FRO­NIUS Selectiva 4.0 30 kW User manual

Fronius prints on elemental chlorine free paper (ECF) sourced from certified sustainable forests (FSC).
/ Perfect Charging / Perfect Welding / Solar Energy
Selectiva 4.0
30 kW
EN-US
Operating instructions
Battery charging system
42,0426,0359,EA 008-12072021

Table of contents
Power categories 5
General 5
30 kW 5
Safety Instructions 6
General 6
Environmental conditions 6
Grid connection 6
Dangers due to Grid and Charging Current 7
Danger due to Acids, Gases, and Vapors 7
General information on working with batteries 8
Personal Protection and Protection of Others 8
Safety Measures in Normal Operation 8
EMC device classifications 8
EMC Measures 9
Data backup 9
Maintenance 9
Repair 9
Obligations of the operating company 9
Safety Inspection 9
Markings on the device 10
Disposal 10
Copyright 10
General information 11
Explanation of Safety Instructions 11
Device concept 11
Intended use 11
Customer-specific information 12
Grid connection 12
Charging cables 13
Correct routing of the grid/charging cables 13
Warning notices on the device 14
Warning notices inside the device 16
Setup regulations 17
Dimensions 19
Removing the pallet 19
Floor mounting 20
Wall mounting 20
Operating controls and connections 23
Operating controls and connections 23
Pin assignment for the optional plug 25
Control panel 26
Charging the battery 28
Starting for the first time 28
Charging process 29
Interrupting the charging process 31
Ending the charging process 31
Display 33
Overview of display modes 33
Standard mode 33
Menu selection 34
Statistics mode 34
History mode 34
Configuration mode 36
Settings 39
Electrolyte circulation 40
Temperature-controlled charging 40
Equalizing charge 41
Delay 42
Calendar 43
Special charges 44
3
EN-US

Special function - opportunity charging 45
DC connection 46
Additional functions 46
General options 47
Reset settings 48
USB mode 49
Status codes 50
Power path status codes 54
Options 55
Safety 55
Electrolyte circulation 55
External start/stop 57
Charging lights 57
Temperature-controlled charging 57
Relay board 58
Aquamatic 59
Charging 59
Charge 50 % 59
Charge 80 % 59
Charge not complete 59
Charge Finish 59
Main Charge Finished 59
Cumulative Error 59
Cumulative error + warning 59
Signal Lamp 59
Immobiliser 60
Battery Cold 60
External air pump (electrolyte circulation) 60
LED strip 60
Air filter 60
Remote control system 60
GatewayLink 60
Gateway 60
Technical data 61
Selectiva 30 kW 61
4

Power categories
General The kW specification for the power categories refers to the housing design and is not dir-
ectly related to the actual device power.
30 kW Selectiva
8250 / 8300 / 8375
5
EN-US

Safety Instructions
General The device has been manufactured using state-of-the-art technology and according to
recognized safety standards. If used incorrectly or misused, however, it can cause
- injury or death to the operator or a third party
- damage to the device and other material assets belonging to the operating company
- inefficient operation of the equipment
All persons involved in the commissioning, operation, maintenance, and servicing of the
device must
- be suitably qualified
- have completely read and followed these operating instructions
The operating instructions must always be at hand wherever the device is being used. In
addition to the operating instructions, all applicable local rules and regulations regarding
accident prevention and environmental protection must also be followed.
All safety and danger notices on the device
- must be kept in a legible state,
- must not be damaged/marked,
- must not be removed,
- must not be covered, pasted, or painted over.
For the location of the safety and danger notices on the device, refer to the section
headed "General Information" in the operating instructions for the device.
Before switching on the device, eliminate any faults that could compromise safety.
Your personal safety is at stake!
Environmental
conditions
Operation or storage of the device outside the stipulated area will be deemed as not in
accordance with the intended purpose. The manufacturer accepts no liability for any
damage resulting from improper use.
For exact information on permitted environmental conditions, please refer to the "Tech-
nical data" chapter.
Grid connection Devices with a high output can influence the energy quality of the grid due to their cur-
rent consumption.
This may affect a number of device types in terms of:
- Connection restrictions, requirements regarding maximum permissible grid imped-
ance *) or
-criteria regarding the minimum required short circuit power *)
*) both at the interface with the public grid
See technical data
In this case, the operator or the person using the device should check whether or not the
device is allowed to be connected, where appropriate through discussion with the grid
operator.
IMPORTANT! Ensure secure grounding of the grid connection.
6

