out by connecting the
plug to a mains socket.
Thesupplysocketmustbeequippedwithanefcientearthplateanditmust
be sized for the load of the appliance (see technical characteristics).
Makesurethatthemainsvoltagecorrespondswithwhatisspeciedonthe
data plate.
Make sure that there is an omnipolar switch above the socket with a minimum
contact break of 3 mm protected by fuses of suitable amperage for the ab-
sorption of the appliance itself (see technical characteristics and data plate).
• Turn the cold water regulator screw F(Fig. 15) (4 to 7 positions are ad-
vised).
12 13
14 15
P
K
F

10
Reservedtoqualiedoperators
6 INTERNAL CLEANING/ HYGIENIC CLEANING
• The operation of higienization/sterilization has to be carried out every
time the refrigerator is installed and:
- every 6 months when it is used (*);
 - everytimethewaterlterischanged;
- after an inoperative period of one or more weeks.
(*)IftherefrigeratorisinstalledinHospitals,Schools,Oldpeople’shomes,
or Clinics, it is recommended to sterilize it every 3 months.
Hygienic cleaning solution preparation:
• Prepare 5 litres of water.
• Add to it 5% of “hydrogen peroxide” at 100 volumes; for the doses, use a
graded measure or an ordinary syringe.
NB: if you use commercial hygienic cleaning solutions, keep to the instruc-
tions provided by the manufacturer and included in the package.
EN
WARNING! Considering that the products used for the hygienic cleaning are acid and alkali corrosive substances, disposable gloves
must be used as well as glasses to protect your eyes. When this hygienic cleaning is carried out, you must keep to the product reaction
times, percentages of hygienic detergent and quantity of water necessary for rinsing.
Warning! If the appliance is equipped with a chlorine lter,
proceed as follows: Remove the lter cartridge and t on the
false cartridge mod. TEST CAN.
• With the help of a pump P, connect the appliance’s water inlet to the
container with the disinfecting solution.
• Start the pump, letting this solution into the appliance and then at the
same time opening the taps so as to let all the hygienic cleaning solution
owoutfromboththedispensingspouts.
• Before the solution runs out, stop the pump and interrupt the dispensing.
• Leave the solution to do its work for minimum 20 minutes.
• Reconnect the appliance to the mains water supply.
• Letatleast15litresofwaterowoutofthetapssoastorinsethehydrau-
lic system suitably, before using the appliance again.
16

11
17.1 17.2 17.3 17.4 17.5
Reservedtoqualiedoperators
7 HOW TO REPLACE THE FILTER CARTRIDGE
Attention!: to carry out this or any other maintenance
operation requiring the machine casing to be opened, use
protective gloves to avoid being cut by sharp edges of the
sheet steel.
The Water lter must be replaced one time per year or at least every six
months, if the water ow decreases.
• Open the Front door
• Put the lever in vertical position to stop the water (Fig. 17.1).
• Turn cartridge slowly, until it stops (Fig. 17.2)
• Pull used cartridge straight down and extract from the cooler (Fig. 17.2
- 17.3).
EN
• There may be a small amount of water during cartridge removal.
• Pushthenewcartridgeintolterheadandturnuntilitstops(Fig.17.4).
• Turn the lever in horizontal position and check if there’re water leaks
(Fig. 17.5).
• Flush the new cartridge for two minutes expelling any trapped air and
carbonnes.Watermayruncloudywithairbutwillquicklyclear.
This work, is reserved to a qualied operator.

12
Reservedtoqualiedoperators
8 FAULTS AND REMEDIESEN
Warning! The operations should be carried out by a qualied professional.
8.1 DIAGNOSIS AND OPERATING ANOMALIES
This section includes the typical anomalies that could occur.
Many of these problems are not caused by the cooler, but they could be brought about by the electricity supply or by an incorrect use of the water cooler.
In the ANOMALY column, the problems report by the customer are listed.
In the POSSIBLE CAUSES column, the “probable reasons” behind the problem are listed.
In the INTERVENTION column, the corresponding corrective action is listed.
8.2 COOLING SYSTEM
ANOMALY POSSIBLE CAUSE INTERVENTION
The compressor will not start. Power failure. Check that there is voltage in the plug.
Thermostat on the off position, or set to the
minimum.
Adjust the thermostat position.
Faulty thermostat. Replace the thermostat.
The over-load protection of the compressor is
faulty.
Replace it.
The starting relay is faulty. Replace it.
The starting capacitor is faulty. Replace it.
The compressor is faulty Replace it.
The water is could but the appliance is operat-
ing excessively or non-stop.
Little ventilation. Place the appliance away from the wall.
The condenser is dirty or covered. Clean the condenser or free it of its obstacles.
The thermostat is on maximum could position. Adjust it.
The room temperature is heigher than 32°C. It is normal that the appliance works at a con-
tinuously high room temperature.
The compressor works continuously, but the
water is not cold.
Gas leak from the cooling system.
Contact a specialised technician (Refrigerationist).
The compressor is faulty. Replace the compressor.
COOLING SYSTEM
Too much noise coming from the appliance, but
it is working normally.
The machine is not levelled. Level the appliance using the adjustable feet.
A few pipes are touching some parts inside the
appliance, thus causing it to vibrate.
Adjust the position of the pipes, making sure
they do not touch any other parts.
Could water comes out slowly or not all. Low pressure of the inlet water. Take steps to increase the pressure (autoclave).
Faulty solenoid valve. Replace it.
Clogged water lter. Replace it.
The temperature adjuster is faulty and causes
complete freezing of the ice compartment.
Make the ice melt.
Replace the temperature adjuster.
Qualified operator service:
The dealer / Installator has to mark this square for the service.
Franke Sissons Ltd.
Carrwood Road, Sheepbridge,
Chesterfield, S41 9QB
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
