Freescale Semiconductor FRDMSTBC-A8471 Reference guide

3-Axis Sensor Toolbox Development Board
FXLS8471Q 3-axis linear accelerometer
Quick Reference Card
Get Started
FREESCALE FREEDOM PLATFORM
documentation under
Jump-Start Your Design
at freescale.com/
sensortoolbox
Download tools and
FRDMSTBC-A8471
FRDM
STBC-
A8471
For more information, visit freescale.com/
sensortoolbox
Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. © 2015 Freescale Semiconductor, Inc. FRDMSTBCA8471QRC REV 1 920-28984 REV A
FRDM
STBC-
A8471

Verify package contents:
FRDMSTBC-A8471
development board
Connect the FRDMSTBC-A8471
development board to a Freescale
Freedom development board,
such as the FRDM-KL25Z (or any
Arduino R3 compatible board).
Refer to the Freescale Freedom
development board Quick Start
Guide for driver information.
Plug one end of a USB cable into
the SDA port on the assembly.
Plug the other end of the cable into
the USB port on the computer.
Download and install the
latest Sensor Toolbox software at:
freescale.com/sensortoolbox
Start the Sensor Toolbox software.
1
2
3
4
5
Test points (12 places)
Learn more at freescale.com/sensortoolbox
Get to Know the FRDMSTBC-A8471
FXLS8471Q 3-axis linear accelerometer
16 QFN (3 mm x 3 mm x 1 mm)
INT1 – 3
5 – I2C_SDA1
4 – VDD
I2C_SDA0 – 9
I2C_SCL0 – 10
6 – I2C_SCL1
3 – RST_MCU
INT2 -1
SA1/CS - 3
SDA/MOSI - 4
SA0/MISO - 5
SPI/I2C_CLK - 6
4 – RST_GPIO
Through hole pins (12 places)
6 – GND