Dangers due to
Grid and Char-
ging Current
Work with battery charging systems poses a number of dangers, such as:
- electrical hazard due to grid and charging current.
- hazardous electromagnetic fields that may pose a risk of death for individuals with
pacemakers.
An electric shock can be fatal. Every electric shock poses a risk of death. To prevent
electric shock during operation:
- do not touch any voltage-carrying parts inside or outside of the device.
- never touch the battery poles.
- do not short-circuit the charging cable or charging terminals.
All cables and leads must be secured, undamaged, insulated, and adequately dimen-
sioned. Loose connections, scorched, damaged, or under-dimensioned cables and leads
must be repaired immediately by an authorized specialist.
Danger due to
Acids, Gases,
and Vapors
Batteries contain acids which pose a risk to the eyes and skin. Furthermore, charging
batteries produces gases and vapors that may be hazardous to your health and are
highly explosive under certain circumstances.
Only use battery charging systems in well ventilated rooms in order to prevent the accu-
mulation of explosive gases. Battery rooms are not considered at risk of explosion if a
hydrogen concentration of less than 4% is guaranteed by natural or artificial ventilation.
During charging observe a minimum distance of 0.5 m (19.69 in.) between the battery
and charging system. Keep potential sources of ignition such as fire and open flames
away from the battery.
Never disconnect the battery (e.g., charging terminals) during charging.
Never breathe in the gases and vapors produced by the battery - Ensure there is a suffi-
cient supply of fresh air.
Do not place any tools or electrically conductive metals on the battery, in order to prevent
short circuits.
Never allow battery acid to come into contact with your eyes, skin, or clothing. Wear eye
protection and appropriate protective clothing. Rinse away any splashed acid immedi-
ately and thoroughly with clean water, and consult a physician if necessary.
7
EN-US

General informa-
tion on working
with batteries
- Protect batteries from dirt and mechanical damage.
- Store charged batteries in cool rooms. The lowest self discharge occurs at approx.
+2°C (35.6°F).
- Refer to the specifications of the battery manufacturer or conduct weekly visual
inspections to ensure that the battery is filled with acid (electrolyte) up to the max-
imum marking.
- Do not start operating the device, or immediately stop operation, and have the bat-
tery inspected by an authorized specialist if:
- the acid level is uneven or there is high water consumption in individual cells
caused by a possible defect
- the battery heats up to an impermissible level, above 55°C (131°F)
Personal Protec-
tion and Protec-
tion of Others
Keep persons, especially children, away from the device and working area during opera-
tion. If persons are in the vicinity, however:
- inform them of any dangers (hazardous acids and gases, risk due to grid and char-
ging current, etc.)
- provide suitable protective equipment
Before leaving the working area, ensure that no personal injury or property damage can
occur in your absence.
Safety Measures
in Normal Opera-
tion
Operate devices with ground conductors only on a grid with a ground conductor and a
socket with a ground conductor contact. Operating the device on a grid without a ground
conductor or on a socket without a ground conductor contact is considered gross negli-
gence. The manufacturer is not responsible for any damage resulting from improper use.
Only operate the device in accordance with the degree of protection shown on the rating
plate.
Never commission the device if it is damaged.
Have the grid and device supply lead regularly inspected by an electrician to ensure that
the ground conductor is functioning properly.
Safety devices that are not fully functional and components with defects must be
repaired by an authorized specialist before the device is turned on.
Never bypass or disable protection devices.
A freely accessible mains plug is required after installation.
EMC device clas-
sifications
Devices in emission class A:
- Are only designed for use in industrial areas
- Can cause wiring-related or radiated interference in other areas.
Devices in emission class B:
- Satisfy the emissions criteria for residential and industrial areas. This is also true for
residential areas in which the energy is supplied from the public low-voltage grid.
8

