FREE RANGE HEN HOUSE User manual

FREE RANGE TM 59”X59”X78” HEN HOUSETM
Assembly Instructions
Congratulations on purchasing your new
FREE RANGE TM Chicken Coop.
Before starting the assembly, we recommend that you read the instructions
thoroughly. Your new Chicken Coop comes with all the holes pre drilled to
make for fast, easy assembly. We recommend that you assemble the coop
using a trestle table or sawhorses and planks. This will ensure that you are
working off the ground and make it easier for you. Assembly is a two person
job and should not be attempted in windy conditions.
Step 1: Check all parts against the component list.
Step 2: Assemble the rear wall panels.
Step 3: Assemble the side wall panels.
Step 4: Assemble the roof panels.
Step 5: Assemble the front wall panels.

Step 6: Assemble the front door.
Step 7: Fit the panels together.
It is recommended that your new Chicken Coop is secured to a concrete slab
as per the specifications in this manual. If you prefer not to use a concrete
slab, and want to secure it to the ground, you may use earth anchors (not
included) with the enclosed anchor brackets.
Concrete slab: Please ensure that your site is level. It is recommended that
your slab is 4” thick and you use builder’s plastic and F52 reinforcing mesh.

We recommend that you make your slab 4 inches bigger than the base
dimensions of your Chicken Coop. This will allow for a 2 inch edge around
your Chicken Coop. We recommend that you slope the 2 inch edges downward
by 1/2'” so that rain water can be drained away from your Chicken Coop.
Tools that may me needed:
After market screws (not included) may be used in place of pop rivets.
Adjustable Wrench

Step 1：Check all parts against the component list
Lay out all parts with number facing outwards and check off against parts list
Picture Description Component Location Part
No.
QTY Check
Sheet 74.8”x30.3”
(1900x770mm)
rear wall
side wall 9S 4
Sheet 74.8”x30.3”
(1900x770mm) side wall 9M 2
Sheet 63”X30.3”
1600x770mm roof 8A 2
Front wall
sheet
75”X28”
(1900x708mm) front 17 1
Door 72.5”X30.3”
(1845x770mm) door 18 1
Channel 59.4” (1508mm) roof
side wall 20A 4

Channel 59.4” (1508mm) rear wall 20B 1
Channel 59.4” (1508mm) rear wall 20C 1
Channel 59.4” (1508mm) front 20E 1
Channel 59.4” (1508mm) front 20F 1
Channel 59.4” (1508mm) side wall 20H 2
Channel 72.7” (1898mm) front 22A 1
Channel 25.8” (655mm) front 86 1
Channel 30.5” (775mm) front 23 1
Channel 57.4” (1458mm)
rear wall
side wall
31A 3
Jamb 74.7” (1898mm) front 41D 1
Jamb 30.5” (775mm) front 42 1
Lip 63” (1601mm) roof 51A 2

Laying shelf
12.6” X 34.8”
(320x885mm)
A1 1
Stairs
12.2” X 41.3”
(310x1050mm)
B2 1
FITTINGS PACK
Picture Component QTY Picture Component QTY
Self tapping
screws(10mm)
140
Self tapping screws(16mm) 12
Φ4.0x10mm Rivet 6 Φ3.0x10mm Rivet 8
Pad bolt 1 Keeper 1
Bracket 8
5/16”x3/4" Hexagonal bolt
8
5/16” Hexagonal Nut 8
Mid wall brace bracket 1

Qty checking date:
Qty checking personal badge number:
Signature:
In the unlikely event that you find you are missing a part, please contact Harris
Farms, LLC at 1(800) 745-9906 or [e-mail] and we will send
the missing part directly to your address.
Overview

Step 2: Assemble the rear wall panels.
You will find it easier to assemble your coop using sawhorses with timber
studs attached (timber needs to be the same length as the coop (5ft) or
alternatively, a trestle table.

Place 9S and 9S the sheet on your work table and join together with the self
tapping screws per the diagram.
Now fit 20B top channel and 20C bottom channel to the sheeting by tapping it
in (diagram A) or sliding it in (diagram B). Note that the small lip of the channel
is always facing out. This is to ensure that rain water can not build up inside
your Chicken Coop.

Now fit 31A mid wall channel to the sheeting and position it by the self
tapping screws. Please note that the groove should face downwards. Position
the top and bottom channels by the self tapping screws as well.

Step 3: Assemble side wall panels
Place 9S and 9M the sheet on your work table and fix them by self tapping
screws. Tap or slide in 20H top channel and 20A bottom channel. Fix and
position the 31A mid wall channel by the self tapping screws. Fix 20A the
bottom channel by the self tapping screws but not 20H the top channel in this
stage. Be noted that the small lip of the channel is always facing out. This is to
ensure that rain water can not build up inside your coop. Repeat the same
steps for 9S and 9M the other side wall.

Step 4: Assemble the roof panel.
Place 8A and 8A the sheeting on your work table and join together with the self
tapping screws per the diagram.

Now tap or slide in 20A and 20A the channels to the sheeting and fix them by
the self tapping screws.
Now fit 51A and 51A side lips to the sheeting and fix them by the self tapping
screws.

Step 5: Assemble the front wall panels.
Place 17 the front wall on the work table. Fit 20F the top channel and 20E the
bottom channel to the front wall sheeting and fix them by the self tapping
screws. Secure the iron net by riveting 86 the channel with 20F the top channel.

It’s recommended to fix the back part first then the front.
Fit the 41D the jamb, 42 the jamb and 23 the bottom channel in following and
fix them by the self tapping screws. Be aware of the joint details per the

diagrams. (Diagram B is as the same as diagram A.)

Step 6: Assemble the front door.
Fit 18 the pre-assembled door to the front wall panel per the diagram. Use
riveter to fix the door into the pre-drilled holes. Fix the pad bolt to the
pre-drill holes by the self tapping screws as well.

Step 7: Fit the panels together.
Attach the two side walls to the back wall, then the front wall, then the roof. Fix
all the components by the self tapping screws. Fix the pad bolt keeper with
16mm self tapping screws here as well.
