Frico ICF 20 User manual

Code. 5.471.084.040
.... 9
SE
.... 14
DE
.... 13
FR
.... 11
FI .... 12 GB
.... xx
PL
.... 10
NO
.... xx
DE .... 16 PL
.... 15
RU
ICF 20/55

2
ICF20/55
Type Height
[mm]
ø
[mm]
Weight
[kg]
ICF20 545 1422 6,2
ICF55 545 1422 6,2
Dimension

˜ 2,3 m
A
84 mm
8 kg
= 32 kg
• 2,7 m
3
ICF20/55
1
2
5
3
4
Installation

6
4
ICF20/55
7
9
10
IPX5
ø < 6 mm
4
8

5
ICF20/55
15
14
13
16
11
IPX5
12
L
N
52
1
(see ) )
19

L
N
521
L
N
521
6
ICF20/55
17 18

L
N
521
L
N
521
7
ICF20/55
19
21
20
Maintenance

Wiring diagrams ICF20/55
~
1234
L
~~
25
°C
M
~
Black
Blue
Red
LN UU 12
N
L
LL
RF
230V~
NN
1
N
5678
NL
230V~
N
L
230V~
CAR15
ICF20/55
25
°C
M
~
Black
Blue
Red
1
ICF20/55
25
°C
M
~
Black
Blue
Red
1
ICF20/55
ICF20/55 ICF20/55
ICF20/55 ICF20/55PE1/2,5
RE5
(L)
25
1
25
1
25
1
25
1
L
N21
NL
230V~
ICF20/55
CFR1R
25
1
5
N
Givare golv/
Sensor floor
Givare tak/
Sensor ceiling
Vidarekoppling/
Relay connection
Anslutning för reversering/
Connection for reverse rotation
Switch
8
ICF20/55

ICF 20/55
12
GB
General Instructions
Read these instructions carefully before
installation and use. Keep this manual for
future reference.
The guarantee is only valid if the units
are used in the manner intended by the
manufacturer and in accordance with the
Frico mounting and operating instructions.
Areas of use
Roof fans are chiefly used to even out the
temperature in premises with high ceilings.
The warm air that collects under the ceiling is
pressed down so that it can heat the occupied
areas underneath. Warm air escape via the
ceiling are thereby reduced. This form of
air mixing also has a quicker heating effect
on cold goods, makes for better drying, and
reduces the risk of cold irradiation.
Enclosure class ICF20: IPX0
Enclosure class ICF55: IPX5
Placement
The fans should be placed symmetrically
in the premises where they can provide
optimum temperature spread. Make sure
the fans are always installed where there is
no risk to people or of contact with objects
from the rotating blades. Nor should they be
placed where they blow air directly on people.
Generally fan speed should be regulated so
that they don’t cause draughts.
Fan installation and electrical connection
See fig. 1-18.
Max. surrounding temperature is +40 °C.
The roof fan(s) should only be wired by a
competent electrician and in accordance with
the latest edition of IEE wiring regulations.
Service and maintenance
See fig. 19-21.
ICF20/55 is basically maintenance free, but
should be checked on a regular basis.
Important! Check the hanging brackets to
avoid the risk of the fan falling down.
Before cleaning the unit or carrying out
maintenance operations, turn the main switch
off and remove the plug from the power
supply.
When several units are controlled with a
common control device the fan speed could
differ from one unit to another. In most cases
these differences will disappear when the fans
have been running for some time (about a
week). Another reason could be that the lower
protective cover is squeezed to tight to the fan,
adjust the coves if necessary.
Safety
This appliance is not intended for use
by children and persons with reduced
physical, sensory or mental capabilities,
or a lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by an individual responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Specifications for the power supply must
correspond to the electrical data on data plate
A (fig. 2).
Assembly and operating instructions

2013-11-11 HH/SÅ/SÄ
Main office
Frico AB Tel: [phone]
Box 102 Fax: [phone]
SE-433 22 Partille [email protected]
Sweden www.frico.se
For latest updated information and information
about your local contact: www.frico.se