EMC device classification as per the rating plate or technical data.
EMC Measures In certain cases, even though a device complies with the standard limit values for emis-
sions, it may affect the application area for which it was designed (e.g., when there is
sensitive equipment at the same location, or if the site where the device is installed is
close to either radio or television receivers).
If this is the case, then the operating company is obliged to take appropriate action to
rectify the situation.
Data backup The user is responsible for backing up any changes made to the factory settings. The
manufacturer accepts no liability for any deleted personal settings.
Maintenance Check the mains plug, mains cable, charging lead, and charging terminals for damage
before each commissioning.
If dirt accumulates on the device, clean the surface of the device housing with a soft
cloth and only with solvent-free cleaning agents.
Repair Repair work must only be carried out by authorized personnel. Use only original spare
and wearing parts (also applies to standard parts). It is impossible to guarantee that
third-party parts are designed and manufactured to meet the demands made on them, or
that they satisfy safety requirements.
Do not carry out any alterations, installations, or modifications to the device without first
obtaining the manufacturer’s permission.
Obligations of the
operating com-
pany
The operating company must only allow persons to work with the device if they
- are familiar with the basic occupational safety and accident prevention regulations
and are trained in handling the device
- have read and understood these Operating Instructions, especially the "Safety rules"
section, and have confirmed this with their signature
- are trained according to the requirements for the work results.
The safety-conscious work of the personnel must be checked regularly.
Safety Inspection The manufacturer recommends that a safety inspection of the device be performed at
least every 12 months.
A safety inspection by a certified electrician is recommended
- after changes,
- after alterations,
- after repair, service and maintenance,
- at least every 12 months.
For the safety inspection, follow the appropriate national and international standards and
guidelines.
You can obtain more information about the safety inspection from your service center.
The service center will provide the necessary documents upon request.
9
EN-US

Markings on the
device
Devices with the CE mark satisfy the essential requirements of the applicable directives.
Devices marked with the EAC mark of conformity satisfy the requirements of the relevant
standards for Russia, Belarus, Kazakhstan, Armenia, and Kyrgyzstan.
Disposal Do not dispose of the product with household waste, but in accordance with the disposal
regulations for waste electrical and electronic equipment applicable at the place of
installation.
Copyright Copyright of these Operating Instructions remains with the manufacturer.
Text and illustrations were accurate at the time of printing. Fronius reserves the right to
make changes. The contents of the Operating Instructions shall not provide the basis for
any claims whatsoever on the part of the purchaser. If you have any suggestions for
improvement, or can point out any mistakes that you have found in the Operating
Instructions, we will be most grateful for your comments.
10

General information
Explanation of
Safety Instruc-
tions
DANGER!
Indicates an immediate danger.
▶Death or serious injury may result if appropriate precautions are not taken.
WARNING!
Indicates a possibly dangerous situation.
▶Death or serious injury may result if appropriate precautions are not taken.
CAUTION!
Indicates a situation where damage or injury could occur.
▶Minor injury or damage to property may result if appropriate precautions are not
taken.
NOTE!
Indicates the possibility of flawed results and damage to the equipment.
Device concept The battery charging systems in the three-phase range are characterized by intelligent
charging technology. The successful Active Inverter Technology with the revolutionary Ri
charging process adapts to the needs of the battery and only charges the current that is
really needed into the battery.
The technology is embedded in a sturdy industry-standard housing. The extremely com-
pact design meets all requirements for safety standards, reduces space requirements
and protects the parts for a long service life.
Equipped with a graphic display, an integrated data logger, new interfaces and additional
options, the device is perfectly equipped for the future.
Intended use The battery charger is intended to charge the following listed batteries. Any other use is
deemed to be not in accordance with the intended purpose. The manufacturer shall not
be liable for any damage resulting from such improper use. Intended use also means
- Following all the instructions in these Operating Instructions
- Regularly checking the grid and charging cable
WARNING!
Danger from charging dry batteries (primary cells) and non-rechargeable batteries.
This can result in severe personal injury and damage to property.
▶Only charge the types of battery listed below.
11
EN-US

WARNING!
Danger from unsuitable batteries connected to the battery charger.
Serious personal injury and property damage as a result of escaping gases, ignition or
explosion may result.
▶Only connect batteries to the battery charger which are suitable for the battery char-
ger in terms of their type, voltage and capacity and which correspond to the settings
on the battery charger.
The battery charger is designed for charging lead-acid batteries and NiCd batteries. Set
the battery charger to the type of battery to be charged:
- Pb-WET batteries (PzS, GiS, ...):
Venting, closed lead-acid wet batteries with liquid electrolyte.
- Pb-GEL batteries (PzV, GiV, ...):
Valve-regulated, sealed lead-acid batteries (VRLA) with fixed electrolyte (gel or
fleece).
- NiCd batteries:
Closed or sealed NiCd batteries with liquid electrolyte.
- Pb-CSM-WET batteries (Copper Strained Metal):
Closed lead-acid CSM batteries with liquid electrolyte.
- Lead Crystal batteries:
Type EVFJ/CNFJ Lead Crystal batteries.
The device must be handled correctly in order for it to work. Never pull on the cable
when handling the device.
Customer-spe-
cific information
If customer-specific information exists for the supplied device, this is provided with the
device.
Grid connection WARNING!
Danger of a residual current.
This may result in serious injuries or death.
▶If necessary, only use a type B residual current circuit breaker for the grid connec-
tion of the device.
▶The minimum cross-section of the ground conductor must comply with the local
safety regulations for high ground conductor power systems.
▶The device has an increased leakage current. This must be taken into account when
installing the device in accordance with national regulations.
▶The leakage current as a function of the mains voltage is specified in the "Technical
data" chapter.
WARNING!
Danger due to incorrect operation.
This can result in severe personal injury and damage to property.
▶Do not use the functions described here until you have fully read and understood the
following documents:
▶Operating Instructions
▶All Operating Instructions for system components, in particular the safety rules
▶Operating Instructions and safety rules provided by the battery and vehicle manufac-
turers
12

