Friedrich TWINTEMP EQ08L11A User manual

TwinTemp
Room Air Conditioners
PURCHASER P.O. # DATE
PROJECT LOCATION
ENGINEER ARCHITECT
SUBMITTED BY FOR APPROVAL FOR REFERENCE
ITEM PLAN DESIGNATION QUANTITY COOLING BTU/H VOLTAGE FRIEDRICH MODEL
TWINTEMP_SUBMITTAL_08
DELUXE FEATURES
• Heat pumps are ideal for southern climates;
heat pump and electric heat models provide
supplemental heating in colder climates*
• Ultraquiet operation
• MoneySaver® setting** saves energy by cycling
the fan with the compressor
• 3 cooling/3 heating speeds***, plus fan-only set-
ting
• Heat anticipating thermostat
• 8-way air ow control
• Defrost control (heat pumps)
• Fresh air intake and stale air exhaust vents*
• Rotary controls
• Washable, antimicrobial lter for protection
against fungal and bacterial growth
• Slide-out chassis for more permanent window
or wall installation (window installation requires
optional window kit)
* Feature not available on model YS09L10. **Feature not available on model EQ08L11A. ***EQ08L11A has 2 cooling and 2 heating speeds, plus fan-only.
T W I N T E M P U N I T S I NSTA L L T H R U - WAL L O R I N A W I N D O W W I T H
O P T I O N A L W I N D O W K I T. S EE S P EC I FI C AT I O N S .
HEAT/COOL
COOLING 7,700 to 36,000 BTU/h HEATING 4,000 to 22,000 BTU/h EERs up to 12.0
MONEY SAVER
FEATURE
ANTIMICROBIAL
FILTER
SLIDE-OUT
CHASSIS
M O D E L E Q 0 8 L11A
COMPACT SIZE FOR EASIER REMOVAL and STORAGE and FULL SIZE FOR MORE PERMANENT INSTALLATION

Model
Circuit Rating
Breaker or
T-D Fuse
Plug Face
(NEMA#)
Wall Outlet
Appearance
EQ08L11A. YS09L10. 125V - 15A 5 - 15P
ES12L33 and ES16L33. YS13L33. 250V - 20A 6 - 20P
EM18L34, EM24L34 and EL36L35A. YM18L34 and
YL24L35.
250V - 30A 6 - 30P
Installation Information / Sleeve Dimensions
Circuit Rating/ Breaker
TWINTEMP®models include accessories for thru-the-wall
installation only. Window mounting requires use of optional
accessory kit as listed above.
Window Mounting Kits
The consumer- through the AHAM Room Air Conditioner Certification Program- can be certain that the AHAM Certification Seal accurately
states the unit’s cooling and heating capacity rating, the amperes and the energy efficiency ratio.
 As an ENERGY STAR® partner, Friedrich Air Conditioning Co. has determined that the selected ENERGY STAR®() models meet the ENERGY STAR®guidelines for energy efficiency.
** Operates on 115 volt and is not equipped with supplemental heat. Will not provide heat at temperatures below 40°F.
Friedrich room air conditioners are designed to operate in outdoor temperatures from 50° F to 115° F.
TwinTemp Heat Pump heating information (shown in red) indicates heat pump heating performance. TwinTemp Electric Heat heating information (shown in red) indicates electric
heat strip performance. For TwinTemp Heat Pump electric heating performance refer to corresponding TwinTemp Electric Heat model.
Due to continuing research in new energy-saving technology, specifications are subject to change without notice.
Sleeve Height Width
Depth
with Front
Depth
Hood to
Louvers
Minimum
Extension
Into Room
Minimum
Extension
Outside
Window Width
Thru-the-wall
Finished Hole
Minimum Maximum Height Width
Q14" 19 ¾" 21 3∕8" 8 ½" 5 ½" 10 ¾" 26" 42" 14 ¼" 20"
S15 15∕16" 25 15∕16" 27 3∕8" 8 ¾" 3 1∕16" 16 15∕16" 27 7∕8" 42" 16 3∕16" 26 3∕16"
M17 15∕16" 25 15∕16" 27 3∕8" 8 ¾" 3 1∕16" 16 15∕16" 27 7∕8" 42" 18 3∕16" 26 3∕16"
L20 3∕16" 28" 33 5∕8" 16 ½" 3 3∕16" 18 15∕16" 29 7∕8" 42" 20 3∕8" 28 ¼"
TwinTemp Model Kit No.
EQ08L11A WIKQ
ES12L33, ES16L33, YS09L10 and YS13L33. WIKS
EM18L34, YM18L34 and EM24L35. WIKM
EL36L35A and YL24L35. WIKL
Cooling
Capacity
BTU/h
Heating
Capacity
Rated
Electrical Characteristics (60 Hertz) Energy
Efficiency
Ratio
EER
Moisture
Removal
Pints/Hr.
Room Side
Air Circulation
CFM Sleeve
Net
Weight
Lbs.Model
Volts
Rated
Cooling
Amps
Cooling
Watts
Heating
Amps
Heating
Watts
COMMERCIAL GRADE
TWINTEMP Heat Pump
YS09L10** 9200 7400 115 7.4 767 6.9 733 12.0 1.7 300 S 113
YS13L33 12700/12500 11000/10500 230/208 5.1/5.6 1149/1131 5.3/5.8 1185/1167 11.0/11.0 3.5 325 S 117
YM18L34 18000/18000 16800/16400 230/208 8.5/9.5 1895/1895 8.5/9.0 1867/1822 9.5/9.5 4.7 400 M 166
YL24L35 24000/24000 22000/21600 230/208 10.9/12.0 2400/2400 11.0/12.0 2444/2400 10.0/10.0 7.0 600 L 198
TWINTEMP Electric Heat
EQ08L11A 7700 4000 115 6.5 733 11.2 1290 10.5 1.9 175 Q 76
ES12L33 12100/11900 10700/8900 230/208 4.8/5.0 1052/1017 16.0/14.7 3500/2900 11.5/11.7 2.9 320 S 111
ES16L33 16200/15900 10700/8900 230/208 7.4/8.0 1653/1656 16.0/14.7 3500/2900 9.8/9.6 4.7 360 S 116
EM18L34 17800/17600 13000/10600 230/208 8.1/8.8 1780/1760 19.5/17.0 4200/3500 10.0/10.0 4.4 400 M 160
EM24L34 23500/23000 13000/10600 230/208 11.2/12.1 2479/2421 19.5/17.0 4200/3500 9.5/9.5 7.0 400 M 154
EL36L35A 36000/35700 17300/14300 230/208 18.0/19.6 4235/4200 24.0/22.4 5500/4650 8.5/8.5 11.0 725 L 220
Specications ENERGY STAR® Models