WARNING!
Danger of faulty or insufficient grid power supply.
This can result in severe personal injury and damage to property.
▶The requirements for the grid power supply according to the "Technical data"
chapter must be fulfilled.
Charging cables WARNING!
Danger due to charging cables lying around.
This can result in severe personal injury and damage to property. Personnel can get
caught or trip on unplugged, loose cables
▶Lay charging cables so that no one can trip over them or get caught on them.
WARNING!
Danger if the active charging process is interrupted by disconnecting the charging
plug.
This can result in severe personal injury and damage to property. The resulting sparks
can ignite the charging gases that form during charging and cause a fire or explosion
▶When charging is complete, wind up the charging cables or place them on the cable
holder, if available.
Correct routing of
the grid/charging
cables
CAUTION!
Danger due to overheating as a result of incorrectly laid grid/charging cables.
Risk of damage to the components.
▶Lay the grid/charging cable without a loop.
▶Do not cover the grid/charging cable.
▶Charging cables longer than 5 m (16 ft. 4.85 in.) must be laid individually (no bund-
ling).
▶For charging cables longer than 5 m (16 ft. 4.85 in.) a maximum ambient temperat-
ure of 30°C (86°F) must not be exceeded.
▶The grid/charging cable may only be replaced by a qualified electrician.
▶Charging cables longer than 5 m (16 ft. 4.85 in.) can have an increased surface tem-
perature (be aware of hot surfaces).
13
EN-US

Warning notices
on the device
The battery charger features safety symbols on the rating plate. The safety symbols
must not be removed or painted over.
Ser. No.:
Part No.:
UDC nom.
IDC max.
Protective class I
IAC max.
UAC nom.
PAC max.
www.fronius.com
OVC III
IP20
xxV
xxxA
xxA
3~ NPE xxxV 50/60Hz
xxxxW
xxxxxxxx
xxxxxxxx
4,010,xxx
Selectiva x.0 xxxx xkW
HIGH LEAKAGE CURRENT!
Ensure proper grounding
Fronius International GmbH
Froniusstraße 1
4643 Pettenbach
Austria
Ladevorgang immer stoppen bevor das Ladekabel abgezogen wird!
Explosive Gase. Flammen und Funken vermeiden.
Während des Ladens für ausreichend Frischluft-Zufuhr sorgen!
Always stop charging before you disconnect the charging cable!
Explosive gases. Prevent flames and sparks.
Provide adequate ventilation during charge!
Toujours arrêter la charge avant de déconnecter le câble de charge!
Gaz explosifs. Éviter les flammes et les étincelles.
Prévoir une ventilation adaptée pendant la charge!
¡Detener siempre la carga antes de desconectar el cable de carga!
Gases explosivos. Evitar llamas y chipas.
¡Mantener una ventilación adecuada durante la carga!
Interrompere sempre la carica prima di scollegare il cavo di carica!
Gas esplosivi. Evitare fiamme libere e scintille.
Predisporre una ventilazione adeguata durante la carica!
WARNUNG - WARNING - ATTENTION
ADVERTENCIA - AVVISO
42,0409,0419
An electric shock can be fatal. The housing may only be opened by service
technicians trained by the manufacturer. Before working with the housing
open, the device must be disconnected from the grid. A suitable measuring
device must be used to ensure that electrically charged parts (e.g. capacitors)
are completely discharged. Ensure that the device remains disconnected
from the grid until all work is complete.
Use functions only after reading the Operating Instructions in full.
Keep potential sources of ignition such as fire, sparks, and open flames away
from the battery.
Danger of explosion! Oxyhydrogen forms in the battery during charging.
Battery acid is corrosive and must never come into contact with your eyes,
skin or clothing.
Ensure there is a sufficient supply of fresh air during charging.
14

The device can cause DC residual currents in the ground conductor. If a
residual current device (RCD) is used on the grid side to protect against elec-
tric shock, this must be a type B RCD. The device has an increased leakage
current. This must be taken into account when installing the device in accord-
ance with national regulations.
Do not dispose of the product with household waste, but in accordance with
the disposal regulations for waste electrical and electronic equipment applic-
able at the place of installation.
15
EN-US

Warning notices
inside the device WARNING!
Danger from electrical current.
This may result in serious injuries or death.
▶The housing may only be opened by service technicians trained by the manufac-
turer.
▶Before starting work, switch off all devices and components involved, and discon-
nect them from the grid.
▶Secure all devices and components involved so they cannot be switched back on.
▶After opening the device, use a suitable measuring instrument to check that electric-
ally charged parts (such as capacitors) have been discharged.
▶With the aid of a clearly legible, understandable warning sign, ensure that the device
remains disconnected from the grid until all work has been completed.
Inside the device:
WARNING Hazardous Voltage
Kondensator Entladezeit < 3 min.
Capacitor discharge time < 3 min.
Décharge de condensateur < 3 min.
Condensador tiempo de descarga < 3 min.
Condensatore tempo di scaricamento < 3 min.
16

Setup regulations WARNING!
Danger from system components falling or toppling over.
This can result in severe personal injury and damage to property.
▶After delivery, remove the device from the pallet as described in the "Removing the
pallet" section.
▶Set up all system components in a stable position.
▶After installation, it is essential to fix the device to the floor or to the wall by means of
a wall bracket.
▶When using a floor bracket or wall bracket, always ensure that all fastening ele-
ments, including the wall bracket, are firmly seated.
▶The devices must not be stacked, nor may objects be placed on top of the devices.
▶The device must be secured against tipping over during transport.
▶The load must always be secured by suitable means.
▶During transport, the respective cables must be fixed to the cable holder on the rear.
▶When transporting with a platform stacking truck and, in some cases, with a hand
pallet truck, the anti-tipping devices (1) may need to be removed.
▶Is it possible to store the anti-tipping devices (1) at the rear of the device by fixing
them with butterfly nuts (2).
▶If necessary, the anti-tipping devices (1) must be refitted in the positions provided for
them.
(1) (1)
(2) (2)
The device has been tested according to degree of protection IP20. This means:
- Protection against the penetration of solid foreign bodies with a diameter of more
than 12.5 mm (0.49 in.)
- No protection against water
The device must be set up and operated in dry, closed rooms in accordance with degree
of protection IP20. Avoid exposure to moisture.
The permissible operating position of the device is horizontal on the base.
Cooling air
The device must be set up so that cooling air can flow through the housing openings
provided unhindered. There must always be a minimum distance of 0.2 m (7.874 in.)
from the air inlet and outlet openings. The ambient air must be free from
- Excessive dust exposure
- Electrically conductive particles (carbon black or metal chips)
- Heat sources
The cooling air flows in and out as indicated by the arrow symbols in the following illus-
trations.
17
EN-US

NOTE!
Danger due to partially or completely covered air intake and outlet openings.
This can result in damage to property.
▶The setup of several devices one behind the other should be staggered.
30 cm (11.81 in.)
If the devices are arranged in a line one behind the other without being staggered, the
minimum distance between the devices must be as follows:
30 cm (11.81 in.)
18

Dimensions
mm (in.)
780 (30.71) 369 (14.53)
1090 (42.91)
110 (4.33)
600 (23.62)
145 (5.71)
Removing the
pallet
After delivery, remove the device from the
pallet.
WARNING!
Danger when operating the device on
the pallet.
This can result in severe personal injury
and damage to property.
▶The device must not be operated on
the pallet.
▶After installation, it is essential to fix
the device to the floor or to the wall by
means of a wall bracket.
▶Detailed information about the wall
bracket can be found in the "Wall
mounting" section.
19
EN-US

Floor mounting
750 (29.53)mm (in.)
369 (14.53)
13
(.51)
35
(1.38)
300
(11.81)
Wall mounting
Center
240 (9.45)
mm (in.)
950 (37.4)
(1) (1)
1Drill holes (1) according to the screws
and dowels used.
If the surface allows it, the SW10 screws
(3) and washers (4) can be used, which
are used to store the wall bracket as
shown in the figure below.
Otherwise, the use of other suitable
screws and washers is required.
20
